**********************【 Macro Code 】**********************

Cell操作


[ General ]

CCB-)[Calc]Cellに値(数字 & 文字列 & 式)を代入する(1)

Sub EnetrCell()
	ThisComponent.Sheets(0).getCellByPosition(0,0).value=1				'←セルA1に数値の1を入力
	ThisComponent.Sheets(0).getCellByPosition(0,1).String="test"		'←セルA2に文字列のtestを入力
	ThisComponent.Sheets(0).getCellByPosition(0,2).Formula="=A1*10"		'←セルA3に式( =A1* 10)を入力
End Sub
'
[解説]
ThisComponentは本file。Excel風に言うとWorkBooks(1)。
Sheets(0)はSheet1の事( 正確には .getSheets().getByIndex(0) )。Excel風に言うとWorkSheets(1)。
但しExcelのsheet名をTestに変更するとWorkSheets("test")であるが、Calcの場合はSheet名がtestになってもSheets(0)であり、
Sheets("test")ではErrorになる。
Sheet名で指定する場合は getSheets().getByName("test")となる。
ThisComponent.Sheets(0).getCellByPosition(0,0).value=1はSheet1のセルA1に数値データ(value)型の1が入力されるという事。
Excel風に言うとWorkbooks(1).Worksheets(1).cells(1,1)=1。
同じくThisComponent.Sheets(0).getCellByPosition(0,1).String="test"はセルA2に文字列型データ(String)の"test"が入力される。
ここで、VBAではcells(行,列)であるが、OpenOffice BasicではgetCellByPosition(列,行)である事に注意。

つまり、上記をExcel VBAにて表すと以下の様になる。
[Excel VBAでの記述]
Sub main21()
    Workbooks(1).Worksheets(1).Cells(1, 1) = 1
    Workbooks(1).Worksheets(1).Cells(2, 1) = "test"
End Sub

CCB-)[Calc]Cellに値(数字 & 文字列 & 式)を代入する(2)


Sub EnterCell()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "StringName"
		oProp(0).Value = "1"
		oDispatcher.executeDispatch(oFrame, ".uno:EnterString", "", 0, oProp())
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A2"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "StringName"
		oProp(0).Value = "test"
		oDispatcher.executeDispatch(oFrame, ".uno:EnterString", "", 0, oProp())
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A3"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "StringName"
		oProp(0).Value = "=A1*10"
		oDispatcher.executeDispatch(oFrame, ".uno:EnterString", "", 0, oProp())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCB-)[Calc]Cellに値(数字 & 文字列 & 式)を代入する(3)

Sub CalcBasic()
	Dim oDoc as Object, oSheet as Object
	Dim oCell1 as Object, oCell2 as Object, oCell3 as Object
		oDoc = ThisComponent
		'
		oSheet = oDoc.getSheets().getByName("Sheet1")
		'
		oCell1 = oSheet.getCellRangeByName("A1")
		oCell2 = oSheet.getCellRangeByName("A3")
		oCell3 = oSheet.getCellRangeByName("A5")
		'
		oCell1.String = "Test1"
		oCell2.Value = 10
		oCell3.Formula = "=A3*5 "
		msgbox "Success"
End Sub

CCB-)[Calc]Cellから値を取得する


Sub CetCellVauleString()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellType as Long
	Dim oCell(3) as Variant
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		oDisp = "[ Cell 値取得 ]" & Chr$(10)
		for i = 0 to 3
			oCellType = oSheet.getCellByPosition(0, i ).getType()
			Select Case oCellType
				case com.sun.star.table.CellContentType.EMPTY
					oCell( i ) = "空白です。"
				case com.sun.star.table.CellContentType.VALUE
					oCell( i ) = oSheet.getCellByPosition(0, i ).Value
				case com.sun.star.table.CellContentType.TEXT
					oCell( i ) = oSheet.getCellByPosition(0, i ).String
				case com.sun.star.table.CellContentType.FORMULA
					oCell( i ) = oSheet.getCellByPosition(0, i ).Formula
				case Else
					oCell( i ) = "不正な型のDataです。"
			End Select
			'
			oDisp = oDisp & "A" & i & " Cell の値 : " & oCell( i ) & Chr$(10)
		next i
		msgbox(oDisp,0,"各Cellの値")
End Sub

[ Insert・Delete.Copy ]

CCI-)[Calc]Cellの挿入(1)[既存データは下方向に移動]

sub InsertCellDown()
    Dim Doc As Object, oSheet As Object
    Dim CellRangeAddress As New com.sun.star.table.CellRangeAddress
    	oDoc = ThisComponent
    	oSheet =oDoc.getSheets().getByIndex(0)
    	CellRangeAddress.Sheet = 0
    	CellRangeAddress.StartColumn = 2
    	CellRangeAddress.StartRow = 2
    	CellRangeAddress.EndColumn = 4
    	CellRangeAddress.EndRow = 4
    	oSheet.insertCells(CellRangeAddress, com.sun.star.sheet.CellInsertMode.DOWN)
    	msgbox "Success"
End Sub

CCI-)[Calc]Cellの挿入(1)[既存データは下方向に移動]{2}


Sub UnoInsertCell()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"		' "1:1" → 行全体を下げる挿入
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		' Insert Cell ( Direction of Existed Cell is Down )
		oDispatcher.executeDispatch(oFrame,  ".uno:InsertCellsDown", "", 0, Array())
		'
		msgbox "InsertCellsDown" & Chr$(10) & "(Dispatcher)",0,"Insert Cells"
End Sub

CCI-1)[Calc]Cellの挿入(2)[既存データは右方向に移動]{1}

Sub InsertCellRight()
    Dim Doc As Object, oSheet As Object
    Dim CellRangeAddress As New com.sun.star.table.CellRangeAddress
    	oDoc = ThisComponent
    	oSheet =oDoc.getSheets().getByIndex(0)
    	CellRangeAddress.Sheet = 0
    	CellRangeAddress.StartColumn = 2
    	CellRangeAddress.StartRow = 2
    	CellRangeAddress.EndColumn = 4
    	CellRangeAddress.EndRow = 4
    	oSheet.insertCells(CellRangeAddress, com.sun.star.sheet.CellInsertMode.RIGHT)
    	msgbox "Success"
End Sub

CCI-)[Calc]Cellの挿入(2)[既存データは右方向に移動]{2}


Sub UnoInsertCell()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"				'  "A:A" で 列全体を右に移動
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		' Insert Cell ( Direction of Existed Cell is Right )
		oDispatcher.executeDispatch(oFrame,  ".uno:InsertCellsRight", "", 0, Array())
		'
		msgbox "InsertCellsRight" & Chr$(10) & "(Dispatcher)",0,"Insert Cells"
End Sub

CCI-1)[Calc]Cellの挿入(3)[行全体が下方向に移動]

Sub InsertCellRow()
    Dim Doc As Object
    Dim Sheet As Object
    Dim CellRangeAddress As New com.sun.star.table.CellRangeAddress
    Dim iStart as integer
    Dim iRows as integer
    Dim iSheetindex as integer
    	 iSheetindex = 0
    	 iStart = 0
    	 iRows=3
    	Sheet =ThisComponent.getSheets().getByIndex(iSheetindex)
    	CellRangeAddress.Sheet = iSheetindex
    	CellRangeAddress.StartColumn = 0
    	CellRangeAddress.StartRow = iStart
    	CellRangeAddress.EndColumn = 2
    	CellRangeAddress.EndRow = iStart + iRows-1
    	Sheet.insertCells(CellRangeAddress, com.sun.star.sheet.CellInsertMode.ROWS)
End Sub

CCI-1)[Calc]Cellの挿入(4)[列全体が右方向に移動]

Sub InsertCellColumn()
    Dim Doc As Object
    Dim Sheet As Object
    Dim CellRangeAddress As New com.sun.star.table.CellRangeAddress
    Dim iStart as integer
    Dim iRows as integer
    Dim iSheetindex as integer
    	 iSheetindex = 0
    	 iStart = 0
    	 iRows=3
    	Sheet =ThisComponent.getSheets().getByIndex(iSheetindex)
    	CellRangeAddress.Sheet = iSheetindex
    	CellRangeAddress.StartColumn = 0
    	CellRangeAddress.StartRow = iStart
    	CellRangeAddress.EndColumn = 2
    	CellRangeAddress.EndRow = iStart + iRows-1
    	Sheet.insertCells(CellRangeAddress, com.sun.star.sheet.CellInsertMode.COLUMNS)
End Sub

CCI-)[Calc]Cellの挿入(5)


Sub UnoInsertCell()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B3:C5"
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "Flags"
		oProp(0).Value = ">"
		oDispatcher.executeDispatch(oFrame,  ".uno:InsertCell", "", 0, oProp())
		'
		msgbox "Success", 0,"Uno / Insert"
End Sub
'
' [ Note ]
'  V :  Cellを下に移動
'  > :  Cellを右に移動
'  R :  行全体を下に移動
'  C :  列全体を右に移動

CCI-2)[Calc]Cellの削除(1)[既存データは上方向に移動]

Sub DeleteCellUp()
    Dim Doc As Object, oSheet As Object
    Dim CellRangeAddress As New com.sun.star.table.CellRangeAddress
    	oSheet =ThisComponent.getSheets().getByIndex(iSheetindex)
    	CellRangeAddress.Sheet = 0
    	CellRangeAddress.StartColumn = 2
    	CellRangeAddress.StartRow = 2
    	CellRangeAddress.EndColumn = 5
    	CellRangeAddress.EndRow = 5
    	oSheet.removeRange(CellRangeAddress, com.sun.star.sheet.CellDeleteMode.UP)
End  Sub

CCI-)[Calc]Cellの削除(2)[既存データは左方向に移動]

