# MongoDB How to set up PMM to monitor a [MongoDB] or [Percona Server for MongoDB] database instance. ## Before you start Check that: - [PMM Server is installed](../server/index.md) and running with a known IP address or hostname accessible from the client node. - [PMM Client is installed](index.md) and the [node is registered with PMM Server](index.md#register). - You have superuser (root) access on the client host. - You have `adminUserAnyDatabase` or superuser role privilege to any database servers that you want to monitor. - Your MongoDB server is version 4.0 or higher. ## Create PMM account and set permissions We recommend using a dedicated account to connect PMM Client to the monitored database instance. Run the example codes below in a `mongo` session to: - create custom roles with the privileges required for creating/restoring backups and working with Query Analytics (QAN) - create/update a database user with these roles above, plus the built-in `clusterMonitor` role !!! caution alert alert-warning "" Values for username (`user`) and password (`pwd`) are examples. Replace them before using these code snippets. ### Create roles with privileges for backups and QAN ```{.javascript data-prompt=">"} db.getSiblingDB("admin").createRole({ role: "explainRole", privileges: [{ resource: { db: "", collection: "" }, actions: [ "listIndexes", "listCollections", "dbStats", "dbHash", "collStats", "find" ] }], roles: [] }) ``` ```{.javascript data-prompt=">"} db.getSiblingDB("admin").createRole({ "role": "pbmAnyAction", "privileges": [{ "resource": { "anyResource": true }, "actions": [ "anyAction" ] }], "roles": [] }); ``` ### Create/update user and assign created roles ```{.javascript data-prompt=">"} db.getSiblingDB("admin").createUser({ user: "pmm", pwd: "pmm", roles: [ { role: "explainRole", db: "admin" }, { role: "clusterMonitor", db: "admin" }, { role: "read", db: "local" }, { "db" : "admin", "role" : "readWrite", "collection": "" }, { "db" : "admin", "role" : "backup" }, { "db" : "admin", "role" : "clusterMonitor" }, { "db" : "admin", "role" : "restore" }, { "db" : "admin", "role" : "pbmAnyAction" } ] }) db.getSiblingDB("admin").updateUser("pmm", { roles: [ { role: "explainRole", db: "admin" }, { role: "clusterMonitor", db: "admin" }, { role: "read", db: "local" }, { "db" : "admin", "role" : "readWrite", "collection": "" }, { "db" : "admin", "role" : "backup" }, { "db" : "admin", "role" : "clusterMonitor" }, { "db" : "admin", "role" : "restore" }, { "db" : "admin", "role" : "pbmAnyAction" } ] }) ``` ### Permissions for advanced metrics To fetch advanced metrics, use the following to provide additional privileges to an existing PMM user: ```json { resource : { db : "", collection : "system.profile" }, actions : [ "collStats", "dbStats", "indexStats" ] } ``` If the role `explainRole` already exists, then you can use the following command to provide additional privileges: ```{.javascript data-prompt=">"} db.runCommand({ grantPrivilegesToRole: "explainRole", privileges: [{ "resource": { "db": "", "collection": "system.profile" }, "actions": [ "indexStats", "dbStats", "collStats" ] }] }) ``` ## Profiling To use PMM Query Analytics, you must turn on MongoDB's [profiling feature]. You can set profiling: - permanently, by editing the MongoDB configuration file and restarting the database instance (recommended); - when starting MongoDB, by passing arguments to `mongod` on the command line; - until the next database instance restart, by running a command in a `mongo` session. !!! note alert alert-primary "" Profiling is turned off by default as it can adversely affect the performance of the database server. ### Set profiling in the configuration file 1. Edit the configuration file (usually `/etc/mongod.conf`). 2. Create or add this to the `operationProfiling` section. ([Read more][MONGODB_CONFIG_OP_PROF].) ```yml operationProfiling: mode: all slowOpThresholdMs: 200 rateLimit: 100 # (Only available with Percona Server for MongoDB.) ``` !!! caution alert alert-warning "Important" This is a [YAML] file. Indentation matters. 3. Restart the `mongod` service. (Example for `systemd`.) ```sh systemctl restart mongod ``` ### Set profiling on the command Line ```sh mongod --dbpath=DATABASEDIR --profile 2 --slowms 200 --rateLimit 100 ``` - `--dbpath`: The path to database files (usually `/var/lib/mongo`). - `--profile`: The MongoDB profiling level. A value of `2` tells the server to collect profiling data for *all* operations. To lower the load on the server, use a value of `1` to only record slow operations. - `--slowms`: An operation is classified as *slow* if it runs for longer than this number of milliseconds. - `--rateLimit`: (Only available with Percona Server for MongoDB.) The sample rate of profiled queries. A value of `100` means sample every 100th fast query. ([Read more][PSMDB_RATELIMIT].) !!! caution alert alert-warning "Caution" Smaller values improve accuracy but can adversly affect the performance of your server. ### Set profiling in a `mongo` session In a `mongo` session, the profiler should be enabled **per** database. For example, to enable the profiler in the `testdb`, run this: ```{.javascript data-prompt=">"} > use testdb > db.setProfilingLevel(2, {slowms: 0}) ``` !!! note alert alert-primary "" If you have already [added a service](#add-service), you should remove it and re-add it after changing the profiling level. ## Add service When you have configured your database server, you can add a MongoDB service with the user interface or on the command line. ### With the user interface 1. Select *Configuration* → {{icon.inventory}} *Inventory*. 2. Select *MongoDB -- Add a remote instance*. 3. Enter or select values for the fields. 4. Click *Add service*. ### On the command line Use `pmm-admin` to add the database server as a service using one of these example commands. When successful, PMM Client will print `MongoDB Service added` with the service's ID and name. Use the `--environment` and `-custom-labels` options to set tags for the service to help identify them. !!! hint alert alert-success "Tips" - When adding nodes of a sharded cluster, add each node separately using the `--cluster mycluster` option for the MongoDB Cluster Summary dashboard to populate correctly. - Atlas doesn't support direct connections. When connecting to an Atlas instance, use the `pmm-admin` option `--direct-connection=false`. (Doing so will prevent replicaset status from working and the MongoDB Overview dashboard widget will show invalid values.) ### Examples ```sh pmm-admin add mongodb \ --username=pmm_mongodb --password=password \ --query-source=profiler --cluster=mycluster ``` ```sh pmm-admin add mongodb \ --username=pmm_mongodb --password=password \ mongo 127.0.0.1:27017 ``` ```sh pmm-admin add mongodb \ --username=pmm_mongodb --password=password \ --service-name=mymongosvc --host=127.0.0.1 --port=27017 ``` #### Connect via UNIX socket ```sh pmm-admin add mongodb --socket=/tmp/mongodb-27017.sock ``` #### Connecting via SSL/TLS ```sh pmm-admin add mongodb --tls \ --tls-certificate-key-file=PATHTOCER \ --tls-certificate-key-file-password=IFPASSWORDTOCERTISSET \ --tls-ca-file=PATHTOCACERT --authentication-mechanism=AUTHENTICATION-MECHANISM --authentication-database=AUTHENTICATION-DATABASE ``` where: - `PATHTOCERT`: Path to TLS certificate file. - `IFPASSWORDTOCERTISSET`: Password for TLS certificate file. - `PATHTOCACERT`: Path to certificate authority file. - `AUTHENTICATION-MECHANISM`: Authentication mechanism. Default is empty. Use `MONGODB-X509` for SSL certificates. - `AUTHENTICATION-DATABASE`: Authentication database. Default is empty. Use `$external` for SSL certificates. ## Check the service ### With the user interface 1. Select *Configuration* → {{icon.inventory}} *Inventory*. 2. In the *Services* tab, verify the *Service name*, *Addresses*, and any other relevant values used when adding the service. 3. In the *Options* column, expand the *Details* section and check that the Agents are using the desired data source. 4. If your MongoDB instance is configured to use TLS, click on the **Use TLS for database connection** check box and fill in TLS certificates and keys. If you use TLS, the authentication mechanism is automatically set to `MONGODB-X509`. ![!](../../_images/PMM_Add_Instance_MongoDB_TLS.jpg) ### On the command line Look for your service in the output of this command. ```sh pmm-admin inventory list services --service-type=mongodb ``` ### Check data 1. Open the *MongoDB Instances Overview* dashboard. 2. Set the *Service Name* to the newly-added service. #### Query Analytics 1. Open *PMM Query Analytics*. 2. In the *Filters* panel: 1. Under *Service Name*, select your service. 2. Under *Service Type* select `mongodb`. ## Remove service ### With the user interface 1. Select *Configuration* → {{icon.inventory}} *Inventory*. 2. In the first column, click the tick box for the service you want to remove. 3. Click *Delete*. 4. On the *Confirm action* dialog window: 1. (Optional) Select *Force mode* to also delete associated agents. 2. Click *Proceed*. ### On the command line ```sh pmm-admin remove mongodb SERVICE_NAME ``` - `SERVICE_NAME`: The name the service was added as. (Find it with `pmm-admin list`.) !!! seealso alert alert-info "See also" - [`pmm-admin add mongodb`](../../details/commands/pmm-admin.md#mongodb) - [Troubleshooting connection difficulties] [MongoDB]: https://www.mongodb.com/ [Percona Server for MongoDB]: https://www.percona.com/software/mongodb/percona-server-for-mongodb [profiling feature]: https://docs.mongodb.com/manual/tutorial/manage-the-database-profiler/ [YAML]: http://yaml.org/spec/ [MONGODB_CONFIG_OP_PROF]: https://docs.mongodb.com/manual/reference/configuration-options/#operationprofiling-options [PSMDB_RATELIMIT]: https://www.percona.com/doc/percona-server-for-mongodb/LATEST/rate-limit.html#enabling-the-rate-limit [PMM_ADMIN_MAN_PAGE]: ../../details/commands/pmm-admin.md [Troubleshooting connection difficulties]: ../../how-to/troubleshoot.md#connection-difficulties
