{ "cells": [ { "cell_type": "markdown", "metadata": {}, "source": [ "### 一.马尔可夫链简介\n", "这一节聊一下另一个非常实用的模型：马尔科夫链，它的概率图模型如下： \n", "![avatar](./source/12_MC初探.png) \n", "\n", "自然，它的联合概率分布公式可以写作如下： \n", "\n", "$$\n", "p(X_1,X_2,...,X_n)=p(X_1)\\prod_{i=2}^np(X_i\\mid X_{i-1})\n", "$$ \n", "\n", "我们通常处理的马尔科夫链是齐次、离散、有限状态的情况，它假设模型的状态来源于某一有限集合：$S={S_1,S_2,...,S_M}$，且状态转移概率与时间无关，即对任意时刻$t_1,t_2$,任意状态$S_k,S_l\\in S$，都有：$p(X_{t_1}=S_m\\mid X_{t_1-1}=S_l)=p(X_{t_2}=S_m\\mid X_{t_2-1}=S_l)$，所以模型参数可以由两部分构成$\\lambda=\\{\\pi_0,P\\}$： \n", "\n", "#### $\\pi_0$表示初始时刻状态的概率分布： \n", "\n", "$$\n", "\\pi_0=[\\pi_0^1,\\pi_0^2,...,\\pi_0^M]^T\\\\\n", "s.t. \\pi_0^i\\geq 0,i=1,2,...,M \\\\ \n", "\\sum_{i=1}^M\\pi_0^i=1\n", "$$ \n", "这里$\\pi_o^i$表示初始时刻$t=0$时，$S_i$的概率" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "#### P表示状态转移概率：\n", "$$\n", "P=\\begin{bmatrix}\n", "P_{1,1} & P_{1,2} & \\cdots &P_{1,M} \\\\ \n", "P_{2,1} &P_{2,2} & \\cdots & P_{2,M}\\\\ \n", "\\vdots &\\vdots & P_{i,j} & \\vdots \\\\ \n", "P_{M,1} & P_{M,2} & \\cdots & P_{M,M}\n", "\\end{bmatrix}\\\\\n", "s.t. \\sum_{i=1}^MP_{i,j}=1,j=1,2,...,M\n", "$$ \n", "\n", "其中，$P_{i,j}=p(X_t=S_i\\mid X_{t-1}=S_j),t=1,2,...$ \n", "\n", "所以，我们可以非常方便的得到任意时刻的状态分布： \n", "\n", "$$\n", "\\pi_1=P\\pi_0\\\\\n", "\\pi_2=P\\pi_1=P^2\\pi_0\\\\\n", "\\cdots\\\\\n", "\\pi_t=P^t\\pi_0\n", "$$" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "### 二.马尔可夫链的应用\n", "上面介绍了最简单的马尔可夫链的定义，那么一个自然的问题就是马尔可夫链有什么用？ \n", "\n", "（1）一般来说，我们可以通过马尔可夫链来判断某个状态序列$P(X_0,X_1,...,X_M)$出现的概率，这一点在NLP中应用较多，比如语言模型（下一节会撕），它本质就是一个马尔可夫链； \n", "\n", "（2）另外，我们可以用马尔可夫链来作预测，由于马尔科夫假设，未来的状态仅仅与现在的状态有关，而与过去的状态无关，所以预测下一个时刻状态只需要当前时刻的状态信息； \n", "\n", "（3）求马尔可夫链的稳定态，这个初听会有些抽象，其实在某些情况下，马尔可夫链会收敛到某一个稳定的状态分布，即$t\\rightarrow \\infty时,P^t\\pi_0\\rightarrow稳定的分布$，这个性质非常有用，它可被应用于马尔科夫蒙特卡洛抽样（后面撕）； \n", "\n", "（4）由于马尔可夫链是一个生成模型，所以我们也可以用它来生成一些随机状态，比如在训练好的语言模型基础上生成一段文本（下一节会撕） \n", "\n", "接下来，我们先对前两点应用作介绍和实现" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "#### 联合概率计算 \n", "\n", "联合概率计算时，直观感觉需要一步一步的计算，其实不必，由于齐次假设，状态转移概率矩阵不会随着时间变化，所以联合概率完全可以并行计算，比如下面的马尔可夫链，可以拆开为A,B,C三部分同时计算，最后再合并相乘即可（后续HMM的前向后向算法也是一样的道理） \n", "\n", "![avatar](./source/12_MC并行计算.png)" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "关于预测没啥好说的，直接通过概率转移矩阵求解下一个最有可能的状态即可" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "### 三.