Sub oDeleteCellLeft()
    Dim Doc As Object, oSheet As Object
    Dim CellRangeAddress As New com.sun.star.table.CellRangeAddress
    Dim iStart as integer
    Dim iRows as integer
    Dim iSheetindex as integer
    	 iSheetindex = 0
    	 iStart = 0
    	 iRows=3
    	oDoc = ThisComponent
    	oSheet =oDoc.getSheets().getByIndex(iSheetindex)
    	CellRangeAddress.Sheet = iSheetindex
    	CellRangeAddress.StartColumn = 0
    	CellRangeAddress.StartRow = iStart
    	CellRangeAddress.EndColumn = 2
    	CellRangeAddress.EndRow = iStart + iRows-1
    	oSheet.insertCells(CellRangeAddress, com.sun.star.sheet.CellDeleteMode.LEFT)
End Sub

CCI-)[Calc]Cellの削除(3)[行全体が上方向に移動]

Sub oDeleteCellUp()
    Dim Doc As Object, oSheet As Object
    Dim CellRangeAddress As New com.sun.star.table.CellRangeAddress
    Dim iStart as integer
    Dim iRows as integer
    Dim iSheetindex as integer
    	 iSheetindex = 0
    	 iStart = 0
    	 iRows=3
    	oSheet=ThisComponent.getSheets().getByIndex(iSheetindex)
    	CellRangeAddress.Sheet = iSheetindex
    	CellRangeAddress.StartColumn = 0
    	CellRangeAddress.StartRow = iStart
    	CellRangeAddress.EndColumn = 2
    	CellRangeAddress.EndRow = iStart + iRows-1
    	oSheet.insertCells(CellRangeAddress, com.sun.star.sheet.CellDeleteMode.ROWS)
End Sub

CCI-)[Calc]Cellの削除(4)[列全体が左方向に移動]

Sub oDeleteCellLeft()
    Dim Doc As Object, oSheet As Object
    Dim CellRangeAddress As New com.sun.star.table.CellRangeAddress
    Dim iStart as integer
    Dim iRows as integer
    Dim iSheetindex as integer
    	 iSheetindex = 0
    	 iStart = 0
    	 iRows=3
    	oSheet =ThisComponent.getSheets().getByIndex(iSheetindex)
    	CellRangeAddress.Sheet = iSheetindex
    	CellRangeAddress.StartColumn = 0
    	CellRangeAddress.StartRow = iStart
    	CellRangeAddress.EndColumn = 2
    	CellRangeAddress.EndRow = iStart + iRows-1
    	oSheet.insertCells(CellRangeAddress, com.sun.star.sheet.CellDeleteMode.COLUMNS)
End Sub

CCI-)[Calc]Cellの削除(左・上・行全体・列全体が移動)

Sub CalcDeleteCell()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc=ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "A1:B6"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
			oProp(0).Name = "Flags"
			oProp(0).Value = "U"
		oDispatcher.executeDispatch(oFrame, ".uno:DeleteCell", "", 0, oProp())
		msgbox "Success"
End Sub
'
' [ Flag Value ]
' U    : Cell を 上に移動
' L    : Cell を 左に移動
' R    : 行全体を削除
' C    : 列全体を削除

CCI-)[Calc]CellのCOPY

Sub oCopyRange
	Dim oSHeet
	Dim oRangeAddress
	Dim oCellAddress
		oSheet = ThisComponent.Sheets(1)
		oRangeAddress = oSheet.getCellRangeByName("A1:B5").getRangeAddress()
		oCellAddress = oSheet.getCellByPosition(2,0).getCellAddress()
	oSheet.copyRange(oCellAddress, oRangeAddress)
End SUb

CCI-)[Calc]CellのCOPY2

Sub oCopyData
	Dim oDoc as Object
	Dim oSheet1, oSheet2 as Object
	Dim oCopyData as Object
	Dim oCopyRange as Object
	Dim oPasteRange as Object
	Dim sCol, eCol as Long
	Dim sRow, eRow as Long
		oDoc = ThisComponent
		oSheet1 = oDoc.getSheets().getByIndex(0)
		oSheet2 = oDoc.getSheets().getByIndex(1)
		sCol = 0
		eCol = 10
		sRow = 0
		eRow = 100
		oCopyRange = oSheet1.getCellRangeByPosition(sCol, sRow, eCol, eRow)
		oPasteRange = oSheet2.getCellRangeByPosition(sCol, sRow, eCol, eRow)
		oCopyData = oCopyRange.getData()
		oPasteRange.setData(oCopyData)
End Sub

CCI-)[Calc]Cell範囲のCOPY3

Sub oCopyData
	Dim oDoc as Object
	Dim oSheet1, oSheet2 as Object
	Dim oCopyData as Object
	Dim oCopyRange as Object
	Dim oPasteRange as Object
	Dim sCol, eCol as Long
	Dim sRow, eRow as Long
		oDoc = ThisComponent
		oSheet1 = oDoc.getSheets().getByIndex(0)
		oSheet2 = oDoc.getSheets().getByIndex(1)
		sCol = 0
		eCol = 10
		sRow = 0
		eRow = 100
		oCopyRange = oSheet1.getCellRangeByPosition(sCol, sRow, eCol, eRow)
		oPasteRange = oSheet2.getCellRangeByPosition(sCol, sRow, eCol, eRow)
		oCopyData = oCopyRange.getDataArray()
		oPasteRange.setDataArray(oCopyData)
End Sub

CCI-)[Calc]形式を選択して貼り付け

Sub CopyPaste
	Dim oFrame   as object
	Dim dispatcher as object
		'
		oFrame   = ThisComponent.CurrentController.Frame
		dispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		dispatcher.executeDispatch(oFrame, ".uno:Copy", "", 0, Array())
		'
	Dim oArgs2(0) as new com.sun.star.beans.PropertyValue
		oArgs2(0).Name = "ToPoint"
		oArgs2(0).Value = "$B$5"
		dispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oArgs2())
		'
	Dim oArgs3(5) as new com.sun.star.beans.PropertyValue
		oArgs3(0).Name = "Flags"
		oArgs3(0).Value = "SDFNT"			' ← 下記" Flag Value "参照
		oArgs3(1).Name = "FormulaCommand"
		oArgs3(1).Value = 0
		oArgs3(2).Name = "SkipEmptyCells"
		oArgs3(2).Value = false
		oArgs3(3).Name = "Transpose"
		oArgs3(3).Value = false
		oArgs3(4).Name = "AsLink"
		oArgs3(4).Value = false
		oArgs3(5).Name = "MoveMode"
		oArgs3(5).Value = 4
		dispatcher.executeDispatch(oFrame, ".uno:InsertContents", "", 0, oArgs3())
		'
	msgbox "Success"
End Sub
'
' [ Flag Value ]
' S    : String ( テキスト )
' V    : Value ( 値 )
' D    : Date ( 日付 )
' F    : Formula ( 式 )
' N    : Note ( コメント )
' T    : Format ( 書式 )
' 空白 : Object ( オブジェクト )
' A    : 全て








[ Cellの書式設定 ]

CCProp-)[Calc]直接設定した書式の解除

Sub CellProtect()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oDispatcher.executeDispatch(oFrame, ".uno:ResetAttributes", "", 0, Array())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub








{{ Format }}

CCF-)[Calc]セルの表示形式キーNo.取得


Sub NumFormatNo()
	Dim oDoc as Object
	Dim oNumberFormats As Object
	Dim oLocale As New com.sun.star.lang.Locale
	Dim oDF(12) as String
	Dim oKeyNo(12) as Long
		oLocale.Language = "ja"
		oLocale.Country = "JP"
		oDoc = ThisComponent
		oNumberFormats = oDoc.NumberFormats
			oDF(0) = "#,##0"
			oDF(1) = "#,##0.#0"
			oDF(2) = "0%"
			oDF(3) = "0.00%"
			oDF(4) = "[$¥-411]#,##0;-[$¥-411]#,##0"
			oDF(5) = "[$¥-411]#,##0;[RED]-[$¥-411]#,##0"
			oDF(6) = "YYYY/MM/DD"
			oDF(7) = "YYYY年MM月DD日(AAAA)"
			oDF(8) = "GE.M.D"
			oDF(9) = "HH:MM"
			oDF(10) = "HH:MM:SS"
			oDF(11) = "0.00E+00"
			oDF(12) = "# ??/??"
			'
		oDisp = "[ Number ] " & Chr$(10)
			for i = 0 to 1
				oKeyNo(i) = oNumberFormats.queryKey( oDF(i), oLocale, false )
				oDisp = oDisp & oDF(i) & " => " & oKeyNo(i) & Chr$(10)
			next i
			oDisp = oDisp & Chr$(10)
			'
		oDisp = oDisp & "[ Percent ]" & Chr$(10)
			for i = 2 to 3
				oKeyNo(i) = oNumberFormats.queryKey( oDF(i), oLocale, false )
				oDisp = oDisp & oDF(i) & " => " & oKeyNo(i) & Chr$(10)
			next i
			oDisp = oDisp & Chr$(10)
			'
		oDisp = oDisp & "[ Current ]" & Chr$(10)
			for i = 4 to 5
				oKeyNo(i) = oNumberFormats.queryKey( oDF(i), oLocale, false )
				oDisp = oDisp & oDF(i) & " => " & oKeyNo(i) & Chr$(10)
			next i
			oDisp = oDisp & Chr$(10)
			'
		oDisp = oDisp & "[ Date ]" & Chr$(10)
			for i = 6 to 8
				oKeyNo(i) = oNumberFormats.queryKey( oDF(i), oLocale, false )
				oDisp = oDisp & oDF(i) & " => " & oKeyNo(i) & Chr$(10)
			next i
			oDisp = oDisp & Chr$(10)
			'
		oDisp = oDisp & "[ Time ]" & Chr$(10)
			for i = 9 to 10
				oKeyNo(i) = oNumberFormats.queryKey( oDF(i), oLocale, false )
					oDisp = oDisp & oDF(i) & " => " & oKeyNo(i) & Chr$(10)
			next i
			oDisp = oDisp & Chr$(10)
			'
		oDisp = oDisp & "[ 指数 ]" & Chr$(10)
			for i = 11 to 11
				oKeyNo(i) = oNumberFormats.queryKey( oDF(i), oLocale, false )
				oDisp = oDisp & oDF(i) & " => " & oKeyNo(i) & Chr$(10)
			next i
			oDisp = oDisp & Chr$(10)
			'
		oDisp = oDisp & "[ 分数 ]" & Chr$(10)
			for i = 12 to 12
				oKeyNo(i) = oNumberFormats.queryKey( oDF(i), oLocale, false )
				oDisp = oDisp & oDF(i) & " => " & oKeyNo(i) & Chr$(10)
			next i
			'
	MsgBox(oDisp, 0,"表示キーNo.")
End Sub

