openapi: 3.0.2 info: title: openEO API version: 1.3.0 description: |- The openEO API specification for interoperable cloud-based processing of large Earth observation datasets. **Conformance class:** `https://api.openeo.org/1.3.0` # API Principles ## Language In the specification the key words “MUST”, “MUST NOT”, “REQUIRED”, “SHALL”, “SHALL NOT”, “SHOULD”, “SHOULD NOT”, “RECOMMENDED”, “MAY”, and “OPTIONAL” in this document are to be interpreted as described in [RFC 2119](https://www.rfc-editor.org/rfc/rfc2119.html) and [RFC 8174](https://www.rfc-editor.org/rfc/rfc8174.html). ## Literal Case Unless otherwise stated the API works **case sensitive**. All names SHOULD be written in snake case, i.e. words are separated with one underscore character (`_`) and no spaces, with all letters lower-cased. Example: `hello_world`. This applies particularly to endpoints and JSON property names. HTTP header fields are generally case-insensitive according to [RFC 7230](https://www.rfc-editor.org/rfc/rfc7230.html#section-3.2) and their respective casing conventions are followed, e.g. `Content-Type` or `OpenEO-Costs`, for better readability and consistency. ## HTTP / REST This specification uses [HTTP REST](https://en.wikipedia.org/wiki/Representational_state_transfer) [Level 2](https://martinfowler.com/articles/richardsonMaturityModel.html#level2) for communication between client and back-end server. Public API implementations MUST be available via HTTPS only. Endpoints are made use meaningful HTTP verbs (e.g. GET, POST, PUT, PATCH, DELETE) whenever technically possible. If there is a need to transfer big chunks of data for a GET requests to the back-end, POST requests MAY be used as a replacement as they support to send data via request body. Unless otherwise stated, PATCH requests are only defined to work on direct (first level) children of the full JSON object. Therefore, changing a property on a deeper level of the full JSON object always requires sending the whole JSON object defined by the first-level property. Naming rules of the API endpoints follow the REST principles. Therefore, endpoints are centered around resources. Resource identifiers MUST be named with a noun in plural form except for single actions that can not be modelled with the regular HTTP verbs. Single actions MUST be single endpoints with a single HTTP verb (POST is RECOMMENDED) and no other endpoints beneath it. The openEO API makes use of [HTTP Content Negotiation](https://www.rfc-editor.org/rfc/rfc9110.html#name-content-negotiation), including, but not limited to, the request headers `Accept`, `Accept-Charset` and `Accept-Language`. ### JSON The API uses JSON for request and response bodies whenever feasible. Services use JSON as the default encoding. Other encodings can be requested using HTTP Content Negotiation ([`Accept` header](https://www.rfc-editor.org/rfc/rfc9110.html#name-accept)). Clients and servers MUST NOT rely on the order in which properties appear in JSON. To keep the response size small, lists of resources (e.g. the list of batch jobs) usually should not include nested JSON objects, if this information can be requested from the individual resource endpoints (e.g. the metadata for a single batch job). ### Charset If not negotiated otherwise with HTTP Content Negotiation ([`Accept-Charset` header](https://www.rfc-editor.org/rfc/rfc9110.html#name-accept-charset)), services use [UTF-8](https://en.wikipedia.org/wiki/UTF-8) as the default charset. ## Web Linking The API is designed in a way that for most resources, such as collections and processes, a set of links can be added. These can be alternate representations such as data discovery via OGC WCS or OGC CSW, references to a license, references to actual raw data for downloading, detailed information about pre-processing and more. Clients should allow users to follow the links. Whenever links are utilized in the API, the description explains which relation (`rel` property) types are commonly used. A [list of standardized link relations types is provided by IANA](https://www.iana.org/assignments/link-relations/link-relations.xhtml) and the API tries to align whenever feasible. Some very common relation types - usually not mentioned explicitly in the description of `links` fields - are: 1. `self`: Refers to the location that the resource can be (permanently) found online. This is particularly useful when the data is made available offline, so that the downstream user knows the source of the data. 2. `alternate`: An alternative representation of the resource, may it be another metadata standard the data is available in or simply a human-readable version in HTML or PDF. 3. `about`: A resource that is related to or further explains the resource, e.g. a user guide. 4. `canonical`: This relation type usually points to a publicly accessible and more long-lived URL for a resource that otherwise often requires (Bearer) authentication with a short-lived token. This way the exposed resources can be used by non-openEO clients without additional authentication steps. For example, a shared user-defined process or batch job results could be exposed via a canonical link. If a URL should be publicly available to everyone, it can simply a user-specific URL, e.g. `https://openeo.example/processes/john_doe/ndvi`. For resources that should only be accessible to a certain group of user, a signed URL could be given, e.g. `https://openeo.example/processes/81zjh1tc2pt52gbx/ndvi`. Generally, it is RECOMMENDED adding descriptive titles (property `title`) and media type information (property `type`) for a better user experience. ## Error Handling The success of requests MUST be indicated using [HTTP status codes](https://www.rfc-editor.org/rfc/rfc7231.html#section-6) according to [RFC 7231](https://www.rfc-editor.org/rfc/rfc7231.html). If the API responds with a status code between 100 and 399 the back-end indicates that the request has been handled successfully. In general an error is communicated with a status code between 400 and 599. Client errors are defined as a client passing invalid data to the service and the service *correctly* rejecting that data. Examples include invalid credentials, incorrect parameters, unknown versions, or similar. These are generally "4xx" HTTP error codes and are the result of a client passing incorrect or invalid data. Client errors do *not* contribute to overall API availability. Server errors are defined as the server failing to correctly return in response to a valid client request. These are generally "5xx" HTTP error codes. Server errors *do* contribute to the overall API availability. Calls that fail due to rate limiting or quota failures MUST NOT count as server errors. ### JSON error object A JSON error object SHOULD be sent with all responses that have a status code between 400 and 599. ``` json { "id": "936DA01F-9ABD-4D9D-80C7-02AF85C822A8", "code": "SampleError", "message": "A sample error message.", "url": "https://openeo.example/docs/errors/SampleError" } ``` Sending `code` and `message` is REQUIRED. * A back-end MAY add a free-form `id` (unique identifier) to the error response to be able to log and track errors with further non-disclosable details. * The `code` is either one of the [standardized textual openEO error codes](errors.json) or a proprietary error code. * The `message` explains the reason the server is rejecting the request. For "4xx" error codes the message explains how the client needs to modify the request. By default, the message MUST be in English. Content Negotiation is used to localize the error messages: If an `Accept-Language` header is sent by the client and a translation is available, the message should be translated accordingly, and the `Content-Language` header must be present in the response. See "[How to localize your API](http://apiux.com/2013/04/25/how-to-localize-your-api/)" for more information. * `url` is an OPTIONAL attribute and contains a link to a resource that is explaining the error and potential solutions in-depth. ### Standardized status codes The openEO API usually uses the following HTTP status codes for successful requests: - **200 OK**: Indicates a successful request **with** a response body being sent. - **201 Created** Indicates a successful request that successfully created a new resource. Sends a `Location` header to the newly created resource **without** a response body. - **202 Accepted** Indicates a successful request that successfully queued the creation of a new resource, but it has not been created yet. The response is sent **without** a response body. - **204 No Content**: Indicates a successful request **without** a response body being sent. The openEO API reuses commonly used HTTP status codes for failed requests: - **400 Bad Request**: The back-end responds with this error code whenever the error has its origin on client side and no other HTTP status code in the 400 range is suitable. - **401 Unauthorized**: The client did not provide any authentication details for a resource requiring authentication or the provided authentication details are not correct. - **403 Forbidden**: The client did provide correct authentication details, but the privileges/permissions of the provided credentials do not allow requesting the resource. - **404 Not Found**: The resource specified by the path does not exist. One of the resources belonging to the specified identifiers are not available at the back-end. *Note:* Unsupported endpoints MAY also return an HTTP status code 501. - **500 Internal Server Error**: The error has its origin on server side and no other status code in the 500 range is suitable. - **501 Not Implemented**: The requested endpoint is specified by the openEO API, but is not implemented (yet) by the back-end. *Note:* Unsupported endpoints MAY also return HTTP status code 404. If a HTTP status code in the 400 range is returned, the client SHOULD modify the request and repeat the request. For HTTP status code in the 500 range, the client MAY repeat the same request later. All HTTP status codes defined in RFC 7231 in the 400 and 500 ranges can be used as openEO error code in addition to the most used status codes mentioned here. Responding with openEO error codes 400 and 500 SHOULD be avoided in favor of any more specific standardized or proprietary openEO error code. ## Temporal data Date, time, time intervals, and durations are formatted based on [ISO 8601](https://www.iso.org/iso-8601-date-and-time-format.html) or its profile [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) whenever there is an appropriate encoding available in the standard. All temporal data are specified based on the Gregorian calendar. # Authentication The openEO API offers two forms of authentication by default: * OpenID Connect (recommended) at `GET /credentials/oidc` * Basic at `GET /credentials/basic` After authentication with any of the methods listed above, the tokens obtained during the authentication workflows can be sent to protected endpoints in subsequent requests. Further authentication methods MAY be added by back-ends. **Note:** Although it is possible to request several public endpoints for capabilities and discovery that do not require authorization, it is RECOMMENDED that clients (re-)request the public endpoints that support Bearer authentication with the Bearer token once available to also retrieve any private data that is made available specifically for the authenticated user. This may require that clients clear any cached data they retrieved from public endpoints before. # Cross-Origin Resource Sharing (CORS) > Cross-origin resource sharing (CORS) is a mechanism that allows restricted resources [...] on a web page to be requested from another domain outside the domain from which the first resource was served. [...] > CORS defines a way in which a browser and server can interact to determine whether it is safe to allow the cross-origin request. This allows for more freedom and functionality than purely same-origin requests, but is more secure than simply allowing all cross-origin requests. Source: [https://en.wikipedia.org/wiki/Cross-origin_resource_sharing](https://en.wikipedia.org/wiki/Cross-origin_resource_sharing) openEO-based back-ends are usually hosted on a different domain / host than the client that is requesting data from the back-end. Therefore, most requests to the back-end are blocked by all modern browsers. This leads to the problem that the JavaScript library and any browser-based application can not access back-ends. Therefore, all back-end providers SHOULD support CORS to enable browser-based applications to access back-ends. [CORS is a recommendation of the W3C organization](https://www.w3.org/TR/2020/SPSD-cors-20200602/). The following chapters explain how back-end providers can implement CORS support. **Tip**: Most servers can send the required headers and the responses to the OPTIONS requests automatically for all endpoints. Otherwise, a proxy server may be used to add the headers and OPTIONS responses. ## CORS headers The following headers MUST be included with every response: | Name | Description | Example | | -------------------------------- | ------------------------------------------------------------ | ------- | | Access-Control-Allow-Origin | Allowed origin for the request, including protocol, host and port or `*` for all origins. Returning the value `*` to allow requests from browser-based implementations is RECOMMENDED. | `*` | | Access-Control-Expose-Headers | Some endpoints require sending additional HTTP response headers such as `OpenEO-Identifier` and `Location`. To make these headers available to browser-based clients, they MUST be white-listed with this CORS header. The following HTTP headers are white-listed by browsers and MUST NOT be included: `Cache-Control`, `Content-Language`, `Content-Length`, `Content-Type`, `Expires`, `Last-Modified` and `Pragma`. At least the following headers MUST be listed in this version of the openEO API: `Link`, `Location`, `OpenEO-Costs` and `OpenEO-Identifier`. | `Link, Location, OpenEO-Costs, OpenEO-Identifier` | ### Example request and response Request: ```http POST /api/v1/jobs HTTP/1.1 Host: openeo.example Origin: https://company.example:8080 Authorization: Bearer basic//ZXhhbXBsZTpleGFtcGxl ``` Response: ```http HTTP/1.1 201 Created Access-Control-Allow-Origin: * Access-Control-Expose-Headers: Location, OpenEO-Identifier, OpenEO-Costs, Link Content-Type: application/json Location: https://openeo.example/api/v1/jobs/abc123 OpenEO-Identifier: abc123 ``` ## OPTIONS method All endpoints defined in the API specification must additionally respond to the `OPTIONS` HTTP method. This is a response for the preflight requests made by web browsers before sending the actual request (e.g. `POST /jobs`). It needs to respond with a status code of `204` and no response body. **In addition** to the HTTP headers shown in the table above, the following HTTP headers MUST be included with every response to an `OPTIONS` request: | Name | Description | Example | | -------------------------------- | ------------------------------------------------------------ | ------- | | Access-Control-Allow-Headers | Comma-separated list of HTTP headers allowed to be sent with the actual (non-preflight) request. MUST contain at least `Authorization` if any kind of authorization is implemented by the back-end. | `Authorization, Content-Type` | | Access-Control-Allow-Methods | Comma-separated list of HTTP methods allowed to be requested. Back-ends MUST list all implemented HTTP methods for the endpoint. | `OPTIONS, GET, POST, PATCH, PUT, DELETE` | | Content-Type | SHOULD return the content type delivered by the request that the permission is requested for. | `application/json` | ### Example request and response Request: ```http OPTIONS /api/v1/jobs HTTP/1.1 Host: openeo.example Origin: https://company.example:8080 Access-Control-Request-Method: POST Access-Control-Request-Headers: Authorization, Content-Type ``` Note that the `Access-Control-Request-*` headers are automatically attached to the requests by the browsers. Response: ```http HTTP/1.1 204 No Content Access-Control-Allow-Origin: * Access-Control-Allow-Methods: OPTIONS, GET, POST, PATCH, PUT, DELETE Access-Control-Allow-Headers: Authorization, Content-Type Access-Control-Expose-Headers: Location, OpenEO-Identifier, OpenEO-Costs, Link Content-Type: application/json ``` # Processes A **process** is an operation that performs a specific task on a set of parameters and returns a result. An example is computing a statistical operation, such as mean or median, on selected EO data. A process is similar to a function or method in programming languages. In openEO, processes are used to build a chain of processes ([process graph](#section/Processes/Process-Graphs)), which can be applied to EO data to derive your own findings from the data. A **predefined process** is a process provided by the *back-end*. There is a set of predefined processes by openEO to improve interoperability between back-ends. Back-ends SHOULD follow these specifications whenever possible. Not all processes need to be implemented by all back-ends. See the **[process reference](https://processes.openeo.org)** for predefined processes. A **user-defined process** is a process defined by the *user*. It can directly be part of another process graph or be stored as custom process on a back-end. Internally, it is a *process graph* with a variety of additional metadata. A **process graph** chains specific process calls from the set of predefined and user-defined processes together. A process graph itself can be stored as a (user-defined) process again. Similarly to scripts in the context of programming, process graphs organize and automate the execution of one or more processes that could alternatively be executed individually. In a process graph, processes need to be specific, i.e. concrete values or "placeholders" for input parameters need to be specified. These values can be scalars, arrays, objects, references to parameters or previous computations or other process graphs. ## Defining Processes Back-ends and users MAY define new proprietary processes for their domain. **Back-end providers** MUST follow the schema for predefined processes as in [`GET /processes`](#operation/list-processes) to define new processes. This includes: * Choosing a intuitive process id, consisting of only letters (a-z), numbers and underscores. It MUST be unique across the predefined processes. * Defining the parameters and their exact (JSON) schemes. * Specifying the return value of a process also with a (JSON) schema. * Providing examples or compliance tests. * Trying to make the process universally usable so that other back-end providers or openEO can adopt it. **Users** MUST follow the schema for user-defined processes as in [`GET /process_graphs/{process_graph_id}`](#operation/describe-custom-process) to define new processes. This includes: * Choosing a intuitive name as process id, consisting of only letters (a-z), numbers and underscores. It MUST be unique per user across the user-defined processes. * Defining the algorithm as a process graph. * Optionally, specifying the additional metadata for processes. If new process are potentially useful for other back-ends the openEO consortium is happily accepting [pull requests](https://github.com/Open-EO/openeo-processes/pulls) to include them in the list of predefined processes. ### Schemas Each process parameter and the return values of a process define a schema that the value MUST comply to. The schemas are based on [JSON Schema draft-07](http://json-schema.org/). Multiple custom keywords have been defined: * `subtype` for more fine-grained data-types than JSON Schema supports. * `dimensions` to further define the dimension types required if the `subtype` is `datacube`. * `parameters` to specify the parameters of a process graph if the `subtype` is `process-graph`. * `returns` to describe the return value of a process graph if the `subtype` is `process-graph`. ### Subtypes JSON Schema allows to specify only a small set of native data types (string, boolean, number, integer, array, object, null). To support more fine grained data types, a custom [JSON Schema keyword](https://json-schema.org/draft-07/json-schema-core.html#rfc.section.6.4) has been defined: `subtype`. It works similarly as the JSON Schema keyword [`format`](https://json-schema.org/draft-07/json-schema-validation.html#rfc.section.7) and standardizes a number of openEO related data types that extend the native data types, for example: `bounding-box` (object with at least `west`, `south`, `east` and `north` properties), `date-time` (string representation of date and time following RFC 3339), `datacube` (a datacube with dimensions), etc. The subtypes should be re-used in process schema definitions whenever suitable. If a general data type such as `string` or `number` is used in a schema, all subtypes with the same parent data type can be passed, too. Clients should offer make passing subtypes as easy as passing a general data type. For example, a parameter accepting strings must also allow passing a string with subtype `date` and thus clients should encourage this by also providing a date-picker. A list of predefined subtypes is available as JSON Schema in [openeo-processes](https://github.com/Open-EO/openeo-processes). ## Process Graphs As defined above, a **process graph** is a chain of processes with explicit values for their parameters. Technically, a process graph is defined to be a graph of connected processes with exactly one node returning the final result: ``` := { "": , ... } ``` `` is a unique key within the process graph that is used to reference (the return value of) this process in arguments of other processes. The identifier is unique only strictly within itself, excluding any parent and child process graphs. Process node identifiers are also strictly scoped and can not be referenced from child or parent process graphs. Circular references are not allowed. Note: We provide a non-binding [JSON Schema for basic process graph validation](assets/pg-schema.json). ### Processes (Process Nodes) A single node in a process graph (i.e. a specific instance of a process) is defined as follows: ``` := { "process_id": , "namespace": / null, "description": , "arguments": , "result": true / false } ``` A process node MUST always contain key-value-pairs named `process_id` and `arguments`. It MAY contain a `description`. `process_id` MUST be a valid process ID in the `namespace` given. Clients SHOULD warn the user if a user-defined process is added with the same identifier as one of the predefined process. In the following, "end node" (also known as "leaf node") defines a node that is not referenced by any other node in the same process graph. The "root process graph" is the outermost process graph, which is not part of any other process graph. A "result node" is a node (often an end node, but that's not required) that defines the return value of the process graph and has the `result` flag set to `true`. Exactly one of the nodes in a map of processes MUST have the `result` flag set to `true`, all the other nodes can omit it as the default value is `false`. Each child process graph MUST specify its own result node. The root process graph MUST also specify a result node although not strictly needed in all use cases. Having a result node is important as multiple end nodes are possible and in many use cases it is important to identify a specific return value for the process graph that is passed to other processes. The result node is not necessarily an end node. ### Arguments A process can have an arbitrary number of arguments. Their name and value are specified in the process specification as an object of key-value pairs: ``` := { "": } ``` **Notes:** - The specified data types are the native data types supported by JSON, except for `ResultReference`, `UserDefinedProcess` and `ParameterReference`. - Objects are not allowed to have keys with the following reserved names: * `from_node`, except for objects of type `ResultReference` * `process_graph`, except for objects of type `UserDefinedProcess` * `from_parameter`, except for objects of type `ParameterReference` - Arrays and objects can also contain a `ResultReference`, a `UserDefinedProcess` or a `ParameterReference`. So back-ends must *fully* traverse the process graphs, including all children. ### Accessing results of other process nodes A value of type `` is an object with a key `from_node` and a `` as corresponding value: ``` := { "from_node": "" } ``` This tells the back-end that the process expects the result (i.e. the return value) from another process node to be passed as argument. The `` is strictly scoped and can only reference nodes from within the same process graph, not child or parent process graphs. ### Child processes Some processes can run child processes, which is similar to the concept that other programming languages call [callbacks](https://en.wikipedia.org/wiki/Callback_(computer_programming)) or lambda functions. Each child process is simply a user-defined process again and can in theory be arbritarily complex. A very simple example would be to calculate the absolute value of each pixel in a data cube. This can be achieved in openEO by using the `apply` process which gets the `absolute` process passed as child process. In this example, the "child" processes consists of a single process `absolute`, but it can also be a more complex computation such as an NDVI or a prediciton based on a machine learning model. **Example**: A `` argument MUST at least consist of an object with a key `process_graph`. Optionally, it can also be described with the same additional properties available for predefined processes such as an id, parameters, return values etc. When embedded in a process graph, these additional properties of a user-defined process are usually not used, except for validation purposes. ``` := { "process_graph": , ... } ``` ### Accessing process parameters A "parent" process that works with a child process can make so called *process graph parameters* available to the "child" logic. Processes in the "child" process graph can access these parameters by passing a `ParameterReference` object as argument. It is an object with key `from_parameter` specifying the name of the process graph parameter: ``` := { "from_parameter": "" } ``` The parameter names made available for `` are defined and passed to the process graph by one of the parent entities. The parent could be a process (such as `apply` or `reduce_dimension`) or something else that executes a process graph (a secondary web service for example). If the parent is a process, the parameter are defined in the [`parameters` property](#section/Processes/Defining-Processes) of the corresponding JSON Schema. In case of the example given above, the parameter `process` in the process [`apply`](https://processes.openeo.org/#apply) defines two process graph parameters: `x` (the value of each pixel that will be processed) and `context` (additional data passed through from the user). The process `absolute` expects an argument with the same name `x`. The process graph for the example would look as follows: ``` { "process_id": "apply", "arguments": { "data": {"from_node": "loadcollection1"} "process": { "process_graph": { "abs1": { "process_id": "absolute", "arguments": { "x": {"from_parameter": "x"} }, "result": true } } } } } ``` `loadcollection1` would be a result from another process, which is not part of this example. **Important:** `` is less strictly scoped than ``. `` can be any parameter from the process graph or any of its parents. The value for the parameter MUST be resolved as follows: 1. In general the most specific parameter value is used. This means the parameter value is resolved starting from the current scope and then checking each parent for a suitable parameter value until a parameter values is found or the "root" process graph has been reached. 