**This is the official Kubewatch project, [originally by Bitnami](https://github.com/bitnami-labs/kubewatch/), now maintained by [Robusta.dev](https://home.robusta.dev/).** **Feel free to open issues, raise PRs or talk with us on [Slack](https://bit.ly/robusta-slack)!** **kubewatch** is a Kubernetes watcher that publishes notification to available collaboration hubs/notification channels. Run it in your k8s cluster, and you will get event notifications through webhooks. [See the blog post on KubeWatch 2.0 to learn more about how KubeWatch is used.](https://home.robusta.dev/blog/kubewatch-2-0-released)

[![GoDoc](https://godoc.org/github.com/bitnami-labs/kubewatch?status.svg)](https://godoc.org/github.com/bitnami-labs/kubewatch) [![License](https://img.shields.io/badge/License-Apache%202.0-blue.svg)](https://github.com/bitnami-labs/kubewatch/blob/master/LICENSE) [![slack robusta](https://img.shields.io/badge/Slack-Join-4A154B?style=flat-square&logo=slack&logoColor=white)](https://bit.ly/robusta-slack)

# Fine-Grained Resource Tracking KubeWatch tracks all changes to Kubernetes resources of given types. If you need fine-grained filtering of which changes are forwarded, you can use KubeWatch in conjunction with Robusta. For more details, refer to the [Robusta docs on change-tracking](https://docs.robusta.dev/master/playbook-reference/kubernetes-examples/index.html). A diagram showing the two options is shown below. The flow that only uses KubeWatch is purple and the flow that adds Robusta is green. ![image](https://github.com/user-attachments/assets/b271e635-70d6-4bc8-9f61-4c8ae4771be4) # Latest image ``` robustadev/kubewatch:v2.9.0 ``` # Usage ``` $ kubewatch -h Kubewatch: A watcher for Kubernetes kubewatch is a Kubernetes watcher that publishes notifications to Slack/hipchat/mattermost/flock channels. It watches the cluster for resource changes and notifies them through webhooks. supported webhooks: - slack - slackwebhook - msteams - hipchat - mattermost - flock - webhook - cloudevent - smtp Usage: kubewatch [flags] kubewatch [command] Available Commands: config modify kubewatch configuration resource manage resources to be watched version print version Flags: -h, --help help for kubewatch Use "kubewatch [command] --help" for more information about a command. ``` # Install ### Cluster Installation #### Using helm: When you have helm installed in your cluster, use the following setup: ```console helm repo add robusta https://robusta-charts.storage.googleapis.com && helm repo update helm install kubewatch robusta/kubewatch --set='rbac.create=true,slack.channel=#YOUR_CHANNEL,slack.token=xoxb-YOUR_TOKEN,resourcesToWatch.pod=true,resourcesToWatch.daemonset=true' ``` You may also provide a values file instead: ```yaml rbac: create: true customRoles: - apiGroups: ["monitoring.coreos.com"] resources: ["prometheusrules"] verbs: ["get", "list", "watch"] resourcesToWatch: deployment: false replicationcontroller: false replicaset: false daemonset: false services: true pod: true job: false node: false clusterrole: true clusterrolebinding: true serviceaccount: true persistentvolume: false namespace: false secret: false configmap: false ingress: false coreevent: false event: true customresources: - group: monitoring.coreos.com version: v1 resource: prometheusrules slack: channel: '#YOUR_CHANNEL' token: 'xoxb-YOUR_TOKEN' ``` And use that: ```console $ helm upgrade --install kubewatch robusta/kubewatch --values=values-file.yml ``` #### Using kubectl: In order to run kubewatch in a Kubernetes cluster quickly, the easiest way is for you to create a [ConfigMap](https://github.com/robusta-dev/kubewatch/blob/master/kubewatch-configmap.yaml) to hold kubewatch configuration. An example is provided at [`kubewatch-configmap.yaml`](https://github.com/robusta-dev/kubewatch/blob/master/kubewatch-configmap.yaml), do not forget to update your own slack channel and token parameters. Alternatively, you could use secrets. Create k8s configmap: ```console $ kubectl create -f kubewatch-configmap.yaml ``` Create the [Pod](https://github.com/robusta-dev/kubewatch/blob/master/kubewatch.yaml) directly, or create your own deployment: ```console $ kubectl create -f kubewatch.yaml ``` A `kubewatch` container will be created along with `kubectl` sidecar container in order to reach the API server. Once the Pod is running, you will start seeing Kubernetes events in your configured Slack channel. Here is a screenshot: ![slack](./docs/slack.png) To modify what notifications you get, update the `kubewatch` ConfigMap and turn on and off (true/false) resources or configure any resource