CCF-)[Calc]セル数値の表示形式を設定1

Sub NumberFmt()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim NumberFormats As Object
	Dim NumberFormatString As String
	Dim NumberFormatId As Long
	Dim LocalSettings As New com.sun.star.lang.Locale
		'
		oDoc=ThisComponent
		oSheet=oDoc.getSheets().getByName("sheet1")
		oCell=oSheet.getCellByPosition(1,1)		'←設定範囲
		NumberFormats = oDoc.NumberFormats
		NumberFormatString = "#,##0.#0円"
 		'
		NumberFormatId = NumberFormats.queryKey(NumberFormatString, LocalSettings, True)
		If NumberFormatId = -1 Then
   			NumberFormatId = NumberFormats.addNew(NumberFormatString, LocalSettings)	'書式コードを追加
		End If
		oCell.NumberFormat = NumberFormatId
		'
		msgbox "Success"
End Sub

CCF-)[Calc]セル数値の表示形式を設定2

Sub SetNumFormat()
	Dim oNumberFormats As Object
	Dim oLocale As New com.sun.star.lang.Locale
		oLocale.Language = "ja"
		oLocale.Country = "JP"
			oDoc = ThisComponent
			oSheet = oDoc.getSheets.getByIndex(0)
			oCell = oSheet.getCellByPosition(0,0)
		oCell.value = 10000
	oCell.NumberFormat = 5103
End Sub

CCF-)[Calc]セル数値の表示形式を設定3

Sub UnoNumFmt()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B2"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "NumberFormatValue"
		oProp(0).Value = 103
		oDispatcher.executeDispatch(oFrame, ".uno:NumberFormatValue", "", 0, oProp())
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub
'
' [ Note ]
1)	Standard	= 0

{ 数字 }
2)	0		= 1
3)	0.00		= 2
4)	#,##0		= 3
5)	#,##0.00	= 4
6)	#,###.00	= 5

{ Percent }
7)	0%		= 10
8)	0.00%		= 11

{ 通貨 }
9)	[$¥-411]#,##0;-[$¥-411]#,##0			= 101
10)	[$¥-411]#,##0.00;-[$¥-411]#,##0.00		= 103
11)	[$¥-411]#,##0;[RED]-[$¥-411]#,##0		= 103
12)	[$¥-411]#,##0.00;[RED]-[$¥-411]#,##0.00	= 104
13)	[$¥-411]#,##0.--;[RED]-[$¥-411]#,##0.--	= 105
14)	#,##0 [$JPY];[RED]-#,##0 [$JPY]			= 110
15)	¥#,##0;-¥#,##0				= 111
16)	¥#,##0.00;-¥#,##0.00				= 20
17)	¥#,##0;[RED]-¥#,##0				= 21
18)	¥#,##0.00;[RED]-¥#,##0.00			= 22
19)	#,##0 CCC					= 24
20)	¥#,##0.--;[RED]-¥#,##0.--			= 25

{ 日付 }
21)	YY/M/D			= 30
22)	YYYY年MM月DD日(AAAA)	= 38
23)	YY/MM/DD		= 37
24)	YYYY/MM/DD		= 36
25)	YY年M月D日		= 39
26)	YYYY年M月D日		= 75
27)	GGGE年M月D日		= 80
28)	YYYY年M月D日		= 76
29)	GGGE年M月D日(AAAA)	= 81
30)	YY年M月D日(AAA)	= 77
31)	GGGE年M月D日(AAA)	= 31
32)	YYYY年M月D日(AAA)	= 78
33)	YYYY年M月D日(AAAA)	= 79
34)	MM.DD			= 82
35)	GE.M.D			= 83
36)	YYYY-MM-DD		= 84
37)	YY/MM			= 32
38)	M月D日			= 33
39)	M月			= 34
40)	YY年 QQ			= 35
41)	WW			= 85

{ 時刻 }
42)	YY/MM/DD HH:MM		= 50
43)	YYYY/M/D H:MM		= 51
44)	H:MM			= 40
45)	HH:MM:SS		= 41
46)	AM/PM H:MM		= 42
47)	AM/PM H:MM:SS		= 43
48)	[HH]:MM:SS		= 44
49)	MM:SS.00		= 45
50)	[HH]:MM:SS.00		= 46
51)	YY/MM/DD HH:MM		= 50
52)	YYYY/M/D H:MM		= 51

{ 指数 }
53)	0.00E+000	= 60
54)	0.00E+00	= 61

{ 分数 }
55)	# ?/?		= 70
56)	# ??/??		= 71

{ プール値 }
57)	BOOLEAN		= 99

{ テキスト }
58)	@		= 100

CCF-)[Calc]Content Type of Cell

Sub oContentType()
	Dim oDoc
	Dim oSheets
	Dim oCell
		oDoc = ThisComponent
		oSheets = oDoc.Sheets(0)
		oCell = oSheets.getCellByPosition(1,2)
		oType = oCell.getType()
		Select Case oType
			case com.sun.star.table.CellContentType.EMPTY
				oDisp = "Empty"
			case com.sun.star.table.CellContentType.VALUE
				oDisp = "Value"
			case com.sun.star.table.CellContentType.TEXT
				oDisp = "Text"
			case com.sun.star.table.CellContentType.FORMULA
				oDisp = "Formula"
			case Else
				oDisp = "UnKnown"
		End Select
	msgbox(oDisp,0,"com.sun.star.table.CellContentType")
End SUb

CCF-)[Calc]User Defined Attributes

Sub oCellPropertiesService()
	Dim oSheets
	Dim oCell
	Dim oUserData
	Dim oUserAttr as new com.sun.star.xml.AttributeData
		oSheets = ThisComponent.Sheets(1)
		oCell =oSheets.getCellByPosition(0,0)
		'xray oUserAtrr
		oUserAttr.Type ="CDATA"
		oUserAttr.Value = "NewOOo3 macro"
		oUserData = oCell.UserDefinedAttributes
		If NOT oUserData.hasByName("home") then
			oUserData.insertByName("home",oUserAttr)
			oCell.UserDefinedAttributes = oUserData
		End If
		'xray oUserData
		oUser = oUserData.ElementNames
		for i= 0 to UBound(oUser)
			oDisp =oDisp & oUser(i) & Chr$(10)
		next i
	msgbox(oDisp,0,"UserDefinedAtrributes")
End Sub

CCF-)[Calc]固有Format Range

Sub oDisplaySimilarRange
	Dim oSheetUniqueRange
	Dim oSheetCellRange
	Dim oAddress
	Dim oGetFormat
	Dim oSheet
		oSheet = ThisComponent.Sheets(1)
	'getCellFormatRanges()
		oGetFormat = oSheet.getCellFormatRanges()
		oDisp = "[   getCellFormatRanges()  ]" & Chr$(10)
		for i= 0 to oGetFormat.getCount-1
			oSheetCellRange = oGetFormat.getByIndex(i)
			oAddress = oSheetCellRange.getRangeAddress()
			oDisp = oDisp & Chr$(9) & Chr$(9) & _
						 i & " = Sheet" & (oAddress.Sheet +1) & "." & _
						ColumnNumberToString(oAddress.StartColumn) & (oAddress.StartRow + 1) & _
						":" & _
						ColumnNumberToString(oAddress.EndColumn) & (oAddress.EndRow + 1) & _
						Chr$(10)
		next i
		oDisp =oDisp & Chr$(10)
	'
	'getUniqueCellFormatRanges()
		oGetFormat = oSheet.getUniqueCellFormatRanges()
		oDisp = oDisp & "[  getUniqueCellFormatRanges()  ]" & Chr$(10)
		for i= 0 to oGetFormat.getCount-1
			 oSheetUniqueRange = oGetFormat.getByIndex(i)
			 oDisp = oDisp & Chr$(9) & Chr$(9) & _
						 i & " = " & oSheetUniqueRange.getRangeAddressesAsString() & _
						 Chr$(10)
		next i
	'Display
	msgbox(oDisp , 0, "Like Range")
End Sub

'[ Function2 ]
Function ColumnNumberToString(ByVal nColumn As Long) as String
	Dim oReturn2 as String
	Do While nColumn>=0
		oReturn2= Chr$(65+ (nColumn MOD 26)) & oReturn2
		nColumn= nColumn / 26 -1
	Loop
	ColumnNumberToString = oReturn2
End Function









{{ Font }}

CCFo-)[Calc]Cell幅に合わせて改行(1)


Sub oWrapping()
	Dim oDoc As Object
	Dim oSheet as Object
	Dim oCell as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		oCell.String = "LibreOffice / ApacheOpenOffice マクロマニュアル"
		oCell.IsTextWrapped = True
	msgbox "Success"
End Sub

