# Peer Protocol for PeerSwap Swaps ## Introduction The PeerSwap protocol describes on-chain to off-chain atomic swaps between direct Lightning peers. A swap consists of two on-chain transactions: a opening transaction and a spending transaction. The opening transaction can be spent by revealing a payment preimage, received by paying a Lightning invoice. The primary use case of PeerSwap is efficient balancing of Lightning channels. The key words "MUST", "MUST NOT", "REQUIRED", "SHALL", "SHALL NOT", "SHOULD", "SHOULD NOT", "RECOMMENDED", "MAY", and "OPTIONAL" in this document are to be interpreted as described in [RFC 2119](#https://datatracker.ietf.org/doc/html/rfc2119). ## Table of Contents - [Peer Protocol for PeerSwap Swaps](#peer-protocol-for-peerswap-swaps) - [Introduction](#introduction) - [Table of Contents](#table-of-contents) - [General](#general) - [Supported Chains](#supported-chains) - [Terminology Guide](#terminology-guide) - [Swap In](#swap-in) - [Summary](#summary) - [The Swap](#the-swap) - [Negotiation](#negotiation) - [The `swap_in_request` message](#the-swap_in_request-message) - [Requirements](#requirements) - [The `swap_in_agreement` message](#the-swap_in_agreement-message) - [Requirements](#requirements-1) - [Swap Out](#swap-out) - [Summary](#summary-1) - [The Swap](#the-swap-1) - [Negotiation](#negotiation-1) - [The `swap_out_request` message](#the-swap_out_request-message) - [Requirements](#requirements-2) - [The `swap_out_agreement` message](#the-swap_out_agreement-message) - [Requirements](#requirements-3) - [Doing the Swap](#doing-the-swap) - [The `opening_tx_broadcasted` message](#the-opening_tx_broadcasted-message) - [Requirements](#requirements-4) - [Failing a Swap](#failing-a-swap) - [Messages](#messages) - [The `cancel` message](#the-cancel-message) - [Requirements](#requirements-5) - [The `coop_close` message](#the-coop_close-message) - [Requirements](#requirements-6) - [Transactions](#transactions) - [CSV Times and Confirmations](#csv-times-and-confirmations) - [Timeouts and Invoice expiry](#timeouts-and-invoice-expiry) - [Opening Transaction](#opening-transaction) - [Opening Transaction Output](#opening-transaction-output) - [Claim transaction](#claim-transaction) - [The `claim_by_invoice` path](#the-claim_by_invoice-path) - [The `claim_by_coop` path](#the-claim_by_coop-path) - [The `claim_by_csv` path](#the-claim_by_csv-path) ## General The `protocol_version` is included to allow for possible changes in the future. The `protocol_version` of this document is `5`. PeerSwap utilizes custom messages as described in [BOLT#1](https://github.com/Lightning/bolts/blob/master/01-messaging.md). The types are in range `42069`-`42085`. The `payload` is JSON encoded. * Both nodes MUST ignore unexpected Messages. * During a swap the involved peers MUST ensure, that there is only one active swap per channel. * Swaps are identified by a unique `swap_id` that MUST be mapped to the peers `pubkey` and MUST be checked on every message. ### Supported Chains Currently PeerSwap supports atomic swaps via the following chains, both main and testnets: * Bitcoin * Liquid Network ### Terminology Guide * #### Initiator * The peer requesting a swap. * #### Responder * The peer participating in a swap requested by the Initiator. * #### Maker * The peer that makes the on-chain commitment in the swap. * #### Taker * The peer that pays the Lightning invoice in the swap. * #### Swap In * A swap where the initiator is the maker, shifting Lightning balance towards itself. * #### Swap Out * A swap where the initiator is the taker, shifting Lightning balance towards the Responder. ## Swap In ### Summary ``` Before Alice After +-------+-------------------------------+ Swap In +-------------------+-------------------+ | 0.2 | 0.8 | -------> | 0.5 | 0.5 | +-------+-------------------------------+ +-------------------+-------------------+ Alice Bob Alice Bob 0.5 btc 0.5 btc 0.2 btc 0.8 btc on-chain on-chain on-chain on-chain ``` The aim of a `Swap In` is to shift the channel balance towards the