# WAPDA Monitor for Home Assistant
> **Disclaimer:** This is an **unofficial**, community-built integration. The author(s) have **no affiliation, association, or relationship** with WAPDA, PITC, any DISCO (IESCO, LESCO, FESCO, MEPCO, GEPCO, PESCO, HESCO, SEPCO, QESCO, TESCO), or the Roshan Pakistan portal. This project is not endorsed, sponsored, or supported by any of these organizations. All trademarks and service names belong to their respective owners. Use at your own risk.
A Home Assistant custom integration that monitors WAPDA electricity feeders in real time using the [Roshan Pakistan](https://roshanpakistan.pk) / CCMS PITC portal.
Track your feeder's live ON/OFF status, voltage, load shedding schedule, billing, net metering, and more — all natively inside Home Assistant. No external servers needed.
---
## Install with HACS
[](https://my.home-assistant.io/redirect/hacs_repository/?owner=uppaljs&repository=wapda-monitor-hacs&category=integration)
Or manually: **HACS** → ⋮ → **Custom repositories** → paste `https://github.com/uppaljs/wapda-monitor-hacs` → Category: **Integration** → **Add** → **Download**
Then restart Home Assistant.
---
## What You Get
Each reference number creates a **device** with 30+ entities and two outage calendars:
### Real-Time Feeder
| Sensor | Description |
|--------|-------------|
| Feeder Status | ON / OFF |
| Feeder Name | Feeder name from grid |
| Grid Station | Grid station name |
| Grid Voltage | Voltage in kV |
| Grid Current | Current in Amps |
| Active Power | Power in kW |
| Reactive Power | Reactive power in kVar |
| Power Factor | Power factor |
| Feeder Remarks | Operational remarks (e.g. "Tripped", "Under Maintenance") |
| Last Event | Most recent ON/OFF transition with timestamp |
| Status Duration | How long feeder has been in current state |
### Billing & Net Metering
| Sensor | Description |
|--------|-------------|
| Amount Due | Current bill in PKR |
| Net Bill | Net bill after adjustments |
| Bill Due Date | Payment deadline |
| Bill Due In | Days until due date |
| Monthly Consumption | kWh consumed this billing cycle |
| Arrears | Outstanding amount |
| Export Off-Peak / Peak | Net metering export units |
| Import Off-Peak / Peak | Net metering import units |
| Net Metering Balance | Export minus import (positive = you're earning) |
| Energy Charges | Energy charges in PKR |
| Fixed Charges | Fixed charges in PKR |
| FPA | Fuel Price Adjustment |
| GST | General Sales Tax |
### Load Shedding Schedule
| Sensor | Description |
|--------|-------------|
| Scheduled Outage Today | Total scheduled outage hours for today |
| Next Outage In | Hours until the next scheduled outage slot |
| Next Outage Start / Outage End | Timestamp sensors for the next scheduled outage |
### Outage Calendars
The integration also creates two native Home Assistant calendars:
| Calendar | Events |
|----------|--------|
| Scheduled Outages | Forecast outage windows from the published CCMS schedule (today and tomorrow) |
| Actual Outages | Completed OFF-to-ON feeder transitions and the current outage when the feeder is reported OFF |
Use these calendars in Home Assistant's calendar dashboard, `calendar.get_events`, or calendar event automations. Calendar data comes from the integration's existing cached coordinator data; adding the calendars does not add portal requests. Actual history is limited to the event log returned by the portal, and scheduled events are forecasts.
### Binary Sensors
| Sensor | Triggers When |
|--------|---------------|
| **Feeder OFF** | Feeder status = OFF (includes voltage & remarks as attributes) |
| **Scheduled Outage Now** | There is a planned outage during the current hour |
### Account Info
| Sensor | Description |
|--------|-------------|
| Account Name | Consumer name from WAPDA records |
| Tariff | Tariff code (A1, A2, A3, etc.) |
---
## Supported DISCOs
Works with any electricity distribution company that uses the PITC/Roshan Pakistan portal:
**IESCO** · **LESCO** · **FESCO** · **MEPCO** · **GEPCO** · **PESCO** · **HESCO** · **SEPCO** · **QESCO** · **TESCO**
---
## Setup
1. **Settings** → **Devices & Services** → **Add Integration**
2. Search for **WAPDA Monitor**
3. Enter your **14-digit reference number** (from your electricity bill)
4. Done — the integration validates against the Roshan Pakistan server and creates its sensors and outage calendars
Add multiple accounts by adding the integration again with a different reference number.