CCFo-)[Calc]Cell幅に合わせて改行(2)


Sub CalcUnoFont()
	Dim oDoc As Object, oSheet As Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		'
		oDoc = ThisComponent
  		oSheet = oDoc.getSheets().getByName("sheet1")
  		oCell = oSheet.getCellRangeByName("A1")
		oCell.String = "LibreOffice / ApacheOpenOffice マクロマニュアル(DispatchHelper)"
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "WrapText"
			oProp(0).Value = true
		oDispatcher.executeDispatch(oFrame, ".uno:WrapText", "", 0, oProp())
		'
		msgbox "Success"
End Sub

CCFo-)[Calc]文字関連の Property 一覧


Sub CellPropertyList()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
	Dim oTextCursor as Object
		oDoc=ThisComponent
		oSheet=oDoc.getSheets().getByindex(0)
		oCell=oSheet.getCellByPosition(0,1)
		oCell.String="水 素はH2"
		' cell全体の設定
		with oCell
			.CharFontName = "Arial"
			.CharFontNameAsian = "Arial"
			.CharPosture = com.sun.star.awt.FontSlant.ITALIC
			.CharPostureAsian = com.sun.star.awt.FontSlant.OBLIQUE
			.CharHeight=40				'英数字サイズは40(Cell単位での設定)
			.CharHeightAsian=20			'日本語は20(Cell単位での設定)
		end with
		'
		' Versionによっては Cell に値が無い状態で createTextCursor() を行うとCrashする
		if Trim(oCell.String)="" then
			oDisp = "Cellが空白です。" & Chr$(10) & "VersionによってはCrashする可能性があります。" & Chr$(10) & "処理を続けますか?"
			oAns = msgbox(oDisp, 0,"Caution")
			if oAns <> 6 then
				Exit Sub
			end if
		end if
		' Cellの一部の設定
		oTextCursor = oCell.createTextCursor()
		With oTextCursor
    		.gotoStart( False )
    		.goRight(3 , True )
    		.setPropertyValue( "CharContoured", true ) 				'中抜き効果
    		.setPropertyValue( "CharCrossedOut", true ) 				'取り消し線
    		.setPropertyValue("CharEmphasis",3)							'強調文字 3は「・」の上付き、4は「、」の上付
    		.setPropertyValue("CharUnderlineColor", 2918503 )		' 下線色 / 白抜きにしているので無意味
    		.setPropertyValue("CharShadowed",true)						'下線を空白に適用しない
    		.setPropertyValue("CharUnderline",1)						'UnderLine
    		.setPropertyValue("CharRelief",1)							'浮き出し 0はNormal 1は浮き出し効果
    		.setPropertyValue("CharShadowed",true)						'Shadow効果
    		.gotoEnd( False )
    	End with
    msgbox "Success"
End Sub

CCFo-)[Calc]文字列の左1文字を下付文字にする


Sub CellFont()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
	Dim oTextCursor as Object
	Dim oDisp as String
	Dim oAns as Long
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,1)
		oCell.String = "水素はH2"
		'
		' Versionによっては Cell に値が無い状態で createTextCursor() を行うとCrashする
		if Trim(oCell.String)="" then
			oDisp = "Cellが空白です。" & Chr$(10) & "VersionによってはCrashする可能性があります。" & Chr$(10) & "処理を続けますか?"
			oAns = msgbox(oDisp, 0,"Caution")
			if oAns <> 6 then
				Exit Sub
			end if
		end if
		'
		oTextCursor = oCell.createTextCursor()
		With oTextCursor
    		.gotoStart( False )
    		.gotoEnd( False )
    		.goLeft(1 , True )
    		.setPropertyValue( "CharEscapement", -101 ) 	'←下付は「-101」
    		.setPropertyValue( "CharEscapementHeight", 80 )	'←下付文字のサイズは80%としている。
    	End with
    	msgbox "Success"
End Sub

CCFo-)[Calc]Cell背景(1)


Sub BackColorOfCell()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,1)
		oCell.CellBackColor = RGB(0,255,0)
	msgbox("Success")
End Sub

CCFo-)[Calc]Cell背景(2)


Sub UnoCellBackColor()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "BackgroundPattern.BackColor"
		oProp(0).Value = &H00FF00
		oDispatcher.executeDispatch(oFrame, ".uno:BackgroundPattern", "", 0, oProp())
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCFo-)[Calc]文字の角度(1)


Sub CellPropertiesSrv()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell(5) as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		for i = 0 to 5
			oCell(i) = oSheet.getCellByPosition(0,i)
			oCell(i).String = "A"
		next i
		'
		oCell(0).RotateAngle = 2000		'20degree
		oCell(1).RotateAngle = 4000
		oCell(2).RotateAngle = 6000
		oCell(3).RotateAngle = 9000
		oCell(4).RotateAngle = -4500
		oCell(5).RotateAngle = -9000
	msgbox("Success")
End Sub

CCFo-)[Calc]文字の角度(2)


Sub CellPropertiesSrv()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oCell(5) as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		for i = 0 to 3
			oCell(i) = oSheet.getCellByPosition(0,i)
			oCell(i).String = "A"
		next i
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		' Standard
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		oProp(0).Name = "AlignmentRotationMode"
		oProp(0).Value = com.sun.star.table.CellVertJustify.STANDARD
		oDispatcher.executeDispatch(oFrame, ".uno:AlignmentRotationMode", "", 0, oProp())
		oProp(0).Name = "AlignmentRotation"
		oProp(0).Value = 6000			' 60 degree
		oDispatcher.executeDispatch(oFrame, ".uno:AlignmentRotation", "", 0, oProp())
		'
		' Cell の上縁を基準に傾ける
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A2"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		oProp(0).Name = "AlignmentRotationMode"
		oProp(0).Value = com.sun.star.table.CellVertJustify.TOP
		oDispatcher.executeDispatch(oFrame, ".uno:AlignmentRotationMode", "", 0, oProp())
		oProp(0).Name = "AlignmentRotation"
		oProp(0).Value = 6000			' 60 degree
		oDispatcher.executeDispatch(oFrame, ".uno:AlignmentRotation", "", 0, oProp())
		'
		' Cell の下縁を基準に傾ける
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A3"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		oProp(0).Name = "AlignmentRotationMode"
		oProp(0).Value = com.sun.star.table.CellVertJustify.BOTTOM
		oDispatcher.executeDispatch(oFrame, ".uno:AlignmentRotationMode", "", 0, oProp())
		oProp(0).Name = "AlignmentRotation"
		oProp(0).Value = 6000			' 60 degree
		oDispatcher.executeDispatch(oFrame, ".uno:AlignmentRotation", "", 0, oProp())

	msgbox("Success")
End Sub

CCFo-)[Calc]Font Weight


Sub CellFontWeight()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		With oCell
			.String = "LibreOffice / Apache OpenOffice"
			.CharWeight = com.sun.star.awt.FontWeight.BOLD
		End With
	msgbox("Success")
End Sub

CCFo-)[Calc]縦書き


Sub CellPropertiesSrv()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellRangeByName("A1")
		oCell.String = "こんにちは。" & Chr$(10) & "LO Ver4" & Chr$(13) & _
							"5月8日" & Chr$(10) & "( 8は全角 )"
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		' Standard
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		oDispatcher.executeDispatch(oFrame, ".uno:TextdirectionTopToBottom", "", 0, Array())
		'
	msgbox("Success")
End Sub

{{ Font Effet }}

CCFe-1)[Calc]値にUnderLineを入れる

Sub CalcUnderLine()
	Dim oCell as Object
 		oCell=ThisComponent.Sheets(0).getCellByPosition(0,0)
 		oCell.CharUnderline=com.sun.star.awt.FontUnderline.SINGLE		'←実践
 		oCell.CharUnderline=com.sun.star.awt.FontUnderline.DOTTED		'←点線
End Sub

CCFe-)[Calc]各種UnderLine設定

Sub CalcUnderLine()
	Dim oDoc As Object
	Dim oCell(18)
		oDoc=ThisComponent
		for i=0 to 18
			oCell(i)=oDoc.Sheets(0).getCellByPosition(0,i)
			oCell(i).String="No." & i & " underline in OOo Calc"
		next i
		oCell(0).CharUnderline = com.sun.star.awt.FontUnderline.NONE
		oCell(1).CharUnderline = com.sun.star.awt.FontUnderline.SINGLE
		oCell(2).CharUnderline = com.sun.star.awt.FontUnderline.DOUBLE
		oCell(3).CharUnderline = com.sun.star.awt.FontUnderline.DOTTED
		oCell(4).CharUnderline = com.sun.star.awt.FontUnderline.DONTKNOW
		oCell(5).CharUnderline = com.sun.star.awt.FontUnderline.DASH
		oCell(6).CharUnderline = com.sun.star.awt.FontUnderline.LONGDASH
		oCell(7).CharUnderline = com.sun.star.awt.FontUnderline.DASHDOT
		oCell(8).CharUnderline = com.sun.star.awt.FontUnderline.DASHDOTDOT
		oCell(9).CharUnderline = com.sun.star.awt.FontUnderline.SMALLWAVE
		oCell(10).CharUnderline = com.sun.star.awt.FontUnderline.WAVE
		oCell(11).CharUnderline = com.sun.star.awt.FontUnderline.DOUBLEWAVE
		oCell(12).CharUnderline = com.sun.star.awt.FontUnderline.BOLD
		oCell(13).CharUnderline = com.sun.star.awt.FontUnderline.BOLDDOTTED
		oCell(14).CharUnderline = com.sun.star.awt.FontUnderline.BOLDDASH
		oCell(15).CharUnderline = com.sun.star.awt.FontUnderline.BOLDLONGDASH
		oCell(16).CharUnderline = com.sun.star.awt.FontUnderline.BOLDDASHDOT
		oCell(17).CharUnderline = com.sun.star.awt.FontUnderline.BOLDDASHDOTDOT
		oCell(18).CharUnderline = com.sun.star.awt.FontUnderline.BOLDWAVE
End Sub