代码实现" ] }, { "cell_type": "code", "execution_count": 1, "metadata": {}, "outputs": [], "source": [ "\"\"\"\n", "齐次时间、离散、有限状态、一阶马尔可夫链的实现，封装到ml_models.pgm\n", "\"\"\"\n", "import numpy as np\n", "\n", "\n", "class SimpleMarkovModel(object):\n", " def __init__(self, status_num=None):\n", " # 初始状态向量\n", " self.pi = np.zeros(shape=(status_num, 1))\n", " # 状态转移概率矩阵\n", " self.P = np.zeros(shape=(status_num, status_num))\n", "\n", " def fit(self, x):\n", " \"\"\"\n", " 根据训练数据，统计计算初始状态向量以及状态转移概率矩阵\n", " :param x: x可以是单列表或者是列表的列表，比如[s1,s2,...,sn]或者[[s11,s12,...,s1m],[s21,s22,...,s2n],...],\n", " 计算初始状态向量的方式会有差异，单列表会统计所有所有状态作为初始状态分布，列表的列表会统计所有子列表开头\n", " 状态的分布\n", " :return:\n", " \"\"\"\n", " if type(x[0]) == list:\n", " for clist in x:\n", " self.pi[clist[0]] += 1\n", " for cindex in range(0, len(clist) - 1):\n", " self.P[clist[cindex + 1], clist[cindex]] += 1\n", " else:\n", " for index in range(0, len(x) - 1):\n", " self.pi[x[index]] += 1\n", " self.P[x[index + 1], x[index]] += 1\n", " # 归一化\n", " self.pi = self.pi / np.sum(self.pi)\n", " self.P = self.P / np.sum(self.P, axis=0)\n", "\n", " def predict_log_joint_prob(self, status_list):\n", " \"\"\"\n", " 计算联合概率的对数\n", " :param status_list:\n", " :return:\n", " \"\"\"\n", " # 这里偷懒就不并行计算了...\n", " log_prob = np.log(self.pi[status_list[0], 0])\n", " for index in range(0, len(status_list) - 1):\n", " log_prob += np.log(self.P[status_list[index + 1], status_list[index]])\n", " return log_prob\n", "\n", " def predict_prob_distribution(self, time_steps=None, set_init_prob=None, set_prob_trans_matrix=None):\n", " \"\"\"\n", " 计算time_steps后的概率分布，允许通过set_init_prob和set_prob_trans_matrix设置初始概率分布和概率转移矩阵\n", " :param time_steps:\n", " :param set_init_prob:\n", " :param set_prob_trans_matrix:\n", " :return:\n", " \"\"\"\n", " prob = self.pi if set_init_prob is None else set_init_prob\n", " trans_matrix = self.P if set_prob_trans_matrix is None else set_prob_trans_matrix\n", " for _ in range(0, time_steps):\n", " prob = trans_matrix.dot(prob)\n", " return prob\n", "\n", " def predict_next_step_prob_distribution(self, current_status=None):\n", " \"\"\"\n", " 预测下一时刻的状态分布\n", " :param current_status:\n", " :return:\n", " \"\"\"\n", " return self.P[:, [current_status]]\n", "\n", " def predict_next_step_status(self, current_status=None):\n", " \"\"\"\n", " 预测下一个时刻最有可能的状态\n", " :param current_status:\n", " :return:\n", " \"\"\"\n", " return np.argmax(self.predict_next_step_prob_distribution(current_status))" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "#### 案例\n", "这里收集了深圳宝安一个月（4月22日-5月21日）的天气情况，如下图，将天气分为三类，一种是晴天(0)，一种是阴天(1)，一种是雨天(2)，所以状态空间$S=\\{0,1,2\\}$\n", "![avatar](./source/12_MC_天气demo.png)" ] }, { "cell_type": "code", "execution_count": 2, "metadata": {}, "outputs": [], "source": [ "#我们用其训练一个马尔科夫链\n", "train_data=[2,1,2,1,0,0,0,0,0,0,0,1,1,2,2,1,1,1,0,0,0,0,1,0,1,1,1,1,1,1]\n", "smm=SimpleMarkovModel(status_num=3)\n", "smm.fit(train_data)" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "我们看看状态转移概率矩阵的情况，可以发现晴天转晴天，雨天转阴天，阴天转阴天的概率非常高，而雨天转晴天或者晴天转雨天的情况不会发生，这基本符合我们的认知" ] }, { "cell_type": "code", "execution_count": 3, "metadata": {}, "outputs": [ { "data": { "text/plain": [ "array([[0.75 , 0.23076923, 0. ],\n", " [0.25 , 0.61538462, 0.75 ],\n", " [0. , 0.15384615, 0.25 ]])" ] }, "execution_count": 3, "metadata": {}, "output_type": "execute_result" } ], "source": [ "smm.P" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "### 四.马尔科夫链的平稳态" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "接下来，我们看看以当前的初始状态再过3、5、7、10、20天后的概率分布情况" ] }, { "cell_type": "code", "execution_count": 4, "metadata": {}, "outputs": [ { "data": { "text/html": [ "
\n", "\n", "\n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", "
第10天第20天第3天第5天第7天
00.4335560.4337340.4266480.4312600.432870
10.4700020.4698800.4747630.4715850.470475
20.0964410.0963860.0985900.0971550.096654
\n", "
" ], "text/plain": [ " 第10天 第20天 第3天 第5天 第7天\n", "0 0.433556 0.433734 0.426648 0.431260 0.432870\n", "1 0.470002 0.469880 0.474763 0.471585 0.470475\n", "2 0.096441 0.096386 0.098590 0.097155 0.096654" ] }, "execution_count": 4, "metadata": {}, "output_type": "execute_result" } ], "source": [ "import pandas as pd\n", "pd.DataFrame({\"第3天\":smm.predict_prob_distribution(3).reshape(-1).tolist(),\n", " \"第5天\":smm.predict_prob_distribution(5).reshape(-1).tolist(),\n", " \"第7天\":smm.predict_prob_distribution(7).reshape(-1).tolist(),\n", " \"第10天\":smm.predict_prob_distribution(10).reshape(-1).tolist(),\n", " \"第20天\":smm.predict_prob_distribution(20).reshape(-1).tolist()})" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "可以发现概率分布逐渐逼近了一个平稳态，这或许与我们的初始状态有关，让我们换不一样的初始状态看看" ] }, { "cell_type": "code", "execution_count": 5, "metadata": {}, "outputs": [ { "data": { "text/html": [ "
\n", "\n", "\n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", " \n", "
任意天气晴天阴天阴雨天雨天
00.4337190.4337490.4337260.433720.433715
10.4698910.4698700.4698860.469890.469893
20.0963910.0963810.0963880.096390.096392
\n", "
" ], "text/plain": [ " 任意天气 晴天 阴天 阴雨天 雨天\n", "0 0.433719 0.433749 0.433726 0.43372 0.433715\n", "1 0.469891 0.469870 0.469886 0.46989 0.469893\n", "2 0.096391 0.096381 0.096388 0.09639 0.096392" ] }, "execution_count": 5, "metadata": {}, "output_type": "execute_result" } ], "source": [ "pd.DataFrame({\"晴天\":smm.predict_prob_distribution(20,set_init_prob=np.asarray([[1],[0],[0]])).reshape(-1).tolist(),\n", " \"阴天\":smm.predict_prob_distribution(20,set_init_prob=np.asarray([[0],[1],[0]])).reshape(-1).tolist(),\n", " \"雨天\":smm.predict_prob_distribution(20,set_init_prob=np.asarray([[0],[0],[1]])).reshape(-1).tolist(),\n", " \"阴雨天\":smm.predict_prob_distribution(20,set_init_prob=np.asarray([[0],[0.5],[0.5]])).reshape(-1).tolist(),\n", " \"任意天气\":smm.predict_prob_distribution(20,set_init_prob=np.asarray([[0.05],[0.2],[0.75]])).reshape(-1).tolist()})" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "概率分布基本全都一样，也就是说无论当前天气情况如何，对以后一段时间后的天气状况没多大影响，则说明马尔科夫链具有**无记忆性**的特点，下面对马尔科夫链收敛到平稳态做一个说明，看看它是怎么来的： \n", "\n", "（1）首先，我们可以对$P$做特征分解，分解后其对应的特征值为$\\lambda_1,\\lambda_2,...,\\lambda_M$，它对应的特征向量为$\\beta_1,\\beta_2,...,\\beta_M$，所以有如下关系： \n", "\n", "$$\n", "P\\beta_i=\\lambda_i\\beta_i\\\\\n", "P^2\\beta_i=P\\lambda_i\\beta_i=\\lambda_iP\\beta_i=\\lambda_i^2\\beta_i\\\\\n", "......\\\\\n", "P^n\\beta_i=\\lambda_i^n\\beta_i\\\\\n", "i=1,2,...,M\n", "$$ \n", "\n", "（2）若$\\beta_1,\\beta_2,...\\beta_M$线性无关（绝大部分情况也是如此），则任意一个初始分布$\\pi_0$均可以由$\\beta_1,\\beta_2,...,\\beta_M$唯一线性表示： \n", "\n", "$$\n", "\\pi_0=c_1\\beta_1+c_2\\beta_2+\\cdots+c_M\\beta_M\n", "$$ \n", "\n", "（3）对于任意步长$n$有： \n", "\n", "$$\n", "P^n\\pi_0=P^n(c_1\\beta_1+c_2\\beta_2+\\cdots+c_M\\beta_M)\\\\\n", "=c_1\\lambda_1^n\\beta_1+c_2\\lambda_2^n\\beta_2+\\cdots+c_M\\lambda_M^n\\beta_M\n", "$$ \n", "\n", "（4）由于$abs(\\lambda_i)\\leq 1$（证明后面补充），所以当$n\\rightarrow \\infty$时，只有特征值为1的那一项才会保留，假设解为单根，为$c_i\\beta_i$，则： \n", ">（4.1）这里$\\beta_i$仅与$P$相关，与$\\pi_0$无关 \n", "\n", ">（4.2）因为$P^n\\pi_0=c_i\\beta_i$，所以必然有$c_i\\beta_i$各分量之和为1（$P^n\\pi_0始终满足该条件$），所以对于任意$\\pi_0$都有$c_i=\\frac{1}{\\mid\\beta_i\\mid}$ \n", "\n", "PS：随机矩阵是指对每行或每列求和为1的非负矩阵；另外最大特征值为1的存在性很好证明，因为$P-I$线性相关，所以1必然为$P$的一个特征值" ] }, { "cell_type": "markdown", "metadata": {}, "source": [ "#### $abs(\\lambda_i)\\leq 1$的证明\n", "这个其实反证一下就好了（特别感谢**小慧老师**指导），（1）首先，对于$n\\rightarrow \\infty$，$P^n\\pi_0$向量的各分量之和一定为1；（2）$P^n\\pi_0=c_1\\lambda_1^n\\beta_1+c_2\\lambda_2^n\\beta_2+\\cdots+c_M\\lambda_M^n\\beta_M$中若有$abs(\\lambda_i)>1$，则必有$abs(P^n\\pi_0)\\rightarrow \\infty$，这与（1）矛盾了" ] }, { "cell_type": "code", "execution_count": null, "metadata": {}, "outputs": [], "source": [] } ], "metadata": { "kernelspec": { "display_name": "Python 3", "language": "python", "name": "python3" }, "language_info": { "codemirror_mode": { "name": "ipython", "version": 3 }, "file_extension": ".py", "mimetype": "text/x-python", "name": "python", "nbconvert_exporter": "python", "pygments_lexer": "ipython3", "version": "3.6.4" } }, "nbformat": 4, "nbformat_minor": 2 }
