<% set_title(product_name_long, "in 15 Minutes or Less") %> Need a quick introduction to <%=vars.product_name_long%>? Take this brief tour to try out basic features and functionality. ## Step 1: Install <%=vars.product_name_long%> See [How to Install](installation/install_standalone.html#concept_0129F6A1D0EB42C4A3D24861AF2C5425) for instructions. ## Step 2: Use gfsh to start a locator In a terminal window, use the `gfsh` command line interface to start up a locator. <%=vars.product_name_long%> *gfsh* (pronounced "jee-fish") provides a single, intuitive command-line interface from which you can launch, manage, and monitor <%=vars.product_name_long%> processes, data, and applications. See [gfsh](../tools_modules/gfsh/chapter_overview.html). The *locator* is a <%=vars.product_name%> process that tells new, connecting members where running members are located and provides load balancing for server use. A locator, by default, starts up a JMX Manager, which is used for monitoring and managing a <%=vars.product_name%> cluster. The cluster configuration service uses locators to persist and distribute cluster configurations to cluster members. See [Running <%=vars.product_name%> Locator Processes](../configuring/running/running_the_locator.html) and [Overview of the Cluster Configuration Service](../configuring/cluster_config/gfsh_persist.html). 1. Create a scratch working directory (for example, `my_geode`) and change directories into it. `gfsh` saves locator and server working directories and log files in this location. 2. Start gfsh by typing `gfsh` at the command line (or `gfsh.bat` if you are using Windows). ``` pre _________________________ __ / _____/ ______/ ______/ /____/ / / / __/ /___ /_____ / _____ / / /__/ / ____/ _____/ / / / / /______/_/ /______/_/ /_/ <%=vars.product_version%> Monitor and Manage <%=vars.product_name%> gfsh> ``` 3. At the `gfsh` prompt, type the `start locator` command and specify a name for the locator: ``` pre gfsh>start locator --name=locator1 Starting a <%=vars.product_name%> Locator in /home/username/my_geode/locator1... ................................. Locator in /home/username/my_geode/locator1 on ubuntu.local[10334] as locator1 is currently online. Process ID: 3529 Uptime: 18 seconds <%=vars.product_name%> Version: <%=vars.product_version%> Java Version: <%=vars.min_java_version%>.0.<%=vars.min_java_update%> Log File: /home/username/my_geode/locator1/locator1.log JVM Arguments: -Dgemfire.enable-cluster-configuration=true -Dgemfire.load-cluster-configuration-from-dir=false -Dgemfire.launcher.registerSignalHandlers=true -Djava.awt.headless=true -Dsun.rmi.dgc.server.gcInterval=9223372036854775806 Class-Path: /home/username/Apache_Geode_Linux/lib/geode-core-2.0.0.jar: /home/username/Apache_Geode_Linux/lib/geode-dependencies.jar Successfully connected to: JMX Manager [host=10.118.33.169, port=1099] Cluster configuration service is up and running. ``` If you run `start locator` from gfsh without specifying the member name, gfsh will automatically pick a random member name. This is useful for automation. ## Step 3: Start Pulse Start up the browser-based Pulse monitoring tool. Pulse is a Web Application that provides a graphical dashboard for monitoring vital, real-time health and performance of <%=vars.product_name%> clusters, members, and regions. See [<%=vars.product_name%> Pulse](../tools_modules/pulse/pulse-overview.html). ``` pre gfsh>start pulse ``` This command launches Pulse and automatically connects you to the JMX Manager running in the Locator. At the Pulse login screen, type in the default username `admin` and password `admin`. The Pulse application now displays the locator you just started (locator1): ## Step 4: Start a server A <%=vars.product_name%> server is a process that runs as a long-lived, configurable member of a cluster. The <%=vars.product_name%> server is used primarily for hosting long-lived data regions and for running standard <%=vars.product_name%> processes such as the server in a client/server configuration. See [Running <%=vars.product_name%> Server Processes](../configuring/running/running_the_cacheserver.html). Start the cache server: ``` pre gfsh>start server --name=server1 --server-port=40411 ``` This