Swifka
A native macOS Kafka monitor. Read-only by design.
**Why Swifka exists:** Every existing Kafka client is either Java-based (Offset Explorer, Conduktor) or web-based (AKHQ, Kafdrop, Redpanda Console) — and every single one of them tries to be a full Kafka Swiss Army knife. None of them feel at home on macOS, and none of them nail "lightweight, safe, read-only monitoring."
| Tool | Stack | Problem |
|------|-------|---------|
| Offset Explorer | Java (Swing) | Feature-rich but bloated and dated |
| Conduktor | Java (JavaFX) | Pivoted to SaaS, heavy |
| AKHQ / Kafdrop | Java (Web) | Requires deployment, full admin scope |
| Redpanda Console | Go + React (Web) | Web-based, full admin capabilities |
| kcat | CLI | Powerful but raw |
Swifka fills the gap: a native macOS client built for **monitoring only** — safe to point at production, with zero risk of accidental writes. The teams that adopt Swifka are the ones that want a tool they can hand to any engineer, including junior developers and on-call rotations, without worrying about accidental production damage.
# Install
```bash
brew install --cask ender-wang/tap/swifka
```
Or download the latest `.dmg` from [Releases](https://github.com/Ender-Wang/Swifka/releases).
---
# Features
**Cluster & Connection**
- Connect to any Kafka-compatible cluster (Kafka, Redpanda, etc.)
- Multi-cluster management with pin, clone, drag-to-reorder, and keyboard navigation
- Cluster backup & restore (timestamped `.zip` export/import)
- Keychain-secured credentials
**Topics & Messages**
- Browse topics, partitions, and messages with detailed metadata
- Message decoding: UTF-8, Hex, Base64, Protobuf (import `.proto` files), Avro, JSON pretty-print
- Schema Registry integration — auto-decode Confluent wire format messages (Protobuf, Avro, JSON)
- Search messages by keyword, regex, or JSON path (e.g., `user.email:john@`) with time range filter
**Monitoring & Charts**
- Consumer group lag monitoring with per-partition breakdown
- Real-time trend charts: throughput, lag, ISR health (Live & History modes)
- Per-consumer member lag investigation
- Broker health dashboard with leader distribution
- SQL-downsampled historical data with configurable retention
**Alerts & Notifications**
- Configurable alert rules: ISR health, cluster lag, broker latency, broker offline
- Alert history with resolution tracking and detail panel
- macOS desktop notifications
**Quality of Life**
- Menu bar resident mode
- Excel (.xlsx) chart data export
- Manual + timed refresh (5s / 10s / 30s / 60s) with circuit breaker
- Dark mode, compact/regular/large row density
- English + Simplified Chinese (JSON-based, easy to contribute)
- In-app auto-update (GitHub Releases — check, download, verify, install, restart)
- Read-only by design — zero risk of accidental writes to production
---
# Roadmap
| Milestone | Focus | Status |
|-----------|-------|--------|
| 1 | MVP Core — connections, topics, messages, consumer groups, brokers | ✅ |
| 2 | Dashboards & Visualization — charts, alerts, historical data, SQLite | ✅ |
| 3 | Animations & Polish — chart animations, cluster manager, menu bar | ✅ |
| 4 | Advanced Monitoring & Search — Protobuf/Avro decode, regex/JSON path search | ✅ |
| 5 | Release Polish — Schema Registry, alert rules, accessibility, logging, in-app auto-update → **1.0.0** | ✅ |
---
# Contributing
**Requirements:** macOS 15.7+, Xcode 16.2+, [Homebrew](https://brew.sh)
```bash
brew install swiftformat
```
Code style is enforced by [SwiftFormat](https://github.com/nicklockwood/SwiftFormat) via a build phase — rules are in `.swiftformat` at the project root.
## Architecture
### Data Flow
```mermaid
graph TD
V["SwiftUI Views"] -->|"observe"| A["AppState (@Observable)"]
A -->|"user actions"| V
R["RefreshManager"] -->|"periodic fetch"| A
A -->|"async calls"| K["KafkaService (actor)"]
K -->|"C FFI · librdkafka"| C["Kafka / Redpanda"]
A -->|"decode"| D["MessageDeserializer"]
D -.->|"schema lookup"| S["SchemaRegistryClient"]
S -->|"HTTP"| SR["Schema Registry"]
A -->|"check · download · install"| U["UpdateChecker / Installer"]
U -->|"GitHub API"| GH["GitHub Releases"]
A <-->|"metrics"| DB[("SQLite")]
A <-->|"configs"| CS["JSON + Keychain"]
```
### Source Tree
```
Swifka/
├── App/ # Entry point + global state
│ ├── SwifkaApp.swift # @main, window groups, menu commands
│ └── AppState.swift # @Observable — single source of truth for all UI
├── ContentView.swift # NavigationSplitView shell (sidebar → detail router)
│
├── Core/ # Business logic — no SwiftUI imports
│ ├── Kafka/
│ │ ├── KafkaService.swift # actor — librdkafka C FFI (metadata, consume, watermarks)
│ │ ├── Models.swift # TopicInfo, BrokerInfo, ConsumerGroupInfo, etc.
