GLM-5.3-Flash EXL3 on 2x DGX Spark with TensorFold

_{by Mia's AI Lab}

` (after `ssh-keygen -t ed25519` if you have no key); check with `ssh -o BatchMode=yes user@ true`. - Docker with the NVIDIA container runtime, your user in the `docker` group, and `rsync`, on both Sparks. - **Disk, on each Spark:** ~205 GB: ~176 GB (164 GiB) for the checkpoint and ~2.3 GB for DFlash2 under `~/.cache/huggingface`, ~25 GB for the image under Docker's root. `prepare.sh` wants 180 GB free for the download (`MIN_FREE_GB`) and 35 GB under Docker's root (`IMAGE_FREE_GB`; the sum when they share a filesystem), and checks the worker before the copy. With `WORKER_WEIGHTS=nfs` the worker needs only the image ([Worker weights over NFS](#worker-weights-over-nfs)). - Optional: the `hf` CLI on the head (faster download) and a Hugging Face token (`~/.cache/huggingface/token` or `HF_TOKEN`). ## Quick start


`), and its CX7 address when `WORKER` is on another network | | `MASTER_PORT` | `29551` | the ranks' rendezvous port (keep it on the private link) | | `PARALLEL` | `4` (`1` with `DRAFTER=mtp`) | requests decoded together, 1 to 4 (above 1 needs `DRAFTER=dflash2`) | | `CONTEXT` | `1048576` | prompt + reply window per request (with `KV=fp8`; other defaults in [KV pool and memory](#kv-pool-and-memory)); `0`: the largest that fits | | `KV` | `fp8` | `fp8` or `bf16` (exact, shorter window) DSA latent cache and indexer keys | | `WORKER_WEIGHTS` | `copy` | `copy`: the worker keeps its own copy of the weights; `nfs`: it reads the head's over NFS ([Worker weights over NFS](#worker-weights-over-nfs)); with `NFS_PATH`, `NFS_SERVER`, `NFS_VOLUME` | | `KV_POOL_GIB` / `MEMORY_RESERVE_GIB` | `12.5` / `14.5` | the shared pool beyond the window (kept prompts, more long conversations at once) grows into what is free at start minus the reserve, up to `KV_POOL_GIB` GiB a Spark; the reserve sets the lowest free memory on the head (~4.5-5 GiB); raise it when other work shares the Sparks | | `DENSE` | `q4` | the checkpoint's BF16 weights (attention, shared experts, dense layers, head): `q4` (4-bit groups of 64, the head in FP8, kv_b in BF16), `fp8` or `bf16`. **Non-English prompts:** `q4` can lose the end of turn on short French coding prompts (replies run to `max_tokens`, issue #18); `fp8` keeps it, at ~10% decode speed | | `DRAFTER` | `dflash2` | `dflash2`: IncoAI's DFlash2 drafter, licensed [CC BY-NC-ND 4.0](https://creativecommons.org/licenses/by-nc-nd/4.0/), **non-commercial use only**; +5-10% decode. `mtp`: the checkpoint's own MTP head, one request at a time, which avoids that license (set it before the first `./start.sh` and DFlash2 is never downloaded) | | `TF_GLM_MTP` | `auto` | the checkpoint's MTP head beside DFlash2: `auto` leaves it out while DFlash2 drafts every request; `1` (TensorFold v0.6.0's own default) loads it, 1.77 GiB a Spark, with `PARALLEL=1`. `DRAFTER=mtp` always loads it | | `DRAFT_POLICY` | `fnc7:0.3` | how many DFlash2 drafts a round verifies: up to 7, until the drafts' chance under the request's own sampling noise drops below 0.3 | | `COPY` / `COPY_MAX` | `1` / `15` | copy drafts: when the reply's last 8 tokens occurred before, the tokens that followed are verified ahead of DFlash2's, up to 15 a round | | `COPY_CODE` | `1` | 16-row verify windows as CUDA graphs, and copies from the reply itself only after a 16-token match | | `SHARED_PREFIX` | `1` | conversations that share a system prompt reuse its prompt state | | `MAX_TOKENS` | `32768` | the reply budget (reasoning and answer) of a request that sets no `max_tokens`; TensorFold's own default is 4,096 | | `THINKING` | `1` | think before answering by