commands starts a cache server named "server1" on the specified port of 40411. If you run `start server` from gfsh without specifying the member name, gfsh will automatically pick a random member name. This is useful for automation. Observe the changes (new member and server) in Pulse. Try expanding the distributed system icon to see the locator and cache server graphically. ## Step 5: Create a replicated, persistent region In this step you create a region with the `gfsh` command line utility. Regions are the core building blocks of the <%=vars.product_name%> cluster and provide the means for organizing your data. The region you create for this exercise employs replication to replicate data across members of the cluster and utilizes persistence to save the data to disk. See [Data Regions](../basic_config/data_regions/chapter_overview.html#data_regions). 1. Create a replicated, persistent region: ``` pre gfsh>create region --name=regionA --type=REPLICATE_PERSISTENT Member | Status ------- | -------------------------------------- server1 | Region "/regionA" created on "server1" ``` Note that the region is hosted on server1. 2. Use the `gfsh` command line to view a list of the regions in the cluster. ``` pre gfsh>list regions List of regions --------------- regionA ``` 3. List the members of your cluster. The locator and cache server you started appear in the list: ``` pre gfsh>list members Name | Id ------------ | --------------------------------------- Coordinator: | 192.0.2.0(locator1:3529:locator):59926 locator1 | 192.0.2.0(locator1:3529:locator):59926 server1 | 192.0.2.0(server1:3883):65390 ``` 4. To view specifics about a region, type the following: ``` pre gfsh>describe region --name=regionA .......................................................... Name : regionA Data Policy : persistent replicate Hosting Members : server1 Non-Default Attributes Shared By Hosting Members Type | Name | Value ------ | ---- | ----- Region | size | 0 ``` 5. In Pulse, click the green cluster icon to see all the new members and new regions that you just added to your cluster. **Note:** Keep this `gfsh` prompt open for the next steps. ## Step 6: Manipulate data in the region and demonstrate persistence <%=vars.product_name_long%> manages data as key/value pairs. In most applications, a Java program adds, deletes and modifies stored data. You can also use gfsh commands to add and retrieve data. See [Data Commands](../tools_modules/gfsh/quick_ref_commands_by_area.html#topic_C7DB8A800D6244AE8FF3ADDCF139DCE4). 1. Run the following `put` commands to add some data to the region: ``` pre gfsh>put --region=regionA --key="1" --value="one" Result : true Key Class : java.lang.String Key : 1 Value Class : java.lang.String Old Value : gfsh>put --region=regionA --key="2" --value="two" Result : true Key Class : java.lang.String Key : 2 Value Class : java.lang.String Old Value : ``` 2. Run the following command to retrieve data from the region: ``` pre gfsh>query --query="select * from /regionA" Result : true startCount : 0 endCount : 20 Rows : 2 Result ------ two one ``` Note that the result displays the values for the two data entries you created with the `put` commands. See [Data Entries](../basic_config/data_entries_custom_classes/chapter_overview.html). 3. Stop the cache server using the following command: ``` pre gfsh>stop server --name=server1 Stopping Cache Server running in /home/username/my_geode/server1 on ubuntu.local[40411] as server1... Process ID: 3883 Log File: /home/username/my_geode/server1/server1.log .... ``` 4. Restart the cache server using the following command: ``` pre gfsh>start server --name=server1 --server-port=40411 ``` 5. Run the following command to retrieve data from the region again. Notice that the data is still available: ``` pre gfsh>query --query="select * from /regionA" Result : true startCount : 0 endCount : 20 Rows : 2 Result ------ two one ``` Because regionA uses persistence, it writes a copy of the data to disk. When a server hosting regionA starts, the data is populated into the cache. Note that the result displays the values for the two data entries you created with the `put` commands prior to stopping the server. See [Data Entries](../basic_config/data_entries_custom_classes/chapter_overview.html). See [Data Regions](../basic_config/data_regions/chapter_overview.html#data_regions). ## Step 7: Examine the effects of replication In this step, you start a second cache server. Because regionA is replicated, the data will be available on any server hosting the region. See [Data Regions](../basic_config/data_regions/chapter_overview.html#data_regions). 