# Wire: A TCP Networking Library for Zig ## Overview Wire is a networking library written in Zig, designed to simplify building TCP-based client-server applications. It leverages Zig's capabilities for memory safety and performance, and integrates with the `xev` event loop for asynchronous I/O operations able to run on a single thread. ## Goals * Provide a straightforward API for TCP client and server creation. * Implement a simple message framing protocol for clear data exchange. * Enable asynchronous, non-blocking network communication. * Offer a callback-based mechanism for handling network events. * Serve as a practical example of Zig for network programming. ## Architecture Wire is built around two main components: * **`Client`**: Manages a connection to a TCP server. It handles connecting, sending data, and receiving framed messages. * **`Server`**: Listens for incoming TCP connections and manages multiple `ClientConnection` instances. * **`ClientConnection`**: Represents a connection from a client to the server, handling reading and writing of framed data. * **`Frame` / `FrameHeader`**: Defines the structure for messages, where each message is prefixed with a header indicating its type and the length of its payload. This allows for structured communication between client and server. ## Features * **Asynchronous Operations**: Utilizes `xev` for non-blocking network I/O. * **Message Framing**: Implements a basic framing protocol (message type + payload length) to delineate messages over TCP streams. * **Callback-Driven**: Uses callbacks to notify application code of events such as new connections, incoming data, and disconnections. * **Memory Management**: Leverages Zig's allocators for explicit memory control. * **Client and Server Abstractions**: Provides easy-to-use `Client` and `Server` types. ## Learning Outcomes This project can provide insights into: * Network programming in Zig. * Working with event loops (specifically `xev`). * Implementing basic network protocols (framing). * Zig's error handling and memory management in a networking context. * Callback-based event handling. ## Getting Started (Instructions for integrating and using the Wire library will be added as development progresses.) ## Usage Example Here's a basic example of how to use the `Client` to connect to a server and handle messages: ```zig const std = @import("std"); const xev = @import("xev"); // Assuming xev is available const wire = @import("wire"); // 1. Define the message types your application will use. // This enum will be used by the client to dispatch messages to the correct callbacks. pub const MessageTypes = enum { myMessageA, myMessageB, }; // 2. Define callback functions for each message type. // These functions will be called when a message of the corresponding type is received. fn handleMyMessageA(context: ?*anyopaque, payload: []const u8) anyerror!void { // 'context' is the optional context pointer provided during client initialization. // 'payload' is the raw byte slice of the message. // Process payload for myMessageA std.debug.print("Received myMessageA: {s}\n", .{payload}); _ = context; // Avoid unused variable warning if context is not used } const MyCustomStruct = struct { const Self = @This(); fn handleMyMessageB(context: ?*anyopaque, payload: []const u8) anyerror!void { // Process payload for myMessageB const self = @as(*Self, @ptrCast(@alignCast(context))); std.debug.print("Received myMessageB: {s}\n", .{payload}); _ = context; } } var customStruct = MyCustomStruct{}; pub fn main() !void { var gpa = std.heap.GeneralPurposeAllocator(.{}){}; const allocator = gpa.allocator(); defer _ = gpa.deinit(); var loop = try xev.Loop.init(.{}); defer loop.deinit(); // 3. Initialize the Client. var client = try wire.Client(MessageTypes).init( allocator, &loop, .{ // ClientOptions .server_addr = try std.net.Address.parseIp4("127.0.0.1", 8080), // Target server address // .keep_alive = false, // Optional: defaults to false }, .{ // Callbacks for each MessageType .myMessageA = .{ .context = null, .cb = handleMyMessageA }, .myMessageB = .