; } ``` The same pattern works in Vue, Svelte, Solid, and Angular — the widget is framework-agnostic. If you'd rather not write the glue, opening an issue describing how you want to consume it helps us decide whether to ship an official wrapper. ### 3. Verify on Your Backend **Already using Turnstile, reCAPTCHA or hCaptcha?** Point the verification call you already have at your FCaptcha server — the contract is identical: ```diff - https://challenges.cloudflare.com/turnstile/v0/siteverify + https://your-server.com/turnstile/v0/siteverify ``` ```bash curl -X POST https://your-server.com/turnstile/v0/siteverify \ -d "secret=your-secret" -d "response=$TOKEN" # {"success":true,"challenge_ts":"...","hostname":"example.com","action":"login", # "cdata":"","error-codes":[],"score":0.11} ``` See [POST /turnstile/v0/siteverify](#post-turnstilev0siteverify--drop-in-compatibility) for the full contract, including `hostname`/`action` checking and `idempotency_key`. **Or use the native endpoint**, which returns FCaptcha's own shape: ```go // Go: go get github.com/WebDecoy/FCaptcha client := fcaptcha.New("https://your-server.com", "your-secret") result, err := client.Verify(ctx, r.FormValue(fcaptcha.TokenField), "") if err == nil && result.Valid && result.Score < 0.5 { // Valid request from human } // Or guard a handler: 403 on a bad token, 503 if the server is unreachable. mux.Handle("POST /login", client.Middleware(fcaptcha.MiddlewareOptions{Action: "login"})(loginHandler)) ``` ```python # Python import requests result = requests.post('https://your-server.com/api/token/verify', json={'token': '...', 'secret': 'your-secret'} ).json() if result['valid'] and result['score'] < 0.5: # Valid request from human ``` ```javascript // Node.js const result = await fetch('https://your-server.com/api/token/verify', { method: 'POST', headers: { 'Content-Type': 'application/json' }, body: JSON.stringify({ token: '...', secret: 'your-secret' }) }).then(r => r.json()); if (result.valid && result.score < 0.5) { // Valid request from human } ``` ## Privacy, accessibility and compliance The properties a procurement review asks about, with the evidence behind them in [COMPLIANCE.md](COMPLIANCE.md): | | | |---|---| | **Cookies** | None. No consent banner needed for FCaptcha | | **Third parties** | None. No SaaS, no telemetry, no phone-home, no CDN requirement | | **Persistence** | Nothing written to disk. All state in memory, 5 minutes to 1 hour, enumerated | | **Data location** | Your server, wherever you run it | | **Automated decisions** | Every score itemised with a human-readable reason, so an Article 22 decision can be explained rather than quoted | | **Accessibility** | No visual or audio puzzle. WCAG 2.2 AA criteria verified in CI; relevant to the European Accessibility Act | | **False positives** | Measured against a labelled human panel on every run, with a per-signal budget that fails the build | The accessibility work is tested rather than asserted, which is the part worth checking: `test/browser/tests/a11y.spec.ts` computes contrast from what the browser actually paints, focuses the control under a host stylesheet that suppresses outlines globally, and measures the target box. Those checks were written after an audit found the previous palette failing on seven counts, including the checkbox border at 1.72:1. ## How It Works FCaptcha collects signals across many categories and blends them into a single score (category weights sum to 1.0 and are tunable per deployment). The major surfaces: ### Proof of Work (Invisible Layer) Before any verification, clients must solve a SHA-256 hashcash challenge: - **Challenge fetched on page load** - solving runs in the background across parallel Web Workers (one per ~2 CPU cores) - **Non-blocking** - users never see it, computation happens while they fill forms - **Hardened** - 256-bit HMAC-signed challenges, one-time use, replay-protected, with a server-generated per-challenge nonce the client must echo back - **Signal commitment** - the client hashes its collected signals into the PoW input (`prefix:signalsHash:nonce`) and the server verifies the signals weren't tampered with after solving - **Difficulty scaling** - datacenter IPs and high-rate requesters get harder puzzles - **Costs a real browser ~100-600ms** - measured: 0.12s on a desktop, 0.58s on a throttled low-end phone ### What the proof of work does and does not buy you It is a **liveness and timing gate, not a cost function.