2. In case a parameter value is not available, the most unspecific default value from the process graph parameter definitions are used. For example, if default values are available for the root process graph and all children, the default value from the root process graph is used. 3. If no default values are available either, the error `ProcessParameterMissing` must be thrown. ### Full example for an EVI computation Deriving minimum EVI (Enhanced Vegetation Index) measurements over pixel time series of Sentinel-2 imagery. The root process graph in blue, child process graphs in yellow: ![Graph with processing instructions](assets/pg-evi-example.png) The process graph for the algorithm: [pg-evi-example.json](assets/pg-evi-example.json) ## Data Processing Processes can run in three different ways: 1. Results can be pre-computed by creating a ***batch job***. They are submitted to the back-end's processing system, but will remain inactive until explicitly put into the processing queue. They will run only once and store results after execution. Results can be downloaded. Batch jobs are typically time consuming and user interaction is not possible although log files are generated for them. This is the only mode that allows to get an estimate about time, volume and costs beforehand. 2. A more dynamic way of processing and accessing data is to create a **secondary web service**. They allow web-based access using different protocols such as [OGC WMS](http://www.opengeospatial.org/standards/wms), [OGC WCS](http://www.opengeospatial.org/standards/wcs), [OGC API - Features](https://www.ogc.org/standards/ogcapi-features) or [XYZ tiles](https://wiki.openstreetmap.org/wiki/Slippy_map_tilenames). Some protocols such as the OGC WMS or XYZ tiles allow users to change the viewing extent or level of detail (zoom level). Therefore, computations often run *on demand* so that the requested data is calculated during the request. Back-ends should make sure to cache processed data to avoid additional/high costs and reduce waiting times for the user. 3. Processes can also be executed **on-demand** (i.e. synchronously). Results are delivered with the request itself and no job is created. Only lightweight computations, for example previews, should be executed using this approach as timeouts are to be expected for [long-polling HTTP requests](https://www.pubnub.com/guides/long-polling/). ### Validation Process graph validation is a quite complex task. There's a [JSON schema](assets/pg-schema.json) for basic process graph validation. It checks the general structure of a process graph, but only checking against the schema is not fully validating a process graph. Note that this JSON Schema is probably good enough for a first version, but should be revised and improved for production. There are further steps to do: 1. Validate whether there's exactly one `result: true` per process graph. 2. Check whether the process names that are referenced in the field `process_id` are actually available in the corresponding `namespace`. 3. Validate all arguments for each process against the JSON schemas that are specified in the corresponding process specifications. 4. Check whether the values specified for `from_node` have a corresponding node in the same process graph. 5. Validate whether the return value and the arguments requesting a return value with `from_node` are compatible. 7. Check the content of arrays and objects. These could include parameter and result references (`from_node`, `from_parameter` etc.). ### Execution To process the process graph on the back-end you need to go through all nodes/processes in the list and set for each node to which node it passes data and from which it expects data. In another iteration the back-end can find all start nodes for processing by checking for zero dependencies. You can now start and execute the start nodes (in parallel, if possible). Results can be passed to the nodes that were identified beforehand. For each node that depends on multiple inputs you need to check whether all dependencies have already finished and only execute once the last dependency is ready. Please be aware that the result node (`result` set to `true`) is not necessarily the last node that is executed. The author of the process graph may choose to set a non-end node to the result node! contact: name: openEO Project Steering Committee url: 'https://openeo.org' email: openeo.psc@uni-muenster.de license: name: Apache 2.0 url: 'http://www.apache.org/licenses/LICENSE-2.0.html' externalDocs: description: openEO Documentation url: 'https://openeo.org/documentation/1.0/' tags: - name: Capabilities description: General information about the API implementation and other supported capabilities provided by the back-end. - name: Account Management description: |- The following endpoints handle user profiles, accounting and authentication. See also [Authentication](#section/Authentication). In general, the openEO API only defines a minimum subset of user management and accounting functionality. It allows to * [authenticate and authorize](http://www.differencebetween.net/technology/difference-between-authentication-and-authorization/) a user, which may include [user registration with OpenID Connect](http://openid.net/specs/openid-connect-registration-1_0.html), * handle storage space limits (disk quota), * manage billing, which includes to * query the credit a user has available, * estimate costs for certain operations (data processing and downloading), * get information about produced costs, * limit costs of certain operations. Therefore, the API leaves some aspects open that have to be handled by the back-ends separately, including * credentials recovery, e.g. retrieving a forgotten password * user data management, e.g. changing the users payment details or email address * payments, i.e. topping up credits for pre-paid services or paying for post-paid services * other accounting related tasks, e.g. creating invoices, * user registration (except for [user registration with OpenID Connect](http://openid.net/specs/openid-connect-registration-1_0.html)). - name: EO Data Discovery description: |- These endpoints allow to list the collections that are available at the back-end and can be used as data cubes for data processing. ## STAC For data discovery of Earth Observation Collections at the back-ends, openEO strives for compatibility with the specifications [SpatioTemporal Asset Catalog (STAC)](https://stacspec.org/) and [OGC API - Features - Part 1: Core](http://docs.opengeospatial.org/is/17-069r3/17-069r3.html) as far as possible. Implementing the data discovery endpoints of openEO also produces valid STAC API 1.x and OGC API - Features 1.x responses, including ([partial](#provide-data-for-download)) compatibility with their APIs. The data discovery endpoints `GET /collections` and `GET /collections/{collection_id}` are compatible with OGC API - Features and STAC. Both specifications define additional endpoints that need to be implemented to be fully compatible. The additional endpoints can easily be integrated into an openEO API implementation. A rough list of actions for compatibility is available below, but please refer to their specifications to find out the full details. **Important:** [STAC specification](https://github.com/radiantearth/stac-spec) and [STAC API](https://github.com/radiantearth/stac-api-spec) are different specifications and have different version numbers. The openEO API allows for the - STAC versions 1.x.x (RECOMMENDED) and 0.9.x (DEPRECATED), and - STAC API versions 1.x.x (RECOMMENDED) and 0.9.x (DEPRECATED). ### Content Extensions STAC has several [extensions](https://stac-extensions.github.io) that can be used to better describe your data. Clients and server are not required to implement all of them, so be aware that some clients may not be able to read all your metadata. Some commonly used extensions that are relevant for datasets exposed through the openEO API are: - [Classification extension](https://github.com/stac-extensions/classification) - [Data Cube extension](https://github.com/stac-extensions/datacube) (part of the openEO API) - [EO (Electro-Optical) extension](https://github.com/stac-extensions/eo) - [Processing extension](https://github.com/stac-extensions/processing) - [Projection extension](https://github.com/stac-extensions/projection) - [Raster extension](https://github.com/stac-extensions/raster) - [SAR extension](https://github.com/stac-extensions/sar) - [Satellite extension](https://github.com/stac-extensions/sat) - [Scientific Citation extension](https://github.com/stac-extensions/scientific) ### Provide data for download If you'd like to provide your data for download in addition to offering the cloud processing service, you can implement the full STAC API. Therefore, you can implement the endpoints `GET /collections/{collection_id}/items` and `GET /collections/{collection_id}/items/{feature_id}` to support retrieval of individual items. To benefit from the STAC ecosystem and allow searching for items you can also implement `POST /search` and `GET /search`. Further information can be found in the [STAC API repository](https://github.com/radiantearth/stac-api-spec). ### API Extensions STAC API has several [extensions](https://stac-api-extensions.github.io) that can be implemented on top of the openEO API to enrich the API functionality, e.g. for searching. - name: Process Discovery description: |- The process discovery endpoints provide details about the predefined processes that are available at the back-end. To list user-defined processes see '[User-Defined Processes](#tag/User-Defined-Processes)'. - name: User-Defined Processes description: These endpoints allow to store and manage user-defined processes with their process graphs at the back-end. - name: Data Processing description: Organizes and manages data processing on the back-end, either as synchronous on-demand computation or batch jobs. - name: Batch Jobs description: Management of batch processing tasks (jobs) and their results. - name: Secondary Services description: On-demand access to data using other web service protocols. - name: File Storage description: Management of user-uploaded assets and processed data. servers: - url: 'https://openeo.example/api/{version}' description: >- The URL of the API MAY freely be chosen by the back-end providers. The path, including API versioning, is a *recommendation* only. Nevertheless, all servers MUST support HTTPS as the authentication methods are not secure with HTTP only! variables: version: default: v1 description: |- API versioning is RECOMMENDED. As the openEO API is following [SemVer](https://semver.org/) only the **major** part of the version numbers SHOULD be used for API versioning in the URL. To make clear that it is a version number, it is RECOMMENDED to add the prefix `v`. Example: API version `1.2.3` is recommended to use `v1`. The reason to only consider the major part is that backward-incompatible changes are introduced by major changes only. All changes from minor and patch releases can usually be integrated without breakages and thus a change in the URL is not really needed. The version number in the URL MUST not be used by the clients to detect the version number of the API. Use the version number returned in the property `api_version` from `GET /` instead. paths: /: get: summary: Information about the back-end operationId: capabilities description: >- Lists general information about the back-end, including which version and endpoints of the openEO API are supported. May also include billing information. tags: - Capabilities security: - {} responses: '200': description: |- Information about the API version and supported endpoints / features. This endpoint MUST always be available for the API to be valid. content: application/json: schema: title: Capabilities type: object required: - id - title - description - api_version - backend_version - stac_version - conformsTo - type - endpoints - links properties: api_version: type: string description: >- Version number of the openEO API specification the back-end implements. enum: - 1.3.0 backend_version: type: string description: >- Version number of the back-end implementation. Every change on back-end side MUST cause a change of the version number. example: 1.1.2 stac_version: $ref: '#/components/schemas/stac_version' type: type: string enum: - Catalog example: Catalog id: type: string description: >- Identifier for the service. This field originates from STAC and is used as unique identifier for the STAC catalog available at `/collections`. example: cool-eo-cloud title: type: string description: The name of the service. example: Example Cloud Corp. description: type: string format: commonmark description: >- A description of the service, which allows the service provider to introduce the user to its service. [CommonMark 0.29](http://commonmark.org/) syntax MAY be used for rich text representation. example: |- This service is provided to you by [Example Cloud Corp.](https://cloud.example). It implements the full openEO API and allows to process a range of 999 EO data sets, including * Sentinel 1/2/3 and 5 * Landsat 7/8 A free plan is available to test the service. For further information please contact our customer service at [support@cloud.example](mailto:support@cloud.example). conformsTo: $ref: '#/components/schemas/conformsTo' production: $ref: '#/components/schemas/production' endpoints: type: array description: >- Lists all supported endpoints. Supported are all endpoints, which are implemented, return usually a 2XX or 3XX HTTP status code and are fully compatible to the API specification. An entry for this endpoint (path `/` with method `GET`) SHOULD NOT be listed. Each path MUST only be listed once in the array. items: title: Endpoint type: object required: - path - methods properties: path: description: >- Path to the endpoint, relative to the URL of this endpoint. In general the paths MUST follow the paths specified in the openAPI specification as closely as possible. Therefore, paths MUST be prepended with a leading slash, but MUST NOT contain a trailing slash. Variables in the paths MUST be placed in curly braces and follow the parameter names in the openAPI specification, e.g. `{job_id}`. type: string methods: description: >- Supported HTTP verbs in uppercase. It is OPTIONAL to list `OPTIONS` as method (see the [CORS section](#section/Cross-Origin-Resource-Sharing-(CORS))). type: array items: type: string enum: - GET - POST - PATCH - PUT - DELETE - OPTIONS example: - path: /collections methods: - GET - path: '/collections/{collection_id}' methods: - GET - path: /processes methods: - GET - path: /jobs methods: - GET - POST - path: '/jobs/{job_id}' methods: - GET - DELETE - PATCH billing: title: Billing description: >- Billing related data, e.g. the currency used or available plans to process jobs. This property MUST be specified if the back-end uses any billing related API functionalities, e.g. budgeting or estimates. The absence of this property does not mean the back-end is necessarily free to use for all. Providers may choose to bill users outside of the API, e.g. with a monthly fee that is not depending on individual API interactions. type: object required: - currency properties: currency: description: >- The currency the back-end is billing in. The currency MUST be either a valid currency code as defined in ISO-4217 or a back-end specific unit that is used for billing such as credits, tiles or CPU hours. If set to `null`, budget and costs are not supported by the back-end and users can not be charged. type: string nullable: true example: USD default_plan: type: string description: |- Name of the plan the back-end uses for billing in case 1. the user has not subscribed to a specific plan (see `default_plan` in `GET /me`) and 2. also did not provide a specific plan with the processing request. If a free plan is available at the back-end, it is probably most useful to provide this as the back-end wide default plan and override it with paid plans through the user-specific default plan in `GET /me`. Otherwise, users that have not set up payment yet MAY receive an error for each processing requests where they did not provide a free plan specifically. example: free plans: description: Array of plans type: array items: title: Billing Plan type: object required: - name - description - paid properties: name: type: string description: >- Name of the plan. It MUST be accepted in a *case insensitive* manner throughout the API. example: free description: type: string format: commonmark description: >- A description that gives a rough overview over the plan. [CommonMark 0.29](http://commonmark.org/) syntax MAY be used for rich text representation. example: Free plan for testing. paid: type: boolean description: >- Indicates whether the plan is a paid plan (`true`) or a free plan (`false`). url: type: string description: >- URL to a web page with more details about the plan. format: uri example: 'https://cloud.example/plans/free-plan' example: - name: free description: >- Free plan. Calculates one tile per second and a maximum amount of 100 tiles per hour. url: 'https://cloud.example/plans/free-plan' paid: false - name: premium description: >- Premium plan. Calculates unlimited tiles and each calculated tile costs 0.003 USD. url: 'https://cloud.example/plans/premium-plan' paid: true links: description: |- Links related to this service, e.g. the homepage of the service provider or the terms of service. It is highly RECOMMENDED to provide links with the following `rel` (relation) types: 1. `version-history`: A link back to the Well-Known URL (including `/.well-known/openeo`, see the corresponding endpoint for details) to allow clients to work on the most recent version. 2. `terms-of-service`: A link to the terms of service. If a back-end provides a link to the terms of service, the clients MUST provide a way to read the terms of service and only connect to the back-end after the user agreed to them. The user interface MUST be designed in a way that the terms of service are not agreed to by default, i.e. the user MUST explicitly agree to them. 3. `privacy-policy`: A link to the privacy policy (GDPR). If a back-end provides a link to a privacy policy, the clients MUST provide a way to read the privacy policy and only connect to the back-end after the user agreed to them. The user interface MUST be designed in a way that the privacy policy is not agreed to by default, i.e. the user MUST explicitly agree to them. 4. `service-desc` or `service-doc`: A link to the API definition. Use `service-desc` for machine-readable API definition and `service-doc` for human-readable API definition. Required if full OGC API compatibility is desired. 5. `conformance`: A link to the Conformance declaration (see `/conformance`). Required if full OGC API compatibility is desired. 6. `data`: A link to the collections (see `/collections`). Required if full OGC API compatibility is desired. 7. `create-form`: A link to a user registration page. 8. `recovery-form`: A link to a page where a user can recover a user account (e.g. to reset the password or send a reminder about the username to the user's email account). 9. `web-editor`: A link to an openEO Web Editor instance. This allows clients to open a Web Editor for other tasks. It may be accompanied with a `version` flag in the link to allow feature-detection for certain Web Editor functionalities. For additional relation types see also the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). type: array items: $ref: '#/components/schemas/link' example: - href: 'https://cloud.example' rel: about type: text/html title: Homepage of the service provider - href: 'https://cloud.example/tos' rel: terms-of-service type: text/html title: Terms of Service - href: 'https://cloud.example/privacy' rel: privacy-policy type: text/html title: Privacy Policy - href: 'https://cloud.example/register' rel: create-form type: text/html title: User Registration - href: 'https://cloud.example/lost-password' rel: recovery-form type: text/html title: Reset Password - href: 'https://cloud.example/.well-known/openeo' rel: version-history type: application/json title: List of supported openEO versions - href: 'https://cloud.example/api/v1/conformance' rel: conformance type: application/json title: OGC Conformance Classes - href: 'https://cloud.example/api/v1/collections' rel: data type: application/json title: List of Datasets - href: 'https://editor.openeo.org' rel: web-editor type: text/html title: openEO Web Editor version: '0.14.0' 4XX: $ref: '#/components/responses/client_error' 5XX: $ref: '#/components/responses/server_error' /.well-known/openeo: get: summary: Supported openEO versions operationId: connect description: |- Lists all implemented openEO versions supported by the service provider. This endpoint is the Well-Known URI (see [RFC 5785](https://www.rfc-editor.org/rfc/rfc5785.html)) for openEO. This allows a client to easily identify the most recent openEO implementation it supports. By default, a client SHOULD connect to the most recent production-ready version it supports. If not available, the most recent supported version of *all* versions SHOULD be connected to. Clients MAY let users choose to connect to versions that are not production-ready or outdated. The most recent version is determined by comparing the version numbers according to rules from [Semantic Versioning](https://semver.org/), especially [§11](https://semver.org/#spec-item-11). Any pair of API versions in this list MUST NOT be equal according to Semantic Versioning. The Well-Known URI is the entry point for clients and users, so make sure it is permanent and easy to use and remember. Clients MUST NOT require the well-known path (`/.well-known/openeo`) in the URL that is specified by a user to connect to the back-end. For clients, the usual behavior SHOULD follow these steps: 1. The user provides a URI, which may consist of a scheme (protocol), an authority (host, port) and a path. 2. The client parses the URI and appends `/.well-knwon/openeo` to the path. Make sure to correctly handle leading/trailing slashes. 3. Send a request to the new URI. A. On success: Detect the most suitable API instance/version (see above) and read the [capabilities](#tag/Capabilities/operation/capabilities) from there. B. On failure: Directly try to read the capabilities from the original URI given by the user. **This URI MUST NOT be versioned as the other endpoints.** If your API is available at `https://openeo.example/api/v1`, and you instruct your API users to use `https://openeo.example` as connection URI, the Well-Known URI SHOULD be located at `https://openeo.example/.well-known/openeo`. The Well-Known URI is usually directly located at the top-level, but it is not a requirement. For example, `https://openeo.example/eo/.well-known/openeo` is also allowed. Clients MAY get additional information (e.g. title or description) about a back-end from the most recent version that has the `production` flag set to `true`. tags: - Capabilities security: - {} servers: - url: 'https://openeo.example' description: >- The Well-Known URI SHOULD be available directly at `https://{{domain}}/.well-known/openeo` in contrast to the other endpoints, which may be versioned and can run on other hosts, ports, ... etc. responses: '200': description: >- List of all available API instances, each with URL and the implemented openEO API version. content: application/json: schema: title: Well Known Discovery type: object required: - versions properties: versions: type: array items: title: API Instance type: object required: - url - api_version properties: url: type: string format: uri description: '*Absolute* URLs to the service.' example: 'https://openeo.example/api/v1' production: $ref: '#/components/schemas/production' api_version: type: string description: >- Version number of the openEO specification this back-end implements. example: versions: - url: 'https://openeo.example/api/v0' api_version: 0.4.2 - url: 'https://openeo.example/api/v1' api_version: 1.3.0 - url: 'https://dev.openeo.example/api/v2' production: false api_version: 2.0.0-beta 4XX: $ref: '#/components/responses/client_error' 5XX: $ref: '#/components/responses/server_error' /file_formats: get: summary: Supported file formats operationId: list-file-types description: |- Lists supported input and output file formats. *Input* file formats specify which file a back-end can *read* from. *Output* file formats specify which file a back-end can *write* to. The response to this request is an object listing all available input and output file formats separately with their parameters and additional data. This endpoint does not include the supported secondary web services. **Note**: Format names and parameters MUST be fully aligned with the GDAL codes if available, see [GDAL Raster Formats](https://gdal.org/drivers/raster/index.html) and [OGR Vector Formats](https://gdal.org/drivers/vector/index.html). It is OPTIONAL to support all output format parameters supported by GDAL. Some file formats not available through GDAL may be defined centrally for openEO. Custom file formats or parameters MAY be defined. The format descriptions MUST describe how the file formats relate to data cubes. Input file formats MUST describe how the files have to be structured to be transformed into data cubes. Output file formats MUST describe how the data cubes are stored at the back-end and how the resulting file structure looks like. Back-ends MUST NOT support aliases, for example it is not allowed to support `geotiff` instead of `gtiff`. Nevertheless, openEO Clients MAY translate user input for convenience (e.g. translate `geotiff` to `gtiff`). Also, for a better user experience the back-end can specify a `title`. Format names MUST be accepted in a *case insensitive* manner throughout the API. tags: - Capabilities - Data Processing security: - {} - Bearer: [] responses: '200': description: >- An object with containing all input and output format separately. For each property `input` and `output` an object is defined where the file format names are the property keys and the property values are objects that define a title, supported parameters and related links. content: application/json: schema: title: File Formats type: object required: - input - output properties: input: title: Input File Formats type: object description: >- Map of supported input file formats, i.e. file formats a back-end can **read** from. The property keys are the file format names that are used by clients and users, for example in process graphs. additionalProperties: $ref: '#/components/schemas/file_format' output: title: Output File Formats type: object description: >- Map of supported output file formats, i.e. file formats a back-end can **write** to. The property keys are the file format names that are used by clients and users, for example in process graphs. additionalProperties: $ref: '#/components/schemas/file_format' example: output: GTiff: title: GeoTiff description: Export to GeoTiff. Does not support cloud-optimized GeoTiffs (COGs) yet. gis_data_types: - raster parameters: tiled: type: boolean description: >- This option can be used to force creation of tiled TIFF files [true]. By default [false] stripped TIFF files are created. default: false compress: type: string description: Set the compression to use. default: NONE enum: - JPEG - LZW - DEFLATE - NONE jpeg_quality: type: integer description: Set the JPEG quality when using JPEG. minimum: 1 maximum: 100 default: 75 links: - href: 'https://gdal.org/drivers/raster/gtiff.html' rel: about title: GDAL on the GeoTiff file format and storage options GPKG: title: OGC GeoPackage gis_data_types: - raster - vector parameters: version: type: string description: >- Set GeoPackage version. In AUTO mode, this will be equivalent to 1.2 starting with GDAL 2.3. enum: - auto - '1' - '1.1' - '1.2' default: auto links: - href: 'https://gdal.org/drivers/raster/gpkg.html' rel: about title: GDAL on GeoPackage for raster data - href: 'https://gdal.org/drivers/vector/gpkg.html' rel: about title: GDAL on GeoPackage for vector data input: GPKG: title: OGC GeoPackage gis_data_types: - raster - vector parameters: table: type: string description: >- **RASTER ONLY.