OpenMouse is a browser-based control panel for supported gaming mice.
Connect a mouse, view its information, and change supported settings such as DPI
and polling rate without installing a different app for every brand.
Works in Chromium-based browsers that support WebHID. Learn more at
[openmouse.app](https://openmouse.app/).
This branch is deployed as the public development control panel at
[control.openmouse.app](https://control.openmouse.app/).
## Keyboard controls
OpenMouse also detects supported Wooting, Wuque, Kochi, Razer, Logitech and
SteelSeries keyboard command interfaces through WebHID. The Razer, Logitech
and SteelSeries panels expose only controls implemented by the corresponding
keyboard-protocol driver; some settings are shown only when the keyboard
advertises the feature. Razer effect writes and SteelSeries direct lighting
have no active-state read-back. SteelSeries live analog changes require an
explicit on-board profile save; use a disposable profile when testing.
The new Razer, Logitech and SteelSeries paths have codec and simulated-HID
coverage, but no physical keyboard was connected during integration. Model
recognition is not hardware certification. See the [keyboard-protocol coverage
ledgers](https://github.com/OpenMouse-Project/keyboard-protocol/tree/feat/keyboard-vendor-support/docs)
for model-specific limits and capture requirements.
## Development
```bash
npm install
npm run dev
```
Run the full local check before pushing changes:
```bash
npm run check
```
### Bundle budget
Production assets are limited to 3,600,000 JavaScript bytes and 165,000 CSS
bytes. Run `npm run size` after a fresh build for current totals.
### Linux WebHID permissions
If a device appears in Chromium's picker but OpenMouse reports `Failed to open
the device`, check the permissions on its `/dev/hidraw*` nodes. Linux does not
grant user access to every HID device by default.
First inspect the connected device IDs:
```bash
lsusb
```
VXE R1 SE+ hardware ships with more than one receiver implementation. If the
mouse and 1K receiver appear as `3554:f58f` and `3554:f58e`, respectively,
install these narrowly scoped rules:
```udev
SUBSYSTEM=="hidraw", ATTRS{idVendor}=="3554", ATTRS{idProduct}=="f58f", TAG+="uaccess"
SUBSYSTEM=="hidraw", ATTRS{idVendor}=="3554", ATTRS{idProduct}=="f58e", TAG+="uaccess"
```
Save it as `/etc/udev/rules.d/70-openmouse-vxe.rules`, reload the rules, then
unplug and reconnect both devices:
```bash
sudo udevadm control --reload-rules
```
Grant access to every `hidraw` node for each product. Chromium opens the HID
device before OpenMouse selects its vendor configuration collection, so access
to only the `0xff02:0x0002` collection's node is insufficient.
## Local game and app profiles
Games & apps separates OpenMouse presets from Your apps. With the updated
OpenMouse Bridge running, Add game or app lists the apps that are running to
pick from, or takes the full path to an executable. Personal entries are saved in Bridge's
local config, not sent to OpenMouse for approval. They survive catalog refreshes
and Bridge restarts. Adding/editing/removing an entry does not require a mouse.
Each entry is a Game or an App, and its profile is active While running (kept
after alt-tabbing) or While focused (foreground-only switching). The path
matches that installation only. Foreground matching on Linux requires X11. Local profiles retain the
existing native/full-settings limits: Bridge can apply supported DPI/polling
settings with the browser closed; the control panel must remain open to apply
and restore full device-settings snapshots.
Local targets use stable IDs, not display names, so a target can be renamed or
share a name with an OpenMouse preset without losing or confusing its settings.
Removing a local target also removes its linked mouse profiles; clearing its
mouse settings leaves the target available. Older Bridges show update guidance
rather than falling back to a public game request.
## Community
Questions, device requests, bug reports, or just want to follow along? Come
hang out on Discord.