** Be clear-eyed about this, because the distinction decides whether the design is doing what you think. The parts that hold up are the un-spoofable ones. The server signs each challenge, allows it once, and measures the gap between issuing it and receiving a solution on its own clock. A solution returned in under 1.5 seconds is scored as too fast regardless of what the client claims, so a visitor cannot arrive with a pre-computed answer, and each token costs an attacker a real 1.5 seconds of wall clock per identity. What the compute cost does **not** do is price an attacker out. Treat the hash as a gate, not a toll, and do not lean on it as a rate limiter — that job belongs to the timing floor above, and to IP and site-key limits. This is also why SHA-256 having GPUs and ASICs behind it is not the weakness it appears to be, and why swapping in a memory-hard function (Argon2id, RandomX) would not help. Measured in a real browser, a difficulty-1 Argon2id search at 64MiB costs a throttled low-end phone **6.46s** against **0.58s** for what ships today, plus a 64MB allocation and 28KB of WASM. That is a large, regressive cost to honest mobile users for no gain in the constraint that actually binds. Numbers in [bench/POW-PRIMITIVE.md](bench/POW-PRIMITIVE.md). If you want proof of work to genuinely raise an attacker's cost, the lever is the server-measured elapsed time, not the hash. That is what the adaptive cost keys on. The challenge is also bound to the source network that acquired that price (IPv4 `/24`, IPv6 `/56`). This prevents an attacker from obtaining baseline-cost challenges through an unrelated clean proxy and submitting them from an already suspicious source, while tolerating nearby address rotation on mobile networks. Each challenge carries a `minAgeMs`: how long it must be held before a solution is accepted without penalty. A visitor who has done nothing wrong gets the same 1500ms floor the server has always applied. A source that has recently produced strong bot verdicts gets more, up to 15 seconds — which takes it from roughly 40 tokens a minute to four, on hardware no amount of money can speed up. Difficulty barely moves, and now caps at 5 rather than 6. Difficulty 6 costs a native solver about a millisecond and a budget Android phone about sixteen seconds; escalating there taxes the slowest legitimate devices and constrains nobody. Being on a datacenter address no longer raises difficulty at all — a real person on a corporate VPN or iCloud Private Relay was paying several seconds of blocked hashing for a shared IP — and raises the time floor instead, which a hosted scraper feels as reduced throughput and a person filling in a form does not feel at all. The client is told `minAgeMs` and waits it out, so for an ordinary visitor the cost is a short delay rather than a worse score. That distinction matters most for anyone sharing an egress address with whatever earned the delay. A client that submits early anyway is scored, but only as contributory evidence — an older cached client does not know to wait, and should not be treated as automation for it. Suspicion is held per (site key, address) for 15 minutes, records only verdicts at or above 0.8, and stores nothing but timestamps. It is not cross-session correlation and should not grow into it. ### Behavioral Biometrics - Mouse trajectory, velocity, and acceleration curves - Micro-tremor detection (humans have natural hand shake at 3-25Hz) - Click precision, approach directness, pre-click exploration, overshoot corrections - **Input-event forensics** — coalesced pointer-event batches (real mice coalesce several hardware samples per frame; CDP-injected moves don't), `movementX/Y` vs. position-delta coherence, and teleport clicks (a click dispatched at coordinates with no approach trajectory) - **Think-time cadence** — the agent act → screenshot → inference → act loop leaves bursts of activity separated by multi-second perfect silence - **Mobile-native** — touch kinematics (multi-touch, force/radius variance) and passive device-sensor entropy, exempting genuine touch and keyboard-only users - **Scroll morphology** — a wheel or trackpad advances the page tens of pixels per event; `scrollIntoView()` covers the whole page in one. Measured separation: 109px vs. 704px per event. Stands down for keyboard users, since PageDown legitimately jumps a viewport ### Environmental & Automation - WebDriver / automation framework detection (Selenium, Puppeteer, Playwright, PhantomJS, Nightmare, Watir) - **CDP detection** — legacy ChromeDriver/Selenium globals plus a Runtime/DevTools console-attach probe that catches any attached protocol client, even when JS globals are scrubbed - Headless browser indicators, plugin/feature checks, UA ↔ platform consistency - Canvas / WebGL / Audio fingerprinting (session-scoped only) - **TLS fingerprinting** — JA3 (client-supplied) and JA4. JA4 is computed **natively from the ClientHello** when the Go server terminates TLS itself (`FCAPTCHA_TLS_CERT`/`FCAPTCHA_TLS_KEY`), which no client can assert; behind a terminating proxy it falls back to a trusted header. Only JA4-TLS is implemented — the rest of the JA4 family is licensed non-commercially and cannot ship here ### Temporal Signals - Proof of Work timing (reveals API round-trip latency) - Interaction timing patterns and event-sequence analysis - Page-load-to-interaction timing ### Form Interaction - Programmatic `form.submit()` and programmatic-click detection - **Programmatic fill** — content that appears with zero keystrokes and zero pastes (Playwright `fill()` / `element.value=`) - Time from page load to submission; events-before-submit (no events = bot) - Textarea keystroke analysis — paste ratio, typing speed, rhythm/cadence, keydown/keyup ratio - **Typing cadence floors** — inter-key interval *and* key hold time both below the human range. Measured on real hardware: humans 226.9ms median with 4549 variance and 82ms holds; a scripted agent 7.9ms, variance 8, 7.8ms holds. Gated behind a ten-keystroke minimum and a no-paste requirement, because a paste is two keydowns a millisecond apart and people paste constantly - **Paste/platform contradiction** — Ctrl+V from a client claiming macOS, or Meta+V from one claiming Windows, *with the paste actually landing*. No threshold and no calibration: the client has disagreed with itself. Requiring a completed paste keeps it off the Windows switcher fat-fingering Ctrl+V on a new Mac, where that combination does nothing ### Declared Agents & Reputation - Self-identifying AI-agent user-agents (ClaudeBot, Claude-User, GPTBot, ChatGPT-User, OAI-SearchBot, PerplexityBot, Google-Extended, CCBot, Bytespider, meta-externalagent, Amazonbot, cohere-ai, …) - Web Bot Auth (RFC 9421 HTTP Message Signatures) — cryptographic signature verification against the agent's published key directory (verified / forged / unverified), Go + Node - Datacenter / VPN / proxy IP reputation and reverse-DNS heuristics (with a 2s lookup timeout so request handlers never block) ## AI Agent Detection FCaptcha targets three classes of modern AI agent, each with a different tell. ### 1. Vision agents (screenshot → API → click) A vision agent takes a screenshot, sends it to a vision model (GPT-4V, Claude, etc.) for click coordinates, and executes the click. That pattern is exploitable: | Signal | Human | Vision agent | |--------|-------|-----------| | Mouse movement | Natural curves, micro-tremor | Smooth/linear paths | | Pre-click behavior | Exploration, hesitation | Direct path to target | | Click trajectory | Approach path to the target | Teleport — click with no preceding movement | | Coordinate precision | Slight variance | Pixel-perfect | | PoW timing | Consistent with local execution | Delayed by API round-trip | ### 2. Computer-use / CDP agents (driving a real browser) Agents like Claude in Chrome (via `chrome.debugger`) or Operator-style tools (via Playwright/CDP) drive a *real* browser, so their input events report `isTrusted: true` and slip past global-based checks. Their **shape** still betrays them: | Signal | Human | CDP-driven agent | |--------|-------|-----------| | Coalesced pointer events | Multiple hardware samples per frame | Single-entry batches (synthetic) | | `movementX/Y` vs. position | Coherent | Incoherent / zero while position changes | | Activity cadence | Continuous, noisy idle | Bursts separated by multi-second silence (think time) | | Field entry | Per-character keystrokes | Programmatic fill — value set, no keys/pastes | | Protocol surface | None | DevTools/Runtime console consumer attached | ### 3. Declared agents (the agentic web) Many legitimate agents and crawlers identify themselves — by user-agent (ClaudeBot, GPTBot, PerplexityBot, …) or by cryptographically signing requests with **Web Bot Auth** (RFC 9421). FCaptcha verifies those signatures against the agent's published key directory: - **verified** → a distinct `declared_ai` category (high confidence, low default severity) — a trustworthy identity your app can *allow* by policy. - **forged** (signature fails cryptographic verification) → a contributory bot signal — affirmative evidence of a spoofed identity claim. - **unverified** (unreachable/blocked directory, timeout) → fails open to a presence-only signal; a directory it couldn't fetch is never treated as proof of spoofing. So declared and verified agents get policy handling instead of being treated as attackers, and a bot can't buy leniency just by attaching three unsigned headers. (Go + Node verify cryptographically; the Python server still identifies by header presence.) ## API Reference ### GET /api/pow/challenge Get a Proof of Work challenge. Called automatically by the client on page load. ```json // Request: GET /api/pow/challenge?siteKey=your-site-key // Response { "challengeId": "abc123...", "prefix": "abc123:1703356800000:4", "difficulty": 4, "minAgeMs": 1500, "expiresAt": 1703357100000, "nonce": "f1e2d3...", "sig": "def456..." } ``` The `nonce` is generated per-challenge by the server; the client echoes it back in `signals.meta.challengeNonce` and