** Name of the table containing the tiles. If the GeoPackage dataset only contains one table, this option is not necessary. Otherwise, it is required. links: - href: 'https://gdal.org/drivers/raster/gpkg.html' rel: about title: GDAL on GeoPackage for raster data - href: 'https://gdal.org/drivers/vector/gpkg.html' rel: about title: GDAL on GeoPackage for vector data 4XX: $ref: '#/components/responses/client_error' 5XX: $ref: '#/components/responses/server_error' /conformance: get: summary: Conformance classes this API implements operationId: conformance description: |- Lists all conformance classes specified in various standards that the implementation conforms to. Conformance classes are commonly used in all OGC API standards and the STAC API specification. openEO adds relatively broadly defined conformance classes, especially for the extensions. Otherwise, the implemented functionality can usually be retrieved from the [capabilities](#tag/Capabilities/operation/capabilities) in openEO. The general openEO conformance class is `https://api.openeo.org/1.3.0`. See the individual openEO API extensions for their conformance classes. The conformance classes listed at this endpoint and listed in the corresponding `conformsTo` property in `GET /` MUST be equal. More details: - [STAC API](https://github.com/radiantearth/stac-api-spec), especially the conformance class "STAC API - Collections" - [OGC API standards](https://ogcapi.ogc.org/) tags: - Capabilities security: - {} - Bearer: [] responses: '200': description: The URIs of all conformance classes supported by the server. content: application/json: schema: title: OGC Conformance Classes type: object required: - conformsTo properties: conformsTo: $ref: '#/components/schemas/conformsTo' 4XX: $ref: '#/components/responses/client_error' 5XX: $ref: '#/components/responses/server_error' /collections: get: summary: Basic metadata for all datasets operationId: list-collections description: |- Lists available collections with at least the required information. It is **strongly RECOMMENDED** to keep the response size small by omitting larger optional values from the objects in `collections` (e.g. the `summaries` and `cube:dimensions` properties). To get the full metadata for a collection clients MUST request `GET /collections/{collection_id}`. This endpoint is compatible with [STAC API 1.0.0 and later](https://stacspec.org) and [OGC API - Features 1.0](http://docs.opengeospatial.org/is/17-069r3/17-069r3.html). [STAC API extensions](https://stac-api-extensions.github.io) and [STAC extensions](https://stac-extensions.github.io) can be implemented in addition to what is documented here. Note: Although it is possible to request public collections without authorization, it is RECOMMENDED that clients (re-)request the collections with the Bearer token once available to also retrieve any private collections. tags: - EO Data Discovery security: - {} - Bearer: [] parameters: - $ref: '#/components/parameters/pagination_limit' responses: '200': description: Lists of collections and related links. content: application/json: schema: title: Collections type: object required: - collections - links properties: collections: type: array items: $ref: '#/components/schemas/collection' links: $ref: '#/components/schemas/links_pagination' example: collections: - stac_version: 1.0.0 type: Collection id: Sentinel-2A title: Sentinel-2A MSI L1C description: >- Sentinel-2A is a wide-swath, high-resolution, multi-spectral imaging mission supporting Copernicus Land Monitoring studies, including the monitoring of vegetation, soil and water cover, as well as observation of inland waterways and coastal areas. license: proprietary extent: spatial: bbox: - - -180 - -56 - 180 - 83 temporal: interval: - - '2015-06-23T00:00:00Z' - '2019-01-01T00:00:00Z' keywords: - copernicus - esa - msi - sentinel providers: - name: European Space Agency (ESA) roles: - producer - licensor url: >- https://sentinel.esa.int/web/sentinel/user-guides/sentinel-2-msi - name: openEO roles: - host url: >- https://developers.google.com/earth-engine/datasets/catalog/COPERNICUS_S2 links: - rel: license href: >- https://scihub.copernicus.eu/twiki/pub/SciHubWebPortal/TermsConditions/Sentinel_Data_Terms_and_Conditions.pdf - stac_version: 1.0.0 type: Collection id: MOD09Q1 title: >- MODIS/Terra Surface Reflectance 8-Day L3 Global 250m SIN Grid V006 description: >- The MOD09Q1 Version 6 product provides an estimate of the surface spectral reflectance of Terra MODIS Bands 1-2 corrected for atmospheric conditions such as gasses, aerosols, and Rayleigh scattering. Provided along with the two 250 m MODIS bands is one additional layer, the Surface Reflectance QC 250 m band. For each pixel, a value is selected from all the acquisitions within the 8-day composite period. The criteria for the pixel choice include cloud and solar zenith. When several acquisitions meet the criteria the pixel with the minimum channel 3 (blue) value is used. Validation at stage 3 has been achieved for all MODIS Surface Reflectance products. license: proprietary extent: spatial: bbox: - - -180 - -90 - 180 - 90 temporal: interval: - - '2000-02-01T00:00:00Z' - null links: - rel: license href: 'https://openeo.example/api/v1/collections/MOD09Q1/license' links: - rel: alternate href: 'https://openeo.example/csw' title: openEO catalog (OGC Catalogue Services 3.0) 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' '/collections/{collection_id}': get: summary: Full metadata for a specific dataset operationId: describe-collection description: |- Lists **all** information about a specific collection specified by the identifier `collection_id`. This endpoint is compatible with [STAC API 1.0.0 and later](https://stacspec.org) and [OGC API - Features 1.0](http://docs.opengeospatial.org/is/17-069r3/17-069r3.html). [STAC API extensions](https://stac-api-extensions.github.io) and [STAC extensions](https://stac-extensions.github.io) can be implemented in addition to what is documented here. Note: Providing the Bearer token is REQUIRED for private collections. tags: - EO Data Discovery security: - {} - Bearer: [] parameters: - $ref: '#/components/parameters/collection_id' responses: '200': description: JSON object with the full collection metadata. content: application/json: schema: type: object required: - 'cube:dimensions' - summaries allOf: - $ref: '#/components/schemas/collection' example: stac_version: 1.0.0 stac_extensions: - https://stac-extensions.github.io/datacube/v2.2.0/schema.json type: Collection id: Sentinel-2 title: Sentinel-2 MSI L2A description: >- Sentinel-2A is a wide-swath, high-resolution, multi-spectral imaging mission supporting Copernicus Land Monitoring studies. license: proprietary keywords: - copernicus - esa - msi - sentinel providers: - name: European Space Agency (ESA) roles: - producer - licensor url: >- https://sentinel.esa.int/web/sentinel/user-guides/sentinel-2-msi - name: Google roles: - host url: >- https://developers.google.com/earth-engine/datasets/catalog/COPERNICUS_S2 extent: spatial: bbox: - - -180 - -56 - 180 - 83 temporal: interval: - - '2015-06-23T00:00:00Z' - null links: - rel: license href: https://scihub.copernicus.eu/twiki/pub/SciHubWebPortal/TermsConditions/Sentinel_Data_Terms_and_Conditions.pdf type: application/pdf - rel: http://www.opengis.net/def/rel/ogc/1.0/queryables href: https://openeo.example/api/v1/collections/Sentinel-2A/queryables type: application/schema+json - rel: about href: https://earth.esa.int/web/sentinel/user-guides/sentinel-2-msi/product-types/level-1c type: text/html title: ESA Sentinel-2 MSI Level-1C User Guide - rel: example href: 'https://openeo.example/api/v1/collections/Sentinel-2/examples/true-color.json' type: application/json title: Example Process for True-Color Visualization - rel: example href: 'https://openeo.example/api/v1/collections/Sentinel-2/examples/ndvi.json' type: application/json title: Example Process for NDVI Calculation and Visualization 'cube:dimensions': x: type: spatial axis: x extent: - -180 - 180 reference_system: 4326 y: type: spatial axis: 'y' extent: - -56 - 83 reference_system: 4326 t: type: temporal extent: - '2015-06-23T00:00:00Z' - null step: null bands: type: bands values: - B1 - B2 - B3 - B4 - B5 - B6 - B7 - B8 - B8A - B9 - B10 - B11 - B12 summaries: 'constellation': - Sentinel-2 'platform': - Sentinel-2A - Sentinel-2B 'instruments': - MSI 'eo:cloud_cover': minimum: 0 maximum: 75 'sat:orbit_state': - ascending - descending 'gsd': - 10 - 20 - 60 'eo:bands': - name: B1 common_name: coastal center_wavelength: 0.4439 gsd: 60 - name: B2 common_name: blue center_wavelength: 0.4966 gsd: 10 - name: B3 common_name: green center_wavelength: 0.56 gsd: 10 - name: B4 common_name: red center_wavelength: 0.6645 gsd: 10 - name: B5 center_wavelength: 0.7039 gsd: 20 - name: B6 center_wavelength: 0.7402 gsd: 20 - name: B7 center_wavelength: 0.7825 gsd: 20 - name: B8 common_name: nir center_wavelength: 0.8351 gsd: 10 - name: B8A common_name: nir08 center_wavelength: 0.8648 gsd: 20 - name: B9 common_name: nir09 center_wavelength: 0.945 gsd: 60 - name: B10 common_name: cirrus center_wavelength: 1.3735 gsd: 60 - name: B11 common_name: swir16 center_wavelength: 1.6137 gsd: 20 - name: B12 common_name: swir22 center_wavelength: 2.2024 gsd: 20 'proj:epsg': minimum: 32601 maximum: 32660 assets: thumbnail: href: 'https://openeo.example/api/v1/collections/Sentinel-2/thumbnail.png' type: image/png title: Preview roles: - thumbnail inspire: href: 'https://openeo.example/api/v1/collections/Sentinel-2/inspire.xml' type: application/xml title: INSPIRE metadata description: INSPIRE compliant XML metadata roles: - metadata 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' '/collections/{collection_id}/queryables': get: summary: Metadata filters for a specific dataset operationId: list-collection-queryables description: |- Lists **all** supported metadata filters (also called "queryables") for a specific collection. This endpoint is compatible with the endpoint defined in the STAC API extension [`filter`](https://github.com/stac-api-extensions/filter#queryables) and [OGC API - Features - Part 3: Filtering](https://github.com/opengeospatial/ogcapi-features/tree/master/extensions/filtering). For a precise definition please follow those specifications. This endpoints provides a JSON Schema for each queryable that openEO users can use in multiple scenarios: 1. For loading data from the collection, e.g. in the process `load_collection`. 2. For filtering items using CQL2 on the `/collections/{collection_id}/items` endpoint (if [STAC API - Features is implemented in addition to the openEO API](#tag/EO-Data-Discovery/STAC)). Note: Providing the Bearer token is REQUIRED for private collections. tags: - EO Data Discovery security: - {} - Bearer: [] parameters: - $ref: '#/components/parameters/collection_id' responses: '200': description: |- A JSON Schema defining the queryables. It is RECOMMENDED to dereference all "$refs". content: application/schema+json: schema: $ref: '#/components/schemas/json_schema' example: $schema: https://json-schema.org/draft/2019-09/schema $id: https://openeo.example/api/v1/collections/Sentinel-2A/queryables type: object title: Sentinel-2A properties: 'eo:cloud_cover': title: Cloud Cover type: number minimum: 0 maximum: 100 platform: title: Platform description: The satellite platform. type: string enum: - sentinel-2a - sentinel-2b additionalProperties: false 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' /processes: get: summary: Supported predefined processes operationId: list-processes description: >- Lists all predefined processes and returns detailed process descriptions, including parameters and return values. tags: - Process Discovery security: - {} - Bearer: [] parameters: - $ref: '#/components/parameters/pagination_limit' responses: '200': description: Formal specification describing the supported predefined processes. content: application/json: schema: title: Processes type: object required: - processes - links properties: version: type: string nullable: true description: >- Version number of the openEO process specification this back-end targets. If not provided or `null`, the version is either unknown or multiple versions are implemented. Clients must be able to handle multiple process specification versions at the same time. This is **not** the openEO API specification version. example: 2.0.0 processes: type: array items: title: Predefined Process description: A predefined process made available by the back-end. type: object required: - id - description - parameters - returns allOf: - $ref: '#/components/schemas/process' links: $ref: '#/components/schemas/links_pagination' example: processes: - id: apply summary: Apply a process to each pixel description: >- Applies a *unary* process to each pixel value in the data cube (i.e. a local operation). A unary process takes a single value and returns a single value, for example ``abs()`` or ``linear_scale_range()``. categories: - cubes parameters: - name: data description: A data cube. schema: type: object subtype: datacube - name: process description: 'A unary process to be applied on each value, may consist of multiple sub-processes.' schema: type: object subtype: process-graph parameters: - name: x description: The value to process. schema: description: Any data type. returns: description: 'A data cube with the newly computed values. The resolution, cardinality and the number of dimensions are the same as for the original data cube.' schema: type: object subtype: datacube - id: multiply summary: Multiplication of two numbers description: |- Multiplies the two numbers `x` and `y` (*x * y*) and returns the computed product. No-data values are taken into account so that `null` is returned if any element is such a value. The computations follow [IEEE Standard 754](https://ieeexplore.ieee.org/document/8766229) whenever the processing environment supports it. categories: - math parameters: - name: x description: The multiplier. schema: type: - number - 'null' - name: 'y' description: The multiplicand. schema: type: - number - 'null' returns: description: The computed product of the two numbers. schema: type: - number - 'null' exceptions: MultiplicandMissing: message: Multiplication requires at least two numbers. examples: - arguments: x: 5 y: 2.5 returns: 12.5 - arguments: x: -2 y: -4 returns: 8 - arguments: x: 1 y: null returns: null links: - rel: about href: 'http://mathworld.wolfram.com/Product.html' title: Product explained by Wolfram MathWorld - rel: about href: 'https://ieeexplore.ieee.org/document/8766229' title: IEEE Standard 754-2019 for Floating-Point Arithmetic links: - rel: alternate href: 'https://openeo.example/processes' type: text/html title: HTML version of the processes 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' /udf_runtimes: get: summary: Supported UDF runtimes operationId: list-udf-runtimes description: >- Lists the supported runtimes for user-defined functions (UDFs), which includes either the programming languages including version numbers and available libraries including version numbers or docker containers. tags: - Capabilities security: - {} - Bearer: [] responses: '200': description: Description of UDF runtime support content: application/json: schema: title: UDF Runtimes type: object description: |- Map of available runtime environments. Runtime environments can be either a programming language environment or Docker-based. Each runtime environment has a unique name, which is used as the property key. The name is used in processes to select the runtime environment for UDFs, so the names should be stable and meaningful. It is RECOMMENDED to use the following naming and casing: * For programming langauge environments use the names as provided in in the [Scriptol List of Programming Languages](https://www.scriptol.com/programming/list-programming-languages.php). * For docker images use the docker image identifier excluding the registry path. minProperties: 1 additionalProperties: x-additionalPropertiesName: UDF Runtime name allOf: - $ref: '#/components/schemas/udf_runtime' example: PHP: title: PHP v7.x description: Just an example how to reference a docker image. experimental: true type: docker docker: openeo/udf-php7 default: latest tags: - latest - 7.3.1 - '7.3' - '7.2' links: - href: 'https://hub.docker.com/openeo/udf-php7/' rel: about R: title: R v3.x for Statistical Computing description: R programming language with `Rcpp` and `rmarkdown` extensions installed. type: language default: 3.5.2 versions: 3.1.0: deprecated: true libraries: Rcpp: version: 1.0.10 links: - href: >- https://cran.r-project.org/web/packages/Rcpp/index.html rel: about rmarkdown: version: 1.7.0 links: - href: >- https://cran.r-project.org/web/packages/rmarkdown/index.html rel: about 3.5.2: libraries: Rcpp: version: 1.2.0 links: - href: >- https://cran.r-project.org/web/packages/Rcpp/index.html rel: about rmarkdown: version: 1.7.0 links: - href: >- https://cran.r-project.org/web/packages/rmarkdown/index.html rel: about 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' /credentials/oidc: get: summary: OpenID Connect authentication operationId: authenticate-oidc description: |- Lists the supported [OpenID Connect](http://openid.net/connect/) providers (OP). OpenID Connect Providers MUST support [OpenID Connect Discovery](http://openid.net/specs/openid-connect-discovery-1_0.html). It is highly RECOMMENDED to implement OpenID Connect for public services in favor of Basic authentication. openEO clients MUST use the **access token** as part of the Bearer token for authorization in subsequent API calls (see also the information about Bearer tokens in this document). Clients MUST NOT use the id token or the authorization code. Back-ends MAY request user information ([including Claims](https://openid.net/specs/openid-connect-core-1_0.html#Claims)) from the [OpenID Connect Userinfo endpoint](https://openid.net/specs/openid-connect-core-1_0.html#UserInfo) using the access token (without the prefix described above). Therefore, both openEO client and openEO back-end are relying parties (clients) to the OpenID Connect Provider. tags: - Account Management security: - {} responses: '200': description: Lists the OpenID Connect Providers. content: application/json: schema: title: OpenID Connect Providers type: object required: - providers properties: providers: type: array description: >- The first provider in this list is the default provider for authentication. Clients can either pre-select or directly use the default provider for authentication if the user does not specify a specific value. minItems: 1 items: title: OpenID Connect Provider type: object required: - id - issuer - title properties: id: type: string description: |- A per-back-end **unique** identifier for the OpenID Connect provider. Is used as prefix for the openEO token. pattern: '[\d\w]{1,20}' issuer: type: string format: uri description: |- The [issuer location](https://openid.net/specs/openid-connect-discovery-1_0.html#ProviderConfig) (also referred to as 'authority' in some client libraries) is the URL of the OpenID Connect provider, which conforms to a set of rules: 1. After appending `/.well-known/openid-configuration` to the URL, a [HTTP/1.1 GET request](https://openid.net/specs/openid-connect-discovery-1_0.html#ProviderConfigurationRequest) to the concatenated URL MUST return a [OpenID Connect Discovery Configuration Response](https://openid.net/specs/openid-connect-discovery-1_0.html#ProviderConfigurationResponse). The response provides all information required to authenticate using OpenID Connect. 2. The URL MUST NOT contain a terminating forward slash `/`. example: 'https://accounts.google.com' scopes: type: array description: >- A list of OpenID Connect scopes that the client MUST at least include when requesting authorization. Clients MAY add additional scopes such as the `offline_access` scope to retrieve a refresh token. If scopes are specified, the list MUST at least contain the `openid` scope. items: type: string title: type: string description: >- The name that is publicly shown in clients for this OpenID Connect provider. description: type: string format: commonmark description: |- A description that explains how the authentication procedure works. It should make clear how to register and get credentials. This should include instruction on setting up `client_id`, `client_secret` and `redirect_uri`. [CommonMark 0.29](http://commonmark.org/) syntax MAY be used for rich text representation. default_clients: title: Default OpenID Connect Clients type: array description: |- List of default OpenID Connect clients that can be used by an openEO client for OpenID Connect based authentication. A default OpenID Connect client is managed by the back-end implementer. It MUST be configured to be usable without a client secret, which limits its applicability to OpenID Connect grant types like "Authorization Code Grant with PKCE" and "Device Authorization Grant with PKCE" A default OpenID Connect client is provided without availability guarantees. The back-end implementer CAN revoke, reset or update it any time. As such, openEO clients SHOULD NOT store or cache default OpenID Connect client information for long term usage. A default OpenID Connect client is intended to simplify authentication for novice users. Setting up a dedicated OpenID Connect client is RECOMMENDED for production-ready back-ends. uniqueItems: true items: title: Default OpenID Connect Client type: object required: - id - grant_types properties: id: type: string description: >- The OpenID Connect Client ID to be used in the authentication procedure. grant_types: type: array description: |- List of authorization grant types (flows) supported by the OpenID Connect client. A grant type descriptor consist of a OAuth 2.0 grant type, with an additional `+pkce` suffix when the grant type should be used with the PKCE extension as defined in [RFC 7636](https://www.rfc-editor.org/rfc/rfc7636.html). Allowed values: - `implicit`: Implicit Grant as specified in [RFC 6749, sec. 1.3.2](https://www.rfc-editor.org/rfc/rfc6749.html#section-1.3.2) - `authorization_code` / `authorization_code+pkce`: Authorization Code Grant as specified in [RFC 6749, sec. 1.3.1](https://www.rfc-editor.org/rfc/rfc6749.html#section-1.3.1), with or without PKCE extension. - `urn:ietf:params:oauth:grant-type:device_code` / `urn:ietf:params:oauth:grant-type:device_code+pkce`: Device Authorization Grant (aka Device Code Flow) as specified in [RFC 8628](https://www.rfc-editor.org/rfc/rfc8628.html), with or without PKCE extension. Note that the combination of this grant with the PKCE extension is *not standardized* yet. - `refresh_token`: Refresh Token as specified in [RFC 6749, sec. 1.5](https://www.rfc-editor.org/rfc/rfc6749.html#section-1.5) minItems: 1 uniqueItems: true items: type: string enum: - 'implicit' - 'authorization_code' - 'authorization_code+pkce' - 'urn:ietf:params:oauth:grant-type:device_code' - 'urn:ietf:params:oauth:grant-type:device_code+pkce' - 'refresh_token' redirect_urls: type: array description: |- List of redirect URLs that are whitelisted by the OpenID Connect client. Redirect URLs MUST be provided when the OpenID Connect client supports the Implicit Grant or the Authorization Code Grant (with or without PKCE extension). uniqueItems: true items: type: string format: uri authorization_parameters: type: object description: |- Additional parameters that an openEO client MUST include when requesting the authorization endpoint. This can be used to enforce specific [request parameters such as `prompt`](https://openid.net/specs/openid-connect-core-1_0.html#AuthRequest). example: prompt: consent access_type: offline links: type: array description: |- Links related to this provider, for example a help page or a page to register a new user account. For relation types see the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). items: $ref: '#/components/schemas/link' example: providers: - id: egi issuer: 'https://aai.egi.eu/oidc' title: EGI (default) description: Login with your academic account. scopes: - openid - profile - email default_clients: - id: KStcUzD5AIUA grant_types: - implicit - authorization_code+pkce - urn:ietf:params:oauth:grant-type:device_code+pkce - refresh_token redirect_urls: - https://editor.openeo.org/ - id: google issuer: 'https://accounts.google.com' title: Google description: Login with your Google Account. scopes: - openid - profile - email - earthengine authorization_parameters: access_type: offline - id: ms issuer: 'https://login.microsoftonline.com/example-tenant/v2.0' title: Microsoft description: Login with your Microsoft or Skype Account. scopes: [] 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' /credentials/basic: get: summary: HTTP Basic authentication operationId: authenticate-basic description: |- Checks the credentials provided through [HTTP Basic Authentication according to RFC 7617](https://www.rfc-editor.org/rfc/rfc7617.html) and returns an access token in exchange for providing valid credentials. The credentials (username and password) MUST be sent in the HTTP header `Authorization` with type `Basic` and the Base64 encoded string consisting of username and password separated by a double colon `:`. The header would look as follows for username `user` and password `pw`: `Authorization: Basic dXNlcjpwdw==`. The access token has to be used in the Bearer token for authorization in subsequent API calls (see also the information about Bearer tokens in this document). It is RECOMMENDED to implement this authentication method for non-public services only. tags: - Account Management security: - Basic: [] responses: '200': description: Credentials are correct and authentication succeeded. content: application/json: schema: title: HTTP Basic Access Token type: object required: - access_token properties: access_token: description: >- The access token to be used in the Bearer token for authorization in subsequent API calls (without the custom `basic//` prefix). type: string example: b34ba2bdf9ac9ee1 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' /validation: post: summary: Validate a user-defined process (graph) operationId: validate-custom-process description: |- Validates a user-defined process without executing it. A user-defined process is considered valid unless the `errors` array in the response contains at least one error. Checks whether the process graph is schematically correct and the processes are supported by the back-end. It MUST also check the arguments against the schema, but checking whether the arguments are adequate in the context of data is OPTIONAL. For example, a non-existing band name may get rejected only by a few back-ends. The validation MUST NOT throw an error for unresolvable process parameters. Back-ends MUST validate the process graph. Validating the corresponding metadata is OPTIONAL. Errors that usually occur during processing MAY NOT get reported, e.g. if a referenced file is accessible at the time of execution. Back-ends can either report all errors at once or stop the validation once they found the first error. Please note that a validation always returns with HTTP status code 200. Error codes in the 4xx and 5xx ranges MUST be returned only when the general validation request is invalid (e.g. server is busy or properties in the request body are missing), but never if an error was found during validation of the user-defined process (e.g. an unsupported process). tags: - Data Processing - User-Defined Processes security: - {} - Bearer: [] responses: '200': description: >- Returns the validation result as a list of errors. An empty list indicates a successful validation. content: application/json: schema: title: Validation Result type: object required: - errors properties: errors: description: A list of validation errors. type: array items: $ref: '#/components/schemas/error' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' requestBody: required: true content: application/json: schema: $ref: '#/components/schemas/process_graph_with_metadata' examples: evi_user_defined_process: $ref: '#/components/examples/evi_user_defined_process' description: Specifies the user-defined process to be validated. /result: post: summary: Process and download data synchronously operationId: compute-result description: >- Executes a user-defined process directly (synchronously) and the result will be downloaded in the format specified in the process graph. This endpoint can be used to generate small previews or test user-defined processes before starting a batch job. Timeouts on either client-side or server-side are to be expected for complex computations. Back-ends MAY send the openEO error `ProcessGraphComplexity` immediately if the computation is expected to time out. Otherwise requests MAY time-out after a certain amount of time by sending openEO error `RequestTimeout`. A header named `OpenEO-Costs` MAY be sent with all responses, which MUST include the costs for processing and downloading the data. Additionally, a link to a log file MAY be sent in the header. tags: - Data Processing security: - Bearer: [] responses: '200': description: Result data in the requested output format headers: Content-Type: description: |- The appropriate media (MIME) type for the requested output format MUST be sent, if the response contains a single file. To send multiple files at once it is RECOMMENDED to use the [`tar` file format](https://www.gnu.org/software/tar/manual/html_node/Standard.html) (media type: `application/x-tar`). To mimic the results of batch jobs, it is RECOMMENDED that 1. clients extract the tar file directly after receiving it so that users can directly work on the contained files *and* 2. back-ends add STAC Items and/or Collections to the tar file so that users can make sense of the files. schema: type: string OpenEO-Costs: description: MAY include the costs for processing and downloading the data. schema: $ref: '#/components/schemas/money' OpenEO-Identifier: description: Optionally, an identifier associated with the synchronous processing request. schema: type: string pattern: '^[\w\-\.~]+$' example: a3cca2b2aa1e3b5b Link: description: >- The header MAY indicate a link to a log file generated by the request. If provided, the link MUST be serialized according to [RFC 8288](https://www.rfc-editor.org/rfc/rfc8288.html#section-3) and MUST use the relation type `monitor`. The link MUST follow the specifications for the links `GET /jobs/{job_id}/logs` and `GET /services/{service_id}/logs`, except that is MUST NOT accept any parameters (limit/offset). Therefore, the link MUST be accessible with HTTP GET, MUST be secured using a Bearer token and MUST follow the corresponding request body schema. schema: type: string pattern: ^<[^>]+>;\s?rel="monitor" example: ; rel="monitor" 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' requestBody: description: 'Specifies the job details, e.g. the user-defined process and billing details.' required: true content: application/json: schema: title: Synchronous Result Request type: object required: - process properties: process: $ref: '#/components/schemas/process_graph_with_metadata' budget: $ref: '#/components/schemas/budget' plan: $ref: '#/components/schemas/billing_plan_null_default' log_level: $ref: '#/components/schemas/min_log_level_default' additionalProperties: description: Aditional back-end specific properties are allowed. /process_graphs: get: summary: List all user-defined processes operationId: list-custom-processes description: |- Lists all user-defined processes (process graphs) of the authenticated user that are stored at the back-end. It is **strongly RECOMMENDED** to keep the response size small by omitting larger optional values from the objects in `processes` (e.g. the `exceptions`, `examples` and `links` properties). To get the full metadata for a user-defined process clients MUST request `GET /process_graphs/{process_graph_id}`. tags: - User-Defined Processes - Process Discovery security: - Bearer: [] parameters: - $ref: '#/components/parameters/pagination_limit' responses: '200': description: JSON array with user-defined processes. content: application/json: schema: title: User-Defined Processes type: object required: - processes - links properties: processes: description: Array of user-defined processes type: array items: $ref: '#/components/schemas/user_defined_process_meta' links: $ref: '#/components/schemas/links_pagination' example: processes: - id: evi summary: Enhanced Vegetation Index description: >- Computes the Enhanced Vegetation Index (EVI). It is computed with the following formula: `2.5 * (NIR - RED) / (1 + NIR + 6*RED + -7.5*BLUE)`. parameters: - name: red description: Value from the red band. schema: type: number - name: blue description: Value from the blue band. schema: type: number - name: nir description: Value from the near infrared band. schema: type: number returns: description: Computed EVI. schema: type: number - id: ndsi summary: Normalized-Difference Snow Index parameters: - name: green description: Value from the Visible Green (0.53 - 0.61 micrometers) band. schema: type: number - name: swir description: Value from the Short Wave Infrared (1.55 - 1.75 micrometers) band. schema: type: number returns: schema: type: number - id: my_custom_process links: [] 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' '/process_graphs/{process_graph_id}': parameters: - name: process_graph_id in: path description: Per-user unique identifier for a user-defined process. required: true schema: $ref: '#/components/schemas/process_id' get: summary: Full metadata for a user-defined process operationId: describe-custom-process description: Lists all information about a user-defined process, including its process graph. tags: - User-Defined Processes - Process Discovery security: - Bearer: [] responses: '200': description: The user-defined process with process graph. content: application/json: schema: title: User-Defined Process description: A user-defined process with processing instructions as process graph. type: object required: - process_graph allOf: - $ref: '#/components/schemas/user_defined_process_meta' examples: evi_user_defined_process: $ref: '#/components/examples/evi_user_defined_process' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' put: summary: Store a user-defined process operationId: store-custom-process description: |- Stores a provided user-defined process with process graph that can be reused in other processes. If a process with the specified `process_graph_id` exists, the process is fully replaced. The id can not be changed for existing user-defined processes. The id MUST be unique across its namespace. Partially updating user-defined processes is not supported. To simplify exchanging user-defined processes, the property `id` can be part of the request body. If the values do not match, the value for `id` gets replaced with the value from the `process_graph_id` parameter in the path. tags: - User-Defined Processes security: - Bearer: [] responses: '200': description: The user-defined process has been stored successfully. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' requestBody: required: true description: Specifies the process graph with its meta data. content: application/json: schema: $ref: '#/components/schemas/process_graph_with_metadata' examples: evi_user_defined_process: $ref: '#/components/examples/evi_user_defined_process' delete: summary: Delete a user-defined process operationId: delete-custom-process description: |- Deletes the data related to this user-defined process, including its process graph. Does NOT delete jobs or services that reference this user-defined process. tags: - User-Defined Processes security: - Bearer: [] responses: '204': description: The user-defined process has been successfully deleted 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' /service_types: get: summary: Supported secondary web service protocols operationId: list-service-types description: |- Lists supported secondary web service protocols such as [OGC WMS](http://www.opengeospatial.org/standards/wms), [OGC WCS](http://www.opengeospatial.org/standards/wcs), [OGC API - Features](https://www.ogc.org/standards/ogcapi-features) or [XYZ tiles](https://wiki.openstreetmap.org/wiki/Slippy_map_tilenames). The response is an object of all available secondary web service protocols with their supported configuration settings and expected process parameters. * The configuration settings for the service SHOULD be defined upon creation of a service and the service will be set up accordingly. * The process parameters SHOULD be referenced (with a `from_parameter` reference) in the user-defined process that is used to compute web service results. The appropriate arguments MUST be provided to the user-defined process, usually at runtime from the context of the web service. For example, a map service such as a WMS would need to inject the spatial extent into the user-defined process so that the back-end can compute the corresponding tile correctly. To improve interoperability between back-ends common names for the services SHOULD be used, e.g. the abbreviations used in the official [OGC Schema Repository](http://schemas.opengis.net/) for the respective services. Service names MUST be accepted in a *case insensitive* manner throughout the API. tags: - Capabilities - Secondary Services security: - {} - Bearer: [] responses: '200': description: >- An object with a map containing all service names as keys and an object that defines supported configuration settings and process parameters. content: application/json: schema: title: Service Types type: object description: Map of supported secondary web services. additionalProperties: x-additionalPropertiesName: Service Name title: Service Type type: object required: - configuration - process_parameters properties: title: $ref: '#/components/schemas/object_title' description: $ref: '#/components/schemas/description' deprecated: $ref: '#/components/schemas/deprecated' experimental: $ref: '#/components/schemas/experimental' configuration: title: Service Configuration description: Map of supported configuration settings made available to the creator of the service. type: object additionalProperties: $ref: '#/components/schemas/resource_parameter' process_parameters: title: Process Parameters description: List of parameters made available to user-defined processes. type: array items: $ref: '#/components/schemas/process_parameter' links: description: |- Links related to this service type, e.g. more information about the configuration settings and process parameters. For relation types see the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). type: array items: $ref: '#/components/schemas/link' example: WMS: title: OGC Web Map Service configuration: version: type: string description: The WMS version offered to consumers of the service. default: 1.3.0 enum: - 1.1.1 - 1.3.0 process_parameters: - name: layer description: The layer name. schema: type: string default: roads - name: spatial_extent description: A bounding box in WGS84. schema: type: object required: - west - south - east - north properties: west: description: West (lower left corner, coordinate axis 1). type: number south: description: South (lower left corner, coordinate axis 2). type: number east: description: East (upper right corner, coordinate axis 1). type: number north: description: North (upper right corner, coordinate axis 2). type: number links: - href: 'https://www.opengeospatial.org/standards/wms' rel: about title: OGC Web Map Service Standard OGCAPI-FEATURES: title: OGC API - Features description: Exposes a OGC API - Features in version 1.0 of the specification (successor of OGC WFS 3.0). configuration: title: type: string description: The title for the OGC API - Features landing page description: type: string description: The description for the OGC API - Features landing page conformsTo: type: array description: |- The OGC API - Features conformance classes to enable for this service. `http://www.opengis.net/spec/ogcapi-features-1/1.0/conf/core` is always enabled. items: type: string enum: - http://www.opengis.net/spec/ogcapi-features-1/1.0/conf/oas30 - http://www.opengis.net/spec/ogcapi-features-1/1.0/conf/html - http://www.opengis.net/spec/ogcapi-features-1/1.0/conf/geojson - http://www.opengis.net/spec/ogcapi-features-2/1.0/conf/crs process_parameters: [] links: - href: 'https://www.opengeospatial.org/standards/wfs' rel: about title: OGC Web Feature Service Standard 4XX: $ref: '#/components/responses/client_error' 5XX: $ref: '#/components/responses/server_error' /services: get: summary: List all web services operationId: list-services description: |- Lists all secondary web services submitted by a user. It is **strongly RECOMMENDED** to keep the response size small by omitting all optional non-scalar values (i.e. arrays and objects) from objects in `services` (i.e. the `process`, `configuration` and `attributes` properties). To get the full metadata for a secondary web service clients MUST request `GET /services/{service_id}`. tags: - Secondary Services security: - Bearer: [] parameters: - $ref: '#/components/parameters/pagination_limit' responses: '200': description: Array of secondary web service descriptions content: application/json: schema: title: Secondary Web Services type: object required: - services - links properties: services: type: array items: $ref: '#/components/schemas/service' links: $ref: '#/components/schemas/links_pagination' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' post: summary: Publish a new service operationId: create-service description: |- Creates a new secondary web service such as a [OGC WMS](http://www.opengeospatial.org/standards/wms), [OGC WCS](http://www.opengeospatial.org/standards/wcs), [OGC API - Features](https://www.ogc.org/standards/ogcapi-features) or [XYZ tiles](https://wiki.openstreetmap.org/wiki/Slippy_map_tilenames). The secondary web service SHOULD process the underlying data on demand, based on process parameters provided to the user-defined process (through `from_parameter` references) at run-time, for example for the spatial/temporal extent, resolution, etc. The available process parameters are specified per service type at `GET /service_types`. **Note:** Costs incurred by shared secondary web services are usually paid by the owner, but this depends on the service type and whether it supports charging fees or not. tags: - Secondary Services security: - Bearer: [] responses: '201': description: The service has been created successfully. headers: Location: required: true schema: description: |- Absolute URL to the newly created service. The URL points to the metadata endpoint `GET /services/{service_id}` with the `{service_id}` being the unique identifier (ID) of the created service. MUST NOT point to the actual instance (e.g. WMTS base URL) of the service. The URL to the instance is made available by the metadata endpoint in the property `url`. format: uri type: string example: 'https://openeo.example/api/v1/services/123' OpenEO-Identifier: required: true schema: $ref: '#/components/schemas/service_id' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' requestBody: required: true content: application/json: schema: title: Store Secondary Web Service Request type: object required: - type - process properties: title: $ref: '#/components/schemas/eo_title' description: $ref: '#/components/schemas/eo_description' process: $ref: '#/components/schemas/process_graph_with_metadata' type: $ref: '#/components/schemas/service_type' enabled: allOf: - $ref: '#/components/schemas/service_enabled' - default: true configuration: $ref: '#/components/schemas/service_configuration' plan: $ref: '#/components/schemas/billing_plan_null_default' budget: $ref: '#/components/schemas/budget' log_level: $ref: '#/components/schemas/min_log_level_default' additionalProperties: description: Additional back-end specific properties are allowed. description: The base data required to create the secondary web service. '/services/{service_id}': parameters: - $ref: '#/components/parameters/service_id' patch: summary: Modify a service operationId: update-service description: |- Modifies an existing secondary web service at the back-end, but maintains the identifier. Changes can be grouped into a single request. User MUST create a new service to change the service type. tags: - Secondary Services security: - Bearer: [] responses: '204': description: Changes to the service were applied successfully. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' requestBody: required: true content: application/json: schema: title: Update Secondary Web Service Request type: object properties: title: $ref: '#/components/schemas/eo_title' description: $ref: '#/components/schemas/eo_description' process: $ref: '#/components/schemas/process_graph_with_metadata' enabled: $ref: '#/components/schemas/service_enabled' configuration: $ref: '#/components/schemas/service_configuration' plan: $ref: '#/components/schemas/billing_plan_null' budget: $ref: '#/components/schemas/budget_update' log_level: $ref: '#/components/schemas/min_log_level_update' additionalProperties: description: Additional back-end specific properties are allowed. description: The data to change for the specified secondary web service. get: summary: Full metadata for a service operationId: describe-service description: Lists all information about a secondary web service. tags: - Secondary Services security: - Bearer: [] responses: '200': description: Details of the created service content: application/json: schema: type: object required: - process - configuration - attributes allOf: - $ref: '#/components/schemas/service' additionalProperties: description: You can list additional back-end specific properties here. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' delete: summary: Delete a service operationId: delete-service description: >- Deletes all data related to this secondary web service. Computations are stopped, computed results are deleted, and access to this service is no longer possible. This service will not generate additional costs. tags: - Secondary Services security: - Bearer: [] responses: '204': description: The service has been successfully deleted. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' '/services/{service_id}/logs': get: summary: Logs for a secondary service operationId: debug-service description: >- Lists log entries for the secondary service, usually for debugging purposes. Back-ends can log any information that may be relevant for a user. Users can log information during data processing using respective processes such as `inspect`. If requested consecutively while the secondary service is enabled, it is RECOMMENDED that clients use the offset parameter to get only the entries they have not received yet. While pagination itself is OPTIONAL, the `offset` parameter is REQUIRED to be implemented by back-ends. tags: - Secondary Services security: - Bearer: [] parameters: - $ref: '#/components/parameters/service_id' - $ref: '#/components/parameters/log_offset' - $ref: '#/components/parameters/log_level' - $ref: '#/components/parameters/pagination_limit' responses: '200': $ref: '#/components/responses/logs' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' /jobs: get: summary: List all batch jobs operationId: list-jobs description: |- Lists all batch jobs submitted by a user. It is **strongly RECOMMENDED** to keep the response size small by omitting all optional non-scalar values (i.e. arrays and objects) from objects in `jobs` (i.e. the `process` property). To get the full metadata for a job clients MUST request `GET /jobs/{job_id}`. tags: - Data Processing - Batch Jobs security: - Bearer: [] parameters: - $ref: '#/components/parameters/pagination_limit' responses: '200': description: Array of job descriptions content: application/json: schema: title: Batch Jobs type: object required: - jobs - links properties: jobs: type: array items: $ref: '#/components/schemas/batch_job' links: $ref: '#/components/schemas/links_pagination' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' post: summary: Create a new batch job operationId: create-job description: |- Creates a new batch processing task (job) from one or more (chained) processes at the back-end. Processing the data does not start yet. The job status gets initialized as `created` by default. tags: - Data Processing - Batch Jobs security: - Bearer: [] responses: '201': description: The batch job has been created successfully. headers: Location: required: true schema: description: |- Absolute URL to the newly created batch job. The URL points to the metadata endpoint `GET /jobs/{job_id}` with the `{job_id}` being the unique identifier (ID) of the created batch job. format: uri type: string example: 'https://openeo.example/api/v1/jobs/123' OpenEO-Identifier: required: true schema: $ref: '#/components/schemas/job_id' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' requestBody: required: true content: application/json: schema: title: Store Batch Job Request type: object required: - process properties: title: $ref: '#/components/schemas/eo_title' description: $ref: '#/components/schemas/eo_description' process: $ref: '#/components/schemas/process_graph_with_metadata' plan: $ref: '#/components/schemas/billing_plan_null_default' budget: $ref: '#/components/schemas/budget' log_level: $ref: '#/components/schemas/min_log_level_default' additionalProperties: description: Additional back-end specific properties are allowed. description: 'Specifies the job details, e.g. the user-defined process and billing details.' '/jobs/{job_id}': parameters: - $ref: '#/components/parameters/job_id' patch: summary: Modify a batch job operationId: update-job description: |- Modifies an existing job at the back-end, but maintains the identifier. Changes can be grouped in a single request. The job status does not change. Jobs can only be modified when the job is not queued and not running. Otherwise, requests to this endpoint MUST be rejected with openEO error `JobLocked`. tags: - Data Processing - Batch Jobs security: - Bearer: [] responses: '204': description: Changes to the job applied successfully. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' requestBody: required: true content: application/json: schema: title: Update Batch Job Request type: object properties: title: $ref: '#/components/schemas/eo_title' description: $ref: '#/components/schemas/eo_description' process: $ref: '#/components/schemas/process_graph_with_metadata' plan: $ref: '#/components/schemas/billing_plan_null' budget: $ref: '#/components/schemas/budget_update' log_level: $ref: '#/components/schemas/min_log_level_update' additionalProperties: description: Additional back-end specific properties are allowed. description: Specifies the job details to update. get: summary: Full metadata for a batch job operationId: describe-job description: Lists all information about a submitted batch job. tags: - Data Processing - Batch Jobs security: - Bearer: [] responses: '200': description: Full job information. content: application/json: schema: type: object required: - process allOf: - $ref: '#/components/schemas/batch_job' additionalProperties: description: You can list additional back-end specific properties here. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' delete: summary: Delete a batch job operationId: delete-job description: >- Deletes all data related to a given batch job. Computations are stopped and computed results are deleted. This job will not generate additional costs for processing. tags: - Data Processing - Batch Jobs security: - Bearer: [] responses: '204': description: The job has been successfully deleted. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' '/jobs/{job_id}/estimate': get: summary: Get an estimate for a batch job operationId: estimate-job description: >- Calculates an estimate for a batch job. Back-ends can decide to either calculate the duration, the costs, the size or a combination of them. Back-end providers MAY specify an expiry time for the estimate. Starting to process data afterwards MAY be charged at a higher cost. Costs do often not include download costs. Whether download costs are included or not can be indicated explicitly with the `downloads_included` flag. The estimate SHOULD be the upper limit of the costs, but back-end are free to use the field according to their terms of service. For some batch jobs it is not (easily) possible to estimate the costs reliably, e.g. if a UDF or ML model is part of the process. In this case, the server SHOULD return a `EstimateComplexity` error with HTTP status code 500. tags: - Data Processing - Batch Jobs security: - Bearer: [] parameters: - $ref: '#/components/parameters/job_id' responses: '200': description: >- The estimated costs with regard to money, processing time and storage capacity. At least one of `costs`, `duration` or `size` MUST be provided. content: application/json: schema: title: Batch Job Estimate type: object anyOf: - required: - "costs" - required: - "duration" - required: - "size" properties: costs: $ref: '#/components/schemas/money' duration: type: string description: >- Estimated duration for the operation. Duration MUST be specified as an [ISO 8601 duration](https://en.wikipedia.org/wiki/ISO_8601#Durations). example: P1Y2M10DT2H30M size: type: integer description: >- Estimated required storage capacity, i.e. the size of the generated files. Size MUST be specified in bytes. example: 157286400 downloads_included: type: integer nullable: true description: >- Specifies how many full downloads of the processed data are included in the estimate. Set to `null` for unlimited downloads, which is also the default value. example: 5 default: null expires: type: string format: date-time description: >- Time until which the estimate is valid, formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. example: '2020-11-01T00:00:00Z' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' '/jobs/{job_id}/logs': get: summary: Logs for a batch job operationId: debug-job description: |- Lists log entries for the batch job, usually for debugging purposes. Back-ends can log any information that may be relevant for a user at any stage (status) of the batch job. Users can log information during data processing using respective processes such as `inspect`. If requested consecutively, it is RECOMMENDED that clients use the offset parameter to get only the entries they have not received yet. While pagination itself is OPTIONAL, the `offset` parameter is REQUIRED to be implemented by back-ends. tags: - Data Processing - Batch Jobs security: - Bearer: [] parameters: - $ref: '#/components/parameters/job_id' - $ref: '#/components/parameters/log_offset' - $ref: '#/components/parameters/log_level' - $ref: '#/components/parameters/pagination_limit' responses: '200': $ref: '#/components/responses/logs' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' '/jobs/{job_id}/results': parameters: - $ref: '#/components/parameters/job_id' get: summary: List batch job results operationId: list-results description: |- Lists signed URLs pointing to the processed files, usually after the batch job has finished. Back-ends may also point to intermediate results after the job has stopped due to an error or if the `partial` parameter has been set. The response includes additional metadata. It is a valid [STAC Item](https://github.com/radiantearth/stac-spec/tree/v1.0.0/item-spec) (if it has spatial and temporal references included) or a valid [STAC Collection](https://github.com/radiantearth/stac-spec/tree/v1.0.0/collection-spec) (supported since openEO API version 1.1.0). The assets to download are in both cases available in the property `assets` and have the same structure. Additional metadata is not strictly required to download the files, but are helpful for users to understand the data. STAC Collections can either (1) add all assets as collection-level assets or (2) link to STAC Catalogs and STAC Items with signed URLs, which will provide a full STAC catalog structure a client has to go through. Option 2 is overall the better architectural choice and allows a fine-grained description of the processed data, but it is not compliant with previous versions of the openEO API. **To maintain backward compatibility, it is REQUIRED to still copy all assets in the STAC catalog structure into the collection-level assets.** This requirement is planned to be removed in openEO API version 2.0.0. A client can enforce that the server returns a GeoJSON through content negotiation with the media type `application/geo+json`, but the results may not contain very meaningful metadata aside from the assets. Clients are RECOMMENDED to store this response and all potential sub-catalogs and items with the assets so that the downloaded data is then a self-contained STAC catalog user could publish easily with all the data and metadata. URL signing is a way to protect files from unauthorized access with a key in the URL instead of HTTP header based authorization. The URL signing key is similar to a password and its inclusion in the URL allows to download files using simple GET requests supported by a wide range of programs, e.g. web browsers or download managers. Back-ends are responsible to generate the URL signing keys and to manage their appropriate expiration. The back-end MAY indicate an expiration time by setting the `expires` property in the reponse. Requesting this endpoint SHOULD always return non-expired URLs. Signed URLs that were generated for a previous request and already expired SHOULD NOT be reused, but regenerated with new expiration time. Signed URLs that expired MAY return the openEO error `ResultLinkExpired`. Adding a link with relation type `canonical` to the STAC Item or STAC Collection is STRONGLY RECOMMENDED (see the `links` property for details). If processing has not finished yet and the `partial` parameter is not set to `true` requests to this endpoint MUST be rejected with openEO error `JobNotFinished`. tags: - Data Processing - Batch Jobs security: - Bearer: [] parameters: - name: partial description: >- If set to `true`, the results endpoint returns incomplete results while still running. Enabling this parameter requires to indicate the status of the batch job in the STAC metadata by setting the `openeo:status`. in: query allowEmptyValue: true schema: type: boolean default: false responses: '200': description: >- Valid download links have been returned. The download links does not necessarily need to be located under the API base url. headers: OpenEO-Costs: description: >- Specifies the costs for fully downloading the data **once**, i.e. this header MAY change in subsequent calls. It MUST be set to `0` if the requester is the owner of the job and still has free downloads included in his processing charges estimated by `GET /jobs/{job_id}/estimate`. If a requester other than the owner is requesting the data of a shared job this header indicates the costs for the requester. schema: $ref: '#/components/schemas/money' content: application/json: schema: oneOf: - $ref: '#/components/schemas/batch_job_result' - title: Batch Job Results Response as STAC Collection type: object required: - assets properties: created: $ref: '#/components/schemas/created' updated: $ref: '#/components/schemas/updated' queued: $ref: '#/components/schemas/queued' started: $ref: '#/components/schemas/started' expires: $ref: '#/components/schemas/expires' unpublished: $ref: '#/components/schemas/unpublished' 'openeo:status': $ref: '#/components/schemas/result_status' allOf: - $ref: '#/components/schemas/collection' example: stac_version: 1.0.0 id: a3cca2b2aa1e3b5b title: NDVI based on Sentinel-2 description: Deriving minimum NDVI measurements over pixel time series of Sentinel-2 license: Apache-2.0 providers: - name: Example Cloud Corp. description: No further processing applied. roles: - producer - licensor - host url: https://cloud.example extent: temporal: interval: - - 2019-08-24T14:15:22Z - 2019-08-24T14:15:22Z spatial: bbox: - - -180 - -90 - 180 - 90 assets: preview.png: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/preview.png' type: image/png title: Thumbnail roles: - thumbnail process.json: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/process.json' type: application/json title: Original Process roles: - process - reproduction 1.tif: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/1.tif' type: image/tiff; application=geotiff roles: - data 2.tif: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/2.tif' type: image/tiff; application=geotiff roles: - data inspire.xml: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/inspire.xml' type: application/xml title: INSPIRE metadata description: INSPIRE compliant XML metadata roles: - metadata links: - rel: canonical type: application/json href: https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/collection.json - rel: item type: application/geo+json href: https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/item_1.json - rel: item type: application/geo+json href: https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/item_2.json application/geo+json: schema: $ref: '#/components/schemas/batch_job_result' '424': description: >- The request can not be fulfilled as the batch job failed. This request will deliver the last error message that was produced by the batch job. This HTTP code MUST be sent only when the job `status` is `error`. content: application/json: schema: $ref: '#/components/schemas/log_entry' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' post: summary: Start processing a batch job operationId: start-job description: |- Adds a batch job to the processing queue to compute the results. The result will be stored in the format specified in the process. To specify the format use a process such as `save_result`. The job status is set to `queued`, if processing does not start instantly. The same applies if the job status is `canceled`, `finished`, or `error`, which restarts the job and discards previous results if the back-end does not reject the request with an error. Clients SHOULD warn users and ask for confirmation if results may get discarded. * Once the processing starts the status is set to `running`. * Once the data is available to download the status is set to `finished`. * Whenever an error occurs during processing, the status MUST be set to `error`. This endpoint has no effect if the job status is already `queued` or `running`. In particular, it does not restart a running job. To restart a queued or running job, processing MUST have been canceled. Back-ends SHOULD reject queueing jobs with openEO error `PaymentRequired`, if the back-end is able to detect that the budget is too low to fully process the request. Alternatively, back-ends MAY provide partial results once reaching the budget. If none of the alternatives is feasible, the results are discarded. Thus, client SHOULD warn users that reaching the budget may lead to partial or no results at all. tags: - Data Processing - Batch Jobs security: - Bearer: [] responses: '202': description: The creation of the resource has been queued successfully. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' delete: summary: Cancel processing a batch job operationId: stop-job description: |- Cancels all related computations for this job at the back-end. It will stop generating additional costs for processing. A subset of processed results may be available for downloading depending on the state of the job at the time it was canceled. Results MUST NOT be deleted until the job processing is started again or the job is completely deleted through a request to `DELETE /jobs/{job_id}`. This endpoint only has an effect if the job status is `queued` or `running`. The job status is set to `canceled` if the status was `running` beforehand and partial or preliminary results are available to be downloaded. Otherwise the status is set to `created`. tags: - Data Processing - Batch Jobs security: - Bearer: [] responses: '204': description: Processing the job has been successfully canceled. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' '/files': get: summary: List all files in the workspace operationId: list-files description: >- Lists all user-uploaded files that are stored at the back-end. tags: - File Storage security: - Bearer: [] parameters: - $ref: '#/components/parameters/pagination_limit' responses: '200': description: >- Flattened file tree with path relative to the user's root directory and some basic properties such as the file size and the timestamp of the last modification. All properties except the name are optional. Folders MUST NOT be listed separately so each element in the list MUST be a downloadable file. content: application/json: schema: title: Workspace Files type: object required: - files - links properties: files: type: array items: $ref: '#/components/schemas/file' links: $ref: '#/components/schemas/links_pagination' example: files: - path: test.txt size: 182 modified: '2015-10-20T17:22:10Z' - path: test.tif size: 183142 modified: '2017-01-01T09:36:18Z' - path: >- Sentinel2/S2A_MSIL1C_20170819T082011_N0205_R121_T34KGD_20170819T084427.zip size: 4183353142 modified: '2018-01-03T10:55:29Z' links: [] 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' '/files/{path}': parameters: - name: path in: path description: |- Path of the file, relative to the user's root directory. MAY include folders, but MUST not include relative references such as `.` and `..`. Folder and file names in the path MUST be url-encoded. The path separator `/` and the file extension separator `.` MUST NOT be url-encoded. The URL-encoding may be shown incorrectly in rendered versions due to [OpenAPI 3 not supporting path parameters which contain slashes](https://github.com/OAI/OpenAPI-Specification/issues/892). This may also lead to OpenAPI validators not validating paths containing folders correctly. required: true schema: type: string examples: normal: description: >- A path without special chars. It describes a file `europe.geojson` in a folder called `borders`. value: borders/europe.geojson specialchars: description: >- A path with special chars. It describes a file `münster.shp` in folders called `europe` and `österreich`. value: europe/%C3%B6sterreich/m%C3%BCnster.shp get: summary: Download a file from the workspace operationId: download-file description: >- Offers a file from the user workspace for download. The file is identified by its path relative to the user's root directory. If a folder is specified as path a `FileOperationUnsupported` error MUST be sent as response. tags: - File Storage security: - Bearer: [] responses: '200': description: A file from the workspace. content: application/octet-stream: schema: type: string format: binary 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' put: summary: Upload a file to the workspace operationId: upload-file description: >- Uploads a new file to the given path or updates an existing file if a file at the path exists. Folders are created once required by a file upload. Empty folders can not be created. tags: - File Storage security: - Bearer: [] responses: '200': description: The file has been uploaded successfully. content: application/json: schema: $ref: '#/components/schemas/file' 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' requestBody: required: true content: application/octet-stream: schema: type: string format: binary delete: summary: Delete a file from the workspace operationId: delete-file description: >- Deletes an existing user-uploaded file specified by its path. Resulting empty folders MUST be deleted automatically. Back-ends MAY support deleting folders including its files and sub-folders. If not supported by the back-end a `FileOperationUnsupported` error MUST be sent as response. tags: - File Storage security: - Bearer: [] responses: '204': description: The file has been successfully deleted at the back-end. 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' /me: get: summary: Information about the authenticated user operationId: describe-account description: >- Lists information about the authenticated user such as the user id. The endpoint MAY return the disk quota available to the user. The endpoint MAY also return links related to user management and the user profile, e.g. where payments are handled or the user profile could be edited. For back-ends that involve accounting, this service MAY also return the currently available money or credits in the currency the back-end is working with. This endpoint MAY be extended to fulfil the specification of the [OpenID Connect UserInfo Endpoint](http://openid.net/specs/openid-connect-core-1_0.html#UserInfo). tags: - Account Management security: - Bearer: [] responses: '200': description: Information about the logged in user. content: application/json: schema: title: User Data description: >- Holds user information. If no budget or storage limit applies to the user account the corresponding properties MUST be set to null. type: object required: - user_id properties: user_id: type: string description: >- A unique user identifier specific to the back-end, which could either be chosen by a user or is automatically generated by the back-end during the registration process at the back-end. It is meant to be used as an identifier in URIs (e.g. for sharing purposes), which is primarily used in machine-to-machine communication. Preferrably use the human-readable property `name` to display the user's name in user interfaces instead of the user identifier. pattern: '^[\w\-\.~]+$' example: john_doe name: type: string description: >- The user name, a human-friendly displayable name. Could be the user's real name or a nickname. default_plan: type: string description: Name of the single plan the user is currently subscribed to if any. example: free storage: title: User Storage description: Information about the storage space available to the user. type: object nullable: true required: - free - quota properties: free: $ref: '#/components/schemas/storage_quota_free' quota: $ref: '#/components/schemas/max_storage_quota' budget: type: number nullable: true description: |- The remaining budget a user has available. The value MUST be specified in the currency of the back-end. The value SHOULD be set to `null` if no explicit limit applies. links: description: |- Links related to the user profile, e.g. where payments are handled or the user profile could be edited. Providing links with the following `rel` (relation) types is RECOMMENDED: 1. `payment`: A page where users can recharge their user account with money or credits. 2. `edit-form`: Points to a page where the user can edit his user profile. 3. `alternate`: Any other representation of these (and potentially additional) user information, e.g. the (public) user profile page. It is RECOMMENDED to add descriptive titles for a better user experience. 4. `related`: Any other user-specific links to be shown in clients, e.g. to user-specific settings, invoices, etc. It is RECOMMENDED to add descriptive titles for a better user experience. For additional relation types see also the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). type: array items: $ref: '#/components/schemas/link' example: - href: 'https://openeo.example/john_doe/payment/' rel: payment - href: 'https://openeo.example/john_doe/edit/' rel: edit-form - href: 'https://openeo.example/john_doe/' rel: alternate type: text/html title: User profile - href: 'https://openeo.example/john_doe.vcf' rel: alternate type: text/vcard title: vCard of John Doe - href: 'https://openeo.example/john_doe/invoices' rel: related type: text/html title: Invoices 4XX: $ref: '#/components/responses/client_error_auth' 5XX: $ref: '#/components/responses/server_error' components: schemas: conformsTo: description: |- Lists all conformance classes specified in various standards that the implementation conforms to. Conformance classes are commonly used in all OGC API standards and the STAC API specification. The general openEO conformance class is `https://api.openeo.org/1.3.0`. See the individual openEO API extensions for their conformance classes. type: array items: type: string format: uri example: - https://api.openeo.org/1.3.0 - https://api.openeo.org/extensions/commercial-data/0.1.0 - https://api.openeo.org/extensions/federation/0.2.0 - https://api.stacspec.org/v1.0.0/core - https://api.stacspec.org/v1.0.0/collections udf_runtime: type: object required: - type - default properties: title: $ref: '#/components/schemas/object_title' description: $ref: '#/components/schemas/description' type: type: string description: |- The type of the UDF runtime. Predefined types are: * `language` for Programming Languages and * `docker` for Docker Containers. The types can potentially be extended by back-ends. default: type: string deprecated: $ref: '#/components/schemas/deprecated' experimental: $ref: '#/components/schemas/experimental' links: type: array description: |- Links related to this runtime, e.g. external documentation. It is highly RECOMMENDED to provide at least links with the following `rel` (relation) types: 1. `about`: A resource that further explains the runtime, e.g. a user guide or the documentation. It is RECOMMENDED to add descriptive titles for a better user experience. For additional relation types see also the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). items: $ref: '#/components/schemas/link' discriminator: propertyName: type mapping: language: '#/components/schemas/udf_programming_language' docker: '#/components/schemas/udf_docker' udf_programming_language: allOf: - $ref: '#/components/schemas/udf_runtime' - title: Programming language required: - versions properties: default: type: string description: The default version. MUST be one of the keys in the `versions` object. versions: title: Programming language versions description: Versions available for the programming language. type: object additionalProperties: x-additionalPropertiesName: Programming Language Version title: Programming language version type: object required: - libraries properties: deprecated: $ref: '#/components/schemas/deprecated' experimental: $ref: '#/components/schemas/experimental' libraries: description: >- Map of installed libraries, modules, packages or extensions for the programming language. The names of them are used as the property keys. additionalProperties: x-additionalPropertiesName: Library Name title: Programming language library type: object required: - version properties: version: type: string description: Version number of the library. deprecated: $ref: '#/components/schemas/deprecated' experimental: $ref: '#/components/schemas/experimental' links: type: array description: |- Additional links related to this library, e.g. external documentation for this library. It is highly RECOMMENDED to provide links with the following `rel` (relation) types: 1. `about`: A resource that further explains the library, e.g. a user guide or the documentation. It is RECOMMENDED to add descriptive titles for a better user experience. 