of your choosing with customresources (CRDs): ``` resource: deployment: false replicationcontroller: false replicaset: false daemonset: false services: true pod: true job: false node: false clusterrole: false clusterrolebinding: false serviceaccount: false persistentvolume: false namespace: false secret: false configmap: false ingress: false coreevent: false event: true customresources: - group: monitoring.coreos.com version: v1 resource: prometheusrules ``` #### Working with RBAC Kubernetes Engine clusters running versions 1.6 or higher introduced Role-Based Access Control (RBAC). We can create `ServiceAccount` for it to work with RBAC. ```console $ kubectl create -f kubewatch-service-account.yaml ``` If you do not have permission to create it, you need to become an admin first. For example, in GKE you would run: ``` $ kubectl create clusterrolebinding cluster-admin-binding --clusterrole=cluster-admin --user=REPLACE_EMAIL_HERE ``` Edit `kubewatch.yaml`, and create a new field under `spec` with `serviceAccountName: kubewatch`, you can achieve this by running: ```console $ sed -i '/spec:/a\ \ serviceAccountName: kubewatch' kubewatch.yaml ``` Then just create `pod` as usual with: ```console $ kubectl create -f kubewatch.yaml ``` #### Working with CRDs `kubewatch` can be configured to monitor Kubernetes Custom Resource Definitions (CRDs), allowing you to receive notifications when changes occur. To configure kubewatch to watch custom resources, you need to define the `customresources` section either in your values file or by using the `--set` flag with Helm commands. Include the custom resource configuration in your values file: ```yaml customresources: - group: monitoring.coreos.com version: v1 resource: prometheusrules ``` Then deploy or upgrade `kubwatch` with `helm upgrade` or `helm install` Alternatively, you can pass this configuration directly using the `--set` flag: ```console helm install kubewatch robusta/kubewatch --set='rbac.create=true,slack.channel=#YOUR_CHANNEL,slack.token=xoxb-YOUR_TOKEN,resourcesToWatch.pod=true,resourcesToWatch.daemonset=true,customresources[0].group=monitoring.coreos.com,customresources[0].version=v1,customresources[0].resource=prometheusrules' ``` #### Custom RBAC roles After defining custom resources, make sure that kubewatch has the necessary RBAC permissions to access the custom resources you've configured. Without the appropriate permissions, `kubewatch` will not be able to monitor your custom resources, and you won't receive notifications for changes. To grant these permissions, you can define custom RBAC roles using `customRoles` within the `rbac` section of your values file or by using the `--set` flag with Helm commands. This allows you to specify exactly which API groups, resources, and actions kubewatch should have access to. Here’s how you can configure the necessary permissions to monitor your resources: ```yaml rbac: create: true customRoles: - apiGroups: ["monitoring.coreos.com"] resources: ["prometheusrules"] verbs: ["get", "list", "watch"] ``` Then deploy or upgrade `kubwatch` with `helm upgrade` or `helm install` Alternatively, you can pass this configuration directly using the `--set` flag: ```console helm install kubewatch robusta/kubewatch --set='rbac.create=true,slack.channel=#YOUR_CHANNEL,slack.token=xoxb-YOUR_TOKEN,customRoles[0].apiGroups={monitoring.coreos.com},customRoles[0].resources={prometheusrules},customRoles[0].verbs={get,list,watch}' ``` #### Metrics `kubewatch` runs a Prometheus metrics endpoint at `/metrics` on port `2112` by default. This endpoint can be used to monitor health and the performance of `kubewatch`. The `kubewatch_events_total` metric can help track the total number of Kubernetes events, categorized by resource type (e.g., `Pods`, `Deployments`) and event type (e.g., `Create`, `Delete`). You can change the default port (`2112`) on which the metrics server listens by setting the `LISTEN_ADDRESS` environment variable. Format is `host:port`. `:5454` means any host, and port `5454` ```yaml extraEnvVars: - name: LISTEN_ADDRESS value: ":5454" ``` ### Local Installation #### Using go package installer: ```console # Download and install kubewatch $ go get -u github.com/robusta-dev/kubewatch # Configure the notification channel $ kubewatch config add slack --channel --token # Add resources to be watched $ kubewatch resource add --po --svc INFO[0000] resource svc configured INFO[0000] resource po configured # start kubewatch server $ kubewatch INFO[0000] Starting kubewatch controller pkg=kubewatch-service INFO[0000] Starting kubewatch controller pkg=kubewatch-pod