the server verifies it, preventing challenge replay. `minAgeMs` is how long the client should hold the solved challenge before submitting. The bundled client does this for you. Both fields are covered by `sig`, so neither can be talked down on the way back. Cost scales with what the requesting source has recently been caught doing: | source | difficulty | minAgeMs | |---|---|---| | clean, or unknown | 4 | 1500 | | 1–2 recent strong bot verdicts | 4 | 4000 | | 3–5 | 5 | 8000 | | 6+ | 5 | 15000 | Datacenter addresses, high request rates and exceeded rate limits raise the time floor only — never the difficulty. See [what proof of work does and does not buy you](#what-the-proof-of-work-does-and-does-not-buy-you) for why. ### Preconditions: what a token requires beyond a good score A token is issued only when **all** of these hold. They are checked outside the score on purpose — a score threshold answers "how suspicious is this visitor", which is the wrong question to ask of a caller that never completed the challenge: | Precondition | `reason` when it fails | |---|---| | The score is below the success threshold (0.5) | (score speaks for itself) | | A **valid proof of work** for a challenge this server issued, with the signals bound to it | `pow_not_satisfied` | | The minting origin is permitted, if `FCAPTCHA_ALLOWED_HOSTNAMES` is set | `hostname_not_allowed` | | Fewer than 10 verifications in the last minute from this page instance, device and address | `rate_limited` | | Experimental checks permit issuance, if `FCAPTCHA_EXPERIMENTAL_BLOCKING` is enabled | `experimental_detection` | The widget solves a proof of work on every path and aborts rather than submit without one, so a request that arrives without a valid solution did not come from the widget. Missing, forged, or unbound solutions are also `dispositive`: they floor the reported score at 0.9, so an integrator risk-banding on the score sees the same verdict the gate did. This matters more than it looks. The final score is a weighted sum across ~12 categories, so **any one category contributes at most its own weight** — the `bot` category caps at 0.13 against a 0.5 threshold. Before v1.23.0 that meant a bare `curl` with no proof of work and no browser was issued a valid token: every detector fired correctly and the aggregation discarded the verdict. ### POST /api/verify Verify a checkbox CAPTCHA submission. ```json // Request { "siteKey": "your-site-key", "signals": { /* collected signals */ }, "signalsJson": "{...}", // canonical serialization, hashed for signal commitment "powSolution": { "challengeId": "abc123...", "nonce": 68455, "hash": "0000abc...", "signalsHash": "9f86d0..." // SHA-256 of signalsJson, bound into the PoW input }, "powTiming": { "duration": 230, "iterations": 41000, "difficulty": 4 } } // Response { "success": true, "score": 0.15, "token": "...", "recommendation": "allow" } ``` `signalsJson` is sent alongside `signals` for deterministic hashing across languages; the server recomputes `SHA-256(signalsJson)` and checks it matches `powSolution.signalsHash`, so signals can't be swapped after the proof of work is solved. `powTiming` is sent separately (not inside the committed signals) to avoid a chicken-and-egg with PoW timing. ### POST /api/score Get a score for invisible mode. ```json // Request { "siteKey": "your-site-key", "signals": { /* collected signals */ }, "action": "login", "powSolution": { "challengeId": "abc123...", "nonce": 68455, "hash": "0000abc..." } } // Response { "success": true, "score": 0.12, "token": "...", "action": "login" } ``` ### Experimental observations Both `/api/verify` and `/api/score`, and the Node scoring library, include an `experimental` object alongside the production `score`. It is also included in verdict logs when `FCAPTCHA_LOG_VERDICTS` is enabled. `experimental.observations` contains additional versioned browser-consistency checks. Each reports its own `mode`, `status` (`detected`, `clear`, or `unknown`), and fixed detection identifiers. These observations are monitoring-only, even when the policy below is configured to block. They do not change either score, `wouldBlock`, token issuance, or challenge costs. Missing or unsupported probes report `unknown`; a detection is not proof of automation. Do not use these observations for access decisions. Experimental checks **default to monitoring only** (`experimental.mode: "observe"`). To opt into blocking, set `FCAPTCHA_EXPERIMENTAL_BLOCKING=stealth-corroboration-v1` and restart the server. The name must match the shipped policy; unset, unknown, or retired names (including `true`) remain monitoring-only. Policy changes require a new name and an explicit opt-in after upgrading. The response then reports `experimental.mode: "block"`. When experimental checks deny an otherwise acceptable request, it returns `success: false`, `recommendation: "block"`, `reason: "experimental_detection"`, and no token. Existing proof, hostname, and rate-limit failures retain their own reasons. The top-level `score` remains the baseline score in both modes; experimental results do not alter rate limits or future challenge costs. Use `success` and server-side token verification for access decisions, since a low score alone does not guarantee acceptance. Experimental checks are unvalidated and enabling blocking may reject legitimate visitors using developer tools or anti-fingerprinting tools. Monitor your traffic before opting in. The Node library accepts `experimentalBlocking: "stealth-corroboration-v1"` or `false` in `createScoringEngine()` and `createMiddleware()` options. An explicit value overrides the environment setting; unknown or retired names select monitoring, and values other than a string or `false` are rejected. Omitting the option inherits the environment setting. Configure the same policy on every replica. ### POST /api/token/verify Verify a previously issued token (server-side). `secret` is **required** and checked against `FCAPTCHA_VERIFY_SECRET` (defaulting to `FCAPTCHA_SECRET`). Until v1.22.0 it was accepted and silently ignored, which meant anyone who could reach the endpoint could spend a token — set `FCAPTCHA_LEGACY_UNAUTH_VERIFY=true` for one release if you need the old behaviour while you update your backend. `remoteip` is optional. When supplied, it must be the visitor IP associated with the original browser request and is checked against the token. When omitted, no IP check is performed. The API never uses the verification caller's socket address for this check because that caller is normally your backend server. ```json // Request { "token": "...", "secret": "your-secret", "remoteip": "203.0.113.10" } // Response { "valid": true, "site_key": "your-site-key", "score": 0.15, "timestamp": 1703356800, "hostname": "example.com", "action": "login", "cdata": "order-42" } ``` A wrong or missing secret answers `401` with `{"valid": false, "reason": "invalid_secret"}`. ### POST /turnstile/v0/siteverify — drop-in compatibility FCaptcha also answers the siteverify contract that Turnstile, reCAPTCHA and hCaptcha share, on all three paths: ``` POST /turnstile/v0/siteverify POST /recaptcha/api/siteverify POST /siteverify ``` Every backend SDK, CMS plugin and code snippet written against those services speaks this shape already, so **migrating is a base-URL change**: point your existing verification call at your FCaptcha server and keep the rest. ```bash curl -X POST https://your-server.com/turnstile/v0/siteverify \ -d "secret=your-secret" \ -d "response=$TOKEN" \ -d "remoteip=203.0.113.5" ``` Form-encoded and JSON bodies are both accepted. | Parameter | Required | Meaning | |-----------|----------|---------| | `secret` | yes | Your `FCAPTCHA_VERIFY_SECRET` (defaults to `FCAPTCHA_SECRET`) | | `response` | yes | The token from the widget | | `remoteip` | no | Visitor IP; when supplied it must match the token's binding | | `idempotency_key` | no | Lets a retry return the first answer instead of tripping the single-use guard | ```json // Success { "success": true, "challenge_ts": "2026-08-19T17:12:35.000Z", "hostname": "example.com", "action": "login", "cdata": "order-42", "error-codes": [], "score": 0.11 } // Failure { "success": false, "error-codes": ["invalid-input-response"] } ``` `score` is the one addition to the contract — ignore it for pass/fail, or use it to risk-band without a second call. Error codes use the upstream vocabulary: `missing-input-secret`, `invalid-input-secret`, `missing-input-response`, `invalid-input-response`, `bad-request`, `timeout-or-duplicate`, `internal-error`. **Verify `hostname` and `action` in your backend.** They are signed into the token, so they are the mechanism that stops a token minted on someone else's page — or minted for a different action — from being spent on yours: ```js const r = await verify(token); if (!r.success) return reject(); if (r.hostname !== 'example.com') return reject(); // key lifted from your page if (r.action !== 'login') return reject(); // token minted elsewhere on your site ``` Set `action` (and optionally `cdata`) when you request the token — `FCaptcha.execute(siteKey, { action: 'login' })` — and they are bound into it. ## Configuration ### Environment Variables | Variable | Description | Default | |----------|-------------|---------| | `FCAPTCHA_SECRET` | Secret key for token signing | (required) | | `FCAPTCHA_INSECURE_DEV_MODE` | Explicitly use the public development signing key. Local-only escape hatch; never expose a server with this enabled | off | | `FCAPTCHA_VERIFY_SECRET` | Credential a backend presents to `/api/token/verify` and the siteverify endpoints. Split it from `FCAPTCHA_SECRET` so a leaked verify credential cannot also mint tokens | (`FCAPTCHA_SECRET`) | | `FCAPTCHA_LEGACY_UNAUTH_VERIFY` | Restore the pre-1.22.0 behaviour where token verification accepted any caller. One release of migration cover; **do not leave it on** | off | | `FCAPTCHA_ALLOWED_HOSTNAMES` | Comma-separated hostnames permitted to mint tokens, matched against the request's `Origin` (then `Referer`). Unset accepts any origin. A request with no derivable origin (native app, server-side call) is always allowed — an attacker who can forge an `Origin` would just forge a listed one | (any) | | `PORT` | Server port | 3000 | | `REDIS_URL` | Share security state across replicas. Go, Node, and Python share all security stores and support multiple replicas. Configured Redis failures are fail-closed | (unset, process-local state) | | `TRUSTED_PROXIES` | Comma-separated CIDRs/IPs of peers allowed to set `X-Forwarded-For`, `X-Real-IP` and the TLS-fingerprint headers. `*` trusts every peer, `none` trusts none. See [Trusted proxies](#trusted-proxies) | loopback + private ranges | | `FCAPTCHA_SITE_KEYS` | Comma-separated allowlist of accepted site keys. Unset accepts any key (zero-config self-hosting); unlisted keys are folded into a shared overflow bucket rather than allocating their own rate-limit/fingerprint state | (any) | | `FCAPTCHA_MAX_SITE_KEYS_PER_IP` | Distinct site keys one IP may allocate state for before the excess is folded into the overflow bucket. The cap itself is unconditional | 8 | | `TRUSTED_JA4_HEADERS` | Comma-separated reverse-proxy header names carrying a JA4 TLS fingerprint (e.g. set by nginx/Cloudflare). Only these names are read, and only from a peer in `TRUSTED_PROXIES` | (none) | | `FCAPTCHA_TLS_CERT` / `FCAPTCHA_TLS_KEY` | Serve HTTPS directly (Go server). Terminating TLS here is what makes **native JA4** possible — the fingerprint is computed from the ClientHello rather than taken on trust from a proxy. Behind Railway/Cloudflare/nginx, leave unset and use `TRUSTED_JA4_HEADERS` | (none, plain HTTP) | | `FCAPTCHA_CLIENT_PATH` | Explicit path to `client/fcaptcha.js` for same-origin widget serving | (auto-probed) | | `FCAPTCHA_SERVE_CLIENT` | (Python) Serve the widget at `/fcaptcha.js`; set `false` to host the client on a separate CDN | `true` | | `FCAPTCHA_PPROF` | (Go) Enable the pprof debug server (`1`/`true`/`yes`/`on`) | off | | `FCAPTCHA_PPROF_ADDR` | (Go) Listen address for pprof when enabled — keep it loopback-only | `127.0.0.1:3001` | | `FCAPTCHA_LOG_VERDICTS` | Log one privacy-safe JSON line per `/api/verify` and `/api/score` (score, recommendation, category scores, and per-hit category/score/confidence). Omits IP, user agent, raw signals, and free-text detection reasons. For observability/tuning (`1`/`true`/`yes`/`on`) | off | | `FCAPTCHA_EXPERIMENTAL_BLOCKING` | Pin experimental blocking to `stealth-corroboration-v1`. Restart to apply. Unset, unknown, or retired names monitor only; may reject developer-tool or anti-fingerprinting users | off | | `FCAPTCHA_LOG_VERDICTS_INCLUDE_RAW` | Also include the free-text detection `reason` in verdict logs. **Reasons can contain visitor-derived data** (reverse-DNS hostnames, UA/header fragments, form field ids) — only enable in trusted debugging contexts with no privacy obligations. Requires `FCAPTCHA_LOG_VERDICTS` | off | Go and Python HTTP access logs are off by default. Set `FCAPTCHA_LOG_ACCESS=1` to enable them; they include client addresses and request URLs. This is separate from `FCAPTCHA_LOG_VERDICTS`. ### Trusted proxies Every IP-derived check — datacenter ranges, Tor/VPN, rate limiting, token IP binding, PoW difficulty — is only as good as the address the server is handed. `X-Forwarded-For` and `X-Real-IP` are set by whoever opened the connection, so FCaptcha reads them **only when the peer is in `TRUSTED_PROXIES`**. Any other caller is attributed to its socket address, and a forged header is ignored. The same gate covers `X-JA3-Hash` and any header named in `TRUSTED_JA4_HEADERS`. The default — loopback plus the private and link-local ranges — covers nginx on `127.0.0.1`, a sidecar proxy, and an in-cluster ingress with no configuration, while a server exposed directly to the internet sees public peers and therefore ignores their headers. Set it explicitly when your proxy reaches FCaptcha from an address outside those ranges — a Cloudflare Tunnel, a load balancer in another VPC, or a PaaS edge (Railway's is in the RFC 6598 CGNAT block): ```bash TRUSTED_PROXIES=100.64.0.0/10 ./fcaptcha-server # Railway ``` If you get this wrong in the *unsafe* direction nothing breaks visibly, so FCaptcha logs it: a peer that sends forwarding headers but is not trusted produces a one-time warning naming the address to add. Check your logs after deploying — an unlisted proxy means every visitor is being attributed to it, which quietly ruins rate limiting and IP reputation. `*` trusts every