# QNAP QTS QNAP NAS devices use HBA controllers that report SATA drives as SCSI to the operating system. SMART Sniffer handles this automatically since v0.5.5, but there are a couple of QNAP-specific network quirks to watch for during setup. ## What's different about QNAP Three things to know: 1. **SCSI protocol misreport.** QNAP's HBA controllers present SATA drives as SCSI. When smartctl queries with the SCSI protocol, it reports "SMART support is: Unavailable." But the drives are actually SATA and work fine with SAT (SCSI-to-ATA Translation). The agent detects and handles this automatically. 2. **LXC bridge interfaces.** QNAP runs Docker containers via LXC, which creates bridge interfaces like `lxcbr0`. If the agent advertises mDNS on `lxcbr0`, it publishes an internal container IP (like `10.0.3.1`) instead of your LAN address. Home Assistant can't reach that IP. 3. **Standard device paths.** Unlike Synology, QNAP uses standard `/dev/sdX` paths. `smartctl --scan` finds them normally. ## Prerequisites QNAP QTS ships bash 3.2 and does not include systemd. The installer handles both automatically since v0.5.7 -- no manual workarounds needed. You will need `smartmontools` installed so the agent can query SMART data. If you have Entware: ```bash opkg install smartmontools ``` Verify it's available: ```bash smartctl --version ``` ## Step 1: Install the agent SSH into your QNAP and run: ```bash curl -sSL https://raw.githubusercontent.com/DAB-LABS/smart-sniffer/main/install.sh | sudo bash ``` The installer detects that QTS lacks systemd and installs an init.d service script instead. You'll see confirmation in the post-install banner. **Important: pick the right network interface during install.** The installer will show an interface picker. Choose your LAN interface (usually `eth0` or similar) -- **not** `lxcbr0`, `lxdbr0`, `docker0`, or any bridge interface. This ensures mDNS advertises your real LAN IP. If you're not sure which interface is which: ```bash ip addr show ``` Look for the interface with your LAN IP (e.g., `192.168.1.x`). ## Step 2: Verify protocol detection After install, check that the agent found your drives with the correct protocol: ```bash sudo smartha-agent --discover ``` Since v0.5.5, the agent uses `--scan-open` on its first poll cycle, which detects SATA drives behind SCSI-reporting HBAs. If a drive still comes back as SCSI, the agent retries with SAT automatically. You should see output like: ``` /dev/sda -- Seagate IronWolf 4TB (ZDH1ABCD) Protocol: SCSI → SAT fallback succeeded SMART: Available /dev/sdb -- Seagate IronWolf 4TB (ZDH1EFGH) Protocol: SCSI → SAT fallback succeeded SMART: Available ``` If `--discover` finds drives and offers to write config, accept it. Otherwise, the auto-detection is handling things and no manual config is needed. ## Step 3: Add the integration to Home Assistant 1. **HACS** --> Custom repositories --> `https://github.com/DAB-LABS/smart-sniffer` (Integration) 2. Download **SMART Sniffer** --> Restart HA 3. The agent advertises via mDNS -- HA should discover it automatically ## Troubleshooting ### HA discovers the agent but can't connect (wrong IP) This is the `lxcbr0` issue. The agent advertised an internal container bridge IP instead of your LAN IP. Check what IP the agent is advertising: ```bash tail -100 /var/log/smartha-agent.log | grep "preferred IP" ``` If it shows something like `10.0.3.1` instead of your LAN IP, the agent picked the wrong interface. Fix it: ```bash sudo nano /etc/smartha-agent/config.yaml ``` Set `advertise_interface` to your LAN interface: ```yaml advertise_interface: eth0 ``` Restart: ```bash sudo /etc/init.d/smartha-agent restart ``` Since v0.5.5.4, the agent's interface filter excludes `lxcbr0` and `lxdbr0` by default. If you're on an older version, upgrading fixes this automatically: ```bash curl -sSL https://raw.githubusercontent.com/DAB-LABS/smart-sniffer/main/install.sh | sudo bash ``` ### Drives show as UNSUPPORTED or no SMART data This means the SAT fallback didn't kick in. Check the agent logs: ```bash grep -i "sat\|protocol\|scsi" /var/log/smartha-agent.log ``` If you see "device open failed" errors, add manual overrides: ```yaml device_overrides: - device: /dev/sda protocol: sat - device: /dev/sdb protocol: sat ``` Restart the agent after editing config: ```bash sudo /etc/init.d/smartha-agent restart ``` ### I have a hardware RAID controller Some QNAP models (higher-end rackmount units) have hardware RAID controllers. In that case, drives are hidden behind the RAID layer and need explicit protocol flags. See the [Hardware RAID Controllers guide](raid-controllers.md) for `device_overrides` with RAID-specific protocols like `megaraid,0`. Most consumer QNAP models use a standard HBA (not hardware RAID), so this doesn't apply to the typical setup. ## Service management QNAP uses init.d instead of systemd. Common commands: ```bash sudo /etc/init.d/smartha-agent start sudo /etc/init.d/smartha-agent stop sudo /etc/init.d/smartha-agent restart sudo /etc/init.d/smartha-agent status ``` Logs go to `/var/log/smartha-agent.log` (auto-rotated at 10MB): ```bash tail -f /var/log/smartha-agent.log ``` ## Firmware updates QTS firmware updates can reset `/usr/local/bin` and `/etc/init.d/`. If the agent stops working after a firmware update, re-run the installer to restore it -- your config in `/etc/smartha-agent/config.yaml` is preserved: ```bash curl -sSL https://raw.githubusercontent.com/DAB-LABS/smart-sniffer/main/install.sh | sudo bash ``` ## Example config A typical QNAP `config.yaml`: ```yaml port: 9099 scan_interval: 120 advertise_interface: eth0 ``` In most cases, you don't need `device_overrides` -- the agent's automatic SAT fallback handles QNAP's SCSI-to-SATA mismatch. Only add overrides if `--discover` tells you to or if you're seeing UNSUPPORTED drives. ## Related - [Synology guide](synology.md) -- similar protocol issues, different device path quirks - [Platform Install Paths](../platform-install-paths.md) -- install locations on different platforms - [Main README: NAS & RAID Setup](../../README.md#nas--raid-setup) -- quick reference for all NAS platforms