INFO[0000] Processing add to service: default/kubernetes pkg=kubewatch-service INFO[0000] Processing add to service: kube-system/tiller-deploy pkg=kubewatch-service INFO[0000] Processing add to pod: kube-system/tiller-deploy-69ffbf64bc-h8zxm pkg=kubewatch-pod INFO[0000] Kubewatch controller synced and ready pkg=kubewatch-service INFO[0000] Kubewatch controller synced and ready pkg=kubewatch-pod ``` #### Using Docker: To Run Kubewatch Container interactively, place the config file in `$HOME/.kubewatch.yaml` location and use the following command. ``` docker run --rm -it --network host -v $HOME/.kubewatch.yaml:/root/.kubewatch.yaml -v $HOME/.kube/config:/opt/bitnami/kubewatch/.kube/config --name robustadev/kubewatch ``` Example: ``` $ docker run --rm -it --network host -v $HOME/.kubewatch.yaml:/root/.kubewatch.yaml -v $HOME/.kube/config:/opt/bitnami/kubewatch/.kube/config --name kubewatch-app robustadev/kubewatch ==> Writing config file... INFO[0000] Starting kubewatch controller pkg=kubewatch-service INFO[0000] Starting kubewatch controller pkg=kubewatch-pod INFO[0000] Starting kubewatch controller pkg=kubewatch-deployment INFO[0000] Starting kubewatch controller pkg=kubewatch-namespace INFO[0000] Processing add to namespace: kube-node-lease pkg=kubewatch-namespace INFO[0000] Processing add to namespace: kube-public pkg=kubewatch-namespace INFO[0000] Processing add to namespace: kube-system pkg=kubewatch-namespace INFO[0000] Processing add to namespace: default pkg=kubewatch-namespace .... ``` To Demonise Kubewatch container use ``` $ docker run --rm -d --network host -v $HOME/.kubewatch.yaml:/root/.kubewatch.yaml -v $HOME/.kube/config:/opt/bitnami/kubewatch/.kube/config --name kubewatch-app robustadev/kubewatch ``` # Configure Kubewatch supports `config` command for configuration. Config file will be saved at `$HOME/.kubewatch.yaml` ``` $ kubewatch config -h config command allows admin setup his own configuration for running kubewatch Usage: kubewatch config [flags] kubewatch config [command] Available Commands: add add webhook config to .kubewatch.yaml test test handler config present in .kubewatch.yaml view view .kubewatch.yaml Flags: -h, --help help for config Use "kubewatch config [command] --help" for more information about a command. ``` ### Example: ### slack: - Create a [slack Bot](https://my.slack.com/services/new/bot) - Edit the Bot to customize its name, icon and retrieve the API token (it starts with `xoxb-`). - Invite the Bot into your channel by typing: `/invite @name_of_your_bot` in the Slack message area. - Add Api token to kubewatch config using the following steps ```console $ kubewatch config add slack --channel --token ``` You have an altenative choice to set your SLACK token, channel via environment variables: ```console $ export KW_SLACK_TOKEN='XXXXXXXXXXXXXXXX' $ export KW_SLACK_CHANNEL='#channel_name' ``` ### slackwebhookurl: - Create a [slack app](https://api.slack.com/apps/new) - Enable [Incoming Webhooks](https://api.slack.com/messaging/webhooks#enable_webhooks). (On "Settings" page.) - Create an incoming webhook URL (Add New Webhook to Workspace on "Settings" page.) - Pick a channel that the app will post to, and then click to Authorize your app. You will get back your webhook URL. The Slack Webhook URL will look like: https://hooks.slack.com/services/T00000000/B00000000/XXXXXXXXXXXXXXXXXXXXXXXX - Add slack webhook url to kubewatch config using the following steps ```console $ kubewatch config add slackwebhookurl --username --emoji --channel --slackwebhookurl ``` Or, you have an altenative choice to set your SLACK channel, username, emoji and webhook URL via environment variables: ```console $ export KW_SLACK_CHANNEL=slack_channel $ export KW_SLACK_USERNAME=slack_username $ export KW_SLACK_EMOJI=slack_emoji $ export KW_SLACK_WEBHOOK_URL=slack_webhook_url ``` - Example apply done in a bash script: ```console $ cat kubewatch-configmap-slackwebhook.yaml | sed "s||"\"$SlackChannel"\"|g;s||"\"$SlackUsesrName"\"|g;s||"\"$SlackEmoji"\"|g;s||"\"$WebhookUrl"\"|g" | kubectl create -f - ``` - An example kubewatch-configmap-slackwebhook.yaml YAML File: ```yaml apiVersion: v1 kind: ConfigMap metadata: name: kubewatch data: .kubewatch.yaml: | namespace: "" handler: slackwebhook: enabled: true channel: username: emoji: slackwebhookurl: resource: clusterrole: false configmap: false daemonset: false deployment: true ingress: false job: false namespace: false node: false persistentvolume: false pod: true replicaset: false replicationcontroller: false secret: false serviceaccount: false services: true event: true