initiators side. Therefore, the initiator asks its channel peer for a swap on the desired chain. If the peer agrees, the initiator publishes the [`opening transaction`](#opening-transaction) to the mempool and sends a Lightning invoice to the peer. Once the transaction has received enough confirmations, the responder pays the invoice and publishes the [`claim transaction`](#claim-transaction), revealing the preimage of the invoice to claim the transaction output of the opening transaction. ### The Swap ![swap in](img/swap-in-sequence.png) A swap in is initiated by the initiator (Alice) sending a [`swap_in_request` message](#the-swap_in_request-message) to the channel peer (Bob). Bob checks if the request is valid and if he can perform the swap. Bob then responds with the [`swap_in_agreement` message](#the-swap_in_agreement-message). Alice then broadcasts the [`opening_transaction`](#opening-transaction) and sends the [`opening_tx_broadcasted` message](#the-opening_tx_broadcasted-message) with an invoice back to Bob. After the [`opening_transaction`](#opening-transaction) is confirmed, Bob pays the invoice and can then broadcast the [`claim_transaction`](#claim-transaction) with the `preimage` to send the on-chain funds of the swap to an address of his desire. ### Negotiation This phase of the swap is used to agree on the swap conditions. #### The `swap_in_request` message 1. `type`: 42069 2. `payload` json encoded: ``` { protocol_version: uint64, swap_id: string, asset: string, network: string, scid: string, amount: uint64, pubkey: string } ``` `protocol_version` is the version of the PeerSwap peer protocol the sending node uses. `swap_id` is a randomly generated 32 byte string that must be kept the same through the whole process of a swap and serves as an identifier for a specific swap. `asset` is the desired on-chain asset to use. This can be: * Bitcoin: The field is left blank. * Liquid: The asset id of the networks Bitcoin asset. `network` is the desired on-chain network to use. This can be: * Bitcoin: `mainnet`, `testnet`, `signet`, `regtest` * Liquid: The field is left blank as the asset id also identifies the network. `scid` is the short channel id in human readable format, defined by [BOLT#7](https://github.com/Lightning/bolts/blob/master/07-routing-gossip.md) with `x` as separator, i.e. `539268x845x1`. `amount` is the amount in `Sats` that is asked for. `pubkey` is a 33 byte compressed public key generated by the swap initiator. It is used for the spending paths in the [`opening_transaction`](#opening-transaction). ##### Requirements The sending node (swap [maker](#maker)/[initiator](#initiator)): * MUST set the `protocol_version` to the version the implementation it is using. * MUST ensure the `swap_id` is unique from any other swap the node has participated in. * If requesting a swap using the Liquid chain: * MUST leave the `network` field blank. * MUST set the `asset` field to the asset id of the networks Bitcoin asset. * otherwise requesting a swap using the Bitcoin chain: * MUST set the `network` field to the network the bitcoin node operates on, one of `mainnet`, `testnet`, `regtest`. * MUST leave the `asset` field blank. * MUST set `amount` greater than 0 and smaller than or equal to the channel size. * SHOULD ensure that it can spend the asked `amount` on the desired `network` and `asset` from the on-chain wallet. * MUST set the `scid` in desired format for an existing channel between the peers. * SHOULD use a fresh random private key to generate the `pubkey` per swap request. * MUST set a 33 byte sized `pubkey` for the receiving node to build the swap bitcoin script in order to verify the broadcasted [`opening transaction`](#opening-transaction). * SHOULD [fail the swap](#failing-a-swap) after a reasonable time without receiving an answer. The receiving node (swap [taker](#taker)/[responder](#responder)): * MUST [fail the swap](#failing-a-swap) on an incompatible `protocol_version`. * MUST [fail_the_swap](#failing-a-swap) if the `swap_id` is already used * MUST [fail_the_swap](#failing-a-swap) if both or neither `asset` and `network` are set. * if `asset` is set: * MUST [fail the swap](#failing-a-swap) if it does not support the asked `asset`. * if `network` is set: * MUST [fail the swap](#failing-a-swap) if it does not support the asked `network`. * MUST [fail the swap](#failing-a-swap) if the `amount` exceeds channel size. * MUST [fail the swap](#failing-a-swap) if the channel with `scid` does not exist to the peer. * MUST keep the [`swap_in_request` message](#the-swap_in_request-message) field values for later use. #### The `swap_in_agreement` message 1. `type`: 42073 2. `payload` json encoded: ``` { protocol_version: uint64, swap_id: string, pubkey: string, premium: int64 } ``` `protocol_version` is the version of the PeerSwap peer protocol the sending node uses. `swap_id` is the unique identifier of the swap. `pubkey` is a 33 byte compressed public key generated by the swap responder. It is used for the spending paths in the [`opening_transaction`](#opening-transaction). `premium` is a compensation in Sats that the swap partner wants to be paid in order to participate in the swap. ##### Requirements The sending node (swap [taker](#taker)/[responder](#responder)): * MUST set the swap_id to the `swap_id` received from the `swap_in_request` message. * MUST set a 33 byte sized `pubkey` for the maker node to build the bitcoin script for the [`opening transaction`](#opening-transaction). * SHOULD use a fresh random private key to generate the `pubkey`. * SHOULD [fail the swap](#failing-a-swap) after a reasonable time without receiving an answer. * SHOULD set `premium` to the desired compensation in Sats. The receiving node (swap [maker](#maker)/[initiator](#initiator)): * MUST [fail the swap](#failing-a-swap) on an incompatible protocol_version. * MUST ignore the message if the `swap id` is unknown. * MUST keep the `pubkey` for later use in the case of a [failing swap](#failing-a-swap). * if the `premium` exceeds its expectations: * MUST [fail_the_swap](#failing-a-swap) * otherwise: * MUST add the `premium` to the on-chain amount of the [`opening_transaction`](#opening-transaction). The next steps are the same for both kind of swaps and are laid out under [Doing the Swap](#doing-the-swap). ## Swap Out ### Summary ``` Before Alice After +-------------------------------+-------+ Swap Out +-------------------+-------------------+ | 0.8 | 0.2 | -------> | 0.5 | 0.5 | +-------------------------------+-------+ +-------------------+-------------------+ Alice Bob Alice Bob 0.5 btc 0.5 btc 0.8 btc 0.2 btc on-chain on-chain on-chain on-chain ``` The aim of a `Swap Out` is to shift the channel balance towards the responders side. Therefore, the initiator asks its channel peer for a swap on the desired chain. If the responder agrees, it responds with a fee invoice to cover the on-chain fees for claiming the on-chain funds, in case the initiator does not pay the later swap invoice. When the initiator pays the fee invoice, the responder broadcasts the [`opening transaction`](#opening-transaction) to the mempool and sends a Lightning invoice to the initiator. Once the transaction has enough confirmations, the initiator pays the invoice and creates the [`claim transaction`](#claim-transaction) with the preimage. ### The Swap ![swap out](img/swap-out-sequence.png) ### Negotiation This phase of the swap is used to agree on the swap conditions. It involves one more invoice than the swap in negotiation, to compensate for the on-chain fees the swap responder and maker in this case has to account for. #### The `swap_out_request` message 1. `type`: 42071 2. `payload` json encoded: ``` { protocol_version: uint64, swap_id: string, asset: string, network: string, scid: string, amount: uint64, pubkey: string } ``` `protocol_version` is the version of the PeerSwap peer protocol the sending node uses. `swap_id` is a randomly generated 32 byte string, that must be kept the same through the whole process of a swap and serves as an identifier for a specific swap. `asset` is