P.S. 開機後，如果發現PulseAudio無法連接，執行sudo rmmod snd_hdmi_lpe_audio
參考資訊：
http://hansdegoede.livejournal.com/17445.html
雖然該作者是針對Fedora系統客制，不過Arch Linux相關網頁卻也建議使用者依照該網頁編譯Kernel，剛好司徒習慣使用的Linux系統是Debian系統，於是司徒在Debian系統上編譯測試該客制Kernel，結果竟然可以完美地支援電池和音效等相關驅動，於是司徒借花獻佛、依樣畫葫蘆，整理成如下：
$ cd $ git clone https://github.com/jwrdegoede/linux-sunxi $ cd linux-sunxi $ make-kpkg clean $ fakeroot make-kpkg --initrd --revision=0.0.1 kernel_image kernel_headers $ sudo dpkg -i ../linux-image-4.13.0-rc2+_0.0.1_amd64.deb $ sudo reboot
Fix Audio
$ sudo vim /etc/pulse/daemon.conf
realtime-scheduling = no
$ sudo mkdir -p /usr/share/alsa/ucm/chtrt5645
$ sudo vim /usr/share/alsa/ucm/chtrt5645/chtrt5645.conf
Comment "Intel SoC Audio Device"
SectionUseCase."HiFi" {
File "HiFi.conf"
Comment "Default"
}
$ sudo vim /usr/share/alsa/ucm/chtrt5645/HiFi.conf
SectionVerb {
# ALSA PCM
Value {
TQ "HiFi"
# ALSA PCM device for HiFi
PlaybackPCM "hw:chtrt5645"
CapturePCM "hw:chtrt5645"
}
EnableSequence [
cdev "hw:chtrt5645"
# media mixer settings
# compress
cset "name='media0_in Gain 0 Switch' on"
cset "name='media0_in Gain 0 Volume' 0"
# normal
cset "name='media1_in Gain 0 Switch' on"
cset "name='media1_in Gain 0 Volume' 0"
# swm loopback
cset "name='media2_in Gain 0 Switch' off"
cset "name='media2_in Gain 0 Volume' 0%"
# deep buffer
cset "name='media3_in Gain 0 Switch' on"
cset "name='media3_in Gain 0 Volume' 0"
cset "name='media0_out mix 0 media0_in Switch' on"
cset "name='media0_out mix 0 media1_in Switch' on"
cset "name='media0_out mix 0 media2_in Switch' off"
cset "name='media0_out mix 0 media3_in Switch' on"
cset "name='media1_out mix 0 media0_in Switch' off"
cset "name='media1_out mix 0 media1_in Switch' off"
cset "name='media1_out mix 0 media2_in Switch' off"
cset "name='media1_out mix 0 media3_in Switch' off"
cset "name='pcm0_in Gain 0 Switch' on"
cset "name='pcm0_in Gain 0 Volume' 0"
cset "name='pcm1_in Gain 0 Switch' off"
cset "name='pcm1_in Gain 0 Volume' 0%"
# codec0_out settings (used if ssp2 is connected to aif1)
cset "name='codec_out0 mix 0 codec_in0 Switch' off"
cset "name='codec_out0 mix 0 codec_in1 Switch' off"
cset "name='codec_out0 mix 0 media_loop1_in Switch' off"
cset "name='codec_out0 mix 0 media_loop2_in Switch' off"
cset "name='codec_out0 mix 0 pcm0_in Switch' on"
cset "name='codec_out0 mix 0 pcm1_in Switch' off"
cset "name='codec_out0 mix 0 sprot_loop_in Switch' off"
cset "name='codec_out0 Gain 0 Switch' on"
cset "name='codec_out0 Gain 0 Volume' 0"
# modem_out settings (used if ssp0 is connected to aif2)
cset "name='modem_out mix 0 codec_in0 Switch' off"
cset "name='modem_out mix 0 codec_in1 Switch' off"
cset "name='modem_out mix 0 media_loop1_in Switch' off"
cset "name='modem_out mix 0 media_loop2_in Switch' off"
cset "name='modem_out mix 0 pcm0_in Switch' on"
cset "name='modem_out mix 0 pcm1_in Switch' off"
cset "name='modem_out mix 0 sprot_loop_in Switch' off"
cset "name='modem_out Gain 0 Switch' on"
cset "name='modem_out Gain 0 Volume' 0"
# input settings
# pcm1_out settings
# input used when SSP2 is connected
cset "name='codec_in0 Gain 0 Switch' on"
