--- title: "Introduction (ISL 1)" subtitle: "Econ 425T" author: "Dr. Hua Zhou @ UCLA" date: "r format(Sys.time(), '%d %B, %Y')" format: html: theme: cosmo number-sections: true toc: true toc-depth: 4 toc-location: left code-fold: false engine: knitr knitr: opts_chunk: fig.align: 'center' # fig.width: 6 # fig.height: 4 message: FALSE cache: false --- Credit: This note heavily uses material from the books [_An Introduction to Statistical Learning: with Applications in R_](https://www.statlearning.com/) (ISL2) and [_Elements of Statistical Learning: Data Mining, Inference, and Prediction_](https://hastie.su.domains/ElemStatLearn/) (ESL2). Display system information for reproducibility. ::: {.panel-tabset} #### Python {python} import IPython print(IPython.sys_info())  #### R {r} sessionInfo()  #### Julia {julia} #| eval: false using InteractiveUtils versioninfo()  ::: # Overview of statistical/machine learning In this class, we use the phrases **statistical learning**, **machine learning**, or simply **learning** interchangeably. ## Supervised vs unsupervised learning - **Supervised learning**: input(s) -> output. - Prediction: the output is continuous (income, weight, bmi, ...). - Classification: the output is categorical (disease or not, pattern recognition, ...). - **Unsupervised learning**: no output. We learn relationships and structure in the data. - Clustering. - Dimension reduction. ## Supervised learning - **Predictors** $$X = \begin{pmatrix} X_1 \\ \vdots \\ X_p \end{pmatrix}.$$ Also called **inputs**, **covariates**, **regressors**, **features**, **independent variables**. - **Outcome** $Y$ (also called **output**, **response variable**, **dependent variable**, **target**). - In the **regression problem**, $Y$ is quantitative (price, weight, bmi). - In the **classification problem**, $Y$ is categorical. That is $Y$ takes values in a finite, unordered set (survived/died, customer buy product or not, digit 0-9, object in image, cancer class of tissue sample). - We have training data $(\mathbf{x}_1, y_1), \ldots, (\mathbf{x}_n, y_n)$. These are observations (also called samples, instances, cases). Training data is often represented by a predictor matrix $$\mathbf{X} = \begin{pmatrix} x_{11} & \cdots & x_{1p} \\ \vdots & \ddots & \vdots \\ x_{n1} & \cdots & x_{np} \end{pmatrix} = \begin{pmatrix} \mathbf{x}_1^T \\ \vdots \\ \mathbf{x}_n^T \end{pmatrix}$$ {#eq-predictor-matrix} and a response vector $$\mathbf{y} = \begin{pmatrix} y_1 \\ \vdots \\ y_n \end{pmatrix}$$ - Based on the training data, our goal is to - Accurately predict unseen outcome of test cases based on their predictors. - Understand which predictors affect the outcome, and how. - Assess the quality of our predictions and inferences. ### Example: salary - The Wage data set collects the wage and other data for a group of 3000 male workers in the Mid-Atlantic region in 2003-2009. - Our goal is to establish the relationship between salary and demographic variables in population survey data. - Since wage is a quantitative variable, it is a regression problem. ::: {.panel-tabset} #### Python Summary statistics: {python} # Load the pandas library import pandas as pd # Load numpy for array manipulation import numpy as np # Load seaborn plotting library import seaborn as sns import matplotlib.pyplot as plt # Set font size in plots sns.set(font_scale = 2) # Display all columns pd.set_option('display.max_columns', None) # Import Wage data Wage = pd.read_csv( "../data/Wage.csv", dtype = { 'maritl':'category', 'race':'category', 'education':'category', 'region':'category', 'jobclass':'category', 'health':'category', 'health_ins':'category' } ) Wage Wage.info()  {python} #| eval: false # summary statistics Wage.describe(include = "all")  {python} #| label: fig-wage-age #| fig-cap: "Wage changes nonlinearly with age." # Plot wage ~ age sns.lmplot( data = Wage, x = "age", y = "wage", lowess = True, scatter_kws = {'alpha' : 0.1}, height = 8 ).set( xlabel = 'Age', ylabel = 'Wage (k$)' )  {python} #| label: fig-wage-year #| fig-cap: "Average wage increases by$10k in 2003-2009." # Plot wage ~ year sns.lmplot( data = Wage, x = "year", y = "wage", scatter_kws = {'alpha' : 0.1}, height = 