# ℹ️ About
_Welcome to the UI package for StableStudio!_
**If you're ready to dive in and make changes, be sure to read about [technology](#technology), [structure](#structure), [conventions](#conventions), and [plugins](../stablestudio-plugin/README.md) first.**
## 📜 History
StableStudio represents a new direction for [DreamStudio](https://dreamstudio.ai) with renewed focus on open-source and community-driven development, but the project has an interesting backstory...
- **Pre-Stable Diffusion Launch**
_Summer 2022_
[DreamStudio](https://dreamstudio.ai) began as passion-project by [@nin](https://twitter.com/nin_artificial) with the goal of creating an all-in-one creative studio for generative animations using Disco Diffusion. He and several collaborators wrote the original UI using Vue.js and a local Python back-end. With the imminent arrival of Stable Diffusion, focus shifted toward creating an easy-to-use interface for image generation so the release of the model would be as accessible as possible.
- **Post-Stable Diffusion Launch**
_August 2022 – November 2022_
Following the release of Stable Diffusion, [DreamStudio](https://dreamstudio.ai) served as a vehicle for new models and features shipped by [Stability AI](http://stability.ai). This period saw the introduction of [in-painting](https://platform.stability.ai/docs/features/inpainting?tab=typescript), [out-painting](https://platform.stability.ai/docs/features/inpainting?tab=typescript), and [image-to-image](https://platform.stability.ai/docs/features/image-to-image?tab=typescript).
- **React**
_December 2022 – April 2023_
In early December, work began on a new infinite-canvas version of the existing editor. Given the need to manage complicated state and side effects declaratively, the decision was made to switch the editor to React. Once a working editor MVP was finished, the opportunity was taken to rewrite the entire app while also shipping a re-imagined UX.
- **StableStudio**
_Present – Future_
The breakneck speed of the Stable Diffusion community has proven distributing generative AI is better achieved through open-source development. We're hopeful StableStudio can serve as a hub for community collaboration and a home for exciting new features.
# 🦾 Technology
- **[TypeScript](https://www.typescriptlang.org/)** – Type safety ftw!
- **[Vite](https://vitejs.dev/)** – Bundler and live-development tool. You can see the full config in [`vite.config.ts`](./vite.config.ts)
- **[React](https://reactjs.org/)** – We're using React with modern hooks and functional components
- **[Zustand](https://docs.pmnd.rs/zustand/getting-started/introduction)** – Extremely fast and easy-to-use state management, it's powerful and tiny!
- **[Tailwind](https://tailwindcss.com/)** – Our preferred method of styling components, the config is at [`tailwind.config.js`](./tailwind.config.cjs)
- **[Emotion](https://emotion.sh/docs/introduction)** – For when we need to break free of Tailwind and write "native CSS"
# 🏗 Structure
## 🧱 Domain-Driven Design
**The most important aspect of this codebase's structure is adherence to domain-driven design.**
This means we organize code around the _concepts_ rather than technical implementation details.
For example, if we identify a _concept_, let's say `User`, we would create a `User` "domain."
The `User` domain would _own_ all user-related code, including visual representation, state, hooks, etc.
Most domains are _composed_ of smaller domains; a hypothetical `User` domain might be composed of `User.State`, `User.Avatar`, `User.Preferences`, `User.Details`, etc.
_This structure is fractal in nature,_ meaning `User.Details` might itself be composed of `User.Details.SocialMedia`, `User.Details.ContactInformation`, `User.Details.UpdateRequest`, etc.
### \*️⃣ Domain Syntax
Here's an example of how we might represent a `User` domain in code...
```tsx
import { Avatar } from "./Avatar";
import { Preferences } from "./Preferences";
import { Details } from "./Details";
export type User = {
id: ID;
avatar?: User.Avatar;
preferences?: User.Preferences;
details?: User.Details;
};
export function User({ id }: User.Props) {
const user = User.use(id);
return (
<>
);
}
export declare namespace User {
export { Avatar, Preferences, Details };
}
export namespace User {
User.Avatar = Avatar;
User.Preferences = Preferences;
User.Details = Details;
export type Props = {
id?: ID;
};
export const use = (id: ID) => {
// Make an API call for the user or something
};
}
```
This syntax takes advantage of TypeScript's declaration merging feature to enable nice fluent-style APIs for domains...
```tsx
import { User } from "./User";
// You can use `User` as a type
const bob: User = { id: "bob" };
function App(id: ID) {
// You can use `User` as a namespace
const user = User.use(id);
const userPreferences = User.Preferences.use(id);
// You can use `User` as a component
return (
<>
);
}
```
Here is an example of a real domain ([`Editor.Camera`](./src/Editor/Camera/index.tsx)) you'll find in the app...
```tsx
// Owner of all things camera-related in the editor
Editor.Camera;
// Centers the camera in the editor
Editor.Camera.Center;
// The hand tool is used for panning around
Editor.Camera.Hand;
// For resetting the camera to the default view
Editor.Camera.Reset;
// Specifies keyboard shortcuts for camera actions
Editor.Camera.Shortcuts;
// Controls the zoom level of the camera and mouse wheel controls
Editor.Camera.Zoom;
```
Quick note about the `export declare namespace User` syntax from the first example...
This is needed when a namespace exports a type.
It's an unfortunate bit of syntax which might [not be needed](https://github.com/microsoft/TypeScript/issues/39865) in the future.