{ .context = @ptrCast(&customStruct), .cb = handleMyMessageB }, }, ); // 4. Connect to the server. // The connection happens asynchronously. // You might want a connection callback in a real application to know when it's established. client.connect(); // 5. Start reading messages from the server. // This tells the client to begin listening for incoming framed messages. client.startReading(); // Run the event loop to process network events. try loop.run(); } ``` This example demonstrates: * Defining `MessageTypes`. * Creating callback functions for these types. * Initializing the `wire.Client` with server address, options, and callbacks. * Connecting the client using `client.connect()`. * Initiating message reading with `client.startReading()`. * Running the `xev` event loop. ### Server Usage Example Here's a basic example of how to use the `Server` to accept connections and handle client messages: ```zig const std = @import("std"); const xev = @import("xev"); const wire = @import("wire"); // 1. Define message types (must be the same as the client's MessageTypes). pub const MessageTypes = enum { myMessageA, myMessageB, }; // Forward declaration for ConnectionContext if needed for callbacks const ConnectionContext = struct { allocator: std.mem.Allocator, client_conn: *wire.ClientConnection, }; // 2. Implement the callback for when a new client is accepted. fn serverAcceptCallback( server_context: ?*anyopaque, // Context provided during Server.init loop: *xev.Loop, accept_completion: *xev.Completion, client_conn: *wire.ClientConnection, ) xev.CallbackAction { _ = loop; _ = accept_completion; const allocator = @as(*std.mem.Allocator, @ptrCast(@alignCast(server_context))).?; std.debug.print("Server: Client connected (fd: {d})\n", .{client_conn.socket.fd}); // 3. For each connection, set up context and start reading. const conn_ctx = allocator.create(ConnectionContext) catch |err| { std.debug.print("Server: Failed to allocate context for connection: {any}\n", .{err}); // client_conn.close(null); // Close if context allocation fails return .rearm; // Continue accepting other connections }; conn_ctx.* = .{ .allocator = allocator, .client_conn = client_conn, }; // Set a callback for when this specific client connection closes client_conn.setCloseCallback(@ptrCast(conn_ctx), clientCloseCallback); // Start reading messages from this client client_conn.read(@ptrCast(conn_ctx), clientReadCallback); // Server should continue to accept new connections return .rearm; } // 4. Implement the callback for reading data from a client. fn clientReadCallback( context: ?*anyopaque, payload: []const u8, ) void { const conn_ctx = @as(*ConnectionContext, @ptrCast(@alignCast(context))).?; std.debug.print("Server: Received from client (fd: {d}): {s}\n", .{conn_ctx.client_conn.socket.fd, payload}); // Example: Echo the message back or send a different response const response_payload = "Server acknowledges your message!" catch unreachable; // Using a string literal conn_ctx.client_conn.write( MessageTypes, // The enum type .myMessageA, // The specific message type from the enum response_payload, ) catch |err| { std.debug.print("Server: Failed to write to client (fd: {d}): {any}\n", .{conn_ctx.client_conn.socket.fd, err}); // The connection might be closed by the write error handler in ClientConnection }; } // 5. Implement the callback for when a client connection is closed. fn clientCloseCallback(context: ?*anyopaque) anyerror!void { const conn_ctx = @as(*ConnectionContext, @ptrCast(@alignCast(context))).?; std.debug.print("Server: Client disconnected (fd: {d})\n", .{conn_ctx.client_conn.socket.fd}); // Deinitialize/free the ConnectionContext conn_ctx.allocator.destroy(conn_ctx); } pub fn main() !void { var gpa = std.heap.GeneralPurposeAllocator(.{}){}; const allocator = gpa.allocator(); defer _ = gpa.deinit(); var loop = try xev.Loop.init(.{}); defer loop.deinit(); // 6. Initialize the Server. var server = try wire.Server.init( allocator, &loop, .{ // ServerOptions .address = try std.net.Address.parseIp4("127.0.0.1", 8080), .max_connections = 10, }, @ptrCast(&allocator), // Pass allocator as server context for acceptCallback serverAcceptCallback, ); defer server.deinit(); // Ensure server resources are cleaned up // 7. Start accepting connections. // This will continuously listen for new clients in the background via the event loop. server.accept(); std.debug.print("Server listening on 127.0.0.1:8080\n", .{}); // Run the event loop to process network events. try loop.run(); } ``` This server example shows: * Initializing `wire.Server` with an address and an `acceptCallback`. * The `acceptCallback` is invoked for each new client. * Inside `acceptCallback`, `client_conn.read()` is called with a `readCallback` to process incoming data from that specific client. * `client_conn.write()` is used to send framed messages back to the client. * `client_conn.setCloseCallback()` is used to register a function to be called when the client disconnects, allowing for resource cleanup. ## Project Status 🚧 Early Development – The core client and server components, along with message framing, are implemented. Further development will focus on robustness, features, and examples.