the desired on-chain asset to use. This can be: * Bitcoin: The field is left blank. * Liquid: The bitcoin asset hash of the desired network. `network` is the desired on-chain network to use. This can be: * Bitcoin: `mainnet`, `testnet`, `signet`, `regtest` * Liquid: The field is left blank as the asset id also defines the network. `scid` is the short channel id in human readable format, defined by [BOLT#7](https://github.com/Lightning/bolts/blob/master/07-routing-gossip.md) with `x` as separator, i.e. `539268x845x1`. `amount` is the amount in `satoshi` that is asked for. `pubkey` is a 33 byte compressed public key generated by the initiator. It is used for the spending paths in the [`opening_transaction`](#opening-transaction). ##### Requirements The sending node (swap [taker](#taker)/[initiator](#initiator)): * MUST set the `protocol_version` to the version the implementation it is using. * MUST ensure the `swap_id` is unique from any other swap the node has participated in. * If requesting a swap using the Liquid chain: * MUST leave the `network` field blank. * MUST set the `asset` field to the asset id of the networks Bitcoin asset. * otherwise requesting a swap using the Bitcoin chain: * MUST set the `network` field to the network the bitcoin node operates on, one of `mainnet`, `testnet`, `regtest`, `signet`. * MUST leave the `asset` field blank. * MUST set `amount` greater than 0 and smaller than or equal to the capacity of the channel. * MUST set the `scid` in desired format for an existing channel between the peers. * SHOULD use a fresh random private key to generate the `pubkey` per swap request. * MUST set a 33 byte sized compressed `pubkey` for the receiving node to build the swap bitcoin script in order to verify the broadcasted [`opening transaction`](#opening-transaction). * SHOULD [fail the swap](#failing-a-swap) after a reasonable time without receiving an answer. The receiving node (swap responder): * MUST [fail the swap](#failing-a-swap) on an incompatible `protocol_version`. * MUST [fail_the_swap](#failing-a-swap) if the `swap_id` is already used. * MUST [fail_the_swap](#failing-a-swap) if both or neither `asset` and `network` are set. * if `asset` is set: * MUST [fail the swap](#failing-a-swap) if it does not support the asked `asset`. * if `network` is set: * MUST [fail the swap](#failing-a-swap) if it does not support the asked `network`. * MUST [fail the swap](#failing-a-swap) if the `amount` exceeds channel size. * MUST ensure that it can dispose the asked `amount` on the desired `network` and `asset`. * MUST [fail the swap](#failing-a-swap) if the channel with `scid` does not exist to the peer. * MUST keep the [`swap_out_request` message](#the-swap_out_request-message) field values for later use. #### The `swap_out_agreement` message 1. `type`: 42075 2. `payload` json encoded: ``` { protocol_version: uint64, swap_id: string, pubkey: string, payreq: string, premium: uint64 } ``` `protocol_version` is the version of the PeerSwap peer protocol the sending node uses. `swap_id` is the unique identifier of the swap. `pubkey` is a 33 byte compressed public key generated by the responder. It is used by the initiator to build the bitcoin script in order to verify the [`opening_transaction`](#opening-transaction). `payreq` is a [BOLT#11](#https://github.com/Lightning/bolts/blob/master/11-payment-encoding.md) invoice with an amount that covers the fee expenses for the on-chain transactions. `premium` is a compensation in Sats that the swap partner wants to be paid in order to participate in the swap. ##### Requirements The sending node (swap [maker](#maker)/[responder](#responder)): * MUST set the `protocol_version` to the version the implementation is using. * MUST set the swap_id to the `swap_id` received from the `swap_out_request` message. * SHOULD use a fresh random private key to generate the `pubkey`. * MUST set a 33 byte sized `pubkey` for the taker node to build the swap bitcoin script for verification of the [`opening transaction`](#opening-transaction). * MUST