2. `latest-version`: If a library has been marked as deprecated, a link SHOULD point to either a new library replacing the deprecated library or a latest version of the library available at the back-end. For additional relation types see also the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). items: $ref: '#/components/schemas/link' udf_docker: allOf: - $ref: '#/components/schemas/udf_runtime' - title: Docker container required: - docker - tags properties: docker: type: string description: >- Identifier of a Docker image on Docker Hub or a private repository, which can run openEO UDFs. This is what is used in the `docker pull` command excluding the tag, e.g. `php`, `mcr.microsoft.com/dotnet/runtime` or `myregistry.local:5000/testing/test-image`. default: type: string description: The default tag. MUST be one of the values in the `tags` array. tags: type: array description: The docker tags that are supported. minItems: 1 items: type: string result_status: type: string enum: - running - canceled - finished - error description: |- The status of a batch job. This field is REQUIRED if the `partial` parameter is given. This field is strongly RECOMMENDED if the job has stopped due to an error. default: finished batch_job_result: title: Batch Job Results Response as STAC Item description: The STAC specification should be the main guidance for implementing this. Specifying the `bbox` is strongly RECOMMENDED for STAC compliance, but can be omitted if the result is unlocated and the `geometry` is set to `null`. type: object required: - stac_version - id - type - geometry - properties - assets - links properties: stac_version: $ref: '#/components/schemas/stac_version' stac_extensions: $ref: '#/components/schemas/stac_extensions' id: $ref: '#/components/schemas/job_id' type: type: string description: >- The GeoJSON type that applies to this metadata document, which MUST always be a "Feature" according to the STAC specification. This type does **not** describe the spatial data type of the assets. enum: - Feature bbox: $ref: '#/components/schemas/bbox' geometry: type: object nullable: true description: |- Defines the full footprint of the asset represented by this item as GeoJSON Geometry. Results without a known location can set this value to `null`. allOf: - $ref: '#/components/schemas/GeoJsonGeometry' example: type: Polygon coordinates: - - - -180 - -90 - - 180 - -90 - - 180 - 90 - - -180 - 90 - - -180 - -90 properties: type: object title: Item Properties description: >- MAY contain additional properties other than the required property `datetime`, e.g. custom properties or properties from the STAC specification or STAC extensions. required: - datetime additionalProperties: true properties: datetime: title: Date and Time description: >- The searchable date/time of the data, in UTC. Formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. If this field is set to `null` (usually for larger time ranges), it is STRONGLY RECOMMENDED to specify both `start_datetime` and `end_datetime` for STAC compliance. type: string format: date-time nullable: true start_datetime: type: string format: date-time description: >- For time series: The first or start date and time for the data, in UTC. Formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. end_datetime: type: string format: date-time description: >- For time series: The last or end date and time for the data, in UTC. Formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. title: $ref: '#/components/schemas/eo_title' description: $ref: '#/components/schemas/eo_description' license: $ref: '#/components/schemas/stac_license' providers: $ref: '#/components/schemas/stac_providers' created: $ref: '#/components/schemas/created' updated: $ref: '#/components/schemas/updated' queued: $ref: '#/components/schemas/queued' started: $ref: '#/components/schemas/started' expires: $ref: '#/components/schemas/expires' unpublished: $ref: '#/components/schemas/unpublished' 'openeo:status': $ref: '#/components/schemas/result_status' assets: $ref: '#/components/schemas/stac_assets' links: type: array description: |- Links related to this batch job result, e.g. a link to an invoice, additional log files or external documentation. The links MUST NOT contain links to the processed and downloadable data. Instead specify these in the `assets` property. Clients MUST NOT download the data referenced in the links by default. It is **strongly recommended** to add a link with relation type `canonical` pointing to this STAC document using a signed URL. Note that query parameters that influence the response of the current request (like `partial`) MUST also be included or encoded within the signed URL in order to give a consistent response when the signed URL is used. This signed URL allows consumption of the STAC metadata by (possibly non-openEO) clients and tools without additional authentication steps. It is recommended to regenerate the signed URL (and its expiry) with each request. For relation types see the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). items: $ref: '#/components/schemas/link' example: - rel: canonical type: application/geo+json href: https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/item.json file_format: x-additionalPropertiesName: File Format Name title: File Format type: object description: Describes a specific file format. required: - gis_data_types - parameters properties: title: $ref: '#/components/schemas/object_title' description: $ref: '#/components/schemas/description' gis_data_types: type: array description: >- Specifies the supported GIS spatial data types for this format. It is RECOMMENDED to specify at least one of the data types, which will likely become a requirement in a future API version. # minItems: 1 items: type: string enum: - raster - vector - table - pointcloud - other deprecated: $ref: '#/components/schemas/deprecated' experimental: $ref: '#/components/schemas/experimental' parameters: title: File Format Parameters description: Specifies the supported parameters for this file format. type: object additionalProperties: $ref: '#/components/schemas/resource_parameter' links: type: array description: |- Links related to this file format, e.g. external documentation. For relation types see the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). items: $ref: '#/components/schemas/link' production: type: boolean description: >- Specifies whether the implementation is ready to be used in production use (`true`) or not (`false`). Clients SHOULD only connect to non-production implementations if the user explicitly confirmed to use a non-production implementation. This flag is part of `GET /.well-known/openeo` and `GET /`. It MUST be used consistently in both endpoints. default: false links_pagination: description: |- Links related to this list of resources, for example links for pagination or alternative formats such as a human-readable HTML version. The links array MUST NOT be paginated. If pagination is implemented, the following `rel` (relation) types apply: 1. `next` (REQUIRED): A link to the next page, except on the last page. 2. `prev` (OPTIONAL): A link to the previous page, except on the first page. 3. `first` (OPTIONAL): A link to the first page, except on the first page. 4. `last` (OPTIONAL): A link to the last page, except on the last page. For additional relation types see also the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). type: array items: $ref: '#/components/schemas/link' link: title: Link description: >- A link to another resource on the web. Bases on [RFC 5899](https://www.rfc-editor.org/rfc/rfc5988.html). type: object required: - href - rel properties: rel: type: string description: >- Relationship between the current document and the linked document. SHOULD be a [registered link relation type](https://www.iana.org/assignments/link-relations/link-relations.xml) whenever feasible. example: related href: type: string description: The value MUST be a valid URL. format: uri example: 'https://openeo.example' type: type: string description: >- The value MUST be a string that hints at the format used to represent data at the provided URI, preferably a media (MIME) type. example: text/html title: type: string description: Used as a human-readable label for a link. example: openEO asset: title: STAC Asset type: object required: - href properties: href: title: Asset location description: >- URL to the downloadable asset. The URLs SHOULD be available without authentication so that external clients can download them easily. If the data is confidential, signed URLs SHOULD be used to protect against unauthorized access from third parties. type: string title: description: The displayed title for clients and users. type: string description: type: string format: commonmark description: |- Multi-line description to explain the asset. [CommonMark 0.29](http://commonmark.org/) syntax MAY be used for rich text representation. type: title: Media Type description: Media type of the asset. type: string example: image/tiff; application=geotiff roles: type: array items: type: string description: |- Purposes of the asset. Can be any value, but commonly used values are: * `thumbnail`: A visualization of the data, usually a lower-resolution true color image in JPEG or PNG format. * `reproducibility`: Information how the data was produced and/or can be reproduced, e.g. the process graph used to compute the data in JSON format. * `data`: The computed data in the format specified by the user in the process graph (applicable in `GET /jobs/{job_id}/results` only). * `metadata`: Additional metadata available for the computed data. example: - data money: description: >- An amount of money or credits. The value MUST be specified in the currency the back-end is working with. The currency can be retrieved by calling `GET /`. If no currency is set, this field MUST be `null`. type: number minimum: 0 example: 12.98 nullable: true default: null budget: type: number minimum: 0 nullable: true description: |- Maximum amount of costs the request is allowed to produce. The value MUST be specified in the currency of the back-end. No limits apply, if the value is `null` or the back-end has no currency set in `GET /`. example: 100 default: null budget_update: type: number minimum: 0 nullable: true description: |- Maximum amount of costs the request is allowed to produce. The value MUST be specified in the currency of the back-end. No limits apply, if the value is `null`. example: 100 billing_plan: type: string description: |- The billing plan to process and charge the job or service with. Billing plans MUST be handled in a *case insensitive* manner. The plans can be retrieved from `GET /`, but the value returned here may not be in the list of plans any longer. example: free billing_plan_null: type: string description: |- The billing plan to process and charge the job or service with. Billing plans MUST be accepted in a *case insensitive* manner. Back-ends MUST resolve the billing plan in the following way if billing is supported: * If a value is given and it is not `null`: Persist the `plan` that has been provided in the request. * Otherwise, do not change the billing plan. Billing plans not on the list of available plans MUST be rejected with openEO error `BillingPlanInvalid`. example: free nullable: true billing_plan_null_default: type: string description: |- The billing plan to process and charge the job or service with. Billing plans MUST be accepted in a *case insensitive* manner. Back-ends MUST resolve the billing plan in the following way: * If a non-`null` value is given: Persist the `plan` that has been provided in the request. * Otherwise: 1. Persist the `default_plan` exposed through `GET /me`, if available. 2. Persist the `default_plan` exposed through `GET /`, if available. 3. If a single plan is exposed by the back-end, persist it. 4. Otherwise, the back-end MUST throw a `BillingPlanMissing` error. The resolved plan MUST be persisted permanently, regardless of any changes to the exposed billing plans in `GET /` in the future. Billing plans not on the list of available plans MUST be rejected with openEO error `BillingPlanInvalid`. example: free nullable: true default: null storage_quota_free: type: integer description: >- Free storage space in bytes, which is still available to the user. Effectively, this is the disk quota minus the used space by the user, e.g. user-uploaded files and job results. example: 536870912 max_storage_quota: type: integer description: >- Maximum storage space (disk quota) in bytes available to the user. example: 1073741824 collection: title: Collection type: object required: - stac_version - id - description - license - extent - links properties: stac_version: $ref: '#/components/schemas/stac_version' stac_extensions: $ref: '#/components/schemas/stac_extensions' type: type: string enum: - Collection description: >- For STAC versions >= 1.0.0-rc.1 this field is required. id: $ref: '#/components/schemas/collection_id' title: type: string description: A short descriptive one-line title for the collection. description: type: string format: commonmark description: >- Detailed multi-line description to explain the collection. [CommonMark 0.29](http://commonmark.org/) syntax MAY be used for rich text representation. keywords: type: array description: List of keywords describing the collection. items: type: string version: type: string description: |- Version of the collection. This property REQUIRES to add `version` (STAC < 1.0.0-rc.1) or `https://stac-extensions.github.io/version/v1.2.0/schema.json` (STAC >= 1.0.0-rc.1) to the list of `stac_extensions`. deprecated: type: boolean default: false description: |- Specifies that the collection is deprecated with the potential to be removed. It should be transitioned out of usage as soon as possible and users should refrain from using it in new projects. A link with relation type `latest-version` SHOULD be added to the links and MUST refer to the collection that can be used instead. This property REQUIRES to add `version` (STAC < 1.0.0-rc.1) or `https://stac-extensions.github.io/version/v1.2.0/schema.json` (STAC >= 1.0.0-rc.1) to the list of `stac_extensions`. license: $ref: '#/components/schemas/stac_license' providers: $ref: '#/components/schemas/stac_providers' extent: type: object title: Collection Extent description: |- The extent of the data in the collection. Additional members MAY be added to represent other extents, for example, thermal or pressure ranges. The first item in the array always describes the overall extent of the data. All subsequent items describe more preciseextents, e.g. to identify clusters of data. Clients only interested in the overall extent will only need to access the first item in each array. required: - spatial - temporal properties: spatial: title: Collection Spatial Extent description: >- The *potential* spatial extents of the features in the collection. type: object properties: bbox: description: |- One or more bounding boxes that describe the spatial extent of the dataset. The first bounding box describes the overall spatial extent of the data. All subsequent bounding boxes describe more precise bounding boxes, e.g. to identify clusters of data. Clients only interested in the overall spatial extent will only need to access the first item in each array. type: array minItems: 1 items: $ref: '#/components/schemas/bbox' temporal: title: Collection Temporal Extent description: >- The *potential* temporal extents of the features in the collection. type: object properties: interval: description: |- One or more time intervals that describe the temporal extent of the dataset. The first time interval describes the overall temporal extent of the data. All subsequent time intervals describe more precise time intervals, e.g. to identify clusters of data. Clients only interested in the overall extent will only need to access the first item in each array. type: array minItems: 1 items: description: |- Begin and end times of the time interval. The coordinate reference system is the Gregorian calendar. The value `null` is supported and indicates an open time interval. type: array minItems: 2 maxItems: 2 items: type: string format: date-time nullable: true example: - '2011-11-11T12:22:11Z' - null links: description: |- Links related to this collection. Could reference to licensing information, other meta data formats with additional information or a preview image. Providing links with the following `rel` (relation) types is RECOMMENDED: 1. `root` and `parent`: URL to the data discovery endpoint at `/collections`. 2. `license`: A link to the license(s) SHOULD be specified if the `license` field is set to `proprietary` or `various`. 3. `example`: Links to examples of processes that use this collection. 4. `latest-version`: If a collection has been marked as deprecated, a link SHOULD point to the latest version of the collection. The relation types `predecessor-version` (link to older version) and `successor-version` (link to newer version) can also be used to show the relation between versions. 5. `alternate`: An alternative representation of the collection. For example, this could be the collection available through another catalog service such as OGC CSW, a human-readable HTML version or a metadata document following another standard such as ISO 19115 or DCAT. 6. `http://www.opengis.net/def/rel/ogc/1.0/queryables`: URL to the queryables endpoint at `/collections/{collection_id}/queryables`. For JSON Schema documents, the `type` field must be set to `application/schema+json`. For additional relation types see also the lists of [common relation types in openEO](#section/API-Principles/Web-Linking) and the STAC specification for Collections. type: array items: $ref: '#/components/schemas/link' 'cube:dimensions': title: STAC Collection Cube Dimensions description: |- The named default dimensions of the data cube. Names must be unique per collection. The keys of the object are the dimension names. For interoperability, it is RECOMMENDED to use the following dimension names if there is only a single dimension with the specified criteria: * `x` for the dimension of type `spatial` with the axis set to `x` * `y` for the dimension of type `spatial` with the axis set to `y` * `z` for the dimension of type `spatial` with the axis set to `z` * `t` for the dimension of type `temporal` * `bands` for dimensions of type `bands` * `geometry` for dimensions of type `geometry` This property REQUIRES to add a version of the data cube extension to the list of `stac_extensions`, e.g. `https://stac-extensions.github.io/datacube/v2.2.0/schema.json`. type: object additionalProperties: x-additionalPropertiesName: Dimension Name allOf: - $ref: '#/components/schemas/dimension' summaries: title: STAC Summaries (Collection Properties) description: |- Collection properties from STAC extensions (e.g. EO, SAR, Satellite or Scientific) or even custom extensions. Summaries are either a unique set of all available values, statistics *or* a JSON Schema. Statistics only specify the range (minimum and maximum values) by default, but can optionally be accompanied by additional statistical values. The range can specify the potential range of values, but it is recommended to be as precise as possible. The set of values MUST contain at least one element and it is strongly RECOMMENDED to list all values. It is recommended to list as many properties as reasonable so that consumers get a full overview of the Collection. Properties that are covered by the Collection specification (e.g. `providers` and `license`) SHOULD NOT be repeated in the summaries. Potential fields for the summaries can be found here: * **[STAC Common Metadata](https://github.com/radiantearth/stac-spec/blob/v1.1.0/commons/common-metadata.md)**: A list of commonly used fields throughout all domains * **[Content Extensions](https://stac-extensions.github.io)**: Domain-specific fields for domains such as EO, SAR and point clouds. * **Custom Properties**: It is generally allowed to add custom fields. type: object additionalProperties: oneOf: - type: array title: Set of values items: description: A value of any type. - $ref: '#/components/schemas/collection_summary_stats' - $ref: '#/components/schemas/json_schema' assets: description: |- Dictionary of asset objects for data that can be downloaded, each with a unique key. The keys MAY be used by clients as file names. allOf: - $ref: '#/components/schemas/stac_assets' stac_version: type: string description: >- The [version of the STAC specification](https://github.com/radiantearth/stac-spec/releases), which MAY not be equal to the [STAC API version](#tag/EO-Data-Discovery/STAC). The openEO API allows for the STAC versions 1.x.x (RECOMMENDED) and 0.9.x (DEPRECATED). pattern: '^(0\.9.\d+|1\.\d+.\d+)' example: 1.1.0 stac_extensions: type: array description: >- A list of implemented STAC extensions. The list contains URLs to the JSON Schema files it can be validated against. uniqueItems: true items: anyOf: - title: Reference to a JSON Schema type: string format: uri example: 'https://openeo.example/stac/custom-extemsion/v1.0.0/schema.json' - title: Reference to a core extension (STAC < 1.0.0-rc.1 only, DEPRECATED) type: string example: datacube stac_license: type: string description: |- License(s) of the data as a SPDX [License identifier](https://spdx.org/licenses/). Alternatively, use `proprietary` if the license is not on the SPDX license list or `various` if multiple licenses apply. In these two cases links to the license texts SHOULD be added, see the `license` link relation type. Non-SPDX licenses SHOULD add a link to the license text with the `license` relation in the links section. The license text MUST NOT be provided as a value of this field. If there is no public license URL available, it is RECOMMENDED to host the license text and link to it. example: Apache-2.0 stac_providers: type: array description: >- A list of providers, which MAY include all organizations capturing or processing the data or the hosting provider. Providers SHOULD be listed in chronological order with the most recent provider being the last element of the list. items: type: object title: Provider required: - name properties: name: description: The name of the organization or the individual. type: string example: Example Cloud Corp. description: description: >- Multi-line description to add further provider information such as processing details for processors and producers, hosting details for hosts or basic contact information. CommonMark 0.29 syntax MAY be used for rich text representation. type: string example: No further processing applied. roles: description: |- Roles of the provider. The provider's role(s) can be one or more of the following elements: * `licensor`: The organization that is licensing the dataset under the license specified in the collection's license field. * `producer`: The producer of the data is the provider that initially captured and processed the source data, e.g. ESA for Sentinel-2 data. * `processor`: A processor is any provider who processed data to a derived product. * `host`: The host is the actual provider offering the data on their storage. There SHOULD be no more than one host, specified as last element of the list. type: array items: type: string enum: - producer - licensor - processor - host example: - producer - licensor - host url: description: >- Homepage on which the provider describes the dataset and publishes contact information. type: string format: uri example: https://cloud.example stac_assets: type: object title: Assets description: |- Dictionary of asset objects for data that can be downloaded, each with a unique key. The keys MAY be used by clients as file names. additionalProperties: $ref: '#/components/schemas/asset' example: preview.png: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/preview.png' type: image/png title: Thumbnail roles: - thumbnail process.json: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/process.json' type: application/json title: Original Process roles: - process - reproduction 1.tif: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/1.tif' type: image/tiff; application=geotiff title: Band 1 roles: - data 2.tif: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/2.tif' type: image/tiff; application=geotiff title: Band 2 roles: - data inspire.xml: href: 'https://openeo.example/api/v1/download/583fba8b2ce583fba8b2ce/inspire.xml' type: application/xml title: INSPIRE metadata description: INSPIRE compliant XML metadata roles: - metadata collection_summary_stats: type: object title: Statistics / Range description: >- By default, only ranges with a minimum and a maximum value can be specified. Ranges can be specified for ordinal values only, which means they need to have a rank order. Therefore, ranges can only be specified for numbers and some special types of strings. Examples: grades (A to F), dates or times. Implementors are free to add other derived statistical values to the object, for example `mean` or `stddev`. required: - minimum - maximum properties: minimum: description: The minimum value (inclusive). anyOf: - type: string - type: number maximum: description: The maximum value (inclusive). anyOf: - type: string - type: number bbox: description: |- Each bounding box is provided as four or six numbers, depending on whether the coordinate reference system includes a vertical axis (height or depth): * West (lower left corner, coordinate axis 1) * South (lower left corner, coordinate axis 2) * Base (optional, minimum value, coordinate axis 3) * East (upper right corner, coordinate axis 1) * North (upper right corner, coordinate axis 2) * Height (optional, maximum value, coordinate axis 3) The coordinate reference system of the values is WGS 84 longitude/latitude (http://www.opengis.net/def/crs/OGC/1.3/CRS84). For WGS 84 longitude/latitude the values are in most cases the sequence of minimum longitude, minimum latitude, maximum longitude and maximum latitude. However, in cases where the box spans the antimeridian the first value (west-most box edge) is larger than the third value (east-most box edge). If the vertical axis is included, the third and the sixth number are the bottom and the top of the 3-dimensional bounding box. type: array oneOf: - title: 4 elements minItems: 4 maxItems: 4 - title: 6 elements minItems: 6 maxItems: 6 items: type: number example: - -180 - -90 - 180 - 90 collection_id: type: string description: >- A unique identifier for the collection, which MUST match the specified pattern. pattern: '^[\w\-\.