## Sponsors
OpenMouse is supported by [Macroscope](https://macroscope.com/), [Hypertune](https://hypertune.gg/), and [Hone](https://hone.gg/).
## Contributing
OpenMouse is one repository in a family — with the **Desktop** app,
**mouse-protocol**, and **OpenMouse-Bridge**.
Before you start, read the [contribution guide](https://docs.openmouse.app).
It explains how the repositories fit together, per-repo setup and
conventions, and safe reverse-engineering practices.
## Bridge updates
The Settings page compares the connected OpenMouse Bridge against its latest
stable GitHub release. It only retrieves the version, changelog, and download
link; it never downloads or installs an update in the background. Users can
also run the check manually.
When Bridge is reachable, the control panel prefers its loopback native HID
transport over browser WebHID. The same `@openmouse/protocol` drivers continue
to handle device discovery and settings; Bridge only carries HID reports. This
keeps Razer control interfaces protected by Chrome 153+ usable without relying
on the browser's former protected-collection bypass.
Bridge connection attempts, disconnects, request failures, scan durations, and
device inventory changes are written to the browser console with the
`[OpenMouse Bridge]` prefix. The same lifecycle events are included in the
downloadable diagnostics from a connected device's **Advanced** panel; HID
report payloads are not written to the console.
The control panel is organized by feature. Tests sit next to the code they cover.
| Folder | What lives there |
| --- | --- |
| `src/main.tsx` | Entry point: guards, service worker, mounts the app |
| `src/app/` | The shell: `App`, sidebar, pending-changes bar, toasts, AI overlay |
| `src/features/devices/` | Device home, device page, hero, stats, and the setting `cards/` |
| `src/features/buttons/` | Button mapping, setup codes, Logitech button commands |
| `src/features/profiles/` | Onboard profiles and profile sharing |
| `src/features/superstrike/` | Superstrike hit test and presets |
| `src/features/bridge/` | OpenMouse Bridge client, status line, update checks |
| `src/features/games/` | Games page and per-game profiles (Bridge only) |
| `src/features/hardware-test/` | Hardware test page, report builder, supported-devices cross-check |
| `src/features/capture/` | Report capture dialog and export formats |
| `src/features/news/` | News banner and "What's new" |
| `src/features/settings/` | Interface settings and stored preferences |
| `src/device/` | Device controller, per-vendor glue, pending changes, preview fixtures |
| `src/shared/` | UI primitives, icons, colour picker, formatting helpers |
| `src/i18n/` | Strings: `index.ts` is English and the API, `locales/` has one file per language |
| `src/platform/` | Service worker, offline banner, Trusted Types, browser support, sounds |
| `src/styles/` | Design tokens, base styles, and one stylesheet per area |
| `src/types/` | Global type declarations (Vite, WebHID) |
| `test/` | Tests for the Cloudflare functions, security headers and the PWA build |
Packet codecs and WebHID drivers live in the standalone
[`@openmouse/protocol`](https://github.com/OpenMouse-Project/mouse-protocol)
library. Its codec entry points remain transport-independent, while its
`drivers` entry points own discovery filters, device clients, retries, and
application-facing status conversion. OpenMouse consumes the same public
exports that external consumers use.
## Adding a vendor
Codec and driver contributions belong in the `mouse-protocol` repository.
1. Add transport-independent packet definitions and codecs under the vendor's
`mouse-protocol/src//` folder.
2. Add the WebHID implementation under `mouse-protocol/src/drivers//`.
3. Register the driver and browser filters in the shared driver layer.
4. Add or extend codec and driver tests, state which product IDs were verified
on hardware, and run the checks in both repositories.
OpenMouse should only need changes when a driver introduces a genuinely new UI
capability. The control UI otherwise discovers supported clients through the
library registry automatically.
Hardware-specific validation checklists live in the protocol repository's
`docs/` directory.
## Star history
## License
[GNU AGPL-3.0](LICENSE). Contributions are accepted under the same license.