### Polling Intervals (Configurable)
Click **Configure** on the integration card to adjust:
| Data | Default | Range |
|------|---------|-------|
| Feeder status | 5 min | 1 min – 1 hr |
| Billing | 12 hr | 1 hr – 24 hr |
| Schedule | 15 min | 5 min – 2 hr |
### Troubleshooting: schedule unavailable
The portal may omit or return `null` for a feeder code. The integration tries the code from live load data first, then the customer-details response. If neither contains a usable code, it skips only the schedule request rather than failing the coordinator refresh; schedule sensors and the Scheduled Outages calendar may remain empty until the portal provides that code. Please do not include your full reference number or personal account data in issue reports.
---
## Automation Examples
### Power outage alert
```yaml
automation:
- alias: "Feeder OFF Alert"
trigger:
- platform: state
entity_id: binary_sensor.wapda_XXXXXX_feeder_off
to: "on"
action:
- service: notify.mobile_app_your_phone
data:
title: "Power Outage"
message: >
{{ states('sensor.wapda_XXXXXX_feeder_name') }} is OFF.
Voltage: {{ states('sensor.wapda_XXXXXX_feeder_voltage') }} kV
Remarks: {{ states('sensor.wapda_XXXXXX_feeder_remarks') }}
```
### Pre-charge battery before scheduled outage
```yaml
automation:
- alias: "Pre-Charge Battery"
trigger:
- platform: numeric_state
entity_id: sensor.wapda_XXXXXX_next_outage_in
below: 2
condition:
- condition: numeric_state
entity_id: sensor.your_inverter_battery_soc
below: 80
action:
- service: number.set_value
target:
entity_id: number.your_inverter_charge_current
data:
value: 50
```
### Bill due reminder
```yaml
automation:
- alias: "Bill Due Reminder"
trigger:
- platform: numeric_state
entity_id: sensor.wapda_XXXXXX_bill_due_in
below: 4
action:
- service: notify.mobile_app_your_phone
data:
title: "Electricity Bill Due Soon"
message: >
Rs. {{ states('sensor.wapda_XXXXXX_current_bill') }} due in
{{ states('sensor.wapda_XXXXXX_bill_due_in') }} days
```
---
## Dashboard Card
```yaml
type: entities
title: WAPDA Feeder
entities:
- entity: binary_sensor.wapda_XXXXXX_feeder_off
- entity: sensor.wapda_XXXXXX_feeder_name
- entity: sensor.wapda_XXXXXX_feeder_voltage
- entity: sensor.wapda_XXXXXX_active_power
- entity: sensor.wapda_XXXXXX_status_duration
- entity: sensor.wapda_XXXXXX_feeder_remarks
- entity: sensor.wapda_XXXXXX_scheduled_outage_today
- entity: sensor.wapda_XXXXXX_next_outage_in
- entity: sensor.wapda_XXXXXX_current_bill
- entity: sensor.wapda_XXXXXX_bill_due_in
- entity: sensor.wapda_XXXXXX_net_metering_balance
```
---
## How It Works
The integration connects to the PITC CCMS portal (the backend behind Roshan Pakistan) using five internal API endpoints:
| # | Method | Endpoint | Data |
|---|--------|----------|------|
| 1 | GET | `/get-loadinfo/{ref}` | Real-time feeder status, voltage, power, event logs |
| 2 | GET | `/api/details/user?reference=` | Consumer name, address, tariff, feeder code |
| 3 | GET | `/api/details/bill?reference=` | Billing, charges breakdown, net metering, payment history |
| 4 | GET | `/api/schedule_api?feeder_code=&disco_code=` | Hourly outage schedule & actual outage history |
| 5 | POST | `/getflsinfo` | Load shedding schedule (HTML format, not used in HA) |
The integration mimics a real browser session with rotating User-Agent strings, proper Sec-CH-UA headers, and session cookie management to avoid being blocked. All HTTP calls run in a background executor thread so they never block the Home Assistant event loop.
