# Super Dodgeball NES — Recompilation Recompile **Super Dodge Ball (USA)** (NES, 1989, Technos Japan) to native C using the [NESRecomp](https://github.com/mstan/nesrecomp) framework and run it on PC. ![Super Dodge Ball title screen (recompiled build)](docs/assets/title.png) > **Status:** playable — it boots to the title screen, plays through team-select verified byte-exact vs Mesen (state, not just pixels), and plays full matches end-to-end (throws land, damage digits show, HUD/menus render). Not yet tested on a full playthrough to completion, and there is one known mod bug below. See `docs/plan.md` for the frontier. > *Built with [NESRecomp](https://github.com/mstan/nesrecomp) by Matthew Stanley — framework questions belong upstream, game-specific issues belong here. This port is in development — expect rough edges.* --- ## Quick Start ```bash # Full setup (venv, submodules, MesenCE, cycle backend, blargg test ROMs) ./setup.sh # Or build and run in one go (window opens on the launcher — press Play) ./build_and_run.sh # Headless scripted run (input schedule + last-frame screenshot) ./build_and_run.sh --frames 400 --input tas/vectors/sdb_idle.input --screenshot out.png # Per-frame screenshots + memory snapshot at frame N (differential checks) ./build-cycle/nes_game "rom.nes" --frames 400 --input tas/vectors/sdb_idle.input \ --shot-every 10 --screenshot shots/shot.png --mem-frame 399 --mem-out mem.txt ``` ## The launcher The window opens on **[recomp-ui](https://github.com/RetroPortingToolKit/recomp-ui)'s** pre-boot launcher: a settings dashboard where you set display, audio and per-player bindings before the game starts. Press **Play** to boot the ROM, or **Escape** to skip straight in. Once the game is running, **Escape** opens the in-game menu — display and audio, save states, and quit. (The same key does both, because the launcher only exists before boot.) Settings and bindings persist to `build-cycle/config.ini` beside the executable. Keybinds are SDL key names; defaults are P1 = `Z`/`X`/`\`/`Return` + arrows, gamepad = `a`/`x`/`back`/`start` + d-pad. Delete `config.ini` to restore defaults. The launcher is built from the pinned `external/recomp-ui/` submodule — nothing game-specific lives in this repo. To build the window without it (launcher and in-game menu both off): ```bash NESRECOMP_RECOMP_UI=OFF ./build_and_run.sh ``` See `NOTICE.md` for attribution. ## Mods The launcher has a **Mods** screen. Three ship with the build, all **off by default**: - **Remove Character Flicker** — the original release flickered badly, three ways, none of them the NES 8-sprites-per-line limit that emulator "remove sprite limit" options target; this game throttles its own sprites, so no emulator setting can help: 1. **Truncation** — OAM is built in place behind a cursor and the character emitter *stops* once OAM's 64 slots are full, so the rest of a character is never computed. This mod keeps emission going and draws every sprite the game produces, which also lifts the NES 8-per-scanline limit. 2. **Culling** — the game builds a display list each frame and deliberately leaves an object off it, rotating which object, so a whole character blinks out for 4 frames in 9. Three gates on that path are overridden; see `docs/research.md` §2.1. 3. **Orphan emitters** — the floating damage numbers and the team-select position numbers are drawn by emitters with no cursor bump for a hook to sit on, so they were never captured. Both are hooked per-emitter now (`docs/research.md` §2.1). Game logic runs stock either way — nothing reads sprite OAM back, and sprite slot 0 never differs. The truncation half is presentation only (identical cycle count, 2 bytes of the OAM shadow page differ); the culling half is not, because making the game emit an object it had dropped *is* extra guest work — the picture itself is byte-identical on 899 of 910 frames. The feature is off unless you turn it on in the Mods screen (or pass `--remove-character-flicker` headless); with it off the output is byte-identical to the unmodded game. > **Known issue:** with the mod on, the level-switch screen (after winning a match) briefly > shows white ghost sprites. Under investigation — this is why the mod