1. Start a second cache server: ``` pre gfsh>start server --name=server2 --server-port=40412 ``` 2. Run the `describe region` command to view information about regionA: ``` pre gfsh>describe region --name=regionA .......................................................... Name : regionA Data Policy : persistent replicate Hosting Members : server1 server2 Non-Default Attributes Shared By Hosting Members Type | Name | Value ------ | ---- | ----- Region | size | 2 ``` Note that you do not need to create regionA again for server2. The output of the command shows that regionA is hosted on both server1 and server2. When gfsh starts a server, it requests the configuration from the cluster configuration service which then distributes the shared configuration to any new servers joining the cluster. 3. Add a third data entry: ``` pre gfsh>put --region=regionA --key="3" --value="three" Result : true Key Class : java.lang.String Key : 3 Value Class : java.lang.String Old Value : ``` 4. Open the Pulse application (in a Web browser) and observe the cluster topology. You should see a locator with two attached servers. Click the Data tab to view information about regionA. 5. Stop the first cache server with the following command: ``` pre gfsh>stop server --name=server1 Stopping Cache Server running in /home/username/my_geode/server1 on ubuntu.local[40411] as server1... Process ID: 4064 Log File: /home/username/my_geode/server1/server1.log .... ``` 6. Retrieve data from the remaining cache server. ``` pre gfsh>query --query="select * from /regionA" Result : true startCount : 0 endCount : 20 Rows : 3 Result ------ two one three ``` Note that the data contains 3 entries, including the entry you just added. 7. Add a fourth data entry: ``` pre gfsh>put --region=regionA --key="4" --value="four" Result : true Key Class : java.lang.String Key : 3 Value Class : java.lang.String Old Value : ``` Note that only server2 is running. Because the data is replicated and persisted, all of the data is still available. But the new data entry is currently only available on server 2. ``` pre gfsh>describe region --name=regionA .......................................................... Name : regionA Data Policy : persistent replicate Hosting Members : server2 Non-Default Attributes Shared By Hosting Members Type | Name | Value ------ | ---- | ----- Region | size | 4 ``` 8. Stop the remaining cache server: ``` pre gfsh>stop server --name=server2 Stopping Cache Server running in /home/username/my_geode/server2 on ubuntu.local[40412] as server2... Process ID: 4185 Log File: /home/username/my_geode/server2/server2.log ..... ``` ## Step 8: Restart the cache servers in parallel In this step you restart the cache servers in parallel. Because the data is persisted, the data is available when the servers restart. Because the data is replicated, you must start the servers in parallel so that they can synchronize their data before starting. 1. Start server1. Because regionA is replicated and persistent, it needs data from the other server to start and waits for the server to start: ``` pre gfsh>start server --name=server1 --server-port=40411 Starting a <%=vars.product_name%> Server in /home/username/my_geode/server1... ............................................................................ ............................................................................ ``` Note that if you look in the server1.log file for the restarted server, you will see a log message similar to the following: ``` pre [info 2015/01/14 09:08:13.610 PST server1