peer and restores the spoofing bypass — use it only when an edge you control always overwrites the headers. `none` (or an empty value) always uses the socket address. Each server logs the resolved set on startup. Full details in [INSTALLATION.md](INSTALLATION.md#trusted-proxies). ### Score Thresholds | Score | Recommendation | |-------|----------------| | < 0.3 | Allow - likely human | | 0.3 - 0.6 | Challenge - uncertain | | > 0.6 | Block - likely bot | ### How the score is composed Within a category, detections combine as **noisy-OR** — each is treated as independent evidence of strength `score x confidence`, and the category is the probability that at least one is right. Categories then contribute by weight. This replaced a confidence-weighted mean, which had a property nobody intended: corroborating evidence *lowered* the verdict. A browser reporting `navigator.webdriver = true` and nothing else scored 0.95 in the headless category; the same browser also caught with no plugins, a software renderer and five more automation tells scored **0.686**, because each additional signal was individually weaker than the first and pulled the average down. Evidence now accumulates, and an isolated low-confidence hit counts for *less* than it used to rather than setting a whole category. **Self-declared automation sets a floor.** A weighted sum across eleven categories means no single fact can consume much of the budget, so a blatant local agent used to land near 0.5 — "challenge", not "block". Detections marked `dispositive` now floor the score at 0.9. The bar for that mark is that a browser *cannot produce the signal without being automated*: `navigator.webdriver` (W3C-specified, its whole purpose is to announce automation) and ChromeDriver/Puppeteer injected globals. The DevTools console-attach probe is deliberately excluded — the benchmark's human panel proves it fires on a developer with DevTools open. This does not catch a stealth agent that patches the flag before the page sees it, and is not meant to. It closes the case where an agent is not trying to hide. ## Project Structure ``` fcaptcha/ ├── client/ │ └── fcaptcha.js # Client-side widget, signal collection, parallel PoW Web Workers ├── server-go/ │ ├── main.go # Go HTTP server + same-origin widget serving │ ├── scoring.go # Scoring engine, PoW verification, behavioral/vision/CDP detectors │ ├── detection.go # IP reputation, headers, declared-AI, JA3/JA4, form analysis │ ├── clientip.go # Trusted-proxy client IP resolution (TRUSTED_PROXIES) │ ├── sitekeys.go # Bounds on state a client-supplied siteKey can allocate │ ├── inputforensics.go # Typing cadence/modality, scroll morphology, platform coherence │ ├── ja4.go # Native JA4-TLS from the ClientHello (Go 1.24+, stdlib only) │ ├── scoring_test.go # Go unit tests │ ├── clientip_test.go # Trusted-proxy unit tests │ └── go.mod ├── server-python/ │ ├── server.py # Python/FastAPI server + PoW + detectors │ ├── detection.py # IP reputation, headers, declared-AI, JA3/JA4, form analysis │ ├── clientip.py # Trusted-proxy client IP resolution (TRUSTED_PROXIES) │ ├── sitekeys.py # Bounds on state a client-supplied siteKey can allocate │ ├── inputforensics.py # Typing cadence/modality, scroll morphology, platform coherence │ ├── test_clientip.py # Trusted-proxy unit tests │ └── requirements.txt ├── server-node/ │ ├── server.js # Node.js/Express server + PoW + detectors │ ├── detection.js # IP reputation, headers, declared-AI, JA3/JA4, form analysis │ ├── clientip.js # Trusted-proxy client IP resolution (TRUSTED_PROXIES) │ ├── limits.js # LRU-bounded stores + siteKey cardinality guard │ ├── inputforensics.js # Typing cadence/modality, scroll morphology, platform coherence │ ├── clientip.test.js # Trusted-proxy unit tests │ └── package.json ├── bench/ │ ├── capture/ # Drives real Chromium, intercepts the /api/verify body │ ├── corpus/captured/ # Committed real browser traces (14 human + 8 agent personas) │ ├── lib/ # Corpus schema, browser-paced PoW client, metrics, reporting │ ├── run-bench.js # Replay + per-signal FP budgets + CI gate │ └── README.md # What the numbers do and do not establish — read first ├── test/ │ └── test-detection.js # End-to-end detection test suite (runs against a live server) ├── demo/ │ └── index.html # Interactive demo page ├── docker/ │ ├── Dockerfile # Multi-stage build (Go binary + client + demo) │ └── docker-compose.yml # Single-instance Docker Compose deployment ├── .github/workflows/ │ ├── bench.yml # Unit tests + E2E + gated detection benchmark │ ├── docker-publish.yml # GHCR publish on release │ └── npm-publish.yml # npm publish on release ├── .dockerignore ├── ARCHITECTURE.md # Technical architecture documentation └── README.md ``` > All three servers implement the same detection engine and must stay in sync. Each has unit tests that run in CI, and `test/test-detection.js` exercises the full pipeline against a running server. ## Development ```bash # Run Go server cd server-go && FCAPTCHA_SECRET="$(openssl rand -hex 32)" go run . # Run Python server cd server-python && FCAPTCHA_SECRET="$(openssl rand -hex 32)" python server.py # Run Node server cd server-node && FCAPTCHA_SECRET="$(openssl rand -hex 32)" node server.js # Open demo open demo/index.html ``` ### Running Tests Unit tests, no server required. All three run in CI on every pull request. ```bash cd server-go && go test -race ./... # Go cd server-node && npm test # Node cd server-python && python -m unittest discover -p "test_*.py" # Python ``` The Python tests are plain functions collected by a decorator rather than `TestCase` methods, so `testkit.py` bridges them into `unittest` — run a single file directly (`python test_sitekeys.py`) for readable per-test output. Discovery and direct execution both report the same set; if the discovered count drops, a file has stopped being discoverable. The measurement harness has its own tests: ```bash cd bench && npm test ``` End-to-end detection suite (runs against a live server): ```bash # Start a server first (any language) cd server-node && FCAPTCHA_SECRET=fcaptcha-test-suite-0123456789abcdef0123456789abcdef node server.js & # Run the suite node test/test-detection.js ``` Coverage spans bot user-agents, headless/CDP detection, declared AI agents, datacenter/IP reputation, HTTP header and TLS (JA3/JA4) analysis, browser consistency, behavioral and input-event-forensics signals, vision/agent detection, form interaction (paste + programmatic fill), accessibility false positives, proof of work, token verification, and invisible-mode scoring. > The three servers do not all pass the full suite. It is written against the Node > implementation; Go and Python have documented divergences (Python maps > `datacenter` onto `BOT` and has no `datacenter` category; neither implements the > advanced headless fingerprint checks). Baseline before assuming a regression. ### Detection benchmark `bench/` measures what the detection layer actually does to real users. It drives a real Chromium through real input events, intercepts the `/api/verify` body the widget produces, and replays that labeled corpus against a running server — reporting a false-positive rate per persona, a true-positive rate per agent class, and a per-signal FP budget that gates CI. ```bash cd bench && npm install && npm run install-browsers node capture/record.js # one-time; the corpus is committed node run-bench.js # human FPR, agent TPR, per-signal budgets node run-bench.js --gate # non-zero exit when a signal is over budget ``` **Read [bench/README.md](bench/README.md) before quoting any number from it.** A 0% false-positive rate there means "no sample in this corpus crossed the threshold" — not "0% of real users would". Fourteen scripted personas are a structural stand-in for fourteen kinds of user, not a population sample, and the panel's environment is partly reconstructed because an automated browser announces itself. The harness documents both limits rather than burying them. What it is good for is catching regressions and false positives that reasoning alone misses. Its first runs found seven, including mouse-trajectory checks firing on users who have no mouse, a touch exemption that a plain tap could not satisfy, and forwarding headers scored as suspicious on every visitor behind a reverse proxy. ## Contributing Contributions welcome — please read [CONTRIBUTING.md](CONTRIBUTING.md) first. AI-agent detection is built out in phases — declared agents, input-event forensics, Web Bot Auth signature verification, the measurement harness, and typing/scroll/platform-coherence forensics have shipped; hosted-agent environment composites, accessibility-tree honeypots, and cross-session correlation are still open. The most useful contribution right now is **captured traces from real browsers driven by real people**. The benchmark corpus is currently scripted personas from a single machine, which bounds what any false-positive number from it can mean. `bench/corpus/captured/` takes new samples directly — see [bench/README.md](bench/README.md). Other open areas are listed in [CONTRIBUTING.md](CONTRIBUTING.md#what-is-most-useful-right-now), along with how to run the test suites and what to measure before adding a detector. When adding or changing a detector, apply it to **all three** server implementations (Go, Python, Node) so they stay in sync. Security problems go to [SECURITY.md](SECURITY.md), not the issue tracker. ## License MIT License - use freely, contribute back if you can. --- **Privacy Note**: FCaptcha is designed with privacy in mind. No persistent fingerprinting, no cross-site tracking, no PII collection. All fingerprints are session-scoped and used only for bot detection.