8 ).set( xlabel = 'Year', ylabel = 'Wage (k$)' )  {python} #| label: fig-wage-edu #| fig-cap: "Wage increases with education level." # Plot wage ~ education ax = sns.boxplot( data = Wage, x = "education", y = "wage" ) ax.set( xlabel = 'Education', ylabel = 'Wage (k$)' ) ax.set_xticklabels(ax.get_xticklabels(), rotation = 15)  {python} #| label: fig-wage-race #| fig-cap: "Any income inequality?" # Plot wage ~ race ax = sns.boxplot( data = Wage, x = "race", y = "wage" ) ax.set( xlabel = 'Race', ylabel = 'Wage (k$)' ) ax.set_xticklabels(ax.get_xticklabels(), rotation = 15)  #### R {r} #| message: false library(gtsummary) library(ISLR2) library(tidyverse) # Convert to tibble Wage <- as_tibble(Wage) %>% print(width = Inf) # Summary statistics Wage %>% tbl_summary() # Plot wage ~ age Wage %>% ggplot(mapping = aes(x = age, y = wage)) + geom_point() + geom_smooth() + labs(title = "Wage changes nonlinearly with age", x = "Age", y = "Wage (k$)") # Plot wage ~ year Wage %>% ggplot(mapping = aes(x = year, y = wage)) + geom_point() + geom_smooth(method = "lm") + labs(title = "Average wage increases by $10k in 2003-2009", x = "Year", y = "Wage (k$)") # Plot wage ~ education Wage %>% ggplot(mapping = aes(x = education, y = wage)) + geom_point() + geom_boxplot() + labs(title = "Wage increases with education level", x = "Year", y = "Wage (k$)")  #### Julia {julia} #| eval: false using AlgebraOfGraphics, CairoMakie, CSV, DataFrames ENV["DATAFRAMES_COLUMNS"] = 1000 CairoMakie.activate!(type = "png") # Import Wage data Wage = DataFrame(CSV.File("../data/Wage.csv")) # Summary statistics describe(Wage) # Plot Wage ~ age data(Wage) * mapping(:age, :wage) * (smooth() + visual(Scatter)) |> draw  ::: ### Example: stock market {r} #| code-fold: true library(quantmod) SP500 <- getSymbols( "^GSPC", src = "yahoo", auto.assign = FALSE, from = "2022-01-01", to = "2022-12-31") chartSeries(SP500, theme = chartTheme("white"), type = "line", log.scale = FALSE, TA = NULL)  - The Smarket data set contains daily percentage returns for the S&P 500 stock index between 2001 and 2005. - Our goal is to predict whether the index will _increase_ or _decrease_ on a given day, using the past 5 days' percentage changes in the index. - Since the outcome is binary (_increase_ or _decrease_), it is a classification problem. - From the boxplots in @fig-sp500-lag, it seems that the previous 5 days percentage returns do not discriminate whether today's return is positive or negative. ::: {.panel-tabset} #### Python {python} # Import S&P500 data Smarket = pd.read_csv("../data/Smarket.csv") Smarket Smarket.info()  {python} #| eval: false # summary statistics Smarket.describe(include = "all")  {python} #| label: fig-sp500-lag #| fig-cap: "LagX is the percentage return for the previous X days." # Pivot to long format for facet plotting Smarket_long = pd.melt( Smarket, id_vars = ['Year', 'Volume', 'Today', 'Direction'], value_vars = ['Lag1', 'Lag2', 'Lag3', 'Lag4', 'Lag5'], var_name = 'Lag', value_name = 'Perc' ) Smarket_long g = sns.FacetGrid(Smarket_long, col = "Lag", col_wrap = 3, height = 10) g.map_dataframe(sns.boxplot, x = "Direction", y = "Perc") plt.clf()  #### R {r} # Data information help(Smarket) # Convert to tibble Smarket <- as_tibble(Smarket) %>% print(width = Inf) # Summary statistics summary(Smarket) # Plot Direction ~ Lag1, Direction ~ Lag2, ... Smarket %>% pivot_longer(cols = Lag1:Lag5, names_to = "Lag", values_to = "Perc") %>% ggplot() + geom_boxplot(mapping = aes(x = Direction, y = Perc)) + labs( x = "Today's Direction", y = "Percentage change in S&P", title = "Up and down of S&P doesn't depend on previous day(s)'s percentage of change." ) + facet_wrap(~ Lag)  #### Julia ::: ### Example: handwritten digit recognition ::: {#fig-handwritten-digits} ![](./ISL_fig_10_3a.pdf){width=500px height=300px} ![](./ISL_fig_10_3b.pdf){width=500px height=300px} Examples of handwritten digits from the MNIST corpus (ISL Figure 10.3). ::: - Input: 784 pixel values from$28 \times 28$grayscale images. Output: 0, 1, ..., 9, 10 class-classification. - On the [MNIST](https://en.wikipedia.org/wiki/MNIST_database) data set (60,000 training images, 10,000 testing images), accuracies of following