tid=0x1] Region /regionA has pot entially stale data. It is waiting for another member to recover the latest data. My persistent id: DiskStore ID: 8e2d99a9-4725-47e6-800d-28a26e1d59b1 Name: server1 Location: /192.0.2.0:/home/username/my_geode/server1/. Members with potentially new data: [ DiskStore ID: 2e91b003-8954-43f9-8ba9-3c5b0cdd4dfa Name: server2 Location: /192.0.2.0:/home/username/my_geode/server2/. ] Use the "gfsh show missing-disk-stores" command to see all disk stores that are being waited on by other members. ``` 2. In a second terminal window, change directories to the scratch working directory (for example, `my_geode`) and start gfsh: ``` pre [username@localhost ~/my_geode]$ gfsh _________________________ __ / _____/ ______/ ______/ /____/ / / / __/ /___ /_____ / _____ / / /__/ / ____/ _____/ / / / / /______/_/ /______/_/ /_/ <%=vars.product_version%> Monitor and Manage <%=vars.product_name%> ``` 3. Run the following command to connect to the cluster: ``` pre gfsh>connect --locator=localhost[10334] Connecting to Locator at [host=localhost, port=10334] .. Connecting to Manager at [host=ubuntu.local, port=1099] .. Successfully connected to: [host=ubuntu.local, port=1099] ``` 4. Start server2: ``` pre gfsh>start server --name=server2 --server-port=40412 ``` When server2 starts, note that **server1 completes its start up** in the first gfsh window: ``` pre Server in /home/username/my_geode/server1 on ubuntu.local[40411] as server1 is currently online. Process ID: 3402 Uptime: 1 minute 46 seconds <%=vars.product_name%> Version: <%=vars.product_version%> Java Version: <%=vars.min_java_version%>.0.<%=vars.min_java_update%> Log File: /home/username/my_geode/server1/server1.log JVM Arguments: -Dgemfire.default.locators=192.0.2.0[10334] -Dgemfire.use-cluster-configuration=true -XX:OnOutOfMemoryError=kill -KILL %p -Dgemfire.launcher.registerSignalHandlers=true -Djava.awt.headless=true -Dsun.rmi.dgc.server.gcInterval=9223372036854775806 Class-Path: /home/username/Apache_Geode_Linux/lib/geode-core-2.0.0.jar: /home/username/Apache_Geode_Linux/lib/geode-dependencies.jar ``` 5. Verify that the locator and two servers are running: ``` pre gfsh>list members Name | Id ------------ | --------------------------------------- Coordinator: | ubuntu(locator1:2813:locator):46644 locator1 | ubuntu(locator1:2813:locator):46644 server2 | ubuntu(server2:3992):21507 server1 | ubuntu(server1:3402):36532 ``` 6. Run a query to verify that all the data you entered with the `put` commands is available: ``` pre gfsh>query --query="select * from /regionA" Result : true startCount : 0 endCount : 20 Rows : 5 Result ------ one two four Three NEXT_STEP_NAME : END ``` 7. Stop server2 with the following command: ``` pre gfsh>stop server --dir=server2 Stopping Cache Server running in /home/username/my_geode/server2 on 192.0.2.0[40412] as server2... Process ID: 3992 Log File: /home/username/my_geode/server2/server2.log .... ``` 8. Run a query to verify that all the data you entered with the `put` commands is still available: ``` pre gfsh>query --query="select * from /regionA" Result : true startCount : 0 endCount : 20 Rows : 5 Result ------ one two four Three NEXT_STEP_NAME : END ``` ## Step 9: Shut down the system including your locators To shut down your cluster, do the following: 1. In the current `gfsh` session, stop the cluster: ``` pre gfsh>shutdown --include-locators=true ``` See [shutdown](../tools_modules/gfsh/command-pages/shutdown.html). 2. When prompted, type 'Y' to confirm the shutdown of the cluster. ``` pre As a lot of data in memory will be lost, including possibly events in queues, do you really want to shutdown the entire distributed system? (Y/n): Y Shutdown is triggered gfsh> No longer connected to ubuntu.local[1099]. gfsh> ``` 3. Type `exit` to quit the gfsh shell. ## Step 10: What to do next... Here are some suggestions on what to explore next with <%=vars.product_name_long%>: - To ensure that your Geode instances are secure, see: [Security](../security/chapter_overview.html). - To get more practice using `gfsh`, see [Tutorial—Performing Common Tasks with gfsh](../tools_modules/gfsh/tour_of_gfsh.html#concept_0B7DE9DEC1524ED0897C144EE1B83A34). - To learn about the cluster configuration service, see [Tutorial—Creating and Using a Cluster Configuration](../configuring/cluster_config/persisting_configurations.html#task_bt3_z1v_dl). - Continue reading the next section to learn more about the components and concepts that were just introduced.