[ Note ] : NONE = DON'T KNOW

CCFe-)[Calc]下線色 / Color of Underline

Sub FontEffect()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		oCell.String = "LibreOffice"
		' Font Effect
		with oCell
			.CharHeight = 20
			.CharHeightAsian = 20
			.CharUnderline = com.sun.star.awt.FontUnderline.DOUBLE
   			.CharUnderlineColor = RGB(255,0,0) 						' Color of the Underline of Font
   			.CharUnderlineHasColor = true
		end with
End Sub

CCFe-)[Calc]各種UnderLineと下線色

Sub CalcUnoFont()
	Dim oDoc As Object, oSheet As Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim Dummy()
	Dim oDispatcher as Object
	Dim oProp(2) as new com.sun.star.beans.PropertyValue
		'
		oDoc = StarDesktop.loadComponentFromURL("private:factory/scalc", "_blank", 0, Dummy())
  		oSheet = oDoc.getSheets().getByName("sheet1")
  		oCell = oSheet.getCellRangeByName("A1")
		oCell.String = "LibreOffficeです"
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			' 下線
			oProp(0).Name = "Underline.LineStyle"
			oProp(0).Value = com.sun.star.awt.FontUnderline.WAVE
			oProp(1).Name = "Underline.HasColor"
			oProp(1).Value = true
			oProp(2).Name = "Underline.Color"
			oProp(2).Value = &HFF0000				' Red
		oDispatcher.executeDispatch(oFrame, ".uno:Underline", "", 0, oProp())
End Sub

CCFe-)[Calc]影付き文字(1)

Sub FontEffect()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		oCell.String = "LibreOffice"
		' Font Effect
		with oCell
			.CharFontName = "Arial"
			.CharFontNameAsian = "Arial"
			.CharHeight = 20
			.CharHeightAsian = 20
			.CharWeight = com.sun.star.awt.FontWeight.ULTRABOLD
			.CharWeightAsian = com.sun.star.awt.FontWeight.ULTRABOLD
			.CharShadowed = true
		end with
End Sub

CCFe-)[Calc]影付き文字(2)

Sub CalcUnoFont()
	Dim oDoc As Object, oSheet As Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim Dummy()
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		'
		oDoc = StarDesktop.loadComponentFromURL("private:factory/scalc", "_blank", 0, Dummy())
  		oSheet = oDoc.getSheets().getByName("sheet1")
  		oCell = oSheet.getCellRangeByName("A1")
		oCell.String = "LibreOffficeです"
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		' 影付き文字
			oProp(0).Name = "Shadowed"
			oProp(0).Value = true
		oDispatcher.executeDispatch(oFrame, ".uno:Shadowed", "", 0, oProp())
End Sub

CCFe-)[Calc]各種取消し線(1)

Sub FontEffect()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell1, oCell2, oCell3, oCell4, oCell5 as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		' Font Effect
		oCell1 = oSheet.getCellByPosition(0,0)
		oCell1.String = "LibreOffice"
		with oCell1
			.CharHeight  = 20
			.CharHeightAsian = 20
			.CharStrikeout = com.sun.star.awt.FontStrikeout.SINGLE		' 一重線
		end with
		'
		oCell2 = oSheet.getCellByPosition(0,1)
		oCell2.String = "Apache OpenOffice"
		with oCell2
			.CharHeight  = 20
			.CharHeightAsian = 20
			.CharStrikeout = com.sun.star.awt.FontStrikeout.DOUBLE	' 二重線
		end with
		'
		oCell3 = oSheet.getCellByPosition(0,2)
		oCell3.String = "OpeOnffice.org"
		with oCell3
			.CharHeight  = 20
			.CharHeightAsian = 20
			.CharStrikeout = com.sun.star.awt.FontStrikeout.BOLD	' 太線
		end with
		'
		oCell4 = oSheet.getCellByPosition(0,3)
		oCell4.String = "MS-Office"
		with oCell4
			.CharHeight  = 20
			.CharHeightAsian = 20
			.CharStrikeout = com.sun.star.awt.FontStrikeout.SLASH		' 斜線
		end with
		'
		oCell5 = oSheet.getCellByPosition(0,4)
		oCell5.String = "NeoOffice"
		with oCell5
			.CharHeight  = 20
			.CharHeightAsian = 20
			.CharStrikeout = com.sun.star.awt.FontStrikeout.X		' ×線
		end with
End Sub

CCFe-)[Calc]各種取消し線(2)

Sub CalcUnoFont()
	Dim oDoc As Object, oSheet As Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim Dummy()
	Dim oDispatcher as Object
	Dim oProp(2) as new com.sun.star.beans.PropertyValue
		'
		oDoc = StarDesktop.loadComponentFromURL("private:factory/scalc", "_blank", 0, Dummy())
  		oSheet = oDoc.getSheets().getByName("sheet1")
  		oCell = oSheet.getCellRangeByName("A1")
		oCell.String = "LibreOffficeです"
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			' 下線
			oProp(0).Name = "Strikeout.Kind"
			oProp(0).Value = com.sun.star.awt.FontStrikeout.DOUBLE
		oDispatcher.executeDispatch(oFrame, ".uno:Strikeout", "", 0, oProp())
End Sub
'
'[ Note ]
' com.sun.star.awt.FontStrikeout.SINGLE		: 1
' com.sun.star.awt.FontStrikeout.DOUBLE		: 2
' com.sun.star.awt.FontStrikeout.DONTKNOW	: 3
' com.sun.star.awt.FontStrikeout.BOLD		: 4
' com.sun.star.awt.FontStrikeout.SLASH		: 5
' com.sun.star.awt.FontStrikeout.X			: 6

CCFe-)[Calc]各種OverLine

Sub CalcUnoFont()
	Dim oDoc As Object, oSheet As Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim Dummy()
	Dim oDispatcher as Object
	Dim oProp(2) as new com.sun.star.beans.PropertyValue
		'
		oDoc = StarDesktop.loadComponentFromURL("private:factory/scalc", "_blank", 0, Dummy())
  		oSheet = oDoc.getSheets().getByName("sheet1")
  		oCell = oSheet.getCellRangeByName("A1")
		oCell.String = "LibreOffficeです"
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			' 下線
			oProp(0).Name = "Overline.LineStyle"
			oProp(0).Value = 10
			oProp(1).Name = "Overline.HasColor"
			oProp(1).Value = true
			oProp(2).Name = "Overline.Color"
			oProp(2).Value = &HFF0000				' Red
		oDispatcher.executeDispatch(oFrame, ".uno:Overline", "", 0, oProp())
End Sub
'
' [ Note ]
' 0	: NONE
' 1		: SINGLE
' 2		: DOUBLE
' 3		: DOTTED
' 4		: DONTKNOW
' 5		: DASH
' 6		: LONGDASH
' 7		: DASHDOT
' 8		: DASHDOTDOT
' 9		: SMALLWAVE
' 10	: WAVE
' 11	: DOUBLEWAVE
' 12	: BOLD
' 13	: BOLDDOTTED
' 14	: BOLDDASH
' 15	: BOLDLONGDASH
' 16	: BOLDDASHDOT
' 17	: BOLDDASHDOTDOT
' 18	: BOLDWAVE

CCFe-)[Calc]浮き出し/浮き彫り文字

Sub CalcUnoFont()
	Dim oDoc As Object, oSheet As Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim Dummy()
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		'
		oDoc = StarDesktop.loadComponentFromURL("private:factory/scalc", "_blank", 0, Dummy())
  		oSheet = oDoc.getSheets().getByName("sheet1")
  		oCell = oSheet.getCellRangeByName("A1")
		oCell.String = "LibreOffficeです"
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		' 浮き出し
			oProp(0).Name = "CharacterRelief"
			oProp(0).Value = 1
		oDispatcher.executeDispatch(oFrame, ".uno:CharacterRelief", "", 0, oProp())
		msgbox "浮き出し文字",0,"CharacterRelief"
		 ' 浮き彫り
		 	oProp(0).Name = "CharacterRelief"
			oProp(0).Value = 2
		oDispatcher.executeDispatch(oFrame, ".uno:CharacterRelief", "", 0, oProp())
		msgbox "浮き彫り文字",0,"CharacterRelief"
End Sub

CCFe-)[Calc]中抜き文字

Sub CalcUnoFont()
	Dim oDoc As Object, oSheet As Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim Dummy()
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		'
		oDoc = StarDesktop.loadComponentFromURL("private:factory/scalc", "_blank", 0, Dummy())
  		oSheet = oDoc.getSheets().getByName("sheet1")
  		oCell = oSheet.getCellRangeByName("A1")
		oCell.String = "LibreOffficeです"
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		' Outline Font( 中抜き文字 )
			oProp(0).Name = "OutlineFont"
			oProp(0).Value = true
		oDispatcher.executeDispatch(oFrame, ".uno:OutlineFont", "", 0, oProp())
End Sub

CCFe-)[Calc]



{{ Position / Size }}

CCP-)[Calc]Cell内の位置設定1

Sub Main
	Dim oDoc as object
	Dim oSheet as Object
		oDoc=ThisCmponent
		oSheet=oDoc.Sheets(0)
		oCell_Ran = oSheet.getCellRangeByPosition(1,3,1,200)				'←範囲選択
		oCell_Ran.HoriJustify = com.sun.star.table.CellHoriJustify.RIGHT	'←横 右揃え
		oCell_Ran.HoriJustify = com.sun.star.table.CellHoriJustify.CENTER	'←横 中央揃え
		oCell_Ran.HoriJustify = com.sun.star.table.CellHoriJustify.LEFT		'←横 左揃え
		oCell_Ran.VertJustify = com.sun.star.table.CellVertJustify.TOP		'←縦 上揃え
		oCell_Ran.VertJustify = com.sun.star.table.CellVertJustify.CETER	'←縦 中央揃え
		oCell_Ran.VertJustify = com.sun.star.table.CellVertJustify.BOTTOM	'←縦 下揃え
End Sub