~\/]+$' example: Sentinel-2A dimension: title: Dimension description: A dimension, each object represents a distinct dimension with the key being the dimension name. type: object required: - type properties: type: description: Type of the dimension. type: string enum: - spatial - temporal - bands - geometry - other description: $ref: '#/components/schemas/description' discriminator: propertyName: type mapping: spatial: '#/components/schemas/dimension_spatial' temporal: '#/components/schemas/dimension_temporal' bands: '#/components/schemas/dimension_bands' geometry: '#/components/schemas/dimension_geometry' other: '#/components/schemas/dimension_other' dimension_other: allOf: - $ref: '#/components/schemas/dimension' - title: Additional Dimension type: object # This is not supported by ReDoc yet: # oneOf: # - title: Additional Dimension with Extent # required: # - extent # - title: Additional Dimension with Values # required: # - values properties: extent: $ref: '#/components/schemas/collection_dimension_extent_open' values: $ref: '#/components/schemas/collection_dimension_values' step: $ref: '#/components/schemas/collection_dimension_step' unit: $ref: '#/components/schemas/collection_dimension_unit' reference_system: description: The reference system for the dimension. type: string dimension_geometry: allOf: - $ref: '#/components/schemas/dimension' - title: Geometry Dimension type: object required: - bbox properties: axes: description: Axes of the vector dimension as an ordered set of `x`, `y` and `z`. Defaults to `x` and `y`. default: - 'x' - 'y' type: array uniqueItems: true items: $ref: '#/components/schemas/dimension_axis_xyz' bbox: $ref: '#/components/schemas/bbox' values: description: Optionally, a representation of the vectors. This can be a list of WKT string or other free-form identifiers. type: array items: type: string geometry_types: description: A set of all geometry types included in this dimension. If not present, mixed geometry types must be assumed. type: array uniqueItems: true items: $ref: '#/components/schemas/geometry_type' reference_system: $ref: '#/components/schemas/collection_dimension_srs' dimension_bands: allOf: - $ref: '#/components/schemas/dimension' - title: Band Dimension description: |- A dimension for the bands. The band dimension only specifies the band names as dimension labels. Further information to the bands are available in either `sar:bands` or `eo:bands` in the `summaries` property. type: object required: - values properties: values: $ref: '#/components/schemas/collection_dimension_values' dimension_spatial: allOf: - $ref: '#/components/schemas/dimension' - title: Spatial Dimension description: A spatial (raster) dimension in one of the horizontal (x or y) or vertical (z) directions. type: object required: - axis properties: axis: $ref: '#/components/schemas/dimension_axis_xyz' extent: description: >- Extent (lower and upper bounds) of the dimension as two-dimensional array. Open intervals with `null` are not allowed. type: array minItems: 2 maxItems: 2 items: type: number values: description: 'A set of all potential values.' type: array minItems: 1 items: type: number step: $ref: '#/components/schemas/collection_dimension_step' reference_system: $ref: '#/components/schemas/collection_dimension_srs' discriminator: propertyName: axis mapping: x: '#/components/schemas/dimension_spatial_horizontal' y: '#/components/schemas/dimension_spatial_horizontal' z: '#/components/schemas/dimension_spatial_vertical' dimension_axis_xyz: title: Axis description: Axis of a geometry or dimension (`x`, `y` or `z`) type: string enum: - 'x' - 'y' - 'z' dimension_spatial_horizontal: allOf: - $ref: '#/components/schemas/dimension_spatial' - title: Horizontal Spatial Dimension required: - extent dimension_spatial_vertical: allOf: - $ref: '#/components/schemas/dimension_spatial' - title: Vertical Spatial Dimension anyOf: - title: Vertical Spatial Dimension with Extent required: - extent - title: Vertical Spatial Dimension with Values required: - values dimension_temporal: allOf: - $ref: '#/components/schemas/dimension' - title: Temporal Dimension description: >- A temporal dimension based on the ISO 8601 standard. The temporal reference system for the data is expected to be ISO 8601 compliant (Gregorian calendar / UTC). Data not compliant with ISO 8601 can be represented as an *Additional Dimension Object* with `type` set to `temporal`. type: object required: - extent properties: values: description: >- If the dimension consists of set of specific values they can be listed here. The dates and/or times MUST be strings compliant to [ISO 8601](https://en.wikipedia.org/wiki/ISO_8601). type: array minItems: 1 items: type: string extent: description: >- Extent (lower and upper bounds) of the dimension as two-dimensional array. The dates and/or times MUST be strings compliant to [ISO 8601](https://en.wikipedia.org/wiki/ISO_8601). `null` is allowed for open date ranges. type: array minItems: 2 maxItems: 2 items: type: string nullable: true step: description: >- The space between the temporal instances as an [ISO 8601 Duration](https://en.wikipedia.org/wiki/ISO_8601#Durations), e.g. `P1D`. Use `null` for irregularly spaced steps. type: string nullable: true collection_dimension_srs: title: Spatial reference system description: >- The spatial reference system for the data, specified as [EPSG code](http://www.epsg-registry.org/), [WKT2 (ISO 19162) string](http://docs.opengeospatial.org/is/18-010r7/18-010r7.html), [PROJJSON object](https://proj.org/specifications/projjson.html) or [PROJ definition (deprecated)](https://proj.org/usage/quickstart.html). Defaults to EPSG code 4326. default: 4326 oneOf: - type: number title: EPSG code - type: string title: WKT2 or PROJ definition (deprecated) - type: object title: PROJJSON collection_dimension_extent_open: description: >- If the dimension consists of [ordinal](https://en.wikipedia.org/wiki/Level_of_measurement#Ordinal_scale) values, the extent (lower and upper bounds) of the values as two-dimensional array. Use `null` for open intervals. type: array minItems: 2 maxItems: 2 items: type: number nullable: true collection_dimension_values: description: >- A set of all potential values, especially useful for [nominal](https://en.wikipedia.org/wiki/Level_of_measurement#Nominal_level) values. **Important:** The order of the values MUST be exactly how the dimension values are also ordered in the data (cube). If the values specify band names, the values MUST be in the same order as they are in the corresponding band fields (i.e. `eo:bands` or `sar:bands`). type: array minItems: 1 items: oneOf: - type: number - type: string collection_dimension_step: description: >- If the dimension consists of [interval](https://en.wikipedia.org/wiki/Level_of_measurement#Interval_scale) values, the space between the values. Use `null` for irregularly spaced steps. type: number nullable: true collection_dimension_unit: description: >- The unit of measurement for the data, preferably compliant to [UDUNITS-2](https://ncics.org/portfolio/other-resources/udunits2/) units (singular). type: string process_arguments: title: Process Arguments type: object additionalProperties: $ref: '#/components/schemas/process_argument_value' process_argument_value: title: Process Argument Value description: Arguments for a process. See the API documentation for more information. anyOf: - type: object nullable: true title: Object (restricted) properties: from_parameter: not: {} from_node: not: {} process_graph: not: {} - type: string title: String - type: number title: Number (incl. integers) - type: boolean title: Boolean - type: array title: Array items: $ref: '#/components/schemas/process_argument_value' - $ref: '#/components/schemas/process_graph_with_metadata' - type: object title: Result Reference description: Data that is expected to be passed from another process. required: - from_node properties: from_node: description: The ID of the node that data is expected to come from. type: string additionalProperties: false - type: object title: Parameter Reference description: >- A parameter for a process graph. Data that is expected to be passed to a process graph either from the user directly or from the process that is executing the process graph. required: - from_parameter properties: from_parameter: description: The name of the parameter that data is expected to come from. type: string additionalProperties: false process_graph: title: Process Graph description: >- A process graph defines a graph-like structure as a connected set of executable processes. Each key is a unique identifier (node ID) that is used to refer to the process in the graph. type: object additionalProperties: x-additionalPropertiesName: Node ID title: Process Node type: object required: - process_id - arguments properties: process_id: $ref: '#/components/schemas/process_id' namespace: $ref: '#/components/schemas/process_namespace' result: type: boolean description: >- Used to specify which node is the last in the chain and returns the result to return to the requesting context. This flag MUST only be set once in each list of process nodes. default: false description: description: Optional description about the process and its arguments. type: string nullable: true arguments: $ref: '#/components/schemas/process_arguments' example: dc: process_id: load_collection arguments: id: Sentinel-2 spatial_extent: west: 16.1 east: 16.6 north: 48.6 south: 47.2 temporal_extent: - '2018-01-01' - '2018-02-01' bands: process_id: filter_bands description: >- Filter and order the bands. The order is important for the following reduce operation. arguments: data: from_node: dc bands: - B08 - B04 - B02 evi: process_id: reduce description: >- Compute the EVI. Formula: 2.5 * (NIR - RED) / (1 + NIR + 6*RED + -7.5*BLUE) arguments: data: from_node: bands dimension: bands reducer: process_graph: nir: process_id: array_element arguments: data: from_parameter: data index: 0 red: process_id: array_element arguments: data: from_parameter: data index: 1 blue: process_id: array_element arguments: data: from_parameter: data index: 2 sub: process_id: subtract arguments: data: - from_node: nir - from_node: red p1: process_id: product arguments: data: - 6 - from_node: red p2: process_id: product arguments: data: - -7.5 - from_node: blue sum: process_id: sum arguments: data: - 1 - from_node: nir - from_node: p1 - from_node: p2 div: process_id: divide arguments: data: - from_node: sub - from_node: sum p3: process_id: product arguments: data: - 2.5 - from_node: div result: true mintime: process_id: reduce description: Compute a minimum time composite by reducing the temporal dimension arguments: data: from_node: evi dimension: temporal reducer: process_graph: min: process_id: min arguments: data: from_parameter: data result: true save: process_id: save_result arguments: data: from_node: mintime format: GTiff result: true process: title: Process type: object properties: id: $ref: '#/components/schemas/process_id' summary: $ref: '#/components/schemas/process_summary' description: $ref: '#/components/schemas/process_description' categories: $ref: '#/components/schemas/process_categories' parameters: $ref: '#/components/schemas/process_parameters' returns: $ref: '#/components/schemas/process_return_value' deprecated: $ref: '#/components/schemas/deprecated' experimental: $ref: '#/components/schemas/experimental' exceptions: $ref: '#/components/schemas/process_exceptions' examples: type: array description: Examples, may be used for unit tests. items: title: Process Example type: object required: - arguments properties: title: type: string description: A title for the example. description: $ref: '#/components/schemas/process_description' arguments: $ref: '#/components/schemas/process_arguments' returns: description: The return value which can by of any data type. links: type: array description: |- Links related to this process, e.g. additional external documentation. Providing links with the following `rel` (relation) types is RECOMMENDED: 1. `latest-version`: If a process has been marked as deprecated, a link SHOULD point to the preferred version of the process. The relation types `predecessor-version` (link to older version) and `successor-version` (link to newer version) can also be used to show the relation between versions. 2. `version-history`: A link to a changelog and/or a list of versions of the process (see also the relation types `latest-version` etc.). 3. `example`: Links to examples of other processes that use this process. 4. `cite-as`: For all DOIs associated with the process, the respective DOI links SHOULD be added. 5. `license`: Links to applicable license(s). The link titles should reflect the license names. 6. `author`: Links to authors of the process. The `href` can use the `mailto:` protocol to link to an email address. The link titles should reflect the author names and affiliations. 7. `canonical`: Points to a publicly accessible and more long-lived URL. For additional relation types see also the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). items: $ref: '#/components/schemas/link' process_graph: $ref: '#/components/schemas/process_graph' user_defined_process_meta: title: User-defined Process Metadata description: A user-defined process, may only contain metadata and no process graph. type: object required: - id properties: summary: type: string nullable: true description: type: string nullable: true parameters: type: array nullable: true items: {} returns: type: object nullable: true allOf: - $ref: '#/components/schemas/process' process_graph_with_metadata: title: Process Graph with metadata description: A process graph, optionally enriched with process metadata. type: object required: - process_graph properties: id: type: string nullable: true summary: type: string nullable: true description: type: string nullable: true parameters: type: array nullable: true items: {} returns: type: object nullable: true allOf: - $ref: '#/components/schemas/process' process_namespace: type: string nullable: true default: null example: null description: |- The namespace the `process_id` is valid for. The following options are predefined by the openEO API, but additional namespaces may be introduced by back-ends or in a future version of the API. * `null` (default): Checks both user-defined and predefined processes, but prefers user-defined processes if both are available. This allows users to add missing predefined processes for portability, e.g. common processes from [processes.openeo.org](https://processes.openeo.org) that have a process graph included. Logging the namespace selected by the back-end for debugging purposes is RECOMMENDED. * `backend`: Uses exclusively the predefined processes listed at `GET /processes`. * `user`: Uses exclusively the user-defined processes listed at `GET /process_graphs`. If multiple processes with the same identifier exist, Clients SHOULD inform the user that it's recommended to select a namespace. process_id: type: string description: |- The identifier for the process. It MUST be unique across its namespace (e.g. predefined processes or user-defined processes). Clients SHOULD warn the user if a user-defined process is added with the same identifier as one of the predefined process. pattern: '^\w+$' example: ndvi process_summary: type: string description: A short summary of what the process does. process_categories: type: array description: A list of categories. items: type: string description: Name of the category. process_return_value: type: object title: Process Return Value description: Description of the data that is returned by this process. required: - schema properties: description: $ref: '#/components/schemas/process_description' schema: $ref: '#/components/schemas/process_schema' experimental: type: boolean description: >- Declares that the specified entity is experimental, which means that it is likely to change or may produce unpredictable behavior. Users should refrain from using it in production, but still feel encouraged to try it out and give feedback. default: false deprecated: type: boolean description: |- Declares that the specified entity is deprecated with the potential to be removed in any of the next versions. It should be transitioned out of usage as soon as possible and users should refrain from using it in new implementations. default: false process_exceptions: type: object title: Process Exceptions description: |- Declares exceptions (errors) that might occur during execution of this process. This list is just for informative purposes and may be incomplete. This list MUST only contain exceptions that stop the execution of a process and MUST NOT contain warnings, notices or debugging messages. It is meant to primarily contain errors that have been caused by the user. It is RECOMMENDED that exceptions are referred to and explained in process or parameter descriptions. The keys define the error code and MUST match the following pattern: `^\w+$` This schema follows the schema of the general openEO error list (see errors.json). additionalProperties: x-additionalPropertiesName: Error Code title: Process Exception type: object required: - message properties: description: type: string format: commonmark description: |- Detailed description to explain the error to client users and back-end developers. This should not be shown in the clients directly, but MAY be linked to in the errors `url` property. [CommonMark 0.29](http://commonmark.org/) syntax MAY be used for rich text representation. message: type: string description: >- Explains the reason the server is rejecting the request. This message is intended to be displayed to the client user. For "4xx" error codes the message SHOULD explain shortly how the client needs to modify the request. The message MAY contain variables, which are enclosed by curly brackets. Example: `{variable_name}` example: >- The value specified for the process argument '{argument}' in process '{process}' is invalid: {reason} http: type: integer description: >- HTTP Status Code, following the [error handling conventions in openEO](#section/API-Principles/Error-Handling). Defaults to `400`. default: 400 process_parameters: type: array description: |- A list of parameters. The order in the array corresponds to the parameter order to be used in clients that do not support named parameters. **Note:** Specifying an empty array is different from (if allowed) `null` or the property being absent. An empty array means the process has no parameters. `null` / property absent means that the parameters are unknown as the user has not specified them. There could still be parameters in the process graph, if one is specified. items: $ref: '#/components/schemas/process_parameter' base_parameter: type: object required: - name - description properties: name: type: string description: |- A unique name for the parameter. Using [snake case](https://en.wikipedia.org/wiki/Snake_case) (e.g. `window_size` or `scale_factor`) is RECOMMENDED. pattern: '^\w+$' description: $ref: '#/components/schemas/process_description' optional: type: boolean description: >- Determines whether this parameter is optional to be specified even when no default is specified. Clients SHOULD automatically set this parameter to `true`, if a default value is specified. Back-ends SHOULD NOT fail, if a default value is specified and this flag is missing. default: false deprecated: $ref: '#/components/schemas/deprecated' experimental: $ref: '#/components/schemas/experimental' default: description: >- The default value for this parameter. Required parameters SHOULD NOT specify a default value. Optional parameters SHOULD always specify a default value. parameter: title: Parameter type: object required: - schema properties: schema: $ref: '#/components/schemas/data_type_schema' allOf: - $ref: '#/components/schemas/base_parameter' process_parameter: title: Process Parameter type: object required: - schema properties: schema: $ref: '#/components/schemas/process_schema' allOf: - $ref: '#/components/schemas/base_parameter' batch_job: title: Batch Job description: >- The metadata of a batch jobs that has been submitted by the authenticated user. type: object required: - id - status - created properties: id: $ref: '#/components/schemas/job_id' title: $ref: '#/components/schemas/eo_title' description: $ref: '#/components/schemas/eo_description' process: $ref: '#/components/schemas/process_graph_with_metadata' status: type: string enum: - created - queued - running - canceled - finished - error description: |- The current status of a batch job. The following status changes can occur: * `POST /jobs`: The status is initialized as `created`. * `POST /jobs/{job_id}/results`: The status is set to `queued`, if processing does not start instantly. * Once the processing starts the status is set to `running`. * Once the data is available to download the status is set to `finished`. * Whenever an error occurs during processing, the status MUST be set to `error`. * `DELETE /jobs/{job_id}/results`: The status is set to `canceled` if the status was `running` beforehand and partial or preliminary results are available to be downloaded. Otherwise the status is set to `created`. The following state diagram shows the possible status changes: ![State diagram](assets/status-diagram.png) example: running default: created progress: type: number description: >- Indicates the process of a running batch job, in percent. Can also be set for a job which stopped due to an error or was canceled by the user. In this case, the value indicates the progress at which the job stopped. This property may not be available for the status codes `created` and `queued`. Submitted and queued jobs only allow the value `0`, finished jobs only allow the value `100`. minimum: 0 maximum: 100 example: 75.5 created: $ref: '#/components/schemas/created' updated: $ref: '#/components/schemas/updated' queued: $ref: '#/components/schemas/queued' started: $ref: '#/components/schemas/started' unpublished: $ref: '#/components/schemas/unpublished' plan: $ref: '#/components/schemas/billing_plan' costs: $ref: '#/components/schemas/money' budget: $ref: '#/components/schemas/budget' usage: description: |- Metrics about the resource usage of the batch job. Back-ends are not expected to update the metrics while processing data, so the metrics can only be available after the job has finished or has stopped due to an error. For usage metrics during processing, metrics can better be added to the logs (e.g. `GET /jobs/{job_id}/logs`) with the same schema. allOf: - $ref: '#/components/schemas/usage' log_level: $ref: '#/components/schemas/min_log_level_default' links: type: array description: |- Links related to this batch job such as links to invoices, log files or results. Providing links with the following `rel` (relation) types is RECOMMENDED: 1. `monitor`: If logs are available, a link to the [logs endpoint](#tag/Batch-Jobs/operation/debug-job). 2. `result`: If batch job results are available, a link to the [results endpoint](#tag/Batch-Jobs/operation/list-results). The relation types `monitor` and `result` may occur for various batch job states: 1. `created`: When the batch job was executed before and has been reset to `created` after an [update](#tag/Batch-Jobs/operation/update-job) there could still be results and logs available until they get discarded by [queueing the batch job again](#tag/Batch-Jobs/operation/start-job). 2. `finished`: The full log and results are expected to be available. 3. `error` / `canceled`: Partial results and logs may be available. For more relation types see the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). items: $ref: '#/components/schemas/link' example: - rel: result type: application/json title: Batch Job Results href: https://openeo.example/api/v1/jobs/123/logs - rel: result type: application/json title: Batch Job Logs href: https://openeo.example/api/v1/jobs/123/logs job_id: type: string description: >- Per-back-end unique identifier of the batch job, generated by the back-end during creation. MUST match the specified pattern. pattern: '^[\w\-\.~]+$' example: a3cca2b2aa1e3b5b created: type: string format: date-time description: >- Date and time of creation (for batch jobs: the status 'created' was set), formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. example: '2017-01-01T09:32:12Z' updated: type: string format: date-time description: >- Date and time of the last status change, formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. If the status is `error`, `canceled` or `finished`, this is the time when the job has ended. example: '2017-01-01T09:54:18Z' queued: type: string format: date-time description: >- Date and time of queueing the batch job (i.e., when the status 'queued' was set), formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. example: '2017-01-01T09:34:00Z' started: type: string format: date-time description: >- Date and time when the batch job started processing (i.e., when the status 'running' was set), formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. example: '2017-01-01T09:36:18Z' expires: type: string format: date-time description: >- Time in UTC until which the assets and this document are accessible via the signed URL that is provided with the relation type `canonical` in the links. Formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. After expiration, a document with new signed URLs can be retrieved through an authenticated request to this endpoint. example: '2017-02-01T09:54:18Z' unpublished: type: string format: date-time description: >- Time until which the batch job results are stored on the back-end, in UTC. Formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. example: '2018-01-01T09:54:18Z' description: type: string format: commonmark description: >- Detailed description to explain the entity. [CommonMark 0.29](http://commonmark.org/) syntax MAY be used for rich text representation. object_title: type: string description: >- A human-readable short title to be displayed to users **in addition** to the names specified in the keys. This property is only for better user experience so that users can understand the names better. Example titles could be `GeoTiff` for the key `GTiff` (for file formats) or `OGC Web Map Service` for the key `WMS` (for service types). The title MUST NOT be used in communication (e.g. in process graphs), although clients MAY translate the titles into the corresponding names. eo_title: description: A short description to easily distinguish entities. type: string nullable: true example: NDVI based on Sentinel-2 eo_description: type: string format: commonmark description: >- Detailed multi-line description to explain the entity. [CommonMark 0.29](http://commonmark.org/) syntax MAY be used for rich text representation. nullable: true example: Deriving minimum NDVI measurements over pixel time series of Sentinel-2 process_description: type: string format: commonmark description: >- Detailed description to explain the entity. [CommonMark 0.29](http://commonmark.org/) syntax MAY be used for rich text representation. In addition to the CommonMark syntax, clients can convert process IDs that are formatted as in the following example into links instead of code blocks: ``` ``process_id()`` ``` service: title: Secondary Web Service description: >- The metadata of a secondary web service that has been submitted by the authenticated user. type: object required: - id - enabled - type - url properties: id: $ref: '#/components/schemas/service_id' title: $ref: '#/components/schemas/eo_title' description: $ref: '#/components/schemas/eo_description' url: type: string format: uri description: >- URL at which the secondary web service is accessible. Does not necessarily need to be located within the API. example: 'https://openeo.example/wms/wms-a3cca9' type: $ref: '#/components/schemas/service_type' enabled: $ref: '#/components/schemas/service_enabled' process: $ref: '#/components/schemas/process_graph_with_metadata' configuration: $ref: '#/components/schemas/service_configuration' attributes: title: Secondary Web Service Attributes type: object description: >- Additional attributes of the secondary web service, e.g. available layers for a WMS instance based on the bands in the underlying GeoTiff. example: layers: - ndvi - evi created: $ref: '#/components/schemas/created' plan: $ref: '#/components/schemas/billing_plan' costs: $ref: '#/components/schemas/money' budget: $ref: '#/components/schemas/budget' usage: description: |- Metrics about the resource usage of the secondary web service. Back-ends are not expected to update the metrics in real-time. For detailed usage metrics for individual processing steps, metrics can be added to the logs (e.g. `GET /jobs/{job_id}/logs`) with the same schema. allOf: - $ref: '#/components/schemas/usage' log_level: $ref: '#/components/schemas/min_log_level_default' service_type: description: >- Definition of the service type to access result data. All available service types can be retrieved via `GET /service_types`. Service types MUST be accepted in a *case insensitive* manner. type: string example: wms service_configuration: type: object title: Service Configuration description: >- Map of configuration settings, i.e. the setting names supported by the secondary web service combined with actual values. See `GET /service_types` for supported configuration settings. For example, this could specify the required version of the service, visualization details or any other service dependent configuration. example: version: 1.3.0 service_enabled: type: boolean description: >- Describes whether a secondary web service is responding to requests (true) or not (false). Disabled services do not produce any costs. service_id: type: string description: >- A per-back-end unique identifier of the secondary web service, generated by the back-end during creation. MUST match the specified pattern. pattern: '^[\w\-\.