cset "name='codec_in0 Gain 0 Volume' 0"
# input used when SSP0 is connected
cset "name='modem_in Gain 0 Switch' on"
cset "name='modem_in Gain 0 Volume' 0"
cset "name='pcm1_out mix 0 codec_in0 Switch' on"
cset "name='pcm1_out mix 0 modem_in Switch' on"
cset "name='pcm1_out mix 0 codec_in1 Switch' off"
cset "name='pcm1_out mix 0 media_loop1_in Switch' off"
cset "name='pcm1_out mix 0 media_loop2_in Switch' off"
cset "name='pcm1_out mix 0 pcm0_in Switch' off"
cset "name='pcm1_out mix 0 pcm1_in Switch' off"
cset "name='pcm1_out mix 0 sprot_loop_in Switch' off"
cset "name='pcm1_out Gain 0 Switch' on"
cset "name='pcm1_out Gain 0 Volume' 0"
# disable codec_out1
cset "name='codec_out1 mix 0 codec_in0 Switch' off"
cset "name='codec_out1 mix 0 codec_in1 Switch' off"
cset "name='codec_out1 mix 0 media_loop1_in Switch' off"
cset "name='codec_out1 mix 0 media_loop2_in Switch' off"
cset "name='codec_out1 mix 0 pcm0_in Switch' off"
cset "name='codec_out1 mix 0 pcm1_in Switch' off"
cset "name='codec_out1 mix 0 sprot_loop_in Switch' off"
cset "name='codec_out1 Gain 0 Switch' off"
cset "name='codec_out1 Gain 0 Volume' 0%"
# disable codec_in1
cset "name='codec_in1 Gain 0 Switch' off"
cset "name='codec_in1 Gain 0 Volume' 0%"
# disable all loops
cset "name='media_loop1_out mix 0 codec_in0 Switch' off"
cset "name='media_loop1_out mix 0 codec_in1 Switch' off"
cset "name='media_loop1_out mix 0 media_loop1_in Switch' off"
cset "name='media_loop1_out mix 0 media_loop2_in Switch' off"
cset "name='media_loop1_out mix 0 pcm0_in Switch' off"
cset "name='media_loop1_out mix 0 pcm1_in Switch' off"
cset "name='media_loop1_out mix 0 sprot_loop_in Switch' off"
cset "name='media_loop2_out mix 0 codec_in0 Switch' off"
cset "name='media_loop2_out mix 0 codec_in1 Switch' off"
cset "name='media_loop2_out mix 0 media_loop1_in Switch' off"
cset "name='media_loop2_out mix 0 media_loop2_in Switch' off"
cset "name='media_loop2_out mix 0 pcm0_in Switch' off"
cset "name='media_loop2_out mix 0 pcm1_in Switch' off"
cset "name='media_loop2_out mix 0 sprot_loop_in Switch' off"
cset "name='sprot_loop_out mix 0 codec_in0 Switch' off"
cset "name='sprot_loop_out mix 0 codec_in1 Switch' off"
cset "name='sprot_loop_out mix 0 media_loop1_in Switch' off"
cset "name='sprot_loop_out mix 0 media_loop2_in Switch' off"
cset "name='sprot_loop_out mix 0 pcm0_in Switch' off"
cset "name='sprot_loop_out mix 0 pcm1_in Switch' off"
cset "name='sprot_loop_out mix 0 sprot_loop_in Switch' off"
# Output Configuration
cset "name='DAC1 L Mux' IF1 DAC"
cset "name='DAC1 R Mux' IF1 DAC"
cset "name='DAC1 MIXL DAC1 Switch' 1"
cset "name='DAC1 MIXR DAC1 Switch' 1"
cset "name='Stereo DAC MIXL DAC L1 Switch' 1"
cset "name='Stereo DAC MIXR DAC R1 Switch' 1"
cset "name='DAC L2 Mux' IF2 DAC"
cset "name='DAC R2 Mux' IF2 DAC"
cset "name='Mono DAC MIXL DAC L2 Switch' on"
cset "name='Mono DAC MIXR DAC R2 Switch' on"
cset "name='DAC2 Playback Switch' on"
cset "name='HPOVOL MIXL DAC1 Switch' on"
cset "name='HPOVOL MIXR DAC1 Switch' on"
cset "name='HPOVOL MIXL DAC2 Switch' on"