CCP-)[Calc]Cell内の配置設定

sub Main
	Dim oCell as Object
 		oCell=ThisComponent.Sheets(0).getCellByPosition(0,0)
 		oCell.HoriJustify=com.sun.star.table.CellHoriJustify.CENTER			'←横方向をセンター
 		oCell.HoriJustify=com.sun.star.table.CellHoriJustify.LEFT			'←横方向を左揃え
 		oCell.HoriJustify=com.sun.star.table.CellHoriJustify.RIGHT			'←横方向を右揃え
 		oCell.VertJustify=com.sun.star.table.CellVertJustify.CENTER			'←縦方向をセンター
 		oCell.VertJustify=com.sun.star.table.CellVertJustify.TOP			'←縦方向を左揃え
 		oCell.VertJustify=com.sun.star.table.CellVertJustify.BOTTOM			'←縦方向を右揃え
End  Sub

CCP-)[Calc]Cell内の位置設定3


Sub CellPropertiesSrv()
	Dim oDoc as Object, oSheet as Object
	Dim oCell(5) as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
	for i = 0 to 5
		oCell(i) = oSheet.getCellByPosition(0,i)
		oCell(i).Value = i*10
	next i
		oCell(0).HoriJustify = com.sun.star.table.CellHoriJustify.STANDARD
		oCell(1).HoriJustify = com.sun.star.table.CellHoriJustify.LEFT
		oCell(2).HoriJustify = com.sun.star.table.CellHoriJustify.CENTER
		oCell(3).HoriJustify = com.sun.star.table.CellHoriJustify.RIGHT
		oCell(4).HoriJustify = com.sun.star.table.CellHoriJustify.BLOCK
		oCell(5).HoriJustify = com.sun.star.table.CellHoriJustify.REPEAT
	msgbox("Success")
End Sub

CCP-)[Calc]Cell内の位置設定4


Sub CellPropertiesSrv()
	Dim oDoc as Object, oSheet as Object
	Dim oCell(8) as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		for i = 0 to 8
			oCell(i) = oSheet.getCellByPosition(0,i)
			oCell(i).Value = i*10
			if i = 4 then
				oCell(i).String = CStr(oCell(i).Value) & "Test"
			end if
		next i
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "HorizontalJustification"
			oProp(0).Value = com.sun.star.table.CellHoriJustify.STANDARD
		oDispatcher.executeDispatch(oFrame, ".uno:HorizontalJustification", "", 0, oProp())
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A2"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "HorizontalJustification"
			oProp(0).Value = com.sun.star.table.CellHoriJustify.LEFT
		oDispatcher.executeDispatch(oFrame, ".uno:HorizontalJustification", "", 0, oProp())
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A3"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "HorizontalJustification"
			oProp(0).Value = com.sun.star.table.CellHoriJustify.CENTER
		oDispatcher.executeDispatch(oFrame, ".uno:HorizontalJustification", "", 0, oProp())
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A4"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "HorizontalJustification"
			oProp(0).Value = com.sun.star.table.CellHoriJustify.RIGHT
		oDispatcher.executeDispatch(oFrame, ".uno:HorizontalJustification", "", 0, oProp())
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A5"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "HorizontalJustification"
			oProp(0).Value = com.sun.star.table.CellHoriJustify.BLOCK
		oDispatcher.executeDispatch(oFrame, ".uno:HorizontalJustification", "", 0, oProp())
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A6"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "HorizontalJustification"
			oProp(0).Value = com.sun.star.table.CellHoriJustify.REPEAT
		oDispatcher.executeDispatch(oFrame, ".uno:HorizontalJustification", "", 0, oProp())
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A7"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "VerticalJustification"
			oProp(0).Value = com.sun.star.table.CellVertJustify.TOP
		oDispatcher.executeDispatch(oFrame, ".uno:VerticalJustification", "", 0, oProp())
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A8"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "VerticalJustification"
			oProp(0).Value = com.sun.star.table.CellVertJustify.CENTER
		oDispatcher.executeDispatch(oFrame, ".uno:VerticalJustification", "", 0, oProp())
			'
			oProp(0).Name = "ToPoint"
			oProp(0).Value = "A9"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
			oProp(0).Name = "VerticalJustification"
			oProp(0).Value = com.sun.star.table.CellVertJustify.BOTTOM
		oDispatcher.executeDispatch(oFrame, ".uno:VerticalJustification", "", 0, oProp())
		'
		msgbox("Success")
End Sub

CCP-)[Calc]任意のCell位置までの左からの距離

Sub CellPropertiesSrv()
	Dim oSheets
	Dim oCell
		oSheets = ThisComponent.Sheets(1)
		oCell =oSheets.getCellByPosition(1,2)
		oDisp = CStr(oCell.Position.X/100) & "  mm from the Left"
	msgbox(oDisp,0,"com.sun.star.sheet.SheetCell Service")
End Sub

CCP-)[Calc]任意のCell位置までの上からの距離

Sub CellPropertiesService()
	Dim oSheets
	Dim oCell
		oSheets = ThisComponent.Sheets(1)
		oCell =oSheets.getCellByPosition(2,3)	'← B3 cellの値を表示する場合
		oDisp = CStr(oCell.Position.Y/100) & "  mm from the top"
	msgbox(oDisp,0,"com.sun.star.sheet.SheetCell Service")
End Sub

CCP-)[Calc]Cell Size取得


Sub CellSize()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oCellHg as Double, oCellWdh as Double
	Dim oDisp As String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		oCell = oSheet.getCellByposition(1,1)	' B2
		oCellWdh = oCell.Size.Width / 100
		oCellHgt = oCell.Size.Height / 100
		oDisp = "[ Cell Size( About ) ]" & Chr$(10) & oCell.AbsoluteName & Chr$(10) & " Width = " & _
					CStr(oCellWdh) & " mm" & Chr$(10) & " Height = " & CStr(oCellHgt) & " mm"
		msgbox(oDisp,0,"Cell Size")
End Sub

CCP-)[Calc]



{{ 罫線 }}

CCL-)[Calc]選択範囲に罫線を引く(1)


Sub CalcLine()
	Dim oDoc as Object, oSheet as Object, oRange as Object
	Dim aTableBorder as Object, aLine as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oRange = oSheet.getCellRangeByName("B2:E8")
		aTableBorder = CreateUnoStruct("com.sun.star.table.TableBorder")
		aLine = CreateUnoStruct("com.sun.star.table.BorderLine")
		'
		'ラインの内容
			aLine.OuterLineWidth = 100		' in 0.01mm
			aLine.InnerLineWidth = 50		' in 0.01mm
			aLine.LineDistance = 100		' in 0.01mm
			aLine.Color = RGB(255,0,0)
		'
		'表用罫線外枠のライン指定
			aTableBorder.TopLine = aLine
			aTableBorder.BottomLine = aLine
			aTableBorder.LeftLine = aLine
			aTableBorder.RightLine = aLine
		'表用罫線外枠のライン表示のオン
			aTableBorder.IsTopLineValid = True
			aTableBorder.IsBottomLineValid = True
			aTableBorder.IsLeftLineValid = True
			aTableBorder.IsRightLineValid = True
		'表用罫線内側のライン指定
			aTableBorder.HorizontalLine = aLine
			aTableBorder.VerticalLine = aLine
		'表用罫線内側のライン表示のオン
			aTableBorder.IsHorizontalLineValid = true
			aTableBorder.IsVerticalLineValid = true
		'範囲に表用罫線設定反映
			oRange.TableBorder = aTableBorder
			'
		msgbox "Success"
End Sub
'
' [ Note ]
' LibreOffice3.5系は本Codeにて描写できたが、LibreOffice4.1( Windows )では、Error無く実行するが描写はしない。
' LibreOffice4.2 API Documentには記述がある。LibreOffice / Apache OpenOffice

CCL-)[Calc]選択範囲に罫線を引く(2)


Sub CalcLine()
	Dim oDoc As Object
	Dim oCtrl as Object
	Dim oSelRange as Object, oCellRange as Object
	Dim oBorder1 as Object, oBorder2 as Object, oBorder3 as Object, oBorder4 as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oSelRange = oCtrl.getActiveSheet().getCellRangeByName( "B3:D5" )
		oCtrl.select( oSelRange )
		'
  		oCellRange = oDoc.CurrentSelection(0)
  		' Border1 Property
  		oBorder1 = CreateUnoStruct("com.sun.star.table.BorderLine2")
  		oBorder1.Color = RGB(255, 0, 0)
  		oBorder1.LineWidth = 30
  		oBorder1.LineStyle = 2
  		' Border2 Property
  		oBorder2 = CreateUnoStruct("com.sun.star.table.BorderLine2")
  		oBorder2.Color = RGB(0, 0, 255)
  		oBorder2.LineWidth = 10
  		oBorder2.LineStyle = 9
  		' Border3 Property
  		oBorder3 = CreateUnoStruct("com.sun.star.table.BorderLine2")
  		oBorder3.Color = RGB(0, 255, 0)
  		oBorder3.LineWidth = 30
  		oBorder3.LineStyle = 14
  		' Border4 Property
  		oBorder4 = CreateUnoStruct("com.sun.star.table.BorderLine2")
  		oBorder4.Color = RGB(0, 255, 255)
  		oBorder4.LineWidth = 30
  		oBorder4.LineStyle = 10
  		' Set Border
  		oCellRange.BottomBorder = oBorder1
  		oCellRange.TopBorder = oBorder2
  		oCellRange.LeftBorder = oBorder3
  		oCellRange.RightBorder = oBorder4
  		'
  		oSelRange = oCtrl.getActiveSheet().getCellRangeByName( "A1" )
		oCtrl.select( oSelRange )
  	msgbox "Success"
End Sub
' [ Note ]
' Top/Bottom と Left / Rgightでは線の太さやStyleによる。太さがStyle同じ時は ?
' [ LibreOffice ]
' com.sun.star.table.BorderLine2 / com.sun.star.table.BorderLineStyle
' 上記がNetwork Errorの場合は com.sun.star.table.BorderLine2 / com.sun.star.table.BorderLineStyle