│ │ ├── MetricStore.swift # In-memory snapshots for live trend charts
│ │ └── MetricModels.swift # MetricSnapshot, LagSnapshot value types
│ ├── Deserialization/
│ │ ├── MessageDeserializer.swift # Format router (UTF-8, Hex, Base64, Proto, Avro, JSON)
│ │ ├── ProtobufDeserializer.swift # .proto file import + wire-format decode
│ │ └── AvroDecoder.swift # Avro binary decoder (all types)
│ ├── SchemaRegistry/
│ │ ├── SchemaRegistryClient.swift # HTTP — subjects, versions, schema fetch
│ │ └── ConfluentWireFormat.swift # Magic byte 0x00 + 4-byte schema ID extraction
│ ├── Updates/
│ │ ├── UpdateChecker.swift # actor — GitHub Releases API, version comparison
│ │ ├── UpdateDownloader.swift # URLSession delegate with progress tracking
│ │ ├── UpdateInstaller.swift # 9-phase DMG install pipeline + restart
│ │ ├── UpdateModels.swift # GitHubRelease, UpdateStatus, UpdateProgress, UpdateError
│ │ └── ChecksumVerifier.swift # SHA256 verification via CryptoKit
│ ├── Storage/
│ │ ├── ConfigStore.swift # Cluster configs persisted as JSON files
│ │ ├── MetricDatabase.swift # SQLite — historical metrics, alerts, retention
│ │ └── BackupManager.swift # Cluster export/import (.zip archives)
│ └── Security/
│ └── KeychainManager.swift # macOS Keychain for passwords and SASL credentials
│
├── Features/ # One directory per sidebar page
│ ├── Clusters/ # Cluster list — add, edit, pin, clone, connect
│ ├── Connection/ # Dashboard overview + cluster picker
│ ├── Topics/ # Topic list with expandable partition detail
│ ├── Messages/ # Message browser — search, filter, decode
│ ├── Monitor/ # Consumer groups table + broker health cards
│ ├── Trends/ # Throughput, ISR, ping charts (Live + History)
│ ├── Lag/ # Consumer lag investigation (group/topic/partition/member)
│ ├── SchemaRegistry/ # Schema browser — subjects, versions, schema viewer
│ └── Settings/ # Preferences — refresh, density, language, alerts, auto-update, about
│
├── Shared/
│ ├── Components/ # Reusable views — MenuBarView, ConnectionStatusBadge
│ └── Utils/ # L10n, RefreshManager, Log, ChartExporter, XLSXWriter
│
└── Resources/
└── Locales/ # en.json, zh-Hans.json (custom JSON-based i18n)
```
### Key Patterns
| Pattern | Detail |
|---------|--------|
| **Actor isolation** | `KafkaService` is a Swift `actor`. Blocking librdkafka C calls run on a dedicated `DispatchQueue` via `withCheckedThrowingContinuation`, keeping the actor executor free for cancellation |
| **@Observable** | `AppState` uses the `@Observable` macro. Views read properties directly — no `@Published` or `objectWillChange` needed |
| **MainActor by default** | Project sets `SWIFT_DEFAULT_ACTOR_ISOLATION = MainActor`. All types are `@MainActor` unless explicitly opted out (`KafkaService`, model structs) |
| **Read-only** | `KafkaService` only exposes read methods — no produce, delete, or admin operations exist in the codebase |
| **JSON i18n** | `L10n` loads locale JSON at runtime. Access: `l10n["key"]` or `l10n.t("key", arg1, arg2)` for interpolation |
| **DMG auto-update** | `UpdateChecker` (actor) queries GitHub Releases API. `UpdateInstaller` runs a 9-phase pipeline: mount DMG → verify bundle ID → copy + strip quarantine → replace with backup → restart via detached script |
---
# Localization
Swifka uses a custom JSON-based i18n system. Currently supported:
| Language | File | Status |
|----------|------|--------|
| English | `Resources/Locales/en.json` | ✅ |
| Simplified Chinese | `Resources/Locales/zh-Hans.json` | ✅ |
## Contributing a Translation
1. Copy `Resources/Locales/en.json`
2. Rename to your language code (e.g. `ja.json`, `ko.json`, `fr.json`, `de.json`)
3. Translate the values (keep the keys as-is)
4. Submit a PR
No code changes needed — the app picks up new locale files automatically.
---
# License
Swifka is licensed under the [GNU General Public License v3.0](LICENSE).
# Acknowledgments
Swifka is built on top of these open-source projects:
| Project | License | Description |
|---------|---------|-------------|
| [swift-kafka-client](https://github.com/swift-server/swift-kafka-client) | Apache-2.0 | SSWG-maintained Swift Kafka client |
| [librdkafka](https://github.com/confluentinc/librdkafka) | BSD-2-Clause | C library for Kafka protocol, used directly for metadata and watermark APIs |
| [SQLite.swift](https://github.com/stephencelis/SQLite.swift) | MIT | Type-safe SQLite wrapper for metrics storage |
| [SwiftProtobuf](https://github.com/apple/swift-protobuf) | Apache-2.0 | Protocol Buffers runtime for message decoding |
| [SwiftFormat](https://github.com/nicklockwood/SwiftFormat) | MIT | Code formatting tool used in the build pipeline |
---