stays off by default. - **PPU Overclocking** — the game feels slower than it should, because its main loop is an NMI-synced spin: it parks waiting for the next NMI, so the guest only gets 262 scanlines of CPU per frame. This adds **blank scanlines before the NMI**, so the guest completes more of its own work each frame and the game runs faster. Nothing new is drawn — the added lines render nothing and audio pauses across them, so the picture stays 256×240; the effect is purely extra CPU time. Same mechanism as MesenCE's *Additional scanlines before NMI* and FCEUX's post-render scanlines. The Mods screen exposes the count (0–262; 262 roughly doubles the per-frame CPU budget). **This deliberately changes console timing, so it is off by default and is not hardware-accurate** — leave it off if you want original behaviour. Headless: ```bash ./build-cycle/nes_game "roms/Super Dodge Ball (USA).nes" --frames 800 \ --input tas/vectors/sdb_throw.input --ram-init zeros --ppu-overclock 262 ``` It needs `patches/006_ppu_overclock_mmc1` (applied by `setup.sh`); without it the backend refuses the setting on an MMC1 cartridge. Measured numbers and the three-emulator comparison are in `docs/research.md` §23. - **Widescreen** — presents **16:9 / 21:9 / 32:9** (426 / 560 / 854 columns) or the window's own shape, with the extra columns showing court the NES could not display. The guest is never touched: the extra columns are read out of the nametable, CHR and the frame's own scroll, and the stock 256-column picture stays authoritative in the middle — so the centre of a wide frame is pixel-for-pixel the unmodded game. Reconstruction is verified against the machine's own background every frame, and a frame that fails falls back to the ordinary centred picture, which is why title screens and menus just work. Past the court's own 512-pixel world the margin is the backdrop colour: the stadium is 512 pixels wide and an 854-column frame does not fit inside it, so at 21:9 and 32:9 there can be a black band at one end. That is deliberate — mirroring or repeating the world was tried and renders the scoreboard backwards. It is **not** upscaled: the same chunky pixels on a wider canvas. A second feature in the same package, **Remove overscan**, reveals the 8 blank columns at the left that the game hides with PPUMASK — blank in every one of 2112 measured frames. Only takes effect together with widescreen. Headless: ```bash ./build-cycle/nes_game "roms/Super Dodge Ball (USA).nes" --frames 900 \ --input tas/vectors/sdb_throw.input --ram-init zeros --widescreen 32:9 ``` Design notes, the four reconstruction bugs the seam check caught, and the overscan measurement are in `docs/research.md` §25. For headless runs the catalog is only read when you point at it, and the feature is off unless you ask for it: ```bash ./build-cycle/nes_game "roms/Super Dodge Ball (USA).nes" --frames 470 \ --input --ram-init zeros --mods-root build-cycle/mods \ --remove-character-flicker \ --present-out out.png --present-every 1 ``` `--present-out` writes what the *window* would show, which is the only path that exercises the mod — `--screenshot` and `--frame-log` capture the machine's native frame and ignore it. ## Display The launcher's **Graphics** section has a **VSync** row. With it on, each present syncs to the display's refresh, so motion lands evenly at 60 Hz, 120 Hz or anything else. **Presentation only**: the guest keeps its stock clock either way. (Adaptive in that row behaves the same as On.) Needs `patches/007_window_vsync` (applied by `setup.sh`). See `docs/research.md` §24. ## Getting MesenCE (for frame comparison) The recompiled game's frame output can be compared against an accurate NES emulator reference. **MesenCE** (`nesdev-org/MesenCE`) is used as the reference renderer. Three ways to get it: ### Option A: Download pre-built binary (easiest) ```bash wget -O /tmp/mesen.zip https://github.com/nesdev-org/MesenCE/releases/download/2.2.1/Mesen_2.2.1_Linux_x64.zip unzip /tmp/mesen.zip -d /tmp/mesen_extract cp /tmp/mesen_extract/Mesen external/mesence/Mesen ``` Fastest way to get a working Mesen binary. No build tools or .NET SDK required. ### Option B: Build from source ```bash # Prerequisites: g++/clang++, SDL2 dev, make, .NET SDK cd external/mesence USE_GCC=true make -j$(nproc) ``` `setup.sh` does this automatically if the binary doesn't already exist. **Dependencies:** C++17 compiler, SDL2 development headers, make, and a .NET SDK (8.0 available from apt; 10.0 requires `ppa:dotnet/backports`). ### Option C: Let setup.sh handle it ```bash ./setup.sh ``` Clones `external/mesence` from GitHub, builds with `USE_GCC=true make -j$(nproc)`, and copies the binary to `external/mesence/Mesen`. If the binary already exists, it skips the build. ## Controls | NES Button | Keyboard | Gamepad 1 | |---|---|---| | A | Z | a | | B | X | y | | Select | \ | back | | Start | Return | start | | Up | Up | d-pad Up | | Down | Down | d-pad Down | | Left | Left | d-pad Left | | Right | Right | d-pad Right | ## Architecture Static recompilation, not an emulator. The original 6502 machine code is translated to C at build time — one block per ROM instruction with every CPU cycle's bus activity spelled out — then compiled to native code and run on a cycle-accurate console model (CPU, PPU, APU, DMAs, mappers). - **`CMakeLists.txt`** — The game project (root). Wraps the submodule's `runner/cyc/project.cmake` and adds `CXX`, `MODS`, `GAME_ID` and `HOST_EXTRAS`, which the submodule's own project file can't express — so the submodule stays pristine. - **`src/game.toml`** — Recompiler config: display `name` (window title), a `cycle_seed_file`, and ten content-keyed `[[mod_function_hook]]` sites. Hooks are keyed by `crc32`, never by ROM bytes. Fed to the cycle backend at configure time. - **`src/cycle_seeds.txt`** — Recompiler discovery roots. A mod hook site only exists in *recompiled* code, and the sprite emitters the mod hooks ran on the interpreter; these six lines make them native. Total cycle count unchanged. - **`src/sdb_host_extras.c`** — Our three mods: the **character-flicker mod** (captures every OAM sprite the game emits and presents them host-side, overriding the game's own object culling — research.md §2.1), the **PPU-overclocking mod** (picks a value for the backend's extra-scanlines setting — research.md §23) and the **widescreen compositor** (reads the nametable to fill a 426/560/854-column canvas, with a seam check against the machine's own background — research.md §25). - **`mods/`** — The mod packages (`manifest.toml` only; `.nesmod` archives can't carry native code). Off by default, toggleable in the launcher's Mods screen. - **`build-cycle/`** — Cycle-backend build (gitignored): per-instruction C (`game_cyc*.c`, one revision dir per ROM/config) + `nes_game` runner + the preloaded `mods/` catalog. - **`external/nesrecomp/`** — NESRecomp framework submodule (recompiler + runners) - **`external/mesence/`** — MesenCE emulator (reference rendering + oracle Lua API) - **`tools/frame_gen/`** — Mesen frame export Lua script + wrapper - **`tools/overclock/`** — PPU-overclocking oracle harness (research.md §23) - **`tools/widescreen/`** — Nametable and blank-border measurement behind widescreen (research.md §25) - **`tools/blargg/`** — blargg test-ROM suite on the cycle backend (`run_blargg.py`, `manifest.json`); per-ROM builds in `build-cyc-blargg/`, ROMs in `external/nes-test-roms/` (both gitignored) - **`tools/tas/`** — TAS-integrated differential harness: bk2/fm2 → canonical `tas.json`, shared-input runners for MesenCE + cycle backend with full state capture, three-layer first-divergence diff (`run_tas.py`, `diff_tas.py`, `mesen_tas.lua`); vectors in `tas/vectors/`, runs in `tas/runs/` (gitignored) ### Project Structure ``` Super Dodgeball Recomp/ ├── roms/ # NES ROM files (gitignored) ├── src/ # Project source │ ├── game.toml # Recompiler config (display name + mod hook sites) │ ├── sdb_host_extras.c # Flicker / overclock / widescreen mods │ └── third_party/ # Local gitignored build scratch (not shipped) ├── mods/ # Mod package(s), copied beside the executable at build time │ └── packages/ │ ├── super-dodgeball.character-flicker/ # manifest.toml only (data-only by design) │ ├── super-dodgeball.ppu-overclock/ # manifest.toml only (data-only by design) │ └── super-dodgeball.widescreen/ # manifest.toml only (data-only by design) ├── external/nesrecomp/ # NESRecomp