CCL-)[Calc]選択範囲に罫線を引く(3)


Sub CalcLine()
	Dim oDoc As Object
	Dim oCtrl as Object
	Dim oSelRange as Object, oCellRange as Object
	Dim oBorder1 as Object, oBorder2 as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oSelRange = oCtrl.getActiveSheet().getCellRangeByName( "B3:D5" )
		oCtrl.select( oSelRange )
		'
  		oCellRange = oDoc.CurrentSelection(0)
  		' Border1 Property
  		oBorder1 = oCellRange.LeftBorder		' oCellRange.BottomBorder / LeftBorder / RightBorder でも同じ
  		oBorder1.Color = RGB(255, 0, 0)
  		oBorder1.InnerLineWidth = 30
  		oBorder1.LineStyle = 1			' 0 : Line / 1 : Dot( 点線 ) / 2 : Dash( 破線 )
  		' Border2 Property
  		oBorder2 = oCellRange.RightBorder
  		oBorder2.Color = RGB(0, 0, 255)
  		oBorder2.InnerLineWidth = 10
  		oBorder2.LineStyle = 2
  		' Set Border
  		oCellRange.BottomBorder = oBorder1
  		oCellRange.TopBorder = oBorder2
  		oCellRange.LeftBorder = oBorder1
  		oCellRange.RightBorder = oBorder2
  		'
  		oSelRange = oCtrl.getActiveSheet().getCellRangeByName( "A1" )
		oCtrl.select( oSelRange )
  	msgbox "Success"
End Sub
'
' [ Note ]
' com.sun.star.table.BorderLine2 とは .LineWidth と .InneLineWidth が異なり、使えるLineStyleも限定される模様。

CCL-)[Calc]外枠に罫線を引く


Sub UnoCalcLine()
	Dim oDoc As Object, oSheet As Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
	Dim oProp1(7) as new com.sun.star.beans.PropertyValue
	Dim oWidthPt1 as Integer, oWidthPt2 as Integer, oWidthPt3 as Integer
	Dim oColor1 as Long, oColor2 as Long, oColor3 as Long
		'
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B3:C5"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oWidthPt1 = 150		' ← 幅値の設定は?
		oWidthPt2 =  80
		oWidthPt3 = 10
		oColor1 = CLng("&HFF0000")			' Red
		oColor2 = CLng("&H00FF00")			' Green
		oColor3 = CLng("&H0000FF")			' Blue
		'
		' 選択範囲の左に線を引く
		oProp1(0).Name = "BorderOuter.LeftBorder"
		oProp1(0).Value = Array(oColor1, 0, oWidthPt1, 0)
		oProp1(1).Name = "BorderOuter.LeftDistance"
		oProp1(1).Value = 10
		' 選択範囲の右に線を引く
		oProp1(2).Name = "BorderOuter.RightBorder"
		oProp1(2).Value = Array(oColor2, 0, oWidthPt2, 0)
		oProp1(3).Name = "BorderOuter.RightDistance"
		oProp1(3).Value = 0
		' 選択範囲の上に線を引く
		oProp1(4).Name = "BorderOuter.TopBorder"
		oProp1(4).Value = Array(oColor3, 0, oWidthPt3, 0)
		oProp1(5).Name = "BorderOuter.TopDistance"
		oProp1(5).Value = 0
		' 選択範囲の下には線を引かない
		Rem oProp1(6).Name = "BorderOuter.RightBorder"
		Rem oProp1(6).Value = Array(0, 0, oWidthPt, 0)
		Rem oProp1(7).Name = "BorderOuter.RightDistance"
		Rem oProp1(7).Value = 0
		oDispatcher.executeDispatch(oFrame, ".uno:BorderOuter", "", 0, oProp1())
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		msgbox "Success"
End Sub
'
' [ Note ]
' Apache OpenOffice / :: com :: sun :: star :: table :: / Struct BorderLine
' Array(Color, InnerLineWidth, OuterLineWidth, LineDistance)
' BorderOuterでは、InnerLineWidth / LineDistanceの設定は不可?

CCL-)[Calc]Cellに影を付ける(1)


Sub UnoCalcLine()
	Dim oDoc As Object, oSheet As Object, oCell as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
	Dim oProp1(3) as new com.sun.star.beans.PropertyValue
		'
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B3:C5"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp1(0).Name = "BorderShadow.Location"
		oProp1(0).Value = com.sun.star.table.ShadowLocation.BOTTOM_LEFT
		oProp1(1).Name = "BorderShadow.Width"
		oProp1(1).Value = 200			' Cellの端からの間隔 : unit 1/100 mm
		oProp1(2).Name = "BorderShadow.IsTransparent"
		oProp1(2).Value = false
		oProp1(3).Name = "BorderShadow.Color"
		oProp1(3).Value = RGB( 0, 255, 0 )
		oDispatcher.executeDispatch(oFrame, ".uno:BorderShadow", "", 0, oProp1())
		'
		msgbox "Success"
End Sub
'
' [ Note ]
' enum com.sun.star.table.ShadowLocation
' LibreOffice / Apache openOffice

CCL-)[Calc]Cellに影を付ける(2)


Sub CellShadow()
	Dim oDoc as Object, oSheet as Object, oCell As Object
	Dim oShadow As New com.sun.star.table.ShadowFormat
		oDoc = ThisComponent
		oSheet = oDoc.getSheets.getByIndex(0)
  		oCell = oSheet.getCellRangeByName( "B2:C4" )
  		' CellのBackColor
  		' oCell.CellBackColor = RGB( 255, 128, 128 )
  		'
  		oShadow.Color = RGB( 0, 0, 255 )  	' Shadow color
  		oShadow.Location = com.sun.star.table.ShadowLocation.TOP_RIGHT
  		oShadow.IsTransparent = False
  		oShadow.ShadowWidth = 250  	' 1/100 mm
  		oCell.ShadowFormat = oShadow
  		'
  		msgbox "Success"
End Sub
'
' [ Note ]
' com.sun.star.table.ShadowFormat
' LibreOffice / Apache OpenOffice

CCL-)[Calc]












{{ Protection }}

CCPct-)[Calc]保護する& 数式を表示しない(1)


Sub CellProtect()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
	Dim oProp2(1) as  new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		' 直接設定した書式の解除
		oDispatcher.executeDispatch(oFrame, ".uno:ResetAttributes", "", 0, Array())
		' Cellの保護Tab/保護する
		oProp2(0).Name = "Protection.Locked"
		oProp2(0).Value = false							' true : Check ON / false : Check Off
		' 数式を表示しない
		oProp2(1).Name = "Protection.FormulasHidden"
		oProp2(1).Value = true
		oDispatcher.executeDispatch(oFrame, ".uno:Protection", "", 0, oProp2())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCPct-)[Calc]保護する& 数式を表示しない(2)


Sub CellProtect()
	Dim oDoc as Object, oSheet as Object, oRange as Object
	Dim oUnoCellPrct as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		oRange = oSheet.getCellRangeByName("A1:C3")
		'
		' Defalt setting for protection of cell
		oRange.setPropertyToDefault("CellProtection")
		'
		oUnoCellPrct = createUnoStruct("com.sun.star.util.CellProtection")
		With oUnoCellPrct
   			.IsFormulaHidden = true
   			.IsLocked = true
		End With
		oRange.setPropertyValue( "CellProtection", oUnoCellPrct )
		msgbox "Success"
End Sub


CCPct-)[Calc]すべて表示しない(1)


Sub CellProtect()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
	Dim oProp2(0) as  new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		' 直接設定した書式の解除
		oDispatcher.executeDispatch(oFrame, ".uno:ResetAttributes", "", 0, Array())
		' すべて表示しない
		oProp2(0).Name = "Protection.Hidden"
		oProp2(0).Value = true							' true : Check ON / false : Check Off
		oDispatcher.executeDispatch(oFrame, ".uno:Protection", "", 0, oProp2())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCPct-)[Calc]すべて表示しない(2)

Sub CellProtect()
	Dim oDoc as Object, oSheet as Object, oRange as Object
	Dim oUnoCellPrct as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		oRange = oSheet.getCellRangeByName("A1:C3")
		'
		' Defalt setting for protection of cell
		oRange.setPropertyToDefault("CellProtection")
		'
		oUnoCellPrct = createUnoStruct("com.sun.star.util.CellProtection")
		With oUnoCellPrct
   			.IsHidden = true
		End With
		oRange.setPropertyValue( "CellProtection", oUnoCellPrct )
		msgbox "Success"
End Sub

CCPct-)[Calc]印刷しない(1)


Sub CellProtect()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
	Dim oProp2(0) as  new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		' 直接設定した書式の解除
		oDispatcher.executeDispatch(oFrame, ".uno:ResetAttributes", "", 0, Array())
		' 印刷しない
		oProp2(0).Name = "Protection.HiddenInPrintout"
		oProp2(0).Value = true
		oDispatcher.executeDispatch(oFrame, ".uno:Protection", "", 0, oProp2())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCPct-)[Calc]印刷しない(2)

