[](https://github.com/ibrahimilkhan/mqtt-forge/releases/latest) [](LICENSE) An MQTT test tool: connect to a broker, watch the traffic, chart it, publish back. Open source, small and fast. It runs on macOS, Windows, Linux and Docker.  ## What it does - **Topic tree** — every topic the broker carries, with its latest value. - **Log** — the newest message on whatever you pick, with its time, QoS and size, and the history behind it. - **Charts** — any topic sending numbers gets a plot and a summary. A JSON body's fields are chartable by name. - **Messages** — open one in its own window; a JSON body becomes a foldable document with an index. - **Publish** — text, JSON or hex, with QoS and the retained flag. Any logged message loads back into the form. - **Colour rules** — give a filter a colour and every topic it covers wears it, with a second colour for the message under it if you want one. - **Filters, QR, settings** — subscribe to a list of filters, open the session on your phone, set the fonts. ## Download ### Desktop [](https://github.com/ibrahimilkhan/mqtt-forge/releases/latest/download/MQTTForge-windows-x64.zip) [](https://github.com/ibrahimilkhan/mqtt-forge/releases/latest/download/MQTTForge-linux-x64.tar.gz) [](https://github.com/ibrahimilkhan/mqtt-forge/releases/latest/download/MQTTForge-macos-arm64.dmg) [](https://github.com/ibrahimilkhan/mqtt-forge/releases/latest/download/MQTTForge-macos-x64.dmg)

The desktop builds are not signed, so each system asks once

Signing needs a paid certificate this project does not have. - **macOS** — System Settings → Privacy & Security → **Open Anyway**, or right-click → Open on macOS 14 and earlier. Or `xattr -dr com.apple.quarantine /Applications/MQTTForge.app`. - **Windows** — SmartScreen: More info → Run anyway. - **Linux** — install `libwebkit2gtk-4.1-0` if no window appears.

### Docker [](https://github.com/ibrahimilkhan/mqtt-forge/pkgs/container/mqtt-forge) Run it as a container and open http://localhost:5169: ``` docker run -d -p 5169:5169 --name mqtt-forge ghcr.io/ibrahimilkhan/mqtt-forge ```

Running the container next to your broker

Inside a container `localhost` means the container. Use your broker's hostname or IP; for one on this machine outside Docker, `host.docker.internal` (on Linux add `--add-host=host.docker.internal:host-gateway`). Certificates are read inside the container — mount them and give the panel the path in there: ``` docker run -d -p 5169:5169 -v ~/certs:/certs:ro ghcr.io/ibrahimilkhan/mqtt-forge ``` To keep settings across `docker rm`, name a settings file on a volume: ``` docker run -d -p 5169:5169 \ -e MqttForge__SettingsPath=/data/connection-settings.json \ -v mqtt-forge-data:/data \ --name mqtt-forge ghcr.io/ibrahimilkhan/mqtt-forge ``` The desktop app keeps its files in the normal per-user folder. > Both listen on all interfaces, which is what the QR panel needs. On a shared network use > `-p 127.0.0.1:5169:5169`. The broker password is stored as plain text.