methods were reported: | Method | Error rate | |--------|----------| | tangent distance with 1-nearest neighbor classifier | 1.1% | | degree-9 polynomial SVM | 0.8% | | LeNet-5 | 0.8% | | boosted LeNet-4 | 0.7% | ### Example: more computer vision tasks Some popular data sets from computer vision. - [Fashion MNIST](https://github.com/zalandoresearch/fashion-mnist#fashion-mnist): 10-category classification. ![](./fashion-mnist-sprite.png){width=500px} - [CIFAR-10 and CIFAR-100](https://www.cs.toronto.edu/~kriz/cifar.html) ![](./cifar10.jpg){width=500px} - [ImageNet](https://www.image-net.org/) ![](./colah-KSH-results.png){width=500px} - [Microsoft COCO](https://cocodataset.org/#home) (object detection, segmentation, and captioning) ![](./coco-examples.jpeg){width=500px} - [ADE20K](http://groups.csail.mit.edu/vision/datasets/ADE20K/) (scene parsing) ![](./ade20k_examples.png){width=500px} ### Example: classify the pixels in a satellite image, by usage ::: {#fig-landsat} ![](./ESL_fig_13_6.pdf){width=750px height=750px} LANDSET images (ESL Figure 13.6). ::: - LANDSAT: 82x100 pixels. Four heat-map images, two in the visible spectrum and two in the infrared, for an area of agricultural land in Australia. - Each pixel has a class label from the 7-element set \{red soil, cotton, vegetation stubble, mixture, gray soil, damp gray soil, very damp gray soil\}, determined manually by research assistants surveying the area. The objective is to classify the land usage at a pixel, based on the information in the four spectral bands. ## Unsupervised learning - No outcome variable, just predictors. - Objective is more fuzzy: find groups that behave similarly, find features that behave similarly, find linear combinations of features with the most variations, generative models (transformers). - Difficult to know how well you are doing. - Can be useful in exploratory data analysis (EDA) or as a pre-processing step for supervised learning. ### Example: gene expression - The NCI60 data set consists of 6,830 gene expression measurements for each of 64 cancer cell lines. ::: {.panel-tabset} #### Python {python} # Import NCI60 data nci60_data = pd.read_csv('../data/NCI60_data.csv') nci60_labs = pd.read_csv('../data/NCI60_labs.csv') nci60_data.info()  {python} from sklearn.decomposition import PCA from sklearn.preprocessing import scale # Obtain the first 2 principal components nci60_tr = scale(nci60_data, with_mean = True, with_std = True) nci60_pc = pd.DataFrame( PCA(n_components = 2).fit(nci60_tr).transform(nci60_tr), columns = ['PC1', 'PC2'] ) nci60_pc['PC2'] *= -1 # for easier comparison with R nci60_pc['cancer_type'] = nci60_labs nci60_pc  {python} # Plot PC2 vs PC1 sns.relplot( kind = 'scatter', data = nci60_pc, x = 'PC1', y = 'PC2', hue = 'cancer_type', height = 10 )  #### R {r} # NCI60 data and cancel labels str(NCI60) # Cancer type of each cell line table(NCI60$labs) # Apply PCA using prcomp function # Need to scale / Normalize as # PCA depends on distance measure prcomp(NCI60$data, scale = TRUE, center = TRUE, retx = T)$x %>% as_tibble() %>% add_column(cancer_type = NCI60$labs) %>% # Plot PC2 vs PC1 ggplot() + geom_point(mapping = aes(x = PC1, y = PC2, color = cancer_type)) + labs(title = "Gene expression profiles cluster according to cancer types")  #### Julia ::: ### Example: mapping people from their genomes - The genetic makeup of$n$individuals can be represented by a matrix @eq-predictor-matrix, where$x_{ij} \in \{0, 1, 2\}$is the$j$-th genetic marker of the$i-th individual. Is that possible to visualize the geographic relationship of these individuals? - Following picture is from the article [_Genes mirror geography within Europe_](http://www.nature.com/nature/journal/v456/n7218/full/nature07331.html) by Novembre et al (2008) published in Nature. ![](https://media.springernature.com/full/springer-static/image/art%3A10.1038%2Fnature07331/MediaObjects/41586_2008_Article_BFnature07331_Fig1_HTML.jpg?as=webp) ### Ancestry estimation ::: {#fig-open-admixture} ![](./OpenAdmixture.jpg){width=750px height=750px} Unsupervised discovery of ancestry-informative markers and genetic admixture proportions. [Paper](https://doi.org/10.1016/j.ajhg.2022.12.008). ::: ## No