Sub CellProtect()
	Dim oDoc as Object, oSheet as Object, oRange as Object
	Dim oUnoCellPrct as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		oRange = oSheet.getCellRangeByName("A1:C3")
		'
		' Defalt setting for protection of cell
		oRange.setPropertyToDefault("CellProtection")
		'
		oUnoCellPrct = createUnoStruct("com.sun.star.util.CellProtection")
		With oUnoCellPrct
   			.IsPrintHidden = true
		End With
		oRange.setPropertyValue( "CellProtection", oUnoCellPrct )
		msgbox "Success"
End Sub

CCPct-)[Calc]Cellの保護をDefaultに設定

Sub CellProtect()
	Dim oDoc as Object, oSheet as Object, oRange as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		oRange = oSheet.getCellRangeByName("A1")
		'
		oRange.setPropertyToDefault("CellProtection")
		msgbox "Success"
End Sub








{{ Color }}

CCCo-)[Calc]文字Color


Sub CalcCharColor()
	Dim oDoc as Object, oSheet as Object
	Dim oCell(1) as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		for i = 0 to 1
			oCell(i) = oSheet.getCellByPosition(0,i)
			select case i
				case 0
					with oCell(i)
						.String = "LibreOffice"
						.charColor = RGB(0,0,255)
						.IsTextWrapped = false
					end with
				case 1
					with oCell(i)
						.String = "Apache OpenOffice"
						.charColor = RGB(0,255,0)
						.IsTextWrapped = true
					end with
			end select
		next i
		msgbox "Success",0,"CharColor"
End Sub

CCCo-)[Calc]文字列の金額部分(右部分)のみを赤色にする


Sub CalcCharColor()
	Dim oDoc as Object, oSheet as Object
	Dim oCell as Object
	Dim oTextCursor as Object
		oDoc=ThisComponent
		oSheet=oDoc.getSheets().getByName("sheet1")
		oCell=oSheet.getCellByPosition(0,0)
		oCell.String="1,000円(2009/8/16)"
		oTextCursor = oCell.createTextCursor()
		oCNum= InStr(1,oCell.String,"円")		'「円」までの文字数を調べる。
		With oTextCursor
    		.gotoStart( False )
    		.goRight( oCNum, True )
    		.setPropertyValue( "CharColor", RGB(255,0,0) )
    		.gotoEnd( False )
		End With
		msgbox "Success"
End Sub

{{ autoFormat }}

CCAF-)[Calc]autoFormat


Sub oCalcAutoFormat
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellrange as Object
	Dim oAutoFormat as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCellRange = oSheet.getCellRangeByPosition(0, 0, 5, 5)
		oCellRange.autoFormat("3D")
		'
		msgbox "Success"
End Sub
'
' [ Format Name ]
' FormatNameは以下の様な値があるが、3D以外は設定されない。
' 3D
' Black 1
' Black 2
' Blue
' Brown
' Currency
' Currency 3D
' Currency Lavender
' Currency Turquoise
' Gray
' Green
' 参考uRL : http://wiki.services.openoffice.org/wiki/Documentation/OOo3_User_Guides/Calc_Guide/Autoformat_and_themes

CCAF-)[Calc]












{{ Annotation( Comment ) }}

CCCmt-)[Calc]CellのComment取得


Sub CalcAnnotation()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
	Dim oCmt as Object
	Dim oCmtStr as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		oCmt = oCell.getAnnotation()
		oCmtStr = oCmt.getString
		msgbox(oCmtStr, 0, "CellのComment取得")
End Sub

CCCmt-)[Calc]CellへのComment挿入


Sub CalcAnnotation()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
	Dim oCmt as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		' Annotation Object 作成
		oCmt = oCell.getAnnotation()
		' 新規Commentの挿入
		oSheet.getAnnotations().insertNew(oCell.getCellAddress(), "Commentの挿入")
		' Commentの表示
		oCmt.setIsVisible( True )
		'
		msgbox "Success"
End Sub

CCCmt-)[Calc]CellのCommentを削除(1)

Sub CalcAnnotation()
	Dim oDoc as Object
	Dim document   as object
	Dim dispatcher as object
	Dim oArg(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		document   = oDoc.CurrentController.Frame
		dispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		' B2 Cell へ移動
		oArg(0).Name = "ToPoint"
		oArg(0).Value = "$B$2"
		dispatcher.executeDispatch(document, ".uno:GoToCell", "", 0, oArg())
		'
		' Comment 削除
		dispatcher.executeDispatch(document, ".uno:DeleteNote", "", 0, Array())
		msgbox "Success"
End Sub

CCCmt-)[Calc]CellのCommentを削除(2)

Sub CalcAnnotation()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object, oCellRange as Object
	Dim oCmt as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		' Annotation Object 作成
		oCmt = oCell.getAnnotation()
		' 新規Commentの挿入
		oSheet.getAnnotations().insertNew(oCell.getCellAddress(), "Commentの挿入")
		' Commentの表示
		oCmt.setIsVisible( true )
		msgbox "Comment表示", 0, "Comment"
		'
		' Commentを非表示にしないと表示が消えない
		oCmt.setIsVisible( false )
		oCellRange = oSheet.getCellRangeByName("A1")
		oCellRange.clearContents(com.sun.star.sheet.CellFlags.ANNOTATION)
		msgbox "Commentの削除", 0, "Comment"
End Sub

CCCmt-)[Calc]Comment設定数取得


Sub CalcAnnotation()
	Dim oDoc as Object, oSheet as Object
	Dim oCell(2) as Object
	Dim oShtName as String
	Dim oBfrCnt as Long, oAftCnt as Long
	Dim oCmtStr as String
	Dim oCmt as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oShtName = "sheet1"
		oSheet = oDoc.getSheets().getByName(oShtName)
		' Before
		oBfrCnt = oSheet.annotations.count
		oDisp = oShtName & "における" & Chr$(10) & _
					"Annotation数 = " & oBfrCnt & "( Before )"
		'
		for i = 0 to 2
			oCell(i) = oSheet.getCellByPosition(0, 3 + 3*i )
			oCmtStr = "Commnet" & i
			oSheet.getAnnotations().insertNew(oCell(i).getCellAddress(), oCmtStr)
			oCmt = oCell(i).getAnnotation()
			oCmt.setIsVisible( True )
		next i
		' After
		oAftCnt = oSheet.annotations.count
		oDisp = oDisp & Chr$(10) & "Annotation数 = " & oAftCnt & "( After )"
		msgbox oDisp,0,"Annotation"
End Sub

CCCmt-)[Calc]Fill Collor設定


Sub CalcAnnotation()
	Dim oDoc as Object, oSheet as Object
	Dim oCell(2) as Object
	Dim oShtName as String
	Dim oCmtStr as String
	Dim oCmt as Object
	Dim oAntShape as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oShtName = "sheet1"
		oSheet = oDoc.getSheets().getByName(oShtName)
		'
		for i = 0 to 2
			oCell(i) = oSheet.getCellByPosition(0, 3 + 3*i )
			oCmtStr = "Commnet" & i
			oSheet.getAnnotations().insertNew(oCell(i).getCellAddress(), oCmtStr)
			oCmt = oCell(i).getAnnotation()
			oCmt.setIsVisible( True )
			' Properties
			oAntShape = oCmt.annotationShape
			select case i
				case 0
					oAntShape.fillColor = RGB(255,255,0)
				case 1
					oAntShape.fillColor = RGB(0,255,255)
				case 2
					oAntShape.fillColor = RGB(255,0,255)
			end select
		next i
		'
		oDisp = "Success"
		msgbox oDisp,0,"Annotation"
End Sub

CCCmt-)[Calc]文字Color設定


Sub CalcAnnotation()
	Dim oDoc as Object, oSheet as Object
	Dim oCell(2) as Object
	Dim oShtName as String
	Dim oCmtStr as String
	Dim oCmt as Object
	Dim oAntShape as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oShtName = "sheet1"
		oSheet = oDoc.getSheets().getByName(oShtName)
		'
		for i = 0 to 2
			oCell(i) = oSheet.getCellByPosition(0, 3 + 3*i )
			oCmtStr = "Commnet" & i
			oSheet.getAnnotations().insertNew(oCell(i).getCellAddress(), oCmtStr)
			oCmt = oCell(i).getAnnotation()
			oCmt.setIsVisible( True )
			' Properties
			oAntShape = oCmt.annotationShape
			select case i
				case 0
					oAntShape.CharColor = RGB(255,123,0)
				case 1
					oAntShape.CharColor = RGB(0,255,123)
				case 2
					oAntShape.CharColor = RGB(123,0,255)
			end select
		next i
		'
		oDisp = "Success"
		msgbox oDisp,0,"Annotation"
End Sub

CCCmt-)[Calc]文字Font( FontName / Posture / Hieght )設定


Sub CalcAnnotation()
	Dim oDoc as Object, oSheet as Object
	Dim oCell(2) as Object
	Dim oShtName as String
	Dim oCmtStr as String
	Dim oCmt as Object
	Dim oAntShape as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oShtName = "sheet1"
		oSheet = oDoc.getSheets().getByName(oShtName)
		'
		for i = 0 to 2
			oCell(i) = oSheet.getCellByPosition(0, 3 + 4*i )
			oCmtStr = "Commentの設定" & i
			oSheet.getAnnotations().insertNew(oCell(i).getCellAddress(), oCmtStr)
			oCmt = oCell(i).getAnnotation()
			oCmt.setIsVisible( True )
			' Properties
			oAntShape = oCmt.annotationShape
			select case i
				case 0
					with oAntShape
						.CharFontName = "Arial"
						.CharFontNameAsian = "Arial"
						.CharPosture = com.