# MegaManX5Recomp
> _This recompilation is a **byproduct of developing
> [psxrecomp](https://github.com/mstan/psxrecomp)** — the games are the proving ground, the framework is the goal.
> **These are in-development previews, not finished ports — expect rough
> edges**, and depth will keep landing over months, not days. My time for any
> one title is limited, so I ask for your patience. Contributions are welcome —
> testing, issues, and PRs to the game or framework all help and will
> accelerate this game's polish. More on the why at:
> [Recomp + AI: 5 Months Later »](https://1379.tech/recomp-ai-5-months-later/)_
Mega Man X5 (USA, SLUS-01334) statically recompiled to a native PC executable
with [PSXRecomp](https://github.com/mstan/psxrecomp) — the same framework behind
[TombaRecomp](https://github.com/mstan/TombaRecomp) and
[MegaManX6Recomp](https://github.com/mstan/MegaManX6Recomp).
## What This Is
This repository contains the game-specific configuration, seeds, tools, and
build glue for running Mega Man X5 on the PSXRecomp framework. The game's MIPS
code is machine-translated ("recompiled") ahead of time into native C, then
compiled into a real Windows program that runs the game's own logic on a
faithful simulation of the PS1 hardware (GPU, SPU, GTE, memory cards) plus the
real, recompiled PS1 BIOS — no high-level emulation shims.
It does **not** contain the Mega Man X5 disc image, the PS1 BIOS, generated game
code, or any decompiled game C. Those are produced locally from your own legally
obtained assets.
Important files:
- `game.toml`: runtime / recompiler / video / controller config.
- `seeds/`: Ghidra-derived function starts and game-specific seed data.
- `tools/regen.ps1`: regenerates the recompiled C output.
- `tools/package_release.ps1`: builds the redistributable release zip.
- `psxrecomp-v4.pin`: framework commit this project is known-good against.
- `ISSUES.md`: game-specific issue log.
- `DISC.md`: source-disc identity and verification hashes.
## Status
**Playable preview — `v0.0.2-alpha`.** Mega Man
X5 **boots from the PS1 BIOS and plays** — through the opening (including the
intro cutscenes, which now decode and play), into stages, with working
controller input and memory-card **save/load**, and **no known crashes**. It has
not yet been verified all the way to the end, so treat it as a very playable
preview rather than a certified full playthrough.
| Area | State |
|---|---|
| PS1 BIOS boot | Works (real recompiled BIOS) |
| Disc-detect / boot | Works (loads the engine and streamed overlays) |
| Intro cutscenes / FMV | Plays (movies now decode); auto-skip available |
| Controller | Works; DualShock/analog presented by default (required by MMX5) |
| Stage gameplay | Works (not yet verified all the way to the end) |
| Memory-card save / load | Works (standard PS1 `.mcd`, emulator-compatible) |
| Renderers | Software, OpenGL, and Vulkan; OpenGL is the validated default |
| Mods | Widescreen 16:9 and frame interpolation; both default-disabled |
See `ISSUES.md` for notes and the remaining enhancement follow-ups.
## Features
These are the framework features that are already working in this build:
- **Modern renderers.** CPU software, OpenGL, and Vulkan backends are available.
OpenGL is the validated default for this release.
- **Fast loading (turbo loads).** While a load is in progress the whole machine
fast-forwards at your PC's full speed, then drops back to normal the instant
it finishes — so disc loads complete far faster while all of the game's
internal timing (and audio) stays correct. Authentic 1× disc timing is kept;
the speed comes from the load fast-forward, not from speeding up the emulated
CD (which would break timing). On by default; toggleable in the launcher.
- **Intro cutscenes / FMV.** The opening movies (`CAPLOGO.STR` / `X5OP.STR`,
with `BGM.XA` audio) decode and play. Full-motion videos can also be skipped
the instant they start — off by default so you see the intro, toggleable in
the launcher (Settings → "Skip FMVs").
- **DualShock controller by default.** MMX5 will not poll buttons until it
detects an analog-capable pad, so the runtime presents a DualShock by default.
Adjustable stick deadzone; per-player override in the launcher.
- **Supersampling + anti-aliasing.** Internal-resolution SSAA (1×–4×) with
optional linear present filtering for clean edges.
- **Mods view.** Two reviewed, game-owned enhancements are available:
default-disabled 16:9 widescreen and presentation-only frame interpolation.
Widescreen expands the Capcom 2D background tile window and widens enemy
activation and primitive culling; interpolation preserves the game's stock
logic, audio, and VBlank cadence.
- **Graphical launcher.** Pick your BIOS, disc, and memory cards; verify the
disc; configure renderer / supersampling / controller, with live settings
persistence — then press Launch.
## Setup
### Release Package (recommended)
1. Download `MegaManX5Recomp-v*-windows-x64.zip` from Releases and extract it.
2. Run `MegaManX5Recomp.exe`. A **launcher window** opens.
3. OpenBIOS is included and selected automatically. You may optionally choose
a legally obtained retail PlayStation BIOS.
4. Set the game **disc**: select your legally obtained Mega Man X5 (USA,
SLUS-01334) disc image. The launcher verifies the ISO9660 header, region, and
serial.
5. Optionally adjust renderer, supersampling, screen look, and controller
settings, then press **Launch**. Your choices are remembered.
Accepted disc formats: `.cue` + `.bin` (preferred — pick the `.cue`) and `.bin`.
**Do not convert the disc to a 2048-byte "cooked" `.iso`** — that discards the
Mode-2 Form-2 XA sectors MMX5 streams its FMV/audio from. If the header or game
ID does not match `SLUS-01334`, the launcher warns and tries to run it anyway.