set `payreq` to a valid [BOLT#11](#https://github.com/Lightning/bolts/blob/master/11-payment-encoding.md) invoice * SHOULD set the `amount` of the invoice to the fee of the to be created [`opening_transaction`](#opening-transaction). * SHOULD resend the message periodically until one of the following is true: * fee invoice with `payreq` has been paid. * fee invoice with `payreq` expired, in this case MUST [fail the swap](#failing-a-swap). * received a [`cancel`](#the-cancel-message) or [`coop_close`](#the-coop_close-message) message. * SHOULD set `premium` to the desired compensation in Sats. * if the `premium` is set: * MUST add `premium` on payreq of `opening_tx_broadcasted` message. The receiving node (swap initiator): * MUST [fail the swap](#failing-a-swap) on an incompatible `protocol_version`. * MUST ignore the message if the `swap_id` is unknown. * MUST [fail the swap](#failing-a-swap) if `payreq` is not a valid [BOLT#11](#https://github.com/Lightning/bolts/blob/master/11-payment-encoding.md) invoice; * SHOULD [fail the swap](#failing-a-swap) if the `amount` asked for in the `payreq` is exceeding own expectations. * MUST [fail the swap](#failing-a-swap) if the `amount` asked for in the `payreq` added to the `amount` asked for in the [`swap_out_request`](#the-swap_out_request-message) exceeds the peers channel balance. * MUST try to pay the fee invoice and [fail the swap](#failing-a-swap) if this fails. * if the `premium` exceeds its expectations: * MUST [fail_the_swap](#failing-a-swap) When the fee invoice was paid, the next steps are the same for both kind of swaps and are laid out under Doing the Swap. ## Doing the Swap After the peers agreed to the swap conditions, the `swap maker` broadcasts the [`opening_transaction`](#opening-transaction) and sends the [`opening_tx_broadcasted` message](#the-opening_tx_broadcasted-message) to the `swap taker`. #### The `opening_tx_broadcasted` message 1. `type`: 42077 2. `payload` json encoded: ``` { swap_id: string, payreq: string, tx_id: string, script_out: uint64, blinding_key: string, } ``` `swap_id` is the unique identifier of the swap. `payreq` is the invoice as described in [BOLT#11](#https://github.com/Lightning/bolts/blob/master/11-payment-encoding.md) that the responder is requested to pay. `tx_id` is the transaction id of the [`opening_transaction`](#opening-transaction) broadcasted by the initiator. `script_out` is the transaction output that contains the [`opening_transaction`](#opening-transaction) output script for the swap. `blinding_key`: * Bitcoin: Blank. * Liquid Network: Is the 32 byte blinding key to un-blind the outputs of the [`opening_transaction`](#opening-transaction). ##### Requirements The sending node (swap maker): * MUST set `swap_id` matching the ongoing swap. * MUST set `payreq` to a valid [BOLT#11](#https://github.com/Lightning/bolts/blob/master/11-payment-encoding.md) invoice with the amount that was requested in `amount` of the swap request and the payment_hash of the [`opening_transaction`](#opening-transaction) and a [reasonable `expiry`](#timeouts-and-invoice-expiry). * MUST set `tx_id` to the id of the broadcasted [`opening_transaction`](#opening-transaction). * MUST set `script_out` to the output index that contains the script for the [`opening_transaction`](#opening-transaction) * if `asset` was set in the request: * MUST set the `blinding_key` to the blinding key that is used to blind the `opening_transaction` outputs. * otherwise: * MUST NOT set the `blinding_key`. * SHOULD fail any htlc that would change the channel into a state, where the swap invoice can not be paid until the swap invoice was paid. * SHOULD resend the message until one of the following is true: * swap invoice with `payreq` has been paid. * swap invoice with `payreq` expired, in this case MUST [fail the swap](#failing-a-swap). * received a [`cancel`](#the-cancel-message) or [`coop_close`](#the-coop_close-message) message. * if the invoice with `payreq` gets paid: * MUST consider the swap finished and ignore all future messages