# LightweightCharts.jl [](https://bhftbootcamp.github.io/LightweightCharts.jl/stable/) [](https://bhftbootcamp.github.io/LightweightCharts.jl/dev/) [](https://github.com/bhftbootcamp/LightweightCharts.jl/actions/workflows/CI.yml?query=branch%3Amaster) [](https://codecov.io/gh/bhftbootcamp/LightweightCharts.jl) [](https://github.com/JuliaRegistries/General) LightweightCharts is a convenient Julia wrapper for the [Lightweight Charts™](https://github.com/tradingview/lightweight-charts) library by [TradingView, Inc.](https://www.tradingview.com/), designed to output graphical data to an HTML page. ## Installation To install LightweightCharts, simply use the Julia package manager: ```julia ] add LightweightCharts ``` ## Usage Simple line chart with styling options: ```julia using LightweightCharts t_values = round(Int64, time()) .+ collect(1:500) x_values = sin.((1:500) / 10) chart = lwc_line( t_values, x_values; label_name = "lwc_line", line_color = "orange", line_width = 4, line_style = LWC_SOLID, line_type = LWC_STEP, price_scale_id = LWC_LEFT, plugins = LWCPlugin[ lwc_trend_line(100, 0.32, 200, 0.86; line_color = "#9d4edd"), # lwc_delta_tooltip(), # lwc_vert_line(150), # lwc_crosshair_highlight_bar(), # lwc_tooltip(; title = "my_tooltip") ], ) lwc_show(chart) ```  The package also support custom data types (for more information, see the [documentation](https://bhftbootcamp.github.io/LightweightCharts.jl/stable/pages/charts/#custom_data)). In the following example we used [TimeArrays](https://github.com/bhftbootcamp/TimeArrays.jl) to smooth prices: ```julia using TimeArrays using LightweightCharts julia> prices = ta_price_sample_data() 7777-element TimeArray{DateTime, Float64}: TimeTick(2024-04-01T00:00:00.661, 0.6501) TimeTick(2024-04-01T00:05:57.481, 0.6505) ⋮ TimeTick(2024-04-30T23:42:11.920, 0.4417) panel = lwc_panel( lwc_line( prices; label_name = "price", line_color = "#adb5bd", line_type = LWC_STEP, precision = 4, ), lwc_line( ta_sma(prices, 20); label_name = "sma price", line_color = "red", precision = 4, ), lwc_line( ta_wma(prices, 20); label_name = "wma price", line_color = "orange", precision = 4, ), lwc_line( ta_ema(prices, 20); label_name = "ema price", line_color = "green", precision = 4, ); name = "LightweightCharts ❤️ TimeArrays", default_legend_visible = false, h = 1.0, ) lwc_show(panel) ```  Composite layout featuring diverse chart types: ```julia using Dates using NanoDates using LightweightCharts layout = lwc_layout( lwc_panel( lwc_area( NanoDate("2024-01-01") .+ Second.(1:500), map(x -> rand(1:500), collect(1:500)); label_name = "lwc_area", line_color = "#49c7e3", top_color = "#74d7ed", bottom_color = "#85f2f000", line_style = LWC_SOLID, line_type = LWC_STEP, line_width = 2, precision = 3, price_scale_id = LWC_LEFT, ), lwc_line( NanoDate("2024-01-01") .+ Second.(1:500), map(x -> rand(1:500), collect(1:500)); label_name = "lwc_line", line_color = "#ff5752", line_style = LWC_DASHED, line_type = LWC_SIMPLE, line_width = 3, price_scale_id = LWC_RIGHT, ); last_value_visible = true, title_visible = true, default_legend_visible = false, x = 1, y = 1, ), lwc_panel( lwc_baseline( NanoDate("2024-01-01") .+ Second.(1:500), map(x -> rand(1:500), collect(1:500)); label_name = "lwc_baseline", base_value = LWCBaseValue("price", 250), line_style = LWC_SOLID, line_type = LWC_CURVED, line_width = 3, precision = 4, price_scale_id = LWC_RIGHT, ); x = 2, y = 1, ); name = "LightweightCharts ❤️ Julia" ) lwc_show(layout) ```  Scatter plot with distinct color: ```julia using LightweightCharts chart = lwc_panel( lwc_line( round(Int64, time()) .+ collect(1:5000), map(x -> 1.4 + rand([0.0:0.005:0.8..., 0.8:0.01:0.9...])^10.0, 1:5000); label_name = "scatter_purple", line_color = "#9558b2", point_markers_visible = true, line_visible = false, ), lwc_line( round(Int64, time()) .+ collect(1:5000), map(x -> 1.2 + rand([0.0:0.005:0.8..., 0.8:0.01:0.9...])^10.0, 1:5000); label_name = "scatter_green", line_color = "#389826", point_markers_visible = true, line_visible = false, ), lwc_line( round(Int64, time()) .+ collect(1:5000), map(x -> 1.0 + rand([0.0:0.005:0.8..., 0.8:0.01:0.9...])^10.0, 1:5000); label_name = "scatter_red", line_color = "#cb3c33", point_markers_visible = true, line_visible = false, ); crosshair_settings = CrosshairOptions(; mode = LWC_CROSSHAIR_NORMAL, vert_line = CrosshairLineOptions(; style = LWC_CROSSHAIR_SOLID, color = "#C3BCDB44", label_background_color = "#9B7DFF", width = 8, ), horz_line = CrosshairLineOptions(; color = "#9B7DFF", label_background_color = "#9B7DFF", ) ), last_value_visible = true, title_visible = true, max_y = 1.6, h = 1.0 ) lwc_show(chart) ```  ## Contributing Contributions to LightweightCharts are welcome! If you encounter a bug, have a feature request, or would like to contribute code, please open an issue or a pull request on GitHub. ## Useful Links - [tradingview/lightweight-charts](https://github.com/tradingview/lightweight-charts) – Performant financial charts built with HTML5 canvas - [Lightweight Charts™ Documentation](https://www.tradingview.com/lightweight-charts/) – Official TradingView Lightweight Charts documentation - [LightweightCharts.jl Documentation](https://bhftbootcamp.github.io/LightweightCharts.jl/stable/) – Stable documentation for LightweightCharts.jl