default; `0` answers directly unless a request asks to think | | `VISION` / `VISION_URLS` | `1` / `0` | image and video input; `1` also accepts public `https://` URLs | | `COMM` | `roce` | the ranks' small all-gathers as one-shot RDMA writes over the RoCE link; `nccl`: NCCL for all | | `SPLIT` | `1` | prompt chunks' hyper-connection work split between the Sparks, its exchanges overlapped with the next rows' work | | `KDA_CHUNKED` | `1` | KDA prompt chunks in chunked (WY) form, one CUDA kernel | | `TF_GLM_L2PF` | `1` | L2 prefetch in decode: the weights the next kernels read brought into L2 during each layer's all-gathers; `0`: off | | `TF_GLM_EXL3_LOADS` | `nc` | the decode expert kernel's trellis as 16-byte non-coherent loads a step ahead (`nc2` / `nc4`: 2 or 4 steps); `0`: TensorFold's 32-bit loads | | `TF_ROCE_MAX_KB` | `512` | the largest all-gather (KiB) sent over RoCE with `COMM=roce` (TensorFold's default: 256); 512 covers the 17-32-row verify windows of concurrent requests | | `TF_ROCE_WAIT_S` | `20` | seconds a RoCE all-gather waits for the other Spark before it fails (1 to 3600); until the engine is built, each gather first meets the peer in an NCCL barrier, so a long first start (kernels compiling) does not run into it | | `TF_GLM_MULTI_LONE` | `0` | `1`: with `PARALLEL` above 1, a request decoding alone runs on the one-stream graphs (+0.6-0.9%), but its move to the pool's first rows evicts other conversations' kept prompts there (issues #12, #13); `0`: on the batched ones | | `TF_GLM_CACHE_ENTRIES` | `32` | kept prompt states at most (TensorFold's default is 8); the oldest goes past this count, however much of the pool is free. An agent request keeps 1 to 3 (issue #17); each costs ~45 MiB at start | | `MULTI_PREFILL` | `1` | prompts that arrive together are filled in one forward (each with the bits it gets alone); `0`: one after another | | `SERVED_NAME` / `PORT` / `HOST` | `GLM-5.3-Flash-EXL3` / `8888` / `0.0.0.0` | the model id in `/v1/models` and replies; where the API listens | | `TENSORFOLD_GLM_IMAGE_TOKENS` / `_VIDEO_TOKENS` / `_VIDEO_FRAMES` | `2048` / `16384` / `128` | a picture's and a clip's token caps, and a clip's frames | | `TENSORFOLD_GLM_MAX_IMAGES` / `_MAX_VIDEOS` | `50` / `4` | pictures and clips a request | | `TENSORFOLD_GLM_REQUEST_IMAGE_TOKENS` / `_REQUEST_VIDEO_TOKENS` | `16384` / `32768` | tokens a request's pictures and clips share (each still within its own cap) | | `PREPARE` / `PULL` | `auto` / `1` | `start.sh` runs `scripts/prepare.sh` when needed (`1` always, `0` never); `prepare.sh` tries the prebuilt image first (`0`: always build locally) | | `WAIT_TIMEOUT` / `STOP_TIMEOUT` | `1800` / `30` | seconds `start.sh` waits for the server, and `stop.sh` gives it to shut down | Speed settings' measured effects: [What the patches change](#what-the-patches-change). Any `TENSORFOLD_*`, `TF_GLM_*` or `TF_ROCE_*` variable is passed to both ranks (export it in `scripts/local.sh`; `.env` lines are). **Revision pins.** The checkpoint and DFlash2 are pinned to the revisions this recipe was measured with (`MODEL_REVISION`, `DFLASH2_REVISION`): both ranks serve exactly those from the local cache, and a new upstream commit changes nothing until the pin does. Set one empty to take the Hub's `main` when first downloaded. Less common settings are described in `scripts/config.sh` and `scripts/nodes.sh`: `MODEL_ID`, `DFLASH2_ID`, `TF_VERSION`, `TF_REPO`, `BASE_IMAGE` (the patches are made for TensorFold v0.6.0; after changing any of these run `scripts/prepare.sh --rebuild`), `IMAGE`, `CONTAINER_NAME`, `GHCR_IMAGE`, `HF_CACHE` (default `$HF_HOME` or `~/.cache/huggingface`), `KERNEL_CACHE`, `STATE_DIR`, `MIN_FREE_GB`, `IMAGE_FREE_GB`, `NCCL_RAILS` (`1`: one CX7 port even when both are up), `NCCL_CHANNELS` (4), `NCCL_DEBUG`, `RSYNC_OPTS`. `start.sh` also takes `HF_HUB_OFFLINE=0` (let the server reach Hugging Face; by default it serves from the local cache only). ### Thinking and sampling The checkpoint's own sampling defaults apply (temperature 1.0, top_p 0.95). Per request: - `temperature`, `top_p`, `top_k`, `min_p` and `seed` override them (`temperature: 0` decodes greedily). Without a `seed`, the sampler's key comes from the prompt, so the same request gives the same reply. - `reasoning_effort`: `"low"`, `"high"` or `"max"`, at the top level or in `chat_template_kwargs` (`"medium"` is `"high"`, `"xhigh"` is `"max"`). Without it, GLM's template uses `max`; `"none"` (or `"chat_template_kwargs": {"enable_thinking": false}`) answers without thinking. - The reasoning comes back in `reasoning_content`, the answer in `content`. A request without `max_tokens` gets 32,768 tokens for both (`MAX_TOKENS`; cut to what the window has left, never refused). An empty `content` means the model thought until `max_tokens`: give more, or use `reasoning_effort: "low"`. ### API notes - Endpoints: `/v1/chat/completions`, `/v1/completions`, `/v1/responses`, `/v1/models`, `/tokenize` and `/detokenize` (also under `/v1/`), `/health`, and Prometheus `/metrics` (TensorFold v0.6.0's request counters, latency and time-to-first-token histograms, plus `/health`'s figures as `tensorfold_health:` metrics). No Anthropic `/v1/messages`. - **Context limits:** a request whose prompt plus `max_tokens` does not fit the window is refused with HTTP 400 in OpenAI's wording, `"code": "context_length_exceeded"` and `param` naming the field (`messages` or `prompt`). - **Tool calling:** `tools` / `tool_calls`, each call streamed whole once it is written (empty deltas every 2 s meanwhile, for clients with an idle timeout; a reply that ends inside a call, at its token limit, ends with `length` and never sends that call), with arguments typed by their schema (an array as a JSON array, `null` and `const` values as such). Calls written inside the think block count when the reply ends on them, and a tool-calling step's reasoning is put back into the next request when an agent client drops it (`TF_GLM_KEEP_REASONING=0` turns that off). A past tool call whose arguments are not a JSON object is left out of the prompt with its result (and logged) instead of failing the request. - **Structured outputs:** `response_format` (`json_object` or `json_schema`) and the `guided_json` / `guided_regex` / `guided_choice` / `guided_grammar` / `structured_outputs` fields, enforced with xgrammar (after the think block). - **`/tokenize` / `/detokenize`:** vLLM's fields; a `prompt` or `messages` (rendered as the chat route does) to token ids with their `count` and `max_model_len`, and back. - Refused with HTTP 400: `logprobs: true` / `top_logprobs` (this engine returns no token probabilities) and `n` other than 1. Accepted but ignored, with no error: `logit_bias`, and the presence, frequency and repetition penalties. `priority: "background"` serves a request after the others. - Prompt reuse: a new prompt that extends a recent one token for token resumes from its kept state, and a shared system prompt's state is reused (`SHARED_PREFIX`). ## What the patches change `scripts/prepare.sh` bakes every `patches/*.patch` into the image (diffs against TensorFold v0.6.0's site-packages, applied with `patch -p0` in filename order); `start.sh` rebuilds or re-pulls the image when the patches change. | Area | Patches | Change | Effect | | --- | --- | --- | --- | | Weights | `0002-glm-dense-fp8`, `0005-glm-dense-q4` | the checkpoint's BF16 dense weights in FP8, or 4-bit with MSE-searched ranges (`DENSE`) | q4 over fp8: prose 38.9 -> 44.4 tok/s, code 44.2 -> 48.7, prefill ~1,090 -> ~1,260 tok/s | | KV cache | `0038-glm-kv-fp8` | the DSA latent cache and the indexer's pooled keys as FP8 rows (`KV=fp8`) | the 1M window with 4 requests fits | | Prompt | `0001-glm-exl3-prompt-experts`, `0004-glm-prompt-kernels`, `0009-glm-prefill-kernels`, `0020-glm-prompt-experts-order`, `0024-glm-prompt-select-rows`, `0028-glm-lean-prompt-scratch` | EXL3 expert kernels that keep a prompt chunk's rows in L2, launched in a better order; each row's input rotated once; dense attention only where the sparse pass needs it; token selection in blocks of 512 rows; smaller prompt scratch | faster prefill, less memory at 1M | | Prompt, two Sparks | `0010-glm-hc-split`, `0033-glm-prefill-overlap2`, `0017-glm-overlap-priority`, `0022-glm-overlap-normal-priority` | hyper-connection glue split by rows between the Sparks, exchanges overlapped with the next rows' work (`SPLIT`) | 50k prefill ~1,270 -> ~1,730 tok/s with 0009 and 0020; decode rounds pay ~1.5% | | Prompt, KDA | `0012-glm-kda-chunked`, `0014-glm-kda-chunked-gb10`, `0039-glm-kda-chunked-kernel` | the linear-attention layers' prompt chunks in chunked (WY) form, one CUDA kernel (`KDA_CHUNKED`) | 50k prefill 29.3 -> 26.4 s, 149k 91.1 -> 84.5 s (one start each) | | Prompt reuse | `0008-glm-prompt-grid`, `0015-glm-shared-prefix`, `0042-glm-prompt-replay` | prompt chunks and kept states on a token grid; a shared system prompt's state reused; an identical prompt resumes from its kept end state | [Performance](#performance) | | Decode | `0013-glm-decode-rounds`, `0016-glm-decode-kernels`, `0019-glm-decode-kernels2`, `0031-glm-decode-index-regs` | verify windows of up to 16 rows; faster decode matmuls, hyper-connection mixing and indexer scoring | faster decode rounds; long copy drafts (`COPY_MAX` 15: edit replies 84 -> 119 tok/s) | | Decode, memory | `0046-glm-l2-prefetch`, `0047-glm-exl3-decode-loads` | the next kernels' weights prefetched into L2 during each layer's all-gathers (`TF_GLM_L2PF`, adapted from jayleaton/glm53-tensorfold-spark's patch 0460); the routed experts' trellis as 16-byte non-coherent loads a step ahead (`TF_GLM_EXL3_LOADS`, adapted from its patch 0580) | with `TF_ROCE_MAX_KB=512`: one request's prose 48.36 -> 49.68 tok/s, code 59.54 -> 61.49 (+2.7% / +3.3%); 4 at once prose 74.8 -> 76.6, code 100.0 -> 102.7 (two starts each); the same bits | | Decode, indexer | `0043-glm-visible-pools` | a decode row's token scoring and split selection bounded to the pools it can see (TensorFold v0.6.0 bounds its one-program selection, PR #140) | the same tokens | | Link | `0006-cuda-roce-allgather`, `0052-cuda-roce-startup` | the small all-gathers as one-shot RDMA writes over RoCE (`COMM=roce`; up to 512 KiB, `TF_ROCE_MAX_KB`: code at 4 streams +1.4%); until the engine is built, each eager gather first waits for the peer in an NCCL barrier, and the RoCE kernel builds during setup (`TF_ROCE_WAIT_S`, default 20 s; errors print the proxy's counters); an idle rank 1 waiting on a socket is TensorFold v0.6.0's (#132) | 11 us a 16 KiB gather against NCCL's 45, decode +6%; an idle server holds no GPU or CPU core; a first start whose ranks drift apart while building kernels no longer fails | | Drafts | `0007-glm-copy-drafts`, `0032-glm-code-copy-drafts`, `0018-glm-noise-policies`, `0021-glm-dflash-policy-env`, `0025-glm-dflash2-ring` | copy (prompt-lookup) drafts ahead of DFlash2's (`COPY`, `COPY_CODE`); DFlash2 stop rules aware of