# tufte-claude-skill A Claude Code skill that turns "make me a chart" into a Tufte-compliant chart. Distilled from the three foundational books by Edward R. Tufte.


The Visual Display of Quantitative Information 1983 · 2nd ed. 2001 _{pictures of numbers}	Envisioning Information 1990 _{pictures of nouns}	Visual Explanations 1997 _{pictures of verbs}

--- ## Install Clone into your Claude Code skills directory: ```bash git clone https://github.com/aref-vc/tufte-claude-skill.git ~/.claude/skills/tufte ``` That's it. Claude Code auto-loads the skill on next launch. To verify, run `/tufte` or ask Claude to "make a chart of anything." To update later: ```bash cd ~/.claude/skills/tufte && git pull ``` To uninstall: ```bash rm -rf ~/.claude/skills/tufte ``` --- ## The three books, distilled Tufte gives the three-book taxonomy himself on page 9 of *Visual Explanations*: - **VDQI** — how to depict data and enforce statistical honesty. The book that gave us *data-ink ratio*, *chartjunk*, *lie factor*, *small multiples*. - **EI** — how to lay out information in space. Layering, micro/macro readings, color rules, escaping flatland. - **VE** — how to show motion, causality, narrative. The smallest effective difference, parallelism, visual confections. Together they yield the ten principles this skill applies. ### The ten principles 1. **Show the data.** Above all else. Every other decision asks "does this help the reader see the data?" 2. **Maximize the data-ink ratio.** Ink that would change if the data changed is data-ink. Everything else is overhead. 3. **Erase non-data-ink.** Drop the frame box, drop the gridlines, drop the ticks at minor units. 4. **Erase redundant data-ink.** Pick one encoding per quantity. A bar plus a number plus a gridline plus an axis tick all saying "37" is one thing said four times. 5. **Graphical integrity.** Lie factor between 0.95 and 1.05. Bar charts start at zero. Never use area for a 1D quantity. 6. **Small multiples.** When you have a cross-cut (region, segment, cohort), make N small charts on a shared scale instead of one chart with N lines. 7. **Layering and separation.** Data on top, labels next, scaffolding faintest. Watch for the *1+1=3 effect* — when two heavy elements interact to create unintended visual noise. 8. **Micro/macro readings.** Good charts work at two scales: one shape from across the room, every data point legible up close. 9. **The smallest effective difference.** "Make all visual distinctions as subtle as possible, but still clear and effective." Gray for context, one accent for focus. 10. **Word-data integration.** Sparklines belong in sentences. Numbers belong next to their visual. Tables are charts too. Tufte's own five-line summary from VDQI p.105: > Above all else show the data. > Maximize the data-ink ratio. > Erase non-data-ink. > Erase redundant data-ink. > Revise and edit. --- ## How the skill works When you ask Claude to make, design, critique, or improve any chart, the skill activates automatically. It then: 1. **Reads `principles.md`** to recall the ten rules. 2. **Picks the chart type** from `chart-selection.md` based on your data shape and goal — not from what's familiar or what the library makes easy. 3. **Applies `kill-list.md`** — removes the things that don't belong (3D, pie, dual-axis, rainbow scales, frame boxes, redundant legends). 4. **Produces the chart** in your preferred stack: self-contained HTML/SVG, or React (Recharts + D3). 5. **Runs `checklist.md`** as a final pass before declaring it done. Default strictness: Tufte by default, override per chart on request ("I need a pie because the CFO wants one" → comply, but note the alternative). --- ## The one-page cheatsheet A printable reference covering principles, lie-factor formula, chart-selection table, kill list, color rules, and the 12-item checklist. Open [`cheatsheet.html`](./cheatsheet.html) in a browser or print [`cheatsheet.pdf`](./cheatsheet.pdf). ![One-page Tufte cheatsheet](assets/cheatsheet.png) --- ## Before and after Nine pairs comparing typical AI/BI default output (left) to Tufte-applied output (right). The full interactive gallery is at [`before-after.html`](./before-after.html) — open in any browser. Six pairs inlined here: ### 1. Category comparison — sales by product ![Before vs after: category comparison](assets/pair-1-category.png) 3D bars with a six-color rainbow legend become a sorted dot plot with direct labels. The reader ranks in two seconds instead of decoding a key. ### 2. Time series — monthly active users ![Before vs after: time series](assets/pair-3-timeseries.png) A line chart trapped in a frame box (with gridlines, legend, axis title, chart title) becomes a sparkline plus the current value plus two endpoint labels. Same data, ~80% less ink. ### 3. Dashboard — four KPIs ![Before vs after: dashboard](assets/pair-4-dashboard.png) Four KPI tiles with giant numbers and decorative icons become a compact table with