with `swap_id`. * otherwise after the invoice is expired: * MUST [fail the swap](#failing-a-swap). The receiving node (swap taker): * MUST [fail the swap](#failing-a-swap) if the `swap_id` changed. * MUST check that the `payreq` amount matches the negotiated `amount` of the swap and [fail the swap](#failing-a-swap) if not. * SHOULD fail any htlc that would change the channel into a state, where the swap invoice can not be paid until the swap invoice was paid. * MUST wait for the [opening_transaction](#opening-transaction) with `tx_id` to be confirmed. * MUST verify the [opening_transaction](#opening-transaction) output with index `script_out`: * if `asset` was set in the request: * MUST un-blind the amount with the `blinding_key` * MUST check that the amount matches the negotiated `amount` of the swap. * MUST check that the script is built as described by [opening_transaction](#opening-transaction). * if this fails: * MUST [fail the swap](#failing-a-swap). * otherwise: * MUST pay the swap invoice over the channel with the negotiated `scid`. * if this fails: * SHOULD retry to pay the invoice, but MUST NOT pay the invoice if current block height exceeds `CONFIRMATION_HEIGHT + R/2`, where `CONFIRMATION_HEIGHT` is the height of the block at which the [`opening_transaction`](#opening-transaction) counts as [confirmed](#csv-times-and-confirmations), and `R` is the relative locktime of the `claim_by_csv` path of the [`opening_transaction`](#opening-transaction). * if this fails: * MUST [fail the swap](#failing-a-swap). * otherwise: * MUST broadcast the `claim_by_preimage`[`claim_transaction`](#claim-transaction) with a fee high enough to ensure that the transaction is confirmed before the `claim_by_csv` spending path is possible. * MUST consider the swap finished after the [`claim_transaction`](#claim-transaction) has been confirmed. ## Failing a Swap When a node cancels a swap, the most effective way should be used to avoid unnecessary long on-chain locks for the swap partner. This means that if the swap fails after the [`opening_transaction`](#opening-transaction) was broadcasted (e.g. because the invoice can not be paid), the swap taker should be cooperative and fail the swap via the [`coop_close` message](#the-coop_close-message). Both nodes MUST expect `cancel` and `coop_close` at any time during an active swap. ### Messages #### The `cancel` message 1. `type`: 42079 2. `payload` json encoded: ``` { swap_id: string, message: string, } ``` `swap_id` is the unique identifier of the swap. `message` is a hint to why the swap was canceled. ##### Requirements The sending node: * MUST set `swap_id` matching the ongoing swap. * SHOULD set a meaningful `message`. * MUST consider the swap canceled and ignore all future messages with `swap_id`. * if it is the `swap maker` and the [`opening_transaction`](#opening-transaction) was already broadcasted: * MUST broadcast the [`claim_transaction`](#claim-transaction), with the `claim_by_csv` spending path, after the CSV has passed. * MUST allow for new swaps on the channel as soon as the [`claim_transaction`](#claim-transaction) is confirmed. * otherwise: * MUST allow for new swaps on the channel. The receiving node: * MUST consider the swap canceled and ignore all future messages with `swap_id`. * if it is the `swap maker` and the [`opening_transaction`](#opening-transaction) was already broadcasted: * MUST broadcast the [`claim_transaction`](#claim-transaction), with the `claim_by_csv` spending path, after the CSV has passed. * MUST allow for new swaps on the channel as soon as the [`claim_transaction`](#claim-transaction) is confirmed. * otherwise: * MUST allow for new swaps on the channel. #### The `coop_close` message 1. `type`: 42081 2. `payload` json encoded: ``` { swap_id: string, message: string, privkey: string, } ``` `swap_id` is the unique identifier of the swap. `message` is a hint to why the swap was closed cooperatively. `privkey` is the private key to the pubkey that is used to build the [`opening_transaction`](#opening-transaction). ##### Requirements