# BitcoinExchangeFH - Cryptocurrency exchange market data feed handler
BitcoinExchangeFH is a slim application to record the price depth and trades in various exchanges. You can set it up quickly and record the all the exchange data in a few minutes!
Users can
1. Streaming market data to a target application (via ZeroMQ)
2. Recording market data for backtesting and analysis.
3. Recording market data to a in-memory database and other applications can quickly access to it.
4. Customize the project for trading use.
### MySQL
### Kdb+
## Supported exchanges
All exchanges supported by [ccxt](https://github.com/ccxt/ccxt). Currently more than 130 exchanges are supported.
Websocket feeds of the following exchanges are supported by [cryptofeed](https://github.com/bmoscon/cryptofeed)
- Bitfinex
- Coinbase
- Poloniex
- Gemini
- HitBTC
- Bitstamp
- BitMEX
- Kraken
- Binance
- EXX
- Huobi
- OKCoin
- OKEx
If the exchange is not supported with websocket API feed, it will automatically fall into using its REST API feed.
## Supported database/channel
- RDMBS (e.g. sqlite, MySQL, PostgreSQL)
- ZeroMQ
- Kdb+ (Coming soon)
## Getting started
```
pip install bitcoinexchangefh
bitcoinexchangefh --configuration example/configuration.yaml
```
## Configuration
The configuration follows [YAML](https://pyyaml.org/wiki/PyYAMLDocumentation) syntax and contains two sections
- subscriptions
- handlers
### Subscriptions
Subscription section specifies the exchange and instruments to subscribe.
The first key is the exchange name and then follows the exchange details,
- instruments
- number of depth (default is 5 if not specified)
For example,
```
subscription:
Binance:
instruments:
- XRP/BTC
- BCH/BTC
depth
Poloniex:
instruments:
- ETH/BTC
depth: 10
```
### Handlers
After receiving the order book or trade update, each handler is updated. For example, for SQL database handler, it is updated with the corresponding SQl statements.
For example,
```
handlers:
sql:
connection: "sqlite://"
```
#### SQL handler
The following settings can be customized
|Parameter|Description|
|---|---|
|connection|Database connection string required by [SQLAlchemy](https://docs.sqlalchemy.org/en/latest/core/engines.html)|
|is_rotate|Boolean indicating whether to rotate to record the table.|
|rotate_frequency|String in [format](https://docs.python.org/2/library/datetime.html#strftime-strptime-behavior) same as `strftime` and `strptime`|
#### ZeroMQ handler
The feed handler acts as a [publisher](https://learning-0mq-with-pyzmq.readthedocs.io/en/latest/pyzmq/patterns/pubsub.html) in ZeroMQ. To receive the feed, please follow ZeroMQ instructions to start a [subscriber](tests/zmq/zmq_subscriber.py).
The following settings can be customized
|Parameter|Description|
|---|---|
|connection|Connection [format](http://api.zeromq.org/3-2:zmq-connect) in ZeroMQ. For example, "tcp://127.0.0.1:3456"|
## Examples
You can first create a directory `.data` and run the command
```
$ bitcoinexchangefh --configuration example/configuration.yaml
2020-08-07 23:33:32,110 INFO Loading runner
2020-08-07 23:33:32,110 INFO Creating handler sql
2020-08-07 23:33:32,205 INFO Loading handler SqlHandler
2020-08-07 23:33:32,710 INFO Loading exchange Binance
2020-08-07 23:33:34,062 INFO Loading exchange Bitmex
2020-08-07 23:33:40,203 INFO Start running the feed handler
2020-08-07 23:33:40,203 INFO Running handler sql
2020-08-07 23:33:40,210 INFO Running exchange Binance
2020-08-07 23:33:40,215 INFO Running SqlHandler
2020-08-07 23:33:40,219 INFO Running exchange Bitmex
2020-08-07 23:33:40,231 INFO Joining all the processes
2020-08-07 23:33:40,232 INFO Creating table binance_ethbtc_order
2020-08-07 23:33:40,263 INFO Created table binance_ethbtc_order
2020-08-07 23:33:40,265 INFO Creating table binance_xrpbtc_order
2020-08-07 23:33:40,294 INFO Created table binance_xrpbtc_order
2020-08-07 23:33:40,297 INFO Creating table bitmex_ethusd_order
2020-08-07 23:33:40,322 INFO Created table bitmex_ethusd_order
```
After a while, the data is streamed into the file `.data/order_book.db`. You can terminate the process and the database contains the following tables.
```
$ python -c "import sqlite3; print(sqlite3.connect('.data/order_book.db').execute('SELECT name from sqlite_master where type= \"table\"').fetchall())"
[('binance_ethbtc_order',), ('binance_xrpbtc_order',), ('bitmex_ethusd_order',)]
```
## Inquiries
You can first look up to the page [FAQ](https://github.com/gavincyi/BitcoinExchangeFH/wiki/FAQ). For more inquiries, you can either leave it in issues or drop me an email. I will get you back as soon as possible.
## Compatibility
The application is compatible with version higher or equal to python 3.0.
## Contributions
Always welcome for any contribution. Please fork the project, make the changes, and submit the merge request. :)
For any questions and comment, please feel free to contact me through email (gavincyi at gmail)
Your comment will be a huge contribution to the project!
## Continuity
If you are not satisified with python performance, you can contact me to discuss migrating the project into other languages, e.g. C++.