cset "name='HPOVOL MIXR DAC2 Switch' on"
cset "name='HPO MIX HPVOL Switch' on"
cset "name='HPOVOL L Switch' on"
cset "name='HPOVOL R Switch' on"
cset "name='SPK MIXL DAC L1 Switch' on"
cset "name='SPK MIXR DAC R1 Switch' on"
cset "name='SPK MIXL DAC L2 Switch' on"
cset "name='SPK MIXR DAC R2 Switch' on"
cset "name='SPOL MIX SPKVOL L Switch' on"
cset "name='SPOR MIX SPKVOL R Switch' on"
cset "name='SPKVOL L Switch' on"
cset "name='SPKVOL R Switch' on"
# Input Configuration
cset "name='Stereo1 DMIC Mux' 0"
cset "name='Stereo1 ADC2 Mux' 1"
cset "name='ADC Capture Switch' on"
cset "name='ADC Capture Volume' 31"
cset "name='ADC Boost Capture Volume' 3"
cset "name='Mono ADC Capture Volume' 63"
cset "name='Mono ADC Boost Capture Volume' 2"
cset "name='IN Capture Volume' 63"
cset "name='I2S2 Func Switch' on"
]
DisableSequence [
cdev "hw:chtrt5645"
# Disable audio output path
cset "name='codec_out1 mix 0 pcm0_in Switch' off"
cset "name='media0_out mix 0 media1_in Switch' off"
cset "name='media1_in Gain 0 Switch' off"
cset "name='pcm0_in Gain 0 Switch' off"
cset "name='codec_out1 Gain 0 Switch' off"
# Disable audio input path
cset "name='pcm1_out mix 0 media_loop2_in Switch' off"
cset "name='media_loop2_out mix 0 codec_in0 Switch' off"
cset "name='media_loop2_out Gain 0 Switch' off"
cset "name='pcm1_out Gain 0 Switch' off"
cset "name='codec_in0 Gain 0 Switch' off"
]
}
SectionDevice."Speaker" {
Comment "Speaker"
Value {
PlaybackChannels "2"
}
ConflictingDevice [
"Headphones"
]
EnableSequence [
cdev "hw:chtrt5645"
cset "name='Headphone Switch' off"
cset "name='Headphone Channel Switch' off"
cset "name='Ext Spk Switch' on"
cset "name='Speaker Channel Switch' on"
cset "name='Speaker Playback Volume' 31"
]
DisableSequence [
cdev "hw:chtrt5645"
cset "name='Ext Spk Switch' off"
cset "name='Speaker Channel Switch' off"
]
}
SectionDevice."Headphones" {
Comment "Headphones"
Value {
PlaybackChannels "2"
#JackControl "Headphone Jack"
#JackHWMute "Speaker"
}
ConflictingDevice [
"Speaker"
]
EnableSequence [
cdev "hw:chtrt5645"
cset "name='Ext Spk Switch' off"
cset "name='Speaker Channel Switch' off"
cset "name='Headphone Switch' on"
cset "name='Headphone Channel Switch' on"
cset "name='Headphone Playback Volume' 31"
]
DisableSequence [
cdev "hw:chtrt5645"
cset "name='Headphone Switch' off"
cset "name='Headphone Channel Switch' off"
]
}
SectionDevice."Mic".0 {
Comment "Internal Analog Microphones"
Value {
CaptureChannels "2"
CapturePriority "150"
}
EnableSequence [
cdev "hw:chtrt5645"
cset "name='Int Mic Switch' on"
cset "name='Sto1 ADC MIXL ADC1 Switch' on"
cset "name='Sto1 ADC MIXR ADC1 Switch' on"
cset "name='Sto1 ADC MIXL ADC2 Switch' off"
cset "name='Sto1 ADC MIXR ADC2 Switch' off"
cset "name='Mono ADC MIXL ADC1 Switch' on"
cset "name='Mono ADC MIXR ADC1 Switch' on"
cset "name='Mono ADC MIXL ADC2 Switch' off"
cset "name='Mono ADC MIXR ADC2 Switch' off"
cset "name='RECMIXL BST1 Switch' on"
cset "name='RECMIXR BST1 Switch' on"
]
DisableSequence [
cdev "hw:chtrt5645"
cset "name='Sto1 ADC MIXL ADC1 Switch' off"
cset "name='Sto1 ADC MIXR ADC1 Switch' off"