The sending node (swap taker): * MUST set `swap_id` matching the ongoing swap. * SHOULD set a meaningful `message`. * if the node is the initiator: * MUST set `privkey` to the random private key that was used to generate the pubkey that was set in the request message. * otherwise: * MUST set `privkey` to the random private key that was used to generate the pubkey that was set in the agreement message. The receiving node (swap maker): * if the [`opening_transaction`](#opening-transaction) was already broadcasted: * MUST consider the swap canceled and ignore all future messages with `swap_id`. * MUST broadcast the [`claim_transaction`](#claim-transaction) with the `claim_by_coop` spending path using the `privkey`. * if this fails: * MUST broadcast the [`claim_transaction`](#claim-transaction) with the `claim_by_csv` spending path, after the CSV has passed. * otherwise: * MUST consider this to be a [`cancel` message](#the-cancel-message). ## Transactions ### CSV Times and Confirmations Timings are critical to the PeerSwap protocol. The goal is to provide a safe swap while maintaining a reasonable time frame. The timings differ for the supported networks. In the case of Bitcoin: * CSV = 1008 * Min required confirmations for the [`opening_transaction`](#opening-transaction) = 3 In The case of Liquid: * CSV = 60 * Min required confirmations for the [`opening_transaction`](#opening-transaction) = 2 The difference in timings is due to the different fee and consensus models of the Liquid Network and Bitcoin. #### Timeouts and Invoice expiry The expiry of the `swap invoice` MUST be less than or equal to half the CSV time to ensure a secure swap. ### Opening Transaction The opening transaction has a pay-to-witness-script-hash[BIP141](https://github.com/bitcoin/bips/blob/master/bip-0141.mediawiki#witness-program) (P2WSH) output that locks the on-chain part of the swap. This script has three different spending paths. These are the `claim_by_invoice`, `claim_by_csv` and the `claim_by_coop` paths. The transaction maker may use inputs to his desire. If this is a Liquid transaction, it MUST be blinded. #### Opening Transaction Output * The opening transaction policy: ``` or(and(pk(A),or(pk(B),sha256(H))),and(pk(B),older(144))) ``` * The opening transaction output script is a P2WSH: ``` OP_CHECKSIG OP_NOTIF OP_CHECKSIG OP_NOTIF OP_SIZE <20> OP_EQUALVERIFY OP_SHA256 OP_EQUALVERIFY OP_ENDIF OP_CHECKSIG OP_ELSE OP_CHECKSEQUENCEVERIFY OP_ENDIF ``` With: * `` the pubkey of the [`taker`](#taker) * `` the pubkey of the [`maker`](#maker) * `` the payment_hash * `` the number of confirmations before the refund to the maker is possible. See [CSV Times](#csv-times-and-confirmations) ### Claim transaction The claim transaction finishes the atomic swap. There are three different variants for the claiming transaction, depending on how the swap finishes. #### The `claim_by_invoice` path This is the desired way to finish a swap. The taker sends the funds to its address by revealing the preimage of the swap invoice. * txin count: 1 * txin[0] outpoint: `tx_id` and `script_output` from the `opening_tx_broadcasted` message * txin[0] sequence: 0 * txin[0] script bytes: 0 * txin[0] witness: ` <> <> ` #### The `claim_by_coop` path This is the way to cooperatively finish a swap. The maker refunds to its address without waiting for the CSV. * txin count: 1 * txin[0] outpoint: `tx_id` and `script_output` from the `opening_tx_broadcasted` message * txin[0] sequence: 0 * txin[0] script bytes: 0 * txin[0] witness: ` <> ` #### The `claim_by_csv` path This is the way to finish a swap if the invoice was not paid and the taker did not send a `coop_close` message. After the relative locktime has passed, the maker refunds to them. * txin count: 1 * txin[0] outpoint: `tx_id` and `script_output` from the `opening_tx_broadcasted` message * txin[0] sequence: * for `btc` as asset: 0x3F0 corresponding to the CSV of 1008 * for `lbtc` as asset: 0x3C corresponding to the CSV of 60 * txin[0] script bytes: 0 * txin[0] witness: ` `
