# SAS Audio Processor
This is a component of [Signals & Sorcery](https://signalsandsorcery.com/), a music production application.
A suite of 25 audio processing tools — trim, normalize, compress, EQ, reverb, pitch-shift, time-stretch, key detection, MIDI extraction, and more — exposed as MCP tools via [DeclarAgent](https://github.com/shiehn/DeclarAgent).
## What You Get
| Category | Tools |
|----------|-------|
| **Processing** | trim, time-stretch, convert, mono, silence-remove, split-bars |
| **Effects** | normalize, gain, compress, eq, reverb, limit, filter, pitch-shift |
| **Analysis** | analyze, detect-key, loudness, onset-detect |
| **MIDI** | melody-to-midi |
| **Composite** | master-track, sample-prep, tempo-match, full-analysis, melody-extract |
Every tool accepts WAV files and outputs structured JSON.
## Quick Start (Claude Code)
This is the primary use case — use these audio tools directly from Claude Code via MCP.
### 1. Install DeclarAgent
```bash
go install github.com/shiehn/declaragent@latest
```
### 2. Install sas-audio-processor
```bash
# From source
git clone https://github.com/shiehn/sas-audio-processor.git
cd sas-audio-processor
python3 -m venv venv && source venv/bin/activate
pip install -r requirements.txt && pip install -e .
```
Or use the pre-built binary (macOS only):
```bash
./build.sh
# Binary at dist/sas-processor/sas-processor
```
### 3. Add MCP config
Add to `~/.claude/settings.json`:
```json
{
"mcpServers": {
"sas-audio": {
"command": "declaragent",
"args": ["--plans-dir", "/path/to/sas-audio-processor/plans"]
}
}
}
```
### 4. Use it
Now Claude Code has access to all 25 audio tools. Example conversation:
```
You: Analyze this drum loop and tell me the BPM
Claude: [calls analyze tool] The drum loop is at 128 BPM, 44100 Hz, stereo, 8.2 seconds long.
You: Trim it to 4 bars and normalize to -14 LUFS
Claude: [calls trim tool, then normalize tool] Done — trimmed to 4 bars starting at the downbeat, normalized to -14 LUFS.
You: Now master it
Claude: [calls master-track tool] Applied normalize → compress → limit chain. Output saved.
```
## Quick Start (Other MCP Clients)
### Claude Desktop
Add to `claude_desktop_config.json`:
```json
{
"mcpServers": {
"sas-audio": {
"command": "declaragent",
"args": ["--plans-dir", "/path/to/sas-audio-processor/plans"]
}
}
}
```
### Cursor / Windsurf / Copilot
Add the same MCP server config to your editor's MCP settings. The `command` and `args` are identical — only the config file location differs per editor.
## How It Works
```
MCP Client (Claude Code, Claude Desktop, etc.)
│
└─► DeclarAgent (reads YAML plan files from plans/)
│
└─► sas-processor --input ... --output ...
│
└─► stdout: JSON result
```
Each YAML plan file in `plans/` defines one MCP tool. DeclarAgent reads these at startup and exposes them to MCP clients. When a tool is called, DeclarAgent runs the `sas-processor` CLI under the hood.
## Available Tools
### Processing
| Tool | Description |
|------|-------------|
| `trim` | Detect downbeat and trim audio to specified number of bars |
| `time-stretch` | Change tempo while preserving pitch |
| `convert` | Change sample rate and/or bit depth |
| `mono` | Convert stereo to mono |
| `silence-remove` | Trim silence from start and end |
| `split-bars` | Split audio into N-bar chunks |
### Effects
| Tool | Description |
|------|-------------|
| `normalize` | Normalize to target LUFS or peak level |
| `gain` | Apply volume change in dB |
| `compress` | Dynamics compression with threshold/ratio/attack/release |
| `eq` | Parametric EQ band (boost or cut at frequency) |
| `reverb` | Algorithmic reverb with room size and wet/dry mix |
| `limit` | Brick-wall limiter |
| `filter` | High-pass or low-pass filter |
| `pitch-shift` | Shift pitch by semitones |
### Analysis
| Tool | Description |
|------|-------------|
| `analyze` | Detect BPM, duration, sample rate, channels |
| `detect-key` | Detect musical key and mode (major/minor) |
| `loudness` | Measure integrated LUFS and peak dB |
| `onset-detect` | Detect onset/transient times |
### MIDI
| Tool | Description |
|------|-------------|
| `melody-to-midi` | Extract monophonic melody to MIDI file |
### Composite (Multi-Step)
| Tool | Description |
|------|-------------|
| `master-track` | normalize → compress → limit |
| `sample-prep` | analyze → trim → normalize → convert |
| `tempo-match` | analyze → time-stretch to target BPM |
| `full-analysis` | analyze + detect-key + loudness |
| `melody-extract` | normalize → melody-to-midi |
## CLI Reference
All subcommands output line-delimited JSON to stdout. Errors go to stderr as JSON.