cset "name='Mono ADC MIXL ADC1 Switch' off"
cset "name='Mono ADC MIXR ADC1 Switch' off"
cset "name='RECMIXL BST1 Switch' off"
cset "name='RECMIXR BST1 Switch' off"
cset "name='Int Mic Switch' off"
]
}
SectionDevice."DMic".0 {
Comment "Internal Digital Microphones"
Value {
CaptureChannels "2"
}
EnableSequence [
cdev "hw:chtrt5645"
cset "name='Int Mic Switch' on"
cset "name='Stereo1 DMIC Mux' DMIC1"
cset "name='Stereo1 ADC2 Mux' DMIC"
cset "name='Mono ADC L2 Mux' DMIC"
cset "name='Mono ADC R2 Mux' DMIC"
cset "name='Sto1 ADC MIXL ADC1 Switch' off"
cset "name='Sto1 ADC MIXR ADC1 Switch' off"
cset "name='Sto1 ADC MIXL ADC2 Switch' on"
cset "name='Sto1 ADC MIXR ADC2 Switch' on"
cset "name='Mono ADC MIXL ADC1 Switch' off"
cset "name='Mono ADC MIXR ADC1 Switch' off"
cset "name='Mono ADC MIXL ADC2 Switch' on"
cset "name='Mono ADC MIXR ADC2 Switch' on"
]
DisableSequence [
cdev "hw:chtrt5645"
cset "name='Sto1 ADC MIXL ADC2 Switch' off"
cset "name='Sto1 ADC MIXR ADC2 Switch' off"
cset "name='Mono ADC MIXL ADC2 Switch' off"
cset "name='Mono ADC MIXR ADC2 Switch' off"
cset "name='Int Mic Switch' off"
]
}
SectionDevice."HSMic".0 {
Comment "Headset Microphone"
Value {
CaptureChannels "2"
JackControl "Headset Mic Jack"
JackHWMute "Mic"
}
EnableSequence [
cdev "hw:chtrt5645"
cset "name='Headset Mic Switch' on"
cset "name='Sto1 ADC MIXL ADC1 Switch' on"
cset "name='Sto1 ADC MIXR ADC1 Switch' on"
cset "name='Sto1 ADC MIXL ADC2 Switch' off"
cset "name='Sto1 ADC MIXR ADC2 Switch' off"
cset "name='Mono ADC MIXL ADC1 Switch' on"
cset "name='Mono ADC MIXR ADC1 Switch' on"
cset "name='Mono ADC MIXL ADC2 Switch' off"
cset "name='Mono ADC MIXR ADC2 Switch' off"
cset "name='RECMIXL BST1 Switch' on"
cset "name='RECMIXR BST1 Switch' on"
]
DisableSequence [
cdev "hw:chtrt5645"
cset "name='Headset Mic Switch' off"
cset "name='RECMIXL BST1 Switch' off"
cset "name='RECMIXR BST1 Switch' off"
cset "name='Sto1 ADC MIXL ADC1 Switch' off"
cset "name='Sto1 ADC MIXR ADC1 Switch' off"
cset "name='Mono ADC MIXL ADC1 Switch' on"
cset "name='Mono ADC MIXR ADC1 Switch' on"
]
}
Fix Proxy Sensor
$ sudo vim /lib/udev/hwdb.d/99-local.hwdb
sensor:modalias:acpi:KIOX000A*:dmi*:
ACCEL_MOUNT_MATRIX=-1, 0, 0; 0, -1, 0; 0, 0, 1
$ sudo vim /lib/udev/rules.d/60-sensor.rules
# do not edit this file, it will be overwritten on update
ACTION=="remove", GOTO="sensor_end"
# device matching the sensor's name and the machine's DMI data for IIO devices
SUBSYSTEM=="iio", KERNEL=="iio*", SUBSYSTEMS=="usb|i2c", \
IMPORT{builtin}="hwdb 'sensor:modalias:$attr{modalias}:$attr{[dmi/id]modalias}'", \
GOTO="sensor_end"
SUBSYSTEM=="input", ENV{ID_INPUT_ACCELEROMETER}=="1", SUBSYSTEMS=="acpi", \
IMPORT{builtin}="hwdb 'sensor:modalias:acpi:$attr{hid}:$attr{[dmi/id]modalias}'", \
GOTO="sensor_end"
SUBSYSTEM=="input", ENV{ID_INPUT_ACCELEROMETER}=="1", SUBSYSTEMS=="platform", \
IMPORT{builtin}="hwdb 'sensor:modalias:platform:$id:$attr{[dmi/id]modalias}'", \
GOTO="sensor_end"
LABEL="sensor_end"
$ sudo udevadm hwdb --update
完成
P.S. 開機後，如果發現PulseAudio無法連接，執行sudo rmmod snd_hdmi_lpe_audio