the sampling noise (`DRAFT_POLICY`); kept prompt states' DFlash2 window with shared prefixes (the ring itself and `TF_GLM_MTP` are TensorFold v0.6.0's; the recipe sets `TF_GLM_MTP=auto`, so the MTP head is not loaded when DFlash2 drafts) | `COPY`: quote / edit replies 80.3 -> 84.4 tok/s; `COPY_CODE`: code 55.4 -> 56.2, edit 120 -> 125; `DRAFT_POLICY` over `fc5:0.3`: prose 47.2 -> 50.6 tok/s, code 51.7 -> 55.5; memory for the window | | Drafts, tooling | `0011-glm-draft-sim` | records of DFlash2's drafts for an offline simulator of stop rules (`TF_GLM_DRAFT_DUMP`, off) | how the stop rules were tuned | | Concurrent requests | `0026-glm-multi-kda`, `0027-glm-multi-dflash2`, `0029-glm-multi-dsa`, `0030-glm-multi-stream-engine`, `0035-glm-multi-rounds`, `0040-glm-parallel-deadlocks`, `0041-glm-parallel-ring-base`, `0048-glm-timing-tokens`, `0049-glm-multi-prefill` | several streams over one shared pool of per-token caches, one batched verify window a round, both ranks kept in step; prompts that arrive together filled in one forward (`MULTI_PREFILL`: 4 prose requests at once 103.4 -> 108.8 tok/s, first token 590 -> 340 ms); a request alone on the one-stream graphs (`TF_GLM_MULTI_LONE=1`, off by default since v1.3.1: +0.6-0.9%); the startup timings of verify windows on distinct tokens | 4 requests at once ([Performance](#performance)) | | Sampling | `0034-cuda-nucleus-union` | a top_p draw from both ranks' candidates together, the same draw with fewer whole-shard reads (`TENSORFOLD_NUCLEUS_UNION=1`, off by default) | opt-in | | Server | `0003-glm-vision`, `0050-glm-many-media`, `0036-glm-tool-calls`, `0051-glm-tool-history-recovery`, `0053-glm-whole-tool-calls`, `0037-cuda-tokenize`, `0023-server-effort-max`, `0044-cuda-context-errors`, `0045-cuda-metrics` | GLM's image and video processors and vision tower; up to 50 pictures and 4 clips a request in 96 MiB bodies; GLM tool calls for agent clients; a past tool call whose arguments are not a JSON object left out of the prompt with its result and logged, instead of HTTP 400 (agents replay history, so a 400 ended the conversation); each call sent whole once written, a call the reply ends inside never sent; `/tokenize` and `/detokenize`; `reasoning_effort: "max"`; the `param` field and GLM's own refusals on TensorFold v0.6.0's `context_length_exceeded` errors, and `/health`'s figures in its Prometheus `/metrics` | the API features above | ## Checks **Outputs.** Drafts only propose: every drafted token is checked against the model's own keyed sample, so drafted replies equal TensorFold's serial, one-token-at-a-time decoding (send `"draft": false` for that reference). Replies served 4 at a time equal the same requests served alone; `COMM=roce`, `SPLIT=1`, `TF_GLM_L2PF` and `TF_GLM_EXL3_LOADS` move the same bits. Three defaults are not exact against the checkpoint in bf16, for speed and the 1M window: `DENSE=q4` and `KV=fp8` are lossy (quality and the 1M needle: [Performance](#performance)), and `KDA_CHUNKED=1` is close to the serial kernel but not its bits. `DENSE=bf16 KV=bf16 KDA_CHUNKED=0` serves the checkpoint as it is, with a shorter window ([KV pool and memory](#kv-pool-and-memory)). The checks in `tools/` talk to the running server (`API_URL`, default `http://127.0.0.1:8888`; or just `PORT`), from the head or another machine (`API_URL=http://:8888 tools/needle.py`). Performance is measured with [sparkDash](https://github.com/MiaAI-Lab/sparkDash) ([Performance](#performance)). | Script | What it does | | --- | --- | | `tools/needle.py [label] [size]` | hides a passphrase in a ~195k-token prompt (the prompt comes out at ~0.8 x `size` tokens) and checks