# Synology DSM Synology NAS devices run DSM (DiskStation Manager), which does a few things differently from standard Linux. SMART Sniffer supports Synology, but the setup needs a couple of extra steps. ## What's different about Synology Two things trip up a standard install: 1. **Non-standard device paths.** Synology uses `/dev/sata1`, `/dev/sata2`, etc. instead of the standard `/dev/sdX` paths. `smartctl --scan` doesn't find these proprietary paths on its own. 2. **Old smartmontools.** DSM ships smartmontools 6.5, which doesn't support the `--json` flag the agent requires (needs 7.0+). The agent will log a clear error on startup if the version is too old. Both are solved below. ## Step 1: Install smartmontools 7.x via SynoCli DSM's built-in smartmontools is too old. Install a newer version from the SynoCommunity package source. 1. Open **Package Center** in DSM 2. Go to **Settings --> Package Sources** 3. Add a new source: - Name: `SynoCommunity` - Location: `https://packages.synocommunity.com` 4. Back in Package Center, search for **SynoCli Disk Tools** 5. Install it -- this provides smartmontools 7.4+ Verify the version: ```bash /usr/local/bin/smartctl --version ``` You should see 7.4 or newer. The agent auto-detects this path since v0.5.5.1 -- it searches common binary locations even if the system `PATH` only finds the older version. ## Step 2: Install the agent SSH into your Synology (enable SSH in DSM under **Control Panel --> Terminal & SNMP**): ```bash curl -sSL https://raw.githubusercontent.com/DAB-LABS/smart-sniffer/main/install.sh | sudo bash ``` The installer handles Synology-specific setup automatically: - Detects DSM and probes for writable install paths - Finds the SynoCli smartmontools binary - Sets up the systemd service ## Step 3: Run --discover After install, run the discovery tool to detect your drives: ```bash sudo smartha-agent --discover ``` This probes standard Linux paths (`/dev/sdX`) **and** Synology's proprietary paths (`/dev/sata1` through `/dev/sata8`). It also tests protocol detection -- Synology drives typically need SAT (SCSI-to-ATA Translation) because the HBA presents them as SCSI. Example output: ``` Probing drives... /dev/sata1 -- WD Red Plus 4TB (WD-WCC7K1234567) Protocol: SCSI → SAT fallback succeeded SMART: Available /dev/sata2 -- WD Red Plus 4TB (WD-WCC7K7654321) Protocol: SCSI → SAT fallback succeeded SMART: Available /dev/sata3 -- WD Red Plus 10TB (WD-WMC1T0ABCDEF) Protocol: SCSI → SAT fallback succeeded SMART: Available Found 3 drives. Write device_overrides to config? (Y/n) ``` Say yes. The tool writes `device_overrides` entries to your `config.yaml` so the agent uses the correct protocol on every scan. Restart the agent to pick up the new config: ```bash sudo systemctl restart smartha-agent ``` ## Step 4: Add the integration to Home Assistant Same as any other setup: 1. **HACS** --> Custom repositories --> `https://github.com/DAB-LABS/smart-sniffer` (Integration) 2. Download **SMART Sniffer** --> Restart HA 3. The agent advertises via mDNS -- HA should discover it automatically If your Synology and HA are on different VLANs, use manual setup: **Settings --> Devices & Services --> Add Integration --> SMART Sniffer** with the NAS IP and port. ## SHR / RAID considerations Synology's SHR (Synology Hybrid RAID) is a software RAID implementation built on top of Linux MD RAID and LVM. The individual drives are still accessible as `/dev/sataX` block devices -- SHR doesn't hide them behind a hardware RAID controller. This means SMART Sniffer can read each drive directly, which is the ideal scenario. No `RAID=` flags or special RAID config needed for SHR setups. ## Troubleshooting ### "smartctl version too old" on startup The agent found the system smartmontools (6.5) instead of the SynoCli version (7.4+). Since v0.5.5.1, the agent searches common paths automatically. If it's still finding the old version: ```bash which smartctl /usr/local/bin/smartctl --version ``` If `/usr/local/bin/smartctl` shows 7.4+ but the agent isn't using it, you can set the path explicitly in `config.yaml`: ```yaml smartctl_path: /usr/local/bin/smartctl ``` ### No drives detected Run `smartha-agent --discover` to see what the agent finds. If it shows drives but the running agent doesn't, the config may not have the `device_overrides` entries. Check `/etc/smartha-agent/config.yaml` (or the install path shown during setup). ### Drives show as UNSUPPORTED This usually means the agent is querying with the wrong protocol. Synology drives need SAT. Run `--discover` and let it write the config, or add the overrides manually: ```yaml device_overrides: - device: /dev/sata1 protocol: sat - device: /dev/sata2 protocol: sat ``` ## Example config A typical Synology `config.yaml`: ```yaml port: 9099 scan_interval: 120 device_overrides: - device: /dev/sata1 protocol: sat - device: /dev/sata2 protocol: sat - device: /dev/sata3 protocol: sat - device: /dev/sata4 protocol: sat ``` ## Related - [QNAP guide](qnap.md) -- similar HBA/SAT issues on a different NAS platform - [Platform Install Paths](../platform-install-paths.md) -- where the agent installs on Synology and other restricted filesystems - [Main README: NAS & RAID Setup](../../README.md#nas--raid-setup) -- quick reference for all NAS platforms