### Data Update Strategy
The integration uses a `DataUpdateCoordinator` with a tiered polling approach. Feeder status (voltage, current, power) is polled at the fastest interval since it changes in real time. Load shedding schedule is refreshed at a medium interval. Billing data is polled least frequently since it typically only changes once a month. User/account details are fetched once on setup and cached permanently. If the CCMS server becomes unreachable, the integration logs a warning once and continues serving cached data. When connectivity is restored, a recovery message is logged. All poll intervals are configurable via the integration options.
---
## Use Cases
**Power outage monitoring** — Get instant notifications when your feeder goes OFF or comes back ON. Track how long outages last and correlate with scheduled maintenance.
**Bill tracking** — Monitor your electricity bill amount, due date, and consumption without opening the Roshan Pakistan app. Set up automations to remind you before the due date.
**Solar/net metering** — Track your export and import units to see if your solar setup is net-positive. The net metering balance sensor shows export minus import at a glance.
**Smart home integration** — Automatically switch to battery/UPS when an outage is detected, pre-charge batteries before a scheduled outage, or adjust thermostat settings based on current electricity rates.
**Load shedding planning** — Know exactly when your area has scheduled outages and plan activities accordingly. The "Next Outage In" sensor tells you how many hours until the next planned outage.
---
## Known Limitations
- **No real-time push** — The integration polls the CCMS server at intervals; there is no WebSocket or push notification support from the portal.
- **Feeders without AMI metering** — Some older feeders don't have Advanced Metering Infrastructure. For these, real-time voltage/current/power data will be unavailable; only billing and account info will populate.
- **Server-side rate limiting** — The CCMS portal may temporarily block requests if polled too aggressively. Keep the feeder status interval at 60 seconds or above.
- **Schedule accuracy** — The load shedding schedule reflects what's published by the DISCO; actual outages may differ from the schedule.
- **Single portal dependency** — If the Roshan Pakistan / CCMS portal goes down for maintenance, all sensors become unavailable until the portal recovers.
- **No historical data** — The integration provides current-state sensors only. Use HA's built-in recorder/statistics for historical trends.
- **Reference number only** — The portal is queried using the 14-digit reference number; there is no username/password authentication.
---
## Manual Installation
1. Download the [latest release](https://github.com/uppaljs/wapda-monitor-hacs/releases)
2. Copy `custom_components/wapda_monitor/` to your Home Assistant `config/custom_components/` directory
3. Restart Home Assistant
4. Add via Settings → Devices & Services → Add Integration → WAPDA Monitor
---
## Removal
1. **Settings** → **Devices & Services** → find **WAPDA Monitor**
2. Click the **⋮** menu → **Delete**
3. Restart Home Assistant
4. (Optional) If installed via HACS: **HACS** → **Integrations** → find **WAPDA Monitor** → **⋮** → **Remove** → restart again
---
## Troubleshooting
**"Cannot connect to the Roshan Pakistan server"**
The portal at ccms.pitc.com.pk must be reachable from your HA instance. Check if the site is accessible in a browser and that your HA server has internet access.
**Some sensors show "unavailable"**
Not all feeders have AMI (smart) meters installed — load info may be empty for some reference numbers. The schedule API occasionally returns server errors for certain feeder codes. Billing data may be unavailable between billing cycles.
**Feeder code not found**
The integration gets the feeder code from load info first, then falls back to user details (FEEDERCD). If both are empty, schedule-related sensors won't populate.
---
## Notes
- Data accuracy depends on the Roshan Pakistan / CCMS server
- Some feeders lack AMI metering and will only return billing + customer data
- Be considerate with polling intervals — aggressive polling may trigger rate limiting on the CCMS server
---
## Disclaimer
This is an **unofficial**, independently developed, community project. It is **not affiliated with, endorsed by, or associated with** WAPDA (Water and Power Development Authority), PITC (Pakistan Information Technology Company), any electricity distribution company (DISCO), or the Roshan Pakistan portal in any way.
The integration accesses publicly available data from the CCMS portal using your own consumer reference number. The author(s) make no guarantees about data accuracy, availability, or continued functionality. Use this integration at your own risk.
All product names, trademarks, and registered trademarks are the property of their respective owners.
---
