# Dynamic forms
> This module can reused to render dynamic forms returned by the TransferWise for Banks API.
> Note that while all code is fully tested and has a simple, generic API, the interface needs more polish to distribute it as a Maven artifact (e.g. thread safety, review contracts,...).
## About
Some endpoints in the TransferWise API return a dynamic UI that needs to be rendered to the user.
These endpoints are:
- [Recipient account requirements](https://transferwise.github.io/api-docs-banks/#recipient-accounts-requirements), used to get the necessary fields to create a new recipient.
- [Transfer requirements](https://transferwise.github.io/api-docs-banks/#transfers-requirements), needed to get the necessary fields to complete a transfer.
Rendering such a dynamic UI is quite challenging and therefore, the reference implementation contains a separate module dynamicforms that handles all that complexity for you.
## Advantages
When using the `dynamicforms` module, the following problems are solved for you:
- Shows several sections as separate UI tabs
- Renders text input fields with local error validations (min/max length, regex,... )
- Renders selection inputs with refreshes of the form (e.g. choosing the USA as the country adds a "state" input field to the form)
- Summarizes the current form state into either InComplete, ValidationError or Complete
- Allows to add static components on top of the dynamic ones
- Processes the form output to collections that can be sent back to the backend
## Key classes
The main classes involved in displaying a dynamic form UI are:
- `DynamicFormView`: can be included in XML to render a dynamic form
- `DynamicFormController`: main interface with the dynamic form component. Allows to show the form, exposes the current `DynamicFormState` and allows to get the processed form input.
- `DynamicFormsWebservice`: tells the `DynamicFormController` how to load and refresh the form for the current endpoint
- `DynamicFormState`: indicates whether the form is `Loading`, `InComplete`, `ValidationError` or `Complete`
- `StaticFormGenerator`: allows displaying static content on top of the dynamic content
## Getting started
In order to integrate a dynamic form into a new screen:
1. Include a `DynamicFormView` into your `layout.xml`.
```xml
```
2. Implement a `DynamicFormsWebService` and implement `getForm()`and `refreshForm()`.
```kotlin
interface DynamicFormsWebService {
suspend fun getForm(): List
suspend fun refreshForm(attributes: Map, details: Map): List
}
```
3. Get the `DynamicFormController` from the `DynamicFormView` and call `showForm()` on it. As the `DynamicFromController` actually does network requests in the background, it needs a `CoroutineScope` to properly clean up its resources. (typically the [viewModelScope](https://developer.android.com/topic/libraries/architecture/coroutines#viewmodelscope))
```kotlin
val dynamicForm = view.findViewById(R.id.dynamic_form)
dynamicForm.controller.showForm(scope = myCoroutineScope, dynamicWebService = MyDynamicFormsWebService())
```
4. Subscribe to the `DynamicFormController` `uiState` to get updates about the status of the form. Notice how the subscription needs to be done within a `CoroutineScope` to avoid leaking any subscriptions. (typically the [viewModelScope](https://developer.android.com/topic/libraries/architecture/coroutines#viewmodelscope))
```kotlin
myCoroutineScope.launch {
dynamicFormController.uiState.consumeEach {
dynamicFormState -> when (dynamicFormState) {
is Loading -> TODO()
is DynamicFormState.Incomplete -> TODO()
is DynamicFormState.ValidationError -> TODO()
is Complete -> TODO()
}
}
}
```
5. Get the `currentAttributes()` and `currentDetails()` from the `DynamicFormController` to process the form input.
```kotlin
val attributes: Map = dynamicFormController.currentAttributes()
val details: Map = dynamicFormController.currentDetails()
```
6. Specify theme attributes for the dynamic form elements in your `styles.xml` to ensure they form looks as expected.
```xml
```
```xml
```
7. Optionally you can provide a StaticFormGenerator which will prepend static elements to the dynamic form (e.g. name and email field)
```kotlin
interface StaticFormGenerator {
fun generate(
userInput: Map,
serverErrors: Map,
showRequired: Boolean
): List
}
```