coreevent: false ``` ### flock: - Create a [flock bot](https://docs.flock.com/display/flockos/Bots). - Add flock webhook url to config using the following command. ```console $ kubewatch config add flock --url ``` You have an altenative choice to set your FLOCK URL ```console $ export KW_FLOCK_URL='https://api.flock.com/hooks/sendMessage/XXXXXXXX' ``` ## Testing Config To test the handler config by send test messages use the following command. ``` $ kubewatch config test -h Tests handler configs present in .kubewatch.yaml by sending test messages Usage: kubewatch config test [flags] Flags: -h, --help help for test ``` #### Example: ``` $ kubewatch config test Testing Handler configs from .kubewatch.yaml 2019/06/03 12:29:23 Message successfully sent to channel ABCD at 1559545162.000100 ``` ## Viewing config To view the entire config file `$HOME/.kubewatch.yaml` use the following command. ``` $ kubewatch config view Contents of .kubewatch.yaml handler: slack: token: xoxb-xxxxx-yyyy-zzz channel: kube-watch hipchat: token: "" room: "" url: "" mattermost: channel: "" url: "" username: "" flock: url: "" webhook: url: "" cloudevent: url: "" resource: deployment: false replicationcontroller: false replicaset: false daemonset: false services: false pod: true job: false node: false clusterrole: false clusterrolebinding: false serviceaccount: false persistentvolume: false namespace: false secret: false configmap: false ingress: false event: true coreevent: false namespace: "" ``` ## Resources To manage the resources being watched, use the following command, changes will be saved to `$HOME/.kubewatch.yaml`. ``` $ kubewatch resource -h manage resources to be watched Usage: kubewatch resource [flags] kubewatch resource [command] Available Commands: add adds specific resources to be watched remove remove specific resources being watched Flags: --clusterrolebinding watch for cluster role bindings --clusterrole watch for cluster roles --cm watch for plain configmaps --deploy watch for deployments --ds watch for daemonsets -h, --help help for resource --ing watch for ingresses --job watch for jobs --node watch for Nodes --ns watch for namespaces --po watch for pods --pv watch for persistent volumes --rc watch for replication controllers --rs watch for replicasets --sa watch for service accounts --secret watch for plain secrets --svc watch for services --coreevent watch for events from the kubernetes core api. (Old events api, replaced in kubernetes 1.19) Use "kubewatch resource [command] --help" for more information about a command. ``` ### Add/Remove resource: ``` $ kubewatch resource add -h adds specific resources to be watched Usage: kubewatch resource add [flags] Flags: -h, --help help for add Global Flags: --clusterrole watch for cluster roles --clusterrolebinding watch for cluster role bindings --cm watch for plain configmaps --deploy watch for deployments --ds watch for daemonsets --ing watch for ingresses --job watch for jobs --node watch for Nodes --ns watch for namespaces --po watch for pods --pv watch for persistent volumes --rc watch for replication controllers --rs watch for replicasets --sa watch for service accounts --secret watch for plain secrets --svc watch for services --coreevent watch for events from the kubernetes core api. (Old events api, replaced in kubernetes 1.19) ``` ### Example: ```console # rc, po and svc will be watched $ kubewatch resource add --rc --po --svc # rc, po and svc will be stopped from being watched $ kubewatch resource remove --rc --po --svc ``` ### Changing log level In case you want to change the default log level, add an environment variable named `LOG_LEVEL` with value from `trace/debug/info/warning/error` ```yaml env: - name: LOG_LEVEL value: debug ``` ### Changing log format In case you want to change the log format to `json`, add an environment variable named `LOG_FORMATTER` with value `json` ```yaml env: - name: LOG_FORMATTER value: json ``` # Build ### Using go Clone the repository anywhere: ```console $ git clone https://github.com/bitnami-labs/kubewatch.git $ cd kubewatch $ go build ``` or You can also use the Makefile directly: ```console $ make build ``` #### Prerequisites - You need to have [Go](http://golang.org) (v1.5 or later) installed. Make sure to set `$GOPATH` ### Using Docker ```console $ make docker-image $ docker images REPOSITORY TAG IMAGE ID CREATED SIZE kubewatch latest 919896d3cd90 3 minutes ago 27.9MB ``` #### Prerequisites - you need to have [docker](https://docs.docker.com/) installed. # Contribution Refer to the [contribution guidelines](docs/CONTRIBUTION.md) to get started.