Either way, paste your broker's address into the panel that opens. `mqtts://host:8883` goes in whole. ## Connecting MQTT **5.0, 3.1.1 and 3.1**, over **`mqtt://`, `mqtts://`, `ws://` and `wss://`**. It offers 5.0 first and keeps whatever the broker accepts. Client certificates, an extra CA, a server name and ALPN are under **Encryption**. Most brokers need none of it. A failed connection names the cause and what to do about it. Once a link is up the panel stops asking and starts reporting: the state in words, the address, and what the broker agreed to — version, session, keep-alive, how many filters are up. The form is not there, because none of it is a question any more. The panel is the window either way, and the tree is behind it until you close it. **Subscription** is what the console subscribes to on connect: topic filters, one per line, in the order you write them. **Subscribe #** and **Subscribe $SYS** are the first two lines of that list — a box is ticked when the list holds its filter, and deleting the line unticks it. Open **Topic filters** to write your own. `$SYS` is a second subscription rather than part of `#`, because `#` cannot reach it: MQTT does not let a filter starting with a wildcard match a topic starting with `$`. It is off by default — those topics are republished on a timer, so a console that asked for them without being told would fill its log with a subtree nobody wanted. MQTT Explorer asks for both and has this one on. Not every broker has the tree: EMQX refuses the subscription and the log says so, and HiveMQ CE accepts it and publishes nothing — after 20 seconds with nothing under `$SYS/`, the log says that too. A filter the broker refuses is a line in the log and nothing more; the rest are still asked for. ### When the link drops MQTTForge puts a dropped link back up on its own, and it tells you it is doing it. The Broker panel opens by itself, and a notice says what broke the link and counts down to the next try — 1, 2, 4, 8, 16 and then every 30 seconds. **Stop trying** calls off this outage and leaves the link alone until you connect again; **Connect** on the form does not wait for the count. Some faults it does not retry, because retrying could not fix them and sometimes makes them worse: a rejected password, a certificate nobody trusts, a client ID another client has just taken. The notice says the fault is one to fix rather than wait out, and **Try now** attempts it once as it stands if you want to. When a retry does succeed, the topics you were watching are subscribed again on their own. When the link comes back the panel stays open rather than closing on you: it says the link is back, what had broken it, and how long it was gone. Beside the form — under it on a narrow window — **Broker events** keeps the record: every connect, every subscription the broker took or refused, every drop, every try the ladder made, and the link coming back. The log starts again with each connection; this list does not. The **Broker** row in the rail carries all of this as a colour: green while there is a link, amber while something is being done about there not being one — a connect in flight, a reconnect being tried — and red when the link is down and nothing is happening. It goes on naming the broker while the link is down, which is when you most want to know which one went. **Reconnect automatically if the link drops** turns the whole arrangement off. It is on by default, because a MQTTForge running alert rules with no browser pointed at it has to survive a broker restart, and it is remembered in `reconnect.json` beside your other settings. With it off, a dropped link stays down until you press **Connect**. ## Reading a message Double-click a message to open it in its own window. A JSON body becomes a document you can fold, with an index of its top level down the left. The mark in the corner copies what arrived.  ## Charts A topic sending numbers gets a plot and a summary: count, mean, median, spread, range, trend, where it stepped, whether it cycles, and which readings do not belong. The kind of run decides what is said. A temperature gets a mean and a trend; a door or a pump gets counted and timed; a meter gets the rate it climbs at. **auto**, **ends**, **mid** and **log** set the range — readings outside it are drawn on the edge and counted. **time** and **dist** change the view, **csv** saves it. Pin a chart as a window and it keeps its topic while you use the rest of the console.  ## Colouring topics Give the **Colours** panel a filter and a colour — `sensors/+/temp`, `alerts/#` — and every topic it covers is drawn in it, in the tree and in the log. The more exact filter wins. A rule can carry a second colour for the message under the topic. Most rules do not: the path is what tells a scrolling log apart, and the payload stays in the console's own ink. Give one to the rule whose payloads you are actually reading.  ## Alerts Give a rule a filter and a condition — `plant/+/temp` over 90 — and MQTTForge watches for it. A rule that fires raises an alert. Pick what happens: a notice on screen, a tone, a POST to an address you name, or the alert published back onto the broker. Any of the four, or all of them. Rules are written in the **Alerts** panel. Each one opens in a window of its own, carrying the fields its condition needs and nothing else. The panel lists the rules and what each one is seeing — how many topics it covers, how many readings it has read, when it last fired. It is about what is being watched for; how many alarms are ringing is the count on the **Alerts** button in the rail.  A rule subscribes its own filter. Alerting works with the console shut, and in a container with no browser pointed at it at all: the Docker image dials the saved broker as it starts when a rule is enabled. Everywhere else the console opens on the **Broker** panel and waits for you to press Connect; `MqttForge__ConnectOnStart=true` makes any host dial at start-up, and `false` stops the container doing it. Conditions cover a threshold, a band, a text pattern, a set of values, and silence — a topic that has stopped publishing. Four more ask about the readings as a run rather than one at a time: an **outlier**, a reading unlike the ones before it; a **distribution shift**, readings that stop being the shape they were; a **shape change**, a quantity that becomes a switch or a pulse train that stops; and **pulse**, the count, duty, period or width of a signal's own rhythm. Those four need no number from you — a rule that says "tell me when this line stops behaving as it does" works without anybody knowing what it does. Each watches a window of 20 to 2000 readings and says nothing until it has 20 of them, and the panel says how far along each topic is while it fills. **for** waits for the state to hold before it fires, **cooldown** keeps a flapping sensor from filling the panel, and muting a topic quietens it for a while without touching the rule. The **Alerts** button in the rail carries the count of what is ringing, and turns the colour of the worst of them, whatever you have open. The tone needs one click to start — no browser makes a sound before somebody has clicked the page — and the console says so while it is waiting for that click, rather than being on and silent. An alarm survives a restart. What was ringing when the process stopped is still ringing when it comes back, and an alarm whose rule was edited while the process was down ends rather than returning. Rules are kept in `alert-rules.json` beside your other settings. Webhook headers are stored in that file as plain text; `MqttForge__AllowWebhooks=false` turns webhooks off altogether. [SECURITY.md](SECURITY.md) says what that trade is. The editor shows the header names a rule already has with an empty value box beside each: leave it empty and the stored value is kept. Header values never come back out of the server. ## What it costs Measured on a live tram feed: | Holding | Taking it in | Drawing | | --- | --- | --- | | 128k messages · 6.7k topics · 36.8 MB | 1 ms per second | 47 fps | The log keeps half a million messages and drops the oldest. The tree keeps fifty thousand topics and gives up the ones that have been quiet longest, taking their messages with them — a broker whose topic names carry an id (`request//response`) would otherwise grow a console left open for days without end. It says underneath how many it has forgotten. It keeps the first 4 kB of each message for the value on the row; publishing one again takes the whole body from the log. ## Next - **Automation** — run a scripted sequence of publishes and expected replies. - **Recording** — save a session's traffic and play it back. - **Load testing** — many clients at a sustained rate. ## Build it yourself Needs .NET 10 and Node 22+. ``` dotnet run --project src/MqttForge.Api # http://localhost:5169 npm --prefix web run dev # http://localhost:5173 ``` `dotnet publish -c Release` builds everything into one process. [CONTRIBUTING.md](CONTRIBUTING.md) has the rest. ## Ideas are welcome Anything missing or broken — [open an issue](https://github.com/ibrahimilkhan/mqtt-forge/issues). One sentence is enough. ## Licence [AGPL-3.0](LICENSE).