easy answer In modern applications, the line between supervised and unsupervised learning is blurred. ### Example: the Netflix prize ::: {#fig-netflix fig-ncols=1} ![](./netflix_matrix.png){fig-align="center"} ![](./netflix_prize.png){fig-align="center"} The Netflix challenge. ::: - Competition started in Oct 2006. Training data is ratings for 480,189 Netflix customers\times\$ 17,770 movies, each rating between 1 and 5. - Training data is very sparse, about 98\% sparse. - The objective is to predict the rating for a set of 1 million customer-movie pairs that are missing in the training data. - Netflix's in-house algorithm achieved a root MSE of 0.953. The first team to achieve a 10\% improvement wins one million dollars. - Is this a supervised or unsupervised problem? - We can treat rating as outcome and user-movie combinations as predictors. Then it is a supervised learning problem. - Or we can treat it as a matrix factorization or low rank approximation problem. Then it is more of a unsupervised learning problem, similar to PCA. ### Example: large language models (LLMs) Modern large language models, such as [ChatGPT3](https://chat.openai.com), combine both supervised learning and reinforcement learning. ## Statistical learning vs machine learning - Machine learning arose as a subfield of Artificial Intelligence. - Statistical learning arose as a subfield of Statistics. - There is much overlap. Both fields focus on supervised and unsupervised problems. - Machine learning has a greater emphasis on large scale applications and prediction accuracy. - Statistical learning emphasizes models and their interpretability, and precision and uncertainty. - But the distinction has become more and more blurred, and there is a great deal of "cross-fertilization". - Machine learning has the upper hand in Marketing! ## A Brief History of Statistical Learning ![](https://people.idsia.ch/~juergen/deep-learning-history1508x932.png) Image source: - 1676, chain rule by Leibniz. - 1805, least squares / linear regression / shallow learning by Gauss. - 1936, classification by linear discriminant analysis by Fisher. - 1940s, logistic regression. - Early 1970s, generalized linear models (GLMs). - Mid 1980s, classification and regression trees. - 1980s, generalized additive models (GAMs). - 1980s, neural networks gained popularity. - 1990s, support vector machines. - 2010s, deep learning. # Course logistics ## Learning objectives 1. Understand what machine learning is (and isn't). 2. Learn some foundational methods/tools. 3. For specific data problems, be able to choose methods that make sense. ::: {.callout-tip} Q: Wait, Dr. Zhou! Why don't we just learn the best method (aka deep learning) first? A: No single method dominates. One method may prove useful in answering some questions on a given data set. On a related (not identical) data set or question, another might prevail. [Article](https://arxiv.org/abs/2106.03253) ::: ## Syllabus - Read [syllabus](https://ucla-econ-425t.github.io/2023winter/syllabus/syllabus.html) and [schedule](https://ucla-econ-425t.github.io/2023winter/schedule/schedule.html) for a tentative list of topics and course logistics. - Homework assignments will be a mix of theoretical/conceptual and applied/computational questions. Although not required, you are highly encouraged to practice literate programming (using Jupyter, Quarto, RMarkdown, or Google Colab) coordinated through Git/GitHub. This will enhance your GitHub profile and make you more appealing on job market. - We will use Python in this course. Limited support for R and Julia is also available from Dr. Hua Zhou. ## What I expect from you - You are curious and are excited about "figuring stuff out". - You are proficient in coding and debugging (or are ready to work to get there). - You have a solid foundation in introductory statistics (or are ready to work to get there). - You are willing to ask questions. ## What you can expect from me - I value your learning experience and process. - I'm flexible with respect to the topics we cover. - I'm happy to share my professional connections. - I'll try my best to be responsive in class, in office hours, and on Slack.
