{ "cells": [ { "cell_type": "markdown", "metadata": {}, "source": [ "# Single image super-resolution with deep neural networks\n", "\n", "This article is an introduction to single image super-resolution. It covers some important developments in recent years and shows their implementation in Tensorflow 2.0. The primary focus is on specialized residual network architectures and generative adversarial networks (GANs) for fine-tuning super-resolution models. \n", "\n", "Super-resolution is the process of recovering a high-resolution (HR) image from a low-resolution (LR) image. We will refer to a recovered HR image as *super-resolved image* or *SR image*. Super-resolution is an ill-posed problem since a large number of solutions exist for a single pixel in an LR image. Simple approaches like bilinear or bicubic interpolation use only local information in an LR image to compute pixel values in the corresponding SR image. \n", "\n", "Supervised machine learning approaches, on the other hand, learn mapping functions from LR images to HR images from a large number of examples. Super-resolution models are trained with LR images as input and HR images as target. The mapping function learned by these models is the inverse of a downgrade function that transforms HR images to LR images. Downgrade functions can be known or unknown. \n", "\n", "Known downgrade functions are used in image processing pipelines, for example, like bicubic downsampling. With known downgrade functions, LR images can be automatically obtained from HR images. This allows the creation of large training datasets from a vast amount of freely available HR images which enables [self-supervised learning](https://hackernoon.com/self-supervised-learning-gets-us-closer-to-autonomous-learning-be77e6c86b5a).\n", "\n", "If the downgrade function is unknown, supervised model training requires existing LR and HR image pairs to be available which can be difficult to collect. Alternatively, unsupervised learning methods can be used that learn to approximate the downgrade function from unpaired LR and HR images. In this article though, we will use a known downgrade function (bicubic downsampling) and follow a supervised learning approach. \n", "\n", "A more detailed overview on single image super-resolution is given in [these](https://arxiv.org/abs/1902.06068) [papers](https://arxiv.org/abs/1904.07523). A higher-level training API for the example code in this article is implemented in [this repository](https://github.com/krasserm/super-resolution).\n", "\n", "## High-level architecture\n", "\n", "Many state-of-the-art super-resolution models learn most of the mapping function in LR space followed by one or more upsampling layers at the end of the network. This is called *post-upsampling SR* in Fig. 1. Upsampling layers are learnable and trained together with the preceding convolution layers in an end-to-end manner. \n", "\n", "![Fig. 1](docs/images/figure_1.png)\n", "