If you want to discuss this further, please check out [this issue](https://github.com/Stability-AI/StableStudio/issues/7).
### 📁 Directories and Files
_Domains are usually correlated one-to-one with file/folder structure._
For example, the [`Editor.Camera`](./src/Editor/Camera/index.tsx) domain mentioned above is composed of the following files...
```
./src/Editor/Camera/
├── Center.tsx
├── Hand.tsx
├── Reset.tsx
├── Shortcut.tsx
├── Zoom.tsx
└── index.tsx
```
This means if you see a domain like [`Generation.Image.Download`](./src/Generation/Image/Download/index.tsx), you can expect to find it at `./src/Generation/Image/Download`.
All root-level domains located at the top-level of the [`./src`](./src) folder and can be imported using the shorthand syntax...
```ts
import { ExampleDomain } from "~/ExampleDomain";
import { ExampleDomain } from "../../../../../ExampleDomain";
// ^ If you were deep in the folder tree, it would look like this without the `~` alias
```
### 📋 Structuring Tips
- **Look for repeated references to a word or concept**
For example, if you're working in a `User` domain and find yourself using the word "avatar" a lot, you might want to create a `User.Avatar` domain
- **Compound words are structuring hints**
Domains like `DeviceInformation` might be better represented as `Device.Information`.
- **Plural domains are very important**
The singular [`Generation.Image.Input`](./src/Generation/Image/Input/index.tsx) domain owns everything related to the concept of what's being fed to an image generation, but [`Generation.Image.Inputs`](./src/Generation/Image/index.tsx) owns the state of all inputs as a collective.
Plural domains are usually exported at the same level as their singular counterparts, such as [`Editor.Dream`](./src/Editor/Dream/index.tsx) and [`Editor.Dreams`](./src/Editor/Dream/Dreams.tsx).
### ⭐️ Important Domains
- **[`App`](./src/App/index.tsx)** – Owner of app-level functionality such as the React root, sidebars, providers, etc.
- **[`Generation.Image`](./src/Generation/Image/index.tsx)** – Likely the largest domain, owns all things related to image generation
- **[`Generation.Image.Session`](./src/Generation/Image/Session/index.tsx)** – Domain which was poorly named and grew too large as a result, manages the active "image generation session"
- **[`Editor`](./src/GlobalVariables/index.tsd)** – Home of all editor functionality
- **[`Plugin`](./src/Plugin/index.ts)** – Owner of plugin setup and access, contains the important `Plugin.use` hook
- **[`Theme`](./src/Theme/index.ts)** – Contains the StableStudio's design system and common components such as `Theme.Icon`, `Theme.Button`, etc.
- **[`Shortcut`](./src/Shortcut/index.ts)** – Contains the StableStudio's keyboard shortcut system and menu
- **[`GlobalState`](./src/GlobalState/index.ts)** – Mostly a pass-through wrapper around [Zustand](https://docs.pmnd.rs/zustand/getting-started/introduction)
- **[`GlobalVariables`](./src/GlobalVariables/index.ts)** – Extremely useful functions and types available across the StableStudio without needing any imports (`css`, `classes`, `useEffect`, etc.)
# 🤝 Conventions
## 💅 Styles and CSS
Most styling in StableStudio is implemented with [Tailwind CSS](https://tailwindcss.com/).
The [`Theme`](./src/Theme/index.ts) domain contains a bunch of useful pre-made components, make sure to check there first if you need something "off-the-shelf."
You can use the [`classes`](#global-variables) function anywhere without imports if you need conditional styling or to break apart class names...
```tsx
function Example({
isEmphasized,
isDisabled,
children,
}: PropsWithChildren<{
isEmphasized?: boolean;
isDisabled: boolean;
}>) {
return (
{children}
);
}
```
You can always "break glass" and use raw CSS via the globally-available `css` function if you need to, but please try to avoid it...
```tsx
function Example() {
return (
Hello, World!
);
}
```
## 🏛 State Management via [Zustand](https://docs.pmnd.rs/zustand/getting-started/introduction)
StableStudio uses [Zustand](https://docs.pmnd.rs/zustand/getting-started/introduction) for state management, which is honestly super cool.
It's fast and small, you can read through the whole codebase in a few minutes.
We originally used [Recoil](https://recoiljs.org/) it couldn't handle "hot" paths nearly as well.
Whenever you need globally-available state, you can use the [`GlobalState`](./src/GlobalState/index.ts) domain, which wraps Zustand...
```tsx
import { GlobalState } from "~/GlobalState";
function Count() {
const count = Count.use();
const setCount = Count.useSet();
return (
{count}
);
}
export namespace Count {
export const use = State.use(({ count }) => count);
export const useSet = () =>
State.use(({ setCount }) => setCount, GlobalState.shallow);
}
type State = {
count: number;
setCount: (count: number) => void;
};
namespace State {
const store = GlobalState.create((set) => ({
count: 0,
setCount: (count) => set({ count }),
}));
export const use = store;
}
```
Notice how the `Count` domain exports `Count.use` and `Count.useSet` instead of exporting its state directly.
This allows us to change the state implementation without breaking any code that uses it.
Finally, you can see `GlobalState.shallow` used to [limit rerenders](https://github.com/pmndrs/zustand#selecting-multiple-state-slices).