Selected paths and settings persist next to the executable. Clearing the BIOS
row returns to OpenBIOS.
### Building From Source
Builds on **Windows (MSYS2/MinGW)**.
Requirements:
- A C/C++ toolchain (MSYS2 `mingw-w64-x86_64`) and CMake 3.20+.
- Mega Man X5 (USA, SLUS-01334) disc image (`.cue` + `.bin` or `.bin`). Not
included. Verify it against `DISC.md` before reporting regressions.
- A retail Sony BIOS is optional; redistributable OpenBIOS is included.
- The `psxrecomp` framework available at the sibling path `../psxrecomp` (linked
in as the `psxrecomp-v4` junction at the `psxrecomp-v4.pin` SHA), plus a
recompiled BIOS in `psxrecomp/generated/` (see the framework README).
The recompiler needs the game's PS-X EXE extracted from the disc. A helper is
included:
```sh
python3 ../psxrecomp/tools/extract_psx_exe.py "mmx5/Mega Man X5 (USA).bin" SLUS_013.34 mmx5/SLUS_013.34
```
Generate the recompiled C, then build and run:
```sh
# Regenerate generated/SLUS_013.34_{full,dispatch}.c from the disc/EXE.
# Windows: pwsh tools/regen.ps1
# (or invoke the recompiler directly:
# ../psxrecomp/recompiler/build/psxrecomp-game.exe --config game.toml)
cmake -S . -B build -G "Unix Makefiles"
cmake --build build -j16
./build/mmx5-runtime.exe
```
To build the redistributable Windows release (regens, builds with the launcher,
bundles assets + cache, and zips it): `pwsh tools/package_release.ps1`.
## Configuration
Most options are exposed in the launcher and persist to `settings.toml`. The
underlying defaults live in `game.toml`:
- `[video]` — `renderer`, `supersampling` (1–4), `antialiasing`,
`texture_filtering`, and `auto_skip_fmv`. Widescreen and frame interpolation
are owned by the two packages in the Mods view.
- `[controller]` — `default_analog` (DualShock on by default), `deadzone`.
- `[runtime]` — `disc_speed` (kept at `1x`), `turbo_loads`, `bios_hle`,
`overlay_cache`.
## Controls
| PSX button | Keyboard |
|---|---|
| D-Pad Up / Down / Left / Right | Arrow keys |
| Cross | X |
| Square | Z |
| Circle | S |
| Triangle | A |
| L1 / R1 | Q / W |
| L2 / R2 | E / R |
| Start | Enter |
| Select | Right Shift |
| Turbo | Tab (hold) |
| Fullscreen | F11 / Alt+Enter |
A game controller (Xbox, PlayStation, or any SDL-recognized pad) is supported via
SDL when connected. MMX5 expects an analog pad, so a DualShock/analog controller
is presented by default.
| PSX button | Xbox controller |
|---|---|
| D-Pad Up / Down / Left / Right | D-pad or left stick |
| Cross | A |
| Circle | B |
| Square | X |
| Triangle | Y |
| L1 / R1 | LB / RB |
| L2 / R2 | LT / RT |
| Start | Menu |
| Select | View / Back |
Release builds include `input.ini` next to `MegaManX5Recomp.exe`. Edit it to
change controller device index, deadzone, or button mapping.
## Memory Cards
Save and load work. The runtime uses standard PS1 memory-card images
(`.mcd` / `.mcr`) compatible with DuckStation, PCSX-Redux, Mednafen, ePSXe, and
similar emulators. Cards are stored in the `saves` directory and managed in the
launcher's memory-card UI. Runtime memory-card files are local artifacts and must
not be committed.
## Help make your game faster — just by playing
**Why isn't the game already at full speed everywhere?** Most of MMX5's code is
converted ("recompiled") into a fast native program ahead of time. But
PlayStation games don't keep all of their code in memory at once — they stream
extra chunks of code off the disc as you reach new areas (these chunks are
called *overlays*; MMX5 streams most of its game logic from `ROCK_X5.DAT` /
`ROCK_X5.BIN`). We can't convert a chunk we've never seen, and the only way to
see it is for someone to actually visit that area. Until then, that area's code
runs in a slower compatibility mode.
**Releases ship a head start.** The `cache` folder next to the executable
contains pre-converted native code for areas covered so far, and that work is
reused across launches. While you play, the runtime records newly visited areas
into `overlay_captures.json` and your own cache grows automatically.
**Please do not post `overlay_captures.json` publicly.** It contains verbatim
snapshots of the game's code read from your disc, which is copyrighted material —
keep it on your own machine, alongside your disc image.
## Development Rules
- Use the real recompiled BIOS and real hardware simulation in PSXRecomp.
- No HLE BIOS shims, no stubs, no fake events, no hand-edited generated files.
- Framework changes go in `mstan/psxrecomp`, not here.
- Game binaries, generated code, memory cards, Ghidra databases, and build
outputs stay local.
- See `CLAUDE.md` for project-specific rules.
## License
PolyForm Noncommercial 1.0.0. See `LICENSE`.
Mega Man X5 is copyright Capcom. This repository contains none of the game's
original binaries or assets. Release packages contain no game assets or disc
data. They include the MIT-licensed OpenBIOS; a retail BIOS is never included.
The
release executable and the bundled `cache` folder do contain statically
recompiled (machine-translated) builds of the game's code, the same distribution
model used by other static recompilation projects such as N64: Recompiled.
---
R.A.I.D. — Retro AI Development · a Discord for AI-assisted retro reverse-engineering, decomp & recomp
See [original-disc AOT overlays](docs/AOT_OVERLAYS.md) for the reproducible inventory, release audit, and coverage limits.
