# π RGB LED Strip Control System - Custom Project Guide
## πΎ YouTube Video
[YouTube Video](https://youtube.com/shorts/QAX4ULTzuk8)
## π Project Overview
This document details an ESP32-based RGB LED control system with the following capabilities:
- π 2-channel PWM control for red and green LED strips
- π Automatic relay control after 19:00 based on Turkey/Istanbul time
- π± Web interface and physical button control
- π HC-SR04 presence detection for energy saving
- π€οΈ LED dance mode based on Turkey/Ankara weather conditions
## π οΈ Hardware Details
### π§ Required Components
| Component | Qty | Notes |
|----------------------|-----|----------------------------|
| ESP32 DevKit v1 | 1 | Other versions compatible |
| IRFZ44N MOSFET | 2 | For red and green LEDs |
| 5V Relay Module | 1 | Room light control |
| HC-SR04 | 1 | Distance measurement |
| 128x64 OLED (I2C) | 1 | GPIO6 SDA, GPIO7 SCL |
| 10K Potentiometer | 2 | GPIO4 and GPIO5 |
| Button | 3 | GPIO8, GPIO9, GPIO10 |
| 10K Resistor | 5 | For pull-up |
| Breadboard | 1 | Prototyping |
| Jumper Wires | 20+ | For connections |
### ποΈ Pin Connection Diagram
```mermaid
graph TD;
ESP32-->|GPIO4|POT1[Potentiometer 1];
ESP32-->|GPIO5|POT2[Potentiometer 2];
ESP32-->|GPIO8|BTN1[Button 1];
ESP32-->|GPIO9|BTN2[Button 2];
ESP32-->|GPIO10|BTN3[Button 3];
ESP32-->|GPIO12|MOSFET1[IRFZ44N Red];
ESP32-->|GPIO13|MOSFET2[IRFZ44N Green];
ESP32-->|GPIO21|RELAY1[Relay];
ESP32-->|GPIO7|OLED_SCL[OLED SCL];
ESP32-->|GPIO6|OLED_SDA[OLED SDA];
ESP32-->|GPIO14|TRIG[HC-SR04 Trig];
ESP32-->|GPIO15|ECHO[HC-SR04 Echo];
MOSFET1-->LED1[Red LED Strip];
MOSFET2-->LED2[Green LED Strip];
RELAY1-->LIGHT[Room Light];
```
### β‘ Power Management
```mermaid
pie
title Power Consumption (Maximum)
"ESP32" : 120
"LED Strip (12V)" : 2000
"Relay Module" : 80
"HC-SR04" : 15
"OLED Display" : 25
```
## πΎ Software Installation
### π₯ Required Libraries
1. **Core Libraries**:
- `Adafruit_GFX` (v1.10.12)
- `Adafruit_SSD1306` (v2.5.7)
- `WiFi` (v2.0.0)
- `ESPAsyncWebServer` (v3.1.0)
2. **Time and Weather**:
- `NTPClient` (v3.2.1)
- `ArduinoJson` (v6.19.4)
- `HTTPClient` (v1.2)
### βοΈ Code Structure (Detailed)
```plaintext
/RGB-Control-System-with-ESP32-C6
βββ /web-server
β βββ config.php
β βββ connect.php
β βββ color.php
β βββ relay.php
βββ /includes
β βββ functions.php
βββ index.php
βββ /src
β βββ main.ino
βββ βββ settings.h
```
### π Flashing Process
1. In Arduino IDE:
- Tools > Board > ESP32 Dev Module
- Flash Mode: "QIO"
- Flash Size: "4MB (32Mb)"
- Partition Scheme: "Default 4MB"
2. Custom settings:
```cpp
#define WIFI_SSID "YourSSID"
#define WIFI_PASS "YourPassword"
#define OWM_API_KEY "YourAPIKey"
```
## ποΈ System Features
### π‘ LED Control System
- **PWM Specifications**:
- 8-bit resolution (0-255)
- 5kHz PWM frequency
- **Control**:
- POT1 for red LED adjustment
- POT2 for green LED adjustment
### β±οΈ Timing System
- Turkey/Istanbul timezone (GMT+3)
- Relay activates after 19:00 based on HC-SR04 data:
- Person in room: ON
- Person leaves: OFF
### π€οΈ Weather Integration
- Ankara weather (OpenWeatherMap API):
```http
GET https://api.openweathermap.org/data/2.5/weather?q=Ankara,TR&appid=YOUR_API_KEY&units=metric&lang=en
```
- BTN3 dance mode: LEDs synchronize based on weather conditions.
## π₯οΈ User Interface
### πΊ OLED Menu Structure
```mermaid
graph TD;
A[Main Menu] --> B[LED Values];
A --> C[Relay Status];
A --> D[MOSFET Status];
B --> B1[Red: 0-255];
B --> B2[Green: 0-255];
C --> C1[ON/OFF];
D --> D1[PWM Setting];
D --> D2[ON/OFF];
```
### πΉοΈ Button Controls
| Button | Single Click | Double Click | Usage |
|--------|------------------|---------------------|--------------------------|
| BTN1 | Menu down | Relay status | POT1 value adjustment |
| BTN2 | Menu up | MOSFET status | POT1 value adjustment |
| BTN3 | Confirm selection | Dance mode | Toggle operations |
### π Web Interface
- **Endpoints**:
```
/ # Homepage
/relay/on # Relay on
/relay/off # Relay off
```
## π§ Troubleshooting - Ultimate Guide
### π¨ Common Issues
1. **LEDs not lighting**:
- Check MOSFET gate resistor (10K-100Ξ©)
- Verify 12V power supply adequacy
- Reduce PWM frequency (try 500Hz)
2. **HC-SR04 incorrect measurements**:
```cpp
// Correct settings:
#define TRIG_PULSE 10 // 10ΞΌs trigger pulse
#define MAX_DISTANCE 400 // Maximum 4m
```
3. **WiFi connection issues**:
- Use `WiFi.mode(WIFI_STA);`
- Channel setting:
```cpp
WiFi.begin(ssid, password, 6); // Channel 6
```
### π Test Commands (Serial Monitor)
```bash
# System info
> SYSTEM INFO
# LED test
> LED TEST RED 255
# Relay test
> RELAY TOGGLE
# Sensor test
> SENSOR READ
```
## π Advanced Settings
### βοΈ EEPROM Configuration
| Address | Data | Size |
|---------|------------|---------|
| 0x00 | WiFi SSID | 32 byte |
| 0x20 | WiFi Pass | 64 byte |
| 0x60 | LED Settings | 16 byte |
| 0x70 | Timing | 32 byte |
## π License
- **License**: CERN-OHL-S-2.0