```bash
sas-processor [options]
```
### ping
```bash
sas-processor ping
```
Health check — returns version and status.
### analyze
```bash
sas-processor analyze --input
```
Returns BPM, duration, sample rate, and channel count.
### trim
```bash
sas-processor trim --input --output --bpm --bars [--meter 4] [--verbose]
```
Detects the downbeat and trims audio to the specified number of bars.
### time-stretch
```bash
sas-processor time-stretch --input --output --source-bpm --target-bpm
```
Changes tempo while preserving pitch.
### normalize
```bash
sas-processor normalize --input --output [--mode lufs|peak] [--target-lufs -14] [--target-peak -1]
```
### gain
```bash
sas-processor gain --input --output --db
```
### mono
```bash
sas-processor mono --input --output
```
### convert
```bash
sas-processor convert --input --output [--sample-rate ] [--bit-depth 16|24|32]
```
### silence-remove
```bash
sas-processor silence-remove --input --output [--top-db 30]
```
### compress
```bash
sas-processor compress --input --output [--threshold -20] [--ratio 4] [--attack 1.0] [--release 100]
```
### eq
```bash
sas-processor eq --input --output --freq --gain-db [--q 1.0]
```
### reverb
```bash
sas-processor reverb --input --output [--room-size 0.5] [--damping 0.5] [--wet-level 0.33]
```
### limit
```bash
sas-processor limit --input --output [--threshold -1]
```
### filter
```bash
sas-processor filter --input --output --type highpass|lowpass --cutoff-hz
```
### pitch-shift
```bash
sas-processor pitch-shift --input --output --semitones
```
### detect-key
```bash
sas-processor detect-key --input
```
Returns key, mode (major/minor), and confidence score.
### loudness
```bash
sas-processor loudness --input
```
Returns integrated LUFS and peak dB.
### onset-detect
```bash
sas-processor onset-detect --input
```
Returns onset count and onset times in seconds.
### split-bars
```bash
sas-processor split-bars --input --output-dir --bpm [--bars-per-chunk 1] [--meter 4]
```
### melody-to-midi
```bash
sas-processor melody-to-midi --input --output
```
## Building from Source
### Prerequisites
- macOS 10.15+
- Python 3.9+
### Build Steps
```bash
git clone https://github.com/shiehn/sas-audio-processor.git
cd sas-audio-processor
python3 -m venv venv && source venv/bin/activate
pip install -r requirements.txt && pip install -e .
# Build self-contained binary
pyinstaller sas-processor.spec --clean --noconfirm
# Output: dist/sas-processor/
```
Or use the build script:
```bash
./build.sh
```
### Cross-Architecture Builds
**Apple Silicon (ARM64):**
```bash
pyinstaller sas-processor.spec --clean --noconfirm
mv dist/sas-processor dist/sas-processor-arm64
```
**Intel (x86_64):**
```bash
arch -x86_64 /bin/bash -c "
python3 -m venv venv-x64
source venv-x64/bin/activate
pip install -r requirements.txt
pyinstaller sas-processor.spec --clean --noconfirm
"
mv dist/sas-processor dist/sas-processor-x86_64
```
## Running Tests
```bash
source venv/bin/activate
# All tests
pytest tests/ -v
# E2E subcommand tests only
pytest tests/test_plans_e2e.py -v
# With coverage
pytest tests/ -v --cov=sas_processor
```
## JSON Output Format
All subcommands output line-delimited JSON to stdout.
### Result (stdout)
```json
{"type": "", "success": true, "output": "/path/to/output.wav", ...}
```
### Progress Events (stdout, trim only)
```json
{"type": "progress", "stage": "loading", "percent": 0}
{"type": "progress", "stage": "detecting", "percent": 30}
{"type": "progress", "stage": "trimming", "percent": 60}
{"type": "progress", "stage": "complete", "percent": 100}
```
### Errors (stderr)
```json
{"type": "error", "code": "FILE_NOT_FOUND", "message": "Input file not found: /path/to/file.wav", "severity": "fatal"}
```
## Creating a Release
Releases are built automatically by GitHub Actions. To create a new release:
1. Update the version in `pyproject.toml`
2. Commit and push your changes
3. Tag the commit and push the tag:
```bash
git tag v2.0.0
git push origin v2.0.0
```
This triggers the release workflow which:
- Runs tests on both architectures
- Builds self-contained binaries for **ARM64** (Apple Silicon) and **x86_64** (Intel)
- Creates a GitHub Release with both `.tar.gz` archives attached
Download binaries from the [Releases](https://github.com/shiehn/sas-audio-processor/releases) page.
## Limitations
- **WAV only** — no MP3, FLAC, or other formats
- **macOS only** — binary builds target macOS (CLI works anywhere Python runs)
- **Binary size ~220MB** — due to numpy/scipy/librosa dependencies
## License
MIT
