# Sonic 3 & Knuckles — Recompiled Native x64 static recompilation of **Sonic the Hedgehog 3** and **Sonic & Knuckles** for the Sega Genesis / Mega Drive, built on the shared [`segagenesisrecomp`](https://github.com/mstan/segagenesisrecomp) recompiler + runner. ## Opt-in widescreen experiment The custom renderer is available in all three targets, developed first on **Sonic3KRecomp** (the combined cartridge). Open **Mods**, enable **Widescreen**, and select **Adaptive**, **16:9**, **21:9** or **32:9**. Native rendering remains the default. Adaptive follows the window beyond 32:9; the same settings are available in the in-game overlay. The experiment expands stage/background rendering, object activation, rings and the screen-anchored HUD, with optional gameplay CPU headroom. It does not rewrite stage collision or decompression. Initial validation covers Angel Island and Mushroom Hill routes, not every stage or boss. Blue Spheres now has an expanded ground/sphere projection and edge-anchored counters; its native board, movement and collection logic are unchanged. Combined-cartridge save replays cover turning, collection, jumping and the exit fade. See [renderer notes](game/common/CUSTOM-VIDEO.md) for implementation, validation and known limits. Existing build caches may need `-DRECOMP_UI_ENABLE_MODS=ON` to expose the Mods page. ## Knuckles & Knuckles (opt-in gag) In **Sonic3KRecomp** and **SonicAndKnucklesRecomp**, enable **Mods → Knuckles & Knuckles** and play as Knuckles. Type **1-74** in **Extra Knuckles** (default **16**) to choose how many follow you. Busy stages may temporarily use fewer extras. A controller on player 2-4 drives the matching extra; the rest use Tails-style CPU following. S3K's title shows a still Knuckles and **KNUCKLES 3**, and empty save files default to Knuckles. Existing save files keep their character. Both titles get the "Knuckles & Knuckles" treatment. Local play only, off by default. See [docs/KNUCKLES_ARMY.md](docs/KNUCKLES_ARMY.md). Sonic 3 and Sonic & Knuckles shipped as two separate ~2 MB cartridges; **"Sonic 3 & Knuckles"** is the 4 MB **lock-on** combination of the two (S&K boots at `$000000`, Sonic 3 maps in at `$200000`). They share one engine, so this repo hosts all three as **build modes** — each a native target plus a paired `_oracle` (interpreter parity-reference) target: | Target | Game / ROM | Ports (native/oracle) | Status | |---|---|---|---| | `Sonic3Recomp` | Sonic 3 alone, 2 MB (CRC32 `9BC192CE`) | 4384 / 4385 | **Playable bring-up** (Angel Island, saves) | | `SonicAndKnucklesRecomp` | Sonic & Knuckles alone, 2 MB (MD5 `4ea493ea…`) | 4388 / 4389 | Bring-up | | `Sonic3KRecomp` | Sonic 3 & Knuckles combined, 4 MB | 4386 / 4387 | Scaffold / early bring-up | > **Prebuilt Sonic 3 binaries are on the > [Releases](https://github.com/mstan/Sonic3AndKnucklesRecomp/releases) page — > supply your own ROM.** Release binaries are AGPL-free clean-room builds > (PolyForm Noncommercial 1.0.0 + permissive third-party notices). The AGPL > clownmdemu core is used only by unshipped development/oracle targets; see > `segagenesisrecomp/RELEASING.md`. ## Building from source **Prerequisites** - A C compiler — Windows: Visual Studio 2022 (MSVC); macOS: Apple Clang (Xcode CLT); Linux: Clang/GCC. Plus CMake 3.16+ (and Ninja on macOS/Linux). - SDL2 2.28+ — bundled on Windows; `brew install sdl2` (macOS); `libsdl2-dev` (Linux). - Your own legally-obtained ROM(s); ROMs are gitignored and never committed. **1. Clone.** The shared engine (`segagenesisrecomp`) is a git submodule, so a recursive clone is self-contained: ```bash git clone --recursive https://github.com/mstan/Sonic3AndKnucklesRecomp.git cd Sonic3AndKnucklesRecomp # (cloned without --recursive? run: git submodule update --init --recursive) ``` `Skipping submodule 'clownmdemu-core'` in that output is expected and correct. That core is AGPL and dev-only; nothing you build needs it, and CMake skips the dev-only `_oracle` targets automatically when it is absent. **2. Supply your own ROM(s).** Either pass the ROM path on the command line, or drop it into this repo's per-mode game dir so the build copies it next to the exe: | Mode | Place ROM at | Identity | |---|---|---| | Sonic 3 alone | `game/sonic3/sonic3.bin` | CRC32 `9BC192CE` | | Sonic & Knuckles alone | `game/sandk/sandk.bin` | MD5 `4ea493ea…` (2 MB) | | S3 & Knuckles | `game/sonic3k/sonic3k.bin` | 4 MB combined | **3. Build the mode you want, then run.** Generated C is ignored build output; CMake builds the current recompiler and regenerates the selected mode whenever its ROM, configuration/discovery inputs, or the recompiler changes. Windows (MSVC): ```cmd cmake -S . -B build -G "Visual Studio 17 2022" -A x64 cmake --build build --config Release --target Sonic3Recomp :: Sonic 3 alone cmake --build build --config Release --target SonicAndKnucklesRecomp :: S&K alone cmake --build build --config Release --target Sonic3KRecomp :: S3&K combined build\Release\Sonic3Recomp.exe :: the build copies the ROM next to the exe ``` macOS / Linux (Ninja + Clang/GCC): ```bash cmake -S . -B build -G Ninja -DCMAKE_BUILD_TYPE=Release ninja -C build Sonic3Recomp Sonic3KRecomp ./build/Sonic3Recomp "path/to/Sonic 3.bin" ``` > **Local dev across games:** clone `segagenesisrecomp` once at the workspace root > and run `scripts/link-engine.sh` (or `.bat`) to share ONE engine checkout; CMake > prefers the gitignored `engine-local` symlink over the submodule. Each mode also has an `_oracle` target (e.g. `Sonic3Recomp_oracle`) that runs the clown68000 interpreter for native↔interpreter parity debugging; it needs `debug.ini` next to the exe. ### Optional statically recompiled sound Z80 Native targets normally retain the embedded Z80 interpreter. For development, the sound driver can instead use the flat static backend from [`smsggrecomp`](https://github.com/mstan/smsggrecomp). The generated code consumes the framework's pinned [`z80-recomp-core`](https://github.com/mstan/z80-recomp-core) submodule. Capture and generate the ROM-derived `_step.c` locally as described in [`docs/Z80_STATIC_RECOMP.md`](segagenesisrecomp/docs/Z80_STATIC_RECOMP.md), then configure with: ```bash cmake -S . -B build-z80 \ -DGENESIS_Z80_RECOMP=ON \ -DGENESIS_Z80_AOT_SOURCE=/path/to/generated/s3kz80_step.c cmake --build build-z80 --config Release --target Sonic3KRecomp ``` The capture and generated C contain ROM-derived data and remain uncommitted. Opcode shapes are statically decoded; mutable driver operands are read live, with one-instruction interpreter fallback only for unmatched code. Turbo mode silences speaker playback while preserving headless WAV capture. ## Layout This repo owns the Sonic 3 family implementation; only reusable framework code comes from the pinned `segagenesisrecomp` submodule (see [docs/REPOSITORY_OWNERSHIP.md](docs/REPOSITORY_OWNERSHIP.md)): ``` Sonic3AndKnucklesRecomp/ ├── CMakeLists.txt ← three build modes ├── game/ │ ├── common/ ← shared renderer (sonic3_video.c, Blue Spheres) │ ├── sonic3/ sonic3k/ sandk/ ← game.toml, discovery inputs, _spec.c, ROM │ └── skdisasm/ ← pinned source disassembly submodule ├── ghidra/annotations/ ← reproducible annotation exports ├── tests/, tools/, docs/ ← game-owned validation, tooling, documentation └── segagenesisrecomp/ ← submodule (shared engine) ``` ## Manually regenerate the C from a ROM Use the configured build's generation targets (a normal build also runs them automatically): ``` cmake --build build --config Release --target genesisrecomp_generate_sonic3 cmake --build build --config Release --target genesisrecomp_generate_sandk cmake --build build --config Release --target genesisrecomp_generate_sonic3k ``` > Sonic & Knuckles alone shares the S&K master boot path with the combined cart, > so its disasm data is regenerated from the same byte-perfect `skdisasm` > `sonic3k.lst` at offset 0 — see `game/sandk/game.toml`. ## Sonic 3 & Knuckles (combined) mode — why it's harder The combined 4 MB target is early bring-up. Beyond the standalone Sonic 3 work, it has to handle: 1. **RAM-installed IRQ handlers.** VBlank/HBlank vectors point into 68K RAM (`$FFFFFFF0` / `$FFFFFFF6`); boot code copies trampolines into RAM at runtime, which a static call-graph walk can't follow without a hook/directive. 2. **Sega lock-on memory map.** S&K at `$000000–$1FFFFF`, Sonic 3 at `$200000–$3FFFFF`; S&K code JSRs into the Sonic 3 bank. The runtime must honor the lock-on mapping. 3. **Battery SRAM** (`$200001–$203FFF`, odd bytes) for combined save data. 4. **Header quirks**: SSP = `$00000000` (boot sets it), header checksum covers only the original 2 MB, and one `NBCD` (`$4300`) opcode appears at `$3000EE`. See `ISSUES.md` / `FEATURES.md` (currently focused on the Sonic-3-alone mode). ## Audio & video enhancements (opt-in) The runner includes an optional **verified-enhancement shadow** layer — QoL audio/video improvements that run alongside the authentic hardware emulation and substitute only after continuously proving they still match it (reverting loudly if they ever stop). **Off by default** (output is byte-identical to raw hardware emulation); enable per-run via environment variables: | Variable | Values | Effect | |----------|--------|--------| | `GENESIS_SCREEN` | `raw` (default), `crt`, `trinitron`, `composite`, `linear` | Present-time color model — maps the Genesis 9-bit gamut through a CRT/phosphor model (gamma + lifted black). `raw` is bit-identical passthrough. | | `GENESIS_AUDIO_SHADOW` | `0` (default) / `1` | Arms the YM2612 FM shadow — a parallel `ymfm` chip with a relaxed output low-pass that keeps the cleaner, less-aliased highs. | | `GENESIS_FM_LADDER` | unset (default) / `off` | With `off`, renders the FM shadow through ymfm's ladder-free `ym3438` (no YM2612 DAC crossover crunch). Needs `GENESIS_AUDIO_SHADOW=1`. | ```bash GENESIS_AUDIO_SHADOW=1 GENESIS_FM_LADDER=off GENESIS_SCREEN=crt ./Sonic3KRecomp sonic3k.bin ``` Full design, verifier algorithm, and rationale: `segagenesisrecomp/docs/SHADOW_ENHANCEMENTS.md`. ## License & ROM This project's own code: [PolyForm Noncommercial](LICENSE.md) (the recompiler / build wiring). **Third-party engine components are separately licensed and mostly AGPL-3.0** — see `../SonicTheHedgehogRecomp/segagenesisrecomp/THIRD-PARTY-LICENSES.md`. ROM files are **not** included — supply your own legally-obtained copy. ---