~]+$' example: wms-a3cca9 resource_parameter: x-additionalPropertiesName: Parameter Name type: object title: Resource Parameter description: |- Describes a parameter for various resources (e.g. file formats, service types). The parameters are specified according to the [JSON Schema draft-07](http://json-schema.org/) specification. See the chapter ['Schemas' in 'Defining Processes'](#section/Processes/Defining-Processes) for more information. The following more complex JSON Schema keywords SHOULD NOT be used: `if`, `then`, `else`, `readOnly`, `writeOnly`, `dependencies`, `minProperties`, `maxProperties`, `patternProperties`. JSON Schemas SHOULD always be dereferenced (i.e. all `$refs` should be resolved). This allows clients to consume the schemas much better. Clients are not expected to support dereferencing `$refs`. Note: The specified schema is only a common subset of JSON Schema. Additional keywords MAY be used. required: - description properties: description: type: string description: A brief description of the parameter according to [JSON Schema draft-07](https://json-schema.org/draft-07/json-schema-validation.html#rfc.section.10.1). required: type: boolean description: Determines whether this parameter is mandatory. default: false experimental: $ref: '#/components/schemas/experimental' default: description: >- The default value represents what would be assumed by the consumer of the input as the value of the parameter if none is provided. The value MUST conform to the defined type for the parameter defined at the same level. For example, if type is string, then default can be "foo" but cannot be 1. See [JSON Schema draft-07](https://json-schema.org/draft-07/json-schema-validation.html#rfc.section.10.2). allOf: - $ref: '#/components/schemas/json_schema' error: title: General Error description: >- An error object declares additional information about a client-side or server-side error. See also: * [Error Handling](#section/API-Principles/Error-Handling) in the API in general. * [Common Error Codes](errors.json) type: object required: - code - message properties: id: type: string description: >- A back-end MAY add a unique identifier to the error response to be able to log and track errors with further non-disclosable details. A client could communicate this id to a back-end provider to get further information. example: 550e8400-e29b-11d4-a716-446655440000 code: $ref: '#/components/schemas/log_code' message: type: string description: >- A message explaining what the client may need to change or what difficulties the server is facing. example: Parameter 'sample' is missing. links: $ref: '#/components/schemas/log_links' log_code: type: string description: >- The code is either one of the standardized error codes or a custom code, for example specified by a user in the `inspect` process. example: SampleError log_links: description: |- Links related to this log entry / error, e.g. to a resource that provides further explanations. For relation types see the lists of [common relation types in openEO](#section/API-Principles/Web-Linking). type: array items: $ref: '#/components/schemas/link' example: - href: 'https://openeo.example/docs/errors/SampleError' rel: about log_level: description: |- The severity level of the log entry. The order of the levels is as follows (from low to high severity): `debug`, `info`, `warning`, `error`. The level `error` usually corresponds with critical issues that usually terminate the data processing. type: string enum: - error - warning - info - debug example: error min_log_level_default: description: |- The minimum severity level for log entries that the back-end stores for the processing request. The order of the levels is as follows (from low to high severity): `debug`, `info`, `warning`, `error`. That means if `warning` is set, the back-end will only store log entries with the level `warning` and `error`. The default minimum log level is `info`. Users need to specifically set this property to `debug` to capture *all* log entries. It is RECOMMENDED that users set the level at least to "warning" in production workflows. type: string enum: - error - warning - info - debug default: info example: warning min_log_level_update: description: |- Updates the minimum severity level for log entries that the back-end stores for the processing requests. The back-end does not need to update existing log entries. type: string enum: - error - warning - info - debug example: warning data_type_schema: title: Data Types description: Either a single data type or a list of data types. oneOf: - $ref: '#/components/schemas/process_json_schema' - title: Multiple data types description: A list of data types this parameter supports, specified as JSON Schemas. type: array minItems: 1 uniqueItems: true items: $ref: '#/components/schemas/process_json_schema' process_schema: title: Process Data types description: Either a single data type or a list of data types for process parameter or process return values. oneOf: - $ref: '#/components/schemas/process_json_schema' - title: Multiple data types description: A list of data types supported, specified as JSON Schemas. type: array minItems: 1 uniqueItems: true items: $ref: '#/components/schemas/process_json_schema' process_json_schema: type: object title: Single Data Type description: |- Specifies a data type supported by a parameter or return value. The data types are specified according to the [JSON Schema draft-07](http://json-schema.org/) specification. See the chapter ['Schemas' in 'Defining Processes'](#section/Processes/Defining-Processes) for more information. JSON Schemas SHOULD NOT contain `default`, `anyOf`, `oneOf`, `allOf` or `not` at the top-level of the schema. Instead specify each data type in a separate array element. The following more complex JSON Schema keywords SHOULD NOT be used: `if`, `then`, `else`, `readOnly`, `writeOnly`, `dependencies`, `minProperties`, `maxProperties`, `patternProperties`. JSON Schemas SHOULD always be dereferenced (i.e. all `$refs` should be resolved). This allows clients to consume the schemas much better. Clients are not expected to support dereferencing `$refs`. Note: The specified schema is only a common subset of JSON Schema. Additional keywords MAY be used. properties: subtype: type: string description: The allowed sub data type for a value. See the chapter on [subtypes](#section/Processes/Defining-Processes) for more information. deprecated: $ref: '#/components/schemas/deprecated' allOf: - $ref: '#/components/schemas/json_schema' oneOf: - title: Generic - $ref: '#/components/schemas/process_graph_json_schema' - $ref: '#/components/schemas/datacube_json_schema' process_graph_json_schema: title: Process Graph type: object properties: subtype: type: string enum: - process-graph parameters: type: array title: Process Graph Parameters description: |- A list of parameters passed to the child process graph. The order in the array corresponds to the parameter order to be used in clients that do not support named parameters. items: $ref: '#/components/schemas/parameter' returns: type: object title: Process Graph Return Value description: |- Description of the data that is returned by the child process graph. required: - schema properties: description: $ref: '#/components/schemas/process_description' schema: $ref: '#/components/schemas/data_type_schema' allOf: - $ref: '#/components/schemas/process_json_schema' datacube_json_schema: title: Datacube properties: subtype: type: string enum: - datacube dimensions: title: Datacube constraints description: |- Allows to specify requirements the data cube has to fulfill. Right now, it only allows to specify the dimension types and adds for specific dimension types: * axes for `spatial` dimensions in raster datacubes * geometry types for `geometry` dimensions in vector datacubes type: array items: type: object required: - type properties: type: type: string oneOf: - title: Spatial (raster) properties: type: type: string enum: - spatial axis: type: array minItems: 1 items: $ref: '#/components/schemas/dimension_axis_xyz' - title: Spatial (vector) properties: type: type: string enum: - geometry geometry_type: type: array minItems: 1 items: $ref: '#/components/schemas/geometry_type' - title: Other properties: type: type: string enum: - bands - temporal - other json_schema: type: object title: JSON Schema description: |- A JSON Schema compliant to [JSON Schema draft-07](https://json-schema.org/draft-07/json-schema-validation.html) or later. JSON Schemas SHOULD always be dereferenced (i.e. all `$refs` should be resolved). This allows clients to consume the schemas much better. Clients are not expected to support dereferencing `$refs`. Note: The specified schema in the OpenAPI document is only a common subset of JSON Schema. Additional keywords from the JSON Schema specification MAY be used. properties: $schema: description: |- The JSON Schema version. If not given in the context of openEO, defaults to JSON Schema draft-07: `http://json-schema.org/draft-07/schema#` The default value for `$schema` property may have to be added to the JSON Schema object before passing it to a JSON Schema validator. type: string format: uri default: http://json-schema.org/draft-07/schema# $id: description: ID of your JSON Schema. type: string format: uri type: description: |- The allowed data type(s) for a value. If this property is not present, all data types are allowed. oneOf: - $ref: '#/components/schemas/json_schema_type' - type: array minItems: 1 uniqueItems: true items: $ref: '#/components/schemas/json_schema_type' pattern: type: "string" format: "regex" description: The regular expression a string value must match against. enum: type: array items: {} description: An exclusive list of allowed values. minimum: type: number description: The minimum value (inclusive) allowed for a numerical value. maximum: type: number description: The maximum value (inclusive) allowed for a numerical value. minItems: type: number minimum: 0 default: 0 description: The minimum number of items required in an array. maxItems: type: number minimum: 0 description: The maximum number of items required in an array. items: description: Specifies schemas for the items in an array. anyOf: - type: array minItems: 1 items: $ref: '#/components/schemas/json_schema' - $ref: '#/components/schemas/json_schema' additionalProperties: description: >- Any other property supported by the JSON Schema version that is given through the property `$schema` are allowed. Defaults to JSON Schema [draft-07](https://json-schema.org/draft-07/json-schema-validation.html), but can also be any later version of JSON Schema. example: type: string enum: - a - b json_schema_type: type: string enum: - array - boolean - integer - 'null' - number - object - string file: title: Workspace File type: object required: - path properties: path: type: string description: |- Path of the file, relative to the root directory of the user's server-side workspace. MUST NOT start with a slash `/` and MUST NOT be url-encoded. The Windows-style path name component separator `\` is not supported, always use `/` instead. Note: The pattern only specifies a minimal subset of invalid characters. The back-ends MAY enforce additional restrictions depending on their OS/environment. example: folder/file.txt pattern: "^[^/\\r\\n\\t\\\\:'\"][^\\r\\n\\t\\\\:'\"]*$" size: type: integer description: File size in bytes. example: 1024 modified: type: string format: date-time description: >- Date and time the file has lastly been modified, formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. example: '2018-01-03T10:55:29Z' geometry_type: title: Geometry type type: string enum: - Point - MultiPoint - LineString - MultiLineString - Polygon - MultiPolygon - GeometryCollection GeoJsonPoint3D: type: array description: Point in 3D space minItems: 2 maxItems: 3 items: type: number GeoJsonPoint: type: object title: GeoJSON Point required: - type - coordinates properties: type: type: string enum: - Point coordinates: $ref: '#/components/schemas/GeoJsonPoint3D' GeoJsonGeometry: title: GeoJSON Geometry type: object required: - type properties: type: $ref: '#/components/schemas/geometry_type' discriminator: propertyName: type mapping: Point: '#/components/schemas/GeoJsonPoint' LineString: '#/components/schemas/GeoJsonLineString' Polygon: '#/components/schemas/GeoJsonPolygon' MultiPoint: '#/components/schemas/GeoJsonMultiPoint' MultiLineString: '#/components/schemas/GeoJsonMultiLineString' MultiPolygon: '#/components/schemas/GeoJsonMultiPolygon' GeometryCollection: '#/components/schemas/GeoJsonGeometryCollection' GeoJsonLineString: allOf: - $ref: '#/components/schemas/GeoJsonGeometry' - type: object title: GeoJSON LineString required: - coordinates properties: coordinates: type: array items: $ref: '#/components/schemas/GeoJsonPoint3D' GeoJsonPolygon: allOf: - $ref: '#/components/schemas/GeoJsonGeometry' - type: object title: GeoJSON Polygon required: - coordinates properties: coordinates: type: array items: type: array items: $ref: '#/components/schemas/GeoJsonPoint3D' GeoJsonMultiPoint: allOf: - $ref: '#/components/schemas/GeoJsonGeometry' - type: object title: GeoJSON MultiPoint required: - coordinates properties: coordinates: type: array items: $ref: '#/components/schemas/GeoJsonPoint3D' GeoJsonMultiLineString: allOf: - $ref: '#/components/schemas/GeoJsonGeometry' - type: object title: GeoJSON MultiLineString required: - coordinates properties: coordinates: type: array items: type: array items: $ref: '#/components/schemas/GeoJsonPoint3D' GeoJsonMultiPolygon: allOf: - $ref: '#/components/schemas/GeoJsonGeometry' - type: object title: GeoJSON MultiPolygon required: - coordinates properties: coordinates: type: array items: type: array items: type: array items: $ref: '#/components/schemas/GeoJsonPoint3D' GeoJsonGeometryCollection: allOf: - $ref: '#/components/schemas/GeoJsonGeometry' - type: object title: GeoJSON GeometryCollection required: - geometries properties: geometries: type: array items: $ref: '#/components/schemas/GeoJsonGeometry' log_entry: title: Log Entry description: >- An log message that communicates information about the processed data. type: object required: - id - level - message properties: id: type: string description: >- An unique identifier for the log message, could simply be an incrementing number. example: "1" code: $ref: '#/components/schemas/log_code' level: $ref: '#/components/schemas/log_level' message: type: string description: >- A concise message explaining the log entry. Messages do *not* explicitly support [CommonMark 0.29](http://commonmark.org/) syntax as other descriptive fields in the openEO API do, but the messages MAY contain line breaks or indentation. It is NOT RECOMMENDED to add stacktraces to the `message`. example: >- Can not load the UDF file from the URL `https://openeo.example/invalid/file.txt`. Server responded with error 404. time: type: string format: date-time title: Date and Time description: >- The date and time the event happened, in UTC. Formatted as a [RFC 3339](https://www.rfc-editor.org/rfc/rfc3339.html) date-time. data: description: |- Data of any type. It is the back-ends task to decide how to best present passed data to a user. For example, a datacube passed to the `inspect` SHOULD return the metadata similar to the collection metadata, including `cube:dimensions`. There are implementation guidelines available for the `inspect` process. path: description: |- Describes where the log entry originates from. The first element of the array is the process that has triggered the log entry, the second element is the parent of the process that has triggered the log entry, etc. This pattern is followed until the root of the process graph. type: array items: type: object required: - node_id properties: node_id: type: string description: The id of the node the log entry originates from. example: runudf1 process_id: $ref: '#/components/schemas/process_id' namespace: $ref: '#/components/schemas/process_namespace' parameter: type: string description: >- If applicable, the name of the parameter the log entry corresponds to. pattern: '^\w+$' nullable: true example: udf usage: $ref: '#/components/schemas/usage' stacktrace: type: string description: >- A stacktrace or similar, may include whitespaces for formatting. links: $ref: '#/components/schemas/log_links' usage: title: Resource usage metrics type: object properties: cpu: description: |- Specifies the CPU usage, usually in a unit such as `cpu-seconds`. allOf: - $ref: '#/components/schemas/usage_metric' memory: description: |- Specifies the memory usage, usually in a unit such as `mb-seconds` or `gb-hours`. allOf: - $ref: '#/components/schemas/usage_metric' duration: description: |- Specifies the wall time, usually in a unit such as `seconds`, `minutes` or `hours`. allOf: - $ref: '#/components/schemas/usage_metric' network: description: |- Specifies the network transfer usage (incoming and outgoing), usually in a unit such as `b` (bytes), `kb` (kilobytes), `mb` (megabytes) or `gb` (gigabytes). allOf: - $ref: '#/components/schemas/usage_metric' disk: description: |- Specifies the amount of input (read) and output (write) operations on the storage such as disks, usually in a unit such as `b` (bytes), `kb` (kilobytes), `mb` (megabytes) or `gb` (gigabytes). allOf: - $ref: '#/components/schemas/usage_metric' storage: description: |- Specifies the usage of storage space, usually in a unit such as `b` (bytes), `kb` (kilobytes), `mb` (megabytes) or `gb` (gigabytes). allOf: - $ref: '#/components/schemas/usage_metric' additionalProperties: description: |- Additional metrics. allOf: - $ref: '#/components/schemas/usage_metric' example: cpu: value: 40668 unit: cpu-seconds duration: value: 2611 unit: seconds memory: value: 108138811 unit: mb-seconds network: value: 0 unit: kb storage: value: 55 unit: mb usage_metric: type: object required: - value - unit properties: value: type: number minimum: 0 unit: type: string responses: logs: description: Lists the requested log entries. content: application/json: schema: title: Log Entries type: object required: - logs - links properties: level: description: |- The minimum severity level for log entries that the back-end returns. This property MUST reflect the effective lowest `level` that may appear in the document, which is (if implemented) the highest level of: 1. the `log_level` specified by the user for the processing request. 2. the `level` specified by the user for the log request. The order of the levels is as follows (from low to high severity): `debug`, `info`, `warning`, `error`. That means if `warning` is set, the logs will only contain entries with the level `warning` and `error`. type: string enum: - error - warning - info - debug default: debug logs: description: A chronological list of logs. type: array items: $ref: '#/components/schemas/log_entry' links: $ref: '#/components/schemas/links_pagination' client_error: description: |- The request can not be fulfilled due to an error on client-side, i.e. the request is invalid. The client SHOULD NOT repeat the request without modifications. The response body SHOULD contain a JSON error object. MUST be any HTTP status code specified in [RFC 7231](https://www.rfc-editor.org/rfc/rfc7231.html#section-6.6). This request usually does not respond with HTTP status codes 401 and 403 due to missing authorization. HTTP status code 404 SHOULD be used if the value of a path parameter is invalid. See also: * [Error Handling](#section/API-Principles/Error-Handling) in the API in general. * [Common Error Codes](errors.json) content: application/json: schema: $ref: '#/components/schemas/error' client_error_auth: description: |- The request can not be fulfilled due to an error on client-side, i.e. the request is invalid. The client SHOULD NOT repeat the request without modifications. The response body SHOULD contain a JSON error object. MUST be any HTTP status code specified in [RFC 7231](https://www.rfc-editor.org/rfc/rfc7231.html#section-6.6). This request MUST respond with HTTP status codes 401 if authorization is required or 403 if the authorization failed or access is forbidden in general to the authenticated user. HTTP status code 404 SHOULD be used if the value of a path parameter is invalid. See also: * [Error Handling](#section/API-Principles/Error-Handling) in the API in general. * [Common Error Codes](errors.json) content: application/json: schema: $ref: '#/components/schemas/error' server_error: description: |- The request can not be fulfilled due to an error at the back-end. The error is never the client’s fault and therefore it is reasonable for the client to retry the exact same request that triggered this response. The response body SHOULD contain a JSON error object. MUST be any HTTP status code specified in [RFC 7231](https://www.rfc-editor.org/rfc/rfc7231.html#section-6.6). See also: * [Error Handling](#section/API-Principles/Error-Handling) in the API in general. * [Common Error Codes](errors.json) content: application/json: schema: $ref: '#/components/schemas/error' parameters: pagination_limit: name: limit description: |- This parameter enables pagination for the endpoint and specifies the maximum number of elements that arrays in the top-level object (e.g. collections, processes, batch jobs, secondary services, log entries, etc.) are allowed to contain. The `links` array MUST NOT be paginated like the resources, but instead contain links related to the paginated resources or the pagination itself (e.g. a link to the next page). If the parameter is not provided or empty, all elements are returned. Pagination is OPTIONAL: back-ends or clients may not support it. Therefore, it MUST be implemented in a way that clients not supporting pagination get all resources regardless. Back-ends not supporting pagination MUST return all resources. If the response is paginated, the `links` array MUST be used to communicate the links for browsing the pagination with predefined `rel` types. See the `links` array schema for supported `rel` types. Back-end implementations can, unless specified otherwise, use any kind of pagination technique, depending on what is supported best by their infrastructure: page-based, offset-based, token-based or something else. The clients SHOULD use whatever is specified in the links with the corresponding `rel` types. in: query allowEmptyValue: true example: 10 schema: type: integer minimum: 1 log_offset: name: offset description: The last identifier (property `id` of a log entry) the client has received. If provided, the back-end MUST only send the entries that occurred after the specified identifier. If not provided or empty, the back-end MUST start with the first entry. in: query allowEmptyValue: true example: log1234 schema: type: string log_level: name: level description: |- The minimum severity level for log entries that the back-end returns. The order of the levels is as follows (from low to high severity): `debug`, `info`, `warning`, `error`. That means if `warning` is set, the back-end will only return log entries with the level `warning` and `error`. The default minimum log level is `debug`, which returns all log levels. in: query allowEmptyValue: true example: error schema: type: string enum: - error - warning - info - debug default: debug service_id: name: service_id in: path description: Identifier of the secondary web service. required: true schema: $ref: '#/components/schemas/service_id' job_id: name: job_id in: path description: Identifier of the batch job. required: true schema: $ref: '#/components/schemas/job_id' collection_id: name: collection_id in: path description: Collection identifier required: true schema: $ref: '#/components/schemas/collection_id' examples: evi_user_defined_process: description: A user-defined process that computes the Enhanced Vegetation Index (EVI). value: id: evi summary: Enhanced Vegetation Index description: >- Computes the Enhanced Vegetation Index (EVI). It is computed with the following formula: `2.5 * (NIR - RED) / (1 + NIR + 6*RED + -7.5*BLUE)`. parameters: - name: red description: Value from the red band. schema: type: number - name: blue description: Value from the blue band. schema: type: number - name: nir description: Value from the near infrared band. schema: type: number returns: description: Computed EVI. schema: type: number process_graph: sub: process_id: subtract arguments: x: from_parameter: nir y: from_parameter: red p1: process_id: multiply arguments: x: 6 y: from_parameter: red p2: process_id: multiply arguments: x: -7.5 y: from_parameter: blue sum: process_id: sum arguments: data: - 1 - from_parameter: nir - from_node: p1 - from_node: p2 div: process_id: divide arguments: x: from_node: sub y: from_node: sum p3: process_id: multiply arguments: x: 2.5 y: from_node: div result: true securitySchemes: Bearer: type: http scheme: bearer bearerFormat: JWT or openEO description: >- A Bearer token can be provided in two different formats: 1. **JSON Web Token (JWT) - RECOMMENDED** - Conformance class: `https://api.openeo.org/1.3.0/authentication/jwt` The Bearer token is an access token in [JWT](https://datatracker.ietf.org/doc/html/rfc7519) format as defined in RFC 7519. For openEO, it MUST include the issuer in the `iss` claim although being optional in RFC 7519. If the concept of an issuer does not exist in an authentication method (e.g. in HTTP Basic), implementations could use the endpoint for Basic Authentication as the issuer, for example. openEO backend implementations MUST signal their support for JWT by listing the given conformance class. Likewise, openEO clients SHOULD only use JWT when the openEO backend lists the conformance class. 2. **openEO Tokens - DEPRECATED** - Conformance class: *None* The Bearer Token is constructed from the authentication method, a provider ID (if available) and the access token. All separated by a forward slash `/`. Examples (replace `TOKEN` with the actual access token): - Basic authentication (no provider ID available): `basic//TOKEN` - OpenID Connect (provider ID is `ms`): `oidc/ms/TOKEN`. For OpenID Connect, the provider ID corresponds to the value specified for `id` for each provider in `GET /credentials/oidc`. All openEO backends MUST accept this method for backward compatibility until version 2.0 of the specification. The access tokens provided by the identity provider do not include the prefix that includes the authentication method and provider ID. The Bearer Token sent to the openEO backend MUST have the prefix, e.g. `basic//` for Basic authentication. This means that the clients have to prepend the prefix. JWT and openEO tokens can be distinguished by the presence of a slash `/` in the token, which JWT can never contain due to the Base64 encoding. Basic: type: http scheme: basic