submodule ├── external/mesence/ # MesenCE emulator (reference rendering) ├── external/nes-test-roms/ # blargg suite checkout (gitignored, via setup.sh --fetch path) ├── build-cyc-blargg/ # blargg per-ROM cycle builds (gitignored) ├── build-cycle/ # Cycle-backend build (gitignored) ├── tools/ │ ├── compare_frames.py # Mesen reference vs cycle screenshot comparison │ ├── rom_to_asm.py # ROM → assembly listing helper │ ├── run_roundtrip.py # ROM → asm → ROM byte-preservation check │ ├── dis65.py # Dependency-free 6502 disassembler │ ├── blargg/ # blargg suite on the cycle backend (run_blargg.py, manifest) │ ├── tas/ # TAS differential harness (converters, runners, diff) │ ├── frame_gen/ # Mesen frame export + oracle dump + memwatch scripts │ ├── overclock/ # PPU-overclocking oracle harness (research.md §23) │ └── widescreen/ # Nametable + blank-border measurement (research.md §25) ├── tas/ │ ├── vectors/ # TAS movies (.bk2 + format samples, committed) │ └── runs/ # Per-TAS run artifacts (gitignored) ├── venv/ # Python virtual environment (gitignored) ├── docs/ │ ├── research.md # Deep research notes │ ├── plan.md # Project plan │ └── assets/ # README images (title screen) ├── LICENSE.md # PolyForm Noncommercial 1.0.0 ├── NOTICE.md # Attribution + no-ROM disclaimer ├── .github/ │ ├── workflows/ci.yml # ROM-less CI (engine + scripts + config) │ └── raid-discord.png # R.A.I.D. invite badge (footer) ├── setup.sh # Environment setup (venv + submodules + build) ├── build_and_run.sh # Quick build + run (cycle backend, windowed) ├── CMakeLists.txt # Game project: wraps the submodule's project.cmake + MODS/HOST_EXTRAS ├── README.md └── AGENTS.md # Developer reference for AI coding agents ``` ## Frame Comparison Pipeline Compare cycle-backend output against an accurate NES reference using MesenCE. ```bash # Step 1: Generate reference frames with MesenCE ./tools/frame_gen/run_frames.sh roms/Super Dodge Ball (USA).nes 100 nes_reference --start # Step 2: Generate cycle-backend frames with screenshots ./build_and_run.sh --frames 100 --shot-every 1 --screenshot cyc_shots/shot.png # Step 3: Compare pixel-by-pixel (tolerance-based: exact RGB never matches across renderers) # (cyc names shots shot_00000.png; rename to the frame_XXXX.png scheme first) python3 -c "import glob,os; [os.rename(p,'cyc_shots/frame_%04d.png'%int(p.split('_')[-1].split('.')[0])) for p in glob.glob('cyc_shots/shot_*.png')]" python3 tools/compare_frames.py --ref nes_reference --recomp cyc_shots --frames 100 ``` ### TAS-integrated differential testing (`tools/tas/`) Same TAS input drives both the MesenCE oracle and the cycle backend; diffs CPU RAM, CIRAM, palette indices, and OAM byte-exact per video-frame to the first divergence (liveness → state → informational images). Vectors: TASVideos #4976 `.bk2` in `tas/vectors/` (headerless MD5 matches our ROM). ```bash python3 tools/tas/bk2_to_tas.py tas/vectors/sdb_4976.bk2 tas/sdb_4976.tas.json python3 tools/tas/run_tas.py --tas tas/sdb_4976.tas.json --frames 400 --out tas/runs/r400 python3 tools/tas/diff_tas.py tas/runs/r400 ``` The cycle side runs with an absolute-state input schedule plus `--frame-log-at mesen` binary snapshots (RAM/CIRAM/palette/OAM/picture per frame) and `--shot-every` screenshots. Honesty is sealed: cycle snapshots are byte-identical across repeat runs, and real differences get reported (sprite entry-0 mirror bytes masked — hardware mirrors them to the backdrop, see `diff_tas.py`). Current state: RAM/OAM/palette/CIRAM match from boot; 400 TAS frames reach team-select. See `tools/tas/README.md`. ### Cycle-accurate backend (`build-cycle/`, gitignored) This is the backend everything runs on: per-cycle 6502/PPU/APU/DMA with own mappers, via the upstream project integration. `./build_and_run.sh` and `./setup.sh` target it; `./build-cycle/nes_game` takes the host flags (`--frames`, `--input` schedule ` NAMES`, `--ram-init zeros`, `--shot-every`, `--mem-frame`/`--mem-out`, `--miss-log`, `--align 0-3`, `--mods-root`, `--present-out`/`--present-every`/`--present-size`) plus the game's own (`--remove-character-flicker`, `--ppu-overclock N`, `--widescreen MODE`, `--overscan`). `--present-out` is the one that matters for mods: it writes