# TrueNAS SCALE TrueNAS SCALE is a Debian-based NAS OS built around ZFS. SMART Sniffer supports TrueNAS SCALE, though there are some platform-specific details to be aware of. ## What's different about TrueNAS SCALE 1. **ZFS, not ext4 or btrfs.** TrueNAS SCALE uses ZFS for storage management. ZFS pools present drives individually to the OS -- no hardware RAID controller hiding them -- so `smartctl --scan` finds drives normally. SMART data works out of the box. 2. **Filesystem monitoring needs btrfs-progs.** The agent's disk usage monitoring feature (`/api/filesystems`) uses `statvfs` by default, which can return zeros on ZFS. Since v0.5.6, the agent falls back to `btrfs filesystem usage --raw` when `statvfs` returns empty data. On TrueNAS SCALE, install `btrfs-progs` to enable this fallback for accurate filesystem reporting. 3. **Debian base with restrictions.** TrueNAS SCALE is built on Debian but the root filesystem may have restrictions depending on your version. The installer's path probing handles this -- it tries `/usr/local/bin` first, then falls back to `/opt/smartha-agent/` if needed. ## Step 1: Install btrfs-progs (for filesystem monitoring) If you want disk usage monitoring (optional but recommended): ```bash sudo apt install btrfs-progs ``` This is only needed for the filesystem reporting feature. SMART data works without it. ## Step 2: Install the agent ```bash curl -sSL https://raw.githubusercontent.com/DAB-LABS/smart-sniffer/main/install.sh | sudo bash ``` The installer detects your OS, installs smartmontools if missing, and sets up the service. During network interface selection, pick your management interface (the one with your LAN IP). Verify: ```bash sudo systemctl status smartha-agent curl http://localhost:9099/api/health ``` ## Step 3: Add the integration to Home Assistant If HA is running on a separate machine or VM: 1. **HACS** --> Custom repositories --> `https://github.com/DAB-LABS/smart-sniffer` (Integration) 2. Download **SMART Sniffer** --> Restart HA 3. Auto-discovery via mDNS, or manual setup with the TrueNAS IP and port 9099 If HA is running as a VM on TrueNAS SCALE (using the built-in VM functionality), see the [Virtual Machines guide](virtual-machines.md) -- the same agent-on-host / integration-in-VM pattern applies. ## ZFS and SMART -- how they fit together ZFS has its own disk health monitoring (`zpool status`, scrubs, checksums). SMART Sniffer doesn't replace that -- it complements it. ZFS detects errors at the filesystem level (bad checksums, failed reads). SMART Sniffer monitors the drive firmware's own health indicators (reallocated sectors, pending sectors, wear leveling, temperature) which are early warning signs that show up *before* ZFS sees errors. Running both gives you two layers of visibility: SMART catches the drive starting to degrade, ZFS catches the data integrity impact. ## Drive passthrough vs. RAID Most TrueNAS users run their SATA/SAS controllers in HBA mode (IT mode) or use HBA cards directly. This passes each physical drive through to the OS individually -- which is exactly what SMART Sniffer needs. No special configuration required. If you're running a hardware RAID controller in RAID mode (less common on TrueNAS but possible), see the [NAS & RAID Setup](../../README.md#nas--raid-setup) section for `device_overrides` configuration. ## Troubleshooting ### Agent installs but can't find smartctl TrueNAS SCALE includes smartmontools in its base image. If `smartctl --version` shows 7.0+, you're good. If it somehow shows an older version, install a newer one: ```bash sudo apt install smartmontools ``` ### Filesystem monitoring shows zeros Make sure `btrfs-progs` is installed. The agent needs it for the fallback filesystem reporting path. Restart the agent after installing: ```bash sudo apt install btrfs-progs sudo systemctl restart smartha-agent ``` ### HA can't discover the agent Same networking fundamentals as any other setup. If TrueNAS and HA are on different VLANs, mDNS won't cross the boundary. Use manual integration setup with the TrueNAS IP and port. ## Example config ```yaml port: 9099 scan_interval: 120 ``` TrueNAS SCALE typically needs no `device_overrides` since drives are presented directly to the OS via HBA passthrough. ## Related - [Proxmox guide](proxmox.md) -- if you're running HA as a VM on TrueNAS, similar network considerations apply - [Platform Install Paths](../platform-install-paths.md) -- install locations on different platforms - [Main README: NAS & RAID Setup](../../README.md#nas--raid-setup) -- quick reference