the model returns it | | `tools/toolcheck.py` | makes a tool call with an array parameter and checks it comes back as a JSON array | ## Repository layout ``` start.sh set up (first run) and start both ranks stop.sh stop them scripts/ config.sh (all settings), local.sh.example (this setup's WORKER), prepare.sh (image + checkpoint on both Sparks), nodes.sh (ssh and the RoCE link), publish-image.sh (push the image to GHCR), banner.sh (start.sh's banner) patches/ patches baked into the image tools/ checks against the running server (needle, tool calls) CHANGELOG.md what changed in each release CREDITS.md who and what this builds on LICENSE Apache License 2.0 NOTICE third-party notices (TensorFold's MIT and Apache-2.0 notices, b12x, glm53-tensorfold-spark, ShapleyMcg) ``` ## License Apache License 2.0, see [`LICENSE`](LICENSE). [`NOTICE`](NOTICE) carries the third-party notices that go with it: the files in `patches/` modify TensorFold v0.6.0, and the TensorFold code they change or quote as context stays under TensorFold's licenses (Apache 2.0 from v0.6.0, and the MIT notice of code written before it, both in `NOTICE`); parts of patches 0006 (b12x), 0036, 0046 and 0047 (glm53-tensorfold-spark) come from Apache-2.0 projects, credited there and in [`CREDITS.md`](CREDITS.md). The model files are downloaded from Hugging Face and are not part of this repository: - **The checkpoint** is under the ShapleyMcg License 1.0, an attribution-required license; its model card and `LICENSE` file have the terms. Its attribution notice: > This work includes or was produced using ShapleyMcg, created by Brandon M. Music > (https://github.com/brandonmmusic-max/shapleymcg). ShapleyMcg is licensed under the ShapleyMcg License v1.0, an > attribution-required license that grants no rights to the person known as "0xSero." Use of ShapleyMcg without > this attribution is unlicensed. - **The base model** [GLM-5.3-Flash](https://huggingface.co/zai-org/GLM-5.3-Flash) is under the license on its model card. - **The DFlash2 drafter** is under [CC BY-NC-ND 4.0](https://creativecommons.org/licenses/by-nc-nd/4.0/), non-commercial use only (commercial licensing: contact@inco.ai); `DRAFTER=mtp` serves without it. **Third-party software in the image.** The prebuilt image (and the one `scripts/prepare.sh` builds) is based on NVIDIA's PyTorch container `nvcr.io/nvidia/pytorch:26.07-py3`, redistributed as a value-added runtime image. The NVIDIA software in it is governed by the [NVIDIA Software License Agreement](https://www.nvidia.com/en-us/agreements/enterprise-software/nvidia-software-license-agreement/) and the [Product-Specific Terms for NVIDIA AI Products](https://www.nvidia.com/en-us/agreements/enterprise-software/product-specific-terms-for-ai-products/), which the container prints at every start; by pulling or running the image you accept them. The image also contains PyAV (BSD) with its FFmpeg libraries (LGPL) and xgrammar (Apache 2.0). The Apache License above covers this repository's own work only. ## Credits Built on [TensorFold](https://github.com/ashhart/TensorFold) by Ash Hart ([ashhart](https://github.com/ashhart)), [GLM-5.3-Flash](https://huggingface.co/zai-org/GLM-5.3-Flash) by Z.ai, the EXL3 quantization by [Brandon M. Music](https://huggingface.co/brandonmusic) (ShapleyMcg), the DFlash2 drafter by [IncoAI](https://huggingface.co/incoai), b12x's RoCE transport by local-inference-lab, and code from [glm53-tensorfold-spark](https://github.com/jayleaton/glm53-tensorfold-spark) by Jay Leaton (tool calling, L2 prefetch, expert loads). The full list, including the runtime stack and licenses, is in [`CREDITS.md`](CREDITS.md).