what the *window* would show. `--screenshot` and `--frame-log` capture the machine's native frame and never see any of them. Findings: 400 TAS frames reach team-select, matching Mesen; blargg cpu tier 25/25 green (20 RAM-text PASS incl. `12-jmp_jsr` at 99.4% native, 5 screen-confirmed PASS: branch_1/2/3, dummy_reads, timing_test6). ### Deeper oracle work (PPU dumps, per-NMI flag logs) ```bash OUT_DIR=oracle_out DUMP_FRAME=11 MAX_FRAMES=13 HOME="$HOME/mesen-home" \ xvfb-run -a external/mesence/Mesen \ --testrunner "roms/Super Dodge Ball (USA).nes" \ tools/frame_gen/oracle_dump.lua --timeout=60 ``` Isolated HOME needs a `settings.json` (`AllowIoOsAccess`, `ScriptTimeout`, `RamPowerOnState: 1`); see `docs/research.md` §16. Raw `--testRunner` + Lua only — no MCP/bridge layer. ## ROM Specifications | Property | Value | |---|---| | **ROM** | `roms/Super Dodge Ball (USA).nes` | | **Format** | iNES 2.0 | | **Mapper** | 1 (MMC1 / NES-SLROM PCB, MMC1B2) | | **PRG ROM** | 128 KB (8 × 16KB banks) | | **CHR ROM** | 128 KB (16 × 8KB banks) | | **Mirroring** | Horizontal | | **Battery** | None | | **TV System** | NTSC | | **PRG CRC32** | `689971F9` | | **SHA-1** | `42f954e9bd3256c011aba14c7e5b400abe35fde3` | | **File size** | 262,160 bytes (16-byte header + 262,144 data) | ## Known Limitations (current state) - **Menus work to team-select** — 400 TAS frames (TASVideos #4976) reach `CHANGE POSITION?` with rosters and courts rendering; state matches Mesen byte-exact (RAM/OAM/palette/CIRAM). - **Matches play end-to-end** — scripted throw runs (`tas/vectors/sdb_throw.input`, 8000 frames) play full matches: throws land, damage digits show, HUD and menus render, no hangs. Full playthrough to completion (winning rounds, level-switch screens) is untested. - **Mod off by default** — the flicker mod needs a full-playthrough test first. Known issue with it on: white ghost sprites on the level-switch screen (under investigation). - ~~**Sprite flickering**~~ — **fixed, all causes.** Not emulator sprite-limit removal: the game (1) stops emitting once OAM's 64 slots fill, (2) deliberately culls one object off its own display list each frame, rotating which, so a character blinks out 4 frames in 9, and (3) draws its damage numbers and menu digits through emitters no bump hook could see. Characters now stay whole with the opt-in `super-dodgeball.character-flicker` mod — toggleable in the launcher's **Mods** screen. See `docs/research.md` §2 and §2.1. - **Palette mirrors** — sprite entry-0 bytes (`$3F10/$3F14/$3F18/$3F1C`) read stale in cycle snapshots (upstream model keeps power-on bytes; hardware mirrors the backdrop). Masked in the TAS diff; rendering unaffected. - **Widescreen cannot show more world than the game has** — the court is a 512-pixel-wide loop, so at 21:9 and 32:9 the extra columns run off the end and are filled with the backdrop. Expect a black band at whichever end the camera has reached; 16:9 usually fits. - **Widescreen margins are background only** — players are not drawn outside the 256-column viewport, because the game only emits sprites for what it can see. ## Developer Docs **[AGENTS.md](AGENTS.md)** — Developer reference with present-tense constraints, codegen notes, submodule workflow, MesenCE testrunner API, verification procedures, and current-known issues. The canonical document for AI coding agents. **[docs/research.md](docs/research.md)** — Deep research: ROM specs, NESRecomp framework, NMI dispatcher/`$0100` map, MesenCE oracle, NMI survey, current build state, PPU overclocking (§23), VSync (§24), widescreen and overscan (§25). ## References - NESRecomp: https://github.com/mstan/nesrecomp - NESRecomp Discord (R.A.I.D.): `discord.gg/Ad9BwSzctP` - MesenCE: https://github.com/nesdev-org/MesenCE - SNES Port (Rumbleminze): https://github.com/rumbleminze/super-super-dodgeball - Romhacking.net: https://www.romhacking.net/games/814 - StrategyWiki: https://strategywiki.org/wiki/Super_Dodge_Ball_(NES) ## License PolyForm Noncommercial 1.0.0 — see [LICENSE.md](LICENSE.md), with attribution in [NOTICE.md](NOTICE.md). The pinned `external/nesrecomp` submodule carries its own license. You must supply your own legally obtained ROM; no game content is included. ---