value, sparkline (10-month trend), and delta-to-target. One accent color flags the metric that's off-target. ### 4. Period comparison — Q2 vs Q3 by team ![Before vs after: slopegraph](assets/pair-7-slopegraph.png) Clustered bars (two colors, ten bars to mentally pair up) become a slopegraph. Each line's slope is the change. Steepest gainer and only decliner read instantly without decoding a legend. ### 5. Conversion funnel — signup flow ![Before vs after: funnel](assets/pair-8-funnel.png) A 3D tapered funnel chart (where the visual taper exaggerates the drop-off) becomes horizontal bars sized by share of stage 1, with retention percentage printed per step. The worst step is annotated. ### 6. Cohort retention ![Before vs after: cohort retention](assets/pair-9-cohort.png) A rainbow heatmap (where viewers guess if yellow is more than green) becomes a sequential single-hue table with numbers printed in every cell and a sparkline showing each cohort's decay shape. The other three pairs in the gallery: part-to-whole (pie → sorted table), distribution (rainbow histogram → strip plot with quantile markers), geographic (rainbow choropleth → sequential single-hue with annotations). --- ## When to use the skill The skill auto-activates on any of these: - "Make a chart of...", "visualize...", "graph...", "plot..." - "Build a dashboard for...", "design a KPI tile..." - "Improve this chart", "critique this visual" - "What chart should I use for...?" - Direct invocation: `/tufte` or mentioning Tufte by name - Any project where chart code is being added or edited It does *not* activate for: - Logo design, illustration, or decorative graphics - Flowcharts, architecture diagrams, hand-drawn sketches - Pure typography or layout that has no quantitative data --- ## How to use the skill ### Fast path Just ask. The skill loads automatically and produces a Tufte-compliant chart: > Make a chart of monthly revenue for the last 12 months You'll get a sparkline with the current value, two endpoint labels, no frame box, no legend. ### Stack choice Tell Claude which output you want: | Say | You'll get | |---|---| | "as inline SVG" or no preference | Self-contained HTML/SVG, single file | | "in React" or "with Recharts" | Recharts component with Tufte theme | | "with D3" | D3-in-React (for dot plots, slopegraphs, custom small multiples) | ### Override the defaults If you specifically need something on the kill list: > Make a pie chart of revenue mix — the CFO wants a pie Claude will produce the pie, but include a one-line comment noting the Tufte alternative (a sorted table). You stay in control. ### Iterate on an existing chart Paste your chart code or screenshot and say: > Apply Tufte to this Claude will identify violations (frame box, gridlines, gradient fills, redundant legend, wrong sort), and produce a rewritten version. --- ## File index | File | Purpose | |---|---| | [`SKILL.md`](./SKILL.md) | Trigger description + skill index (loaded by Claude) | | [`principles.md`](./principles.md) | The ten rules, with Tufte's exact quotes | | [`chart-selection.md`](./chart-selection.md) | Data + goal → chart type decision table | | [`kill-list.md`](./kill-list.md) | What to remove from any chart | | [`before-after.html`](./before-after.html) | Nine side-by-side comparisons (open in browser) | | [`checklist.md`](./checklist.md) | 12-item pre-publish check | | [`cheatsheet.html`](./cheatsheet.html) / [`cheatsheet.pdf`](./cheatsheet.pdf) | One-page printable reference | | [`presets/html-svg.md`](./presets/html-svg.md) | Style tokens + working SVG templates (sparkline, dot plot, line, small multiples, sparkline-in-table) | | [`presets/react.md`](./presets/react.md) | Recharts theme + D3-in-React patterns (slopegraph, dot plot, what-to-never-import list) | --- ## Requirements - [Claude Code](https://docs.claude.com/en/docs/claude-code) installed - Skill auto-loads from `~/.claude/skills/` - No other dependencies for the skill itself - The cheatsheet PDF is included, but to regenerate it from the HTML you'll need [`weasyprint`](https://weasyprint.org/) (`pip install weasyprint`) --- ## Contributing Pull requests welcome. Useful additions: - More before/after pairs (sankey, network, gantt, calendar heatmap, control chart) - Output presets for other stacks: Python (matplotlib, plotly), Observable Plot, Vega-Lite, ggplot2 - Examples that show Tufte applied to real-world charts you've improved Open an issue first for anything that adds a new chart type to the decision table — let's discuss the rule before adding it. --- ## License [MIT](./LICENSE). Use it, modify it, ship it. The skill content is original; quotations from Tufte's books are used under fair-use for educational reference and are attributed inline. --- > The principles of information design are universal — like mathematics — and are not tied to unique features of a particular language or culture. > > — Edward R. Tufte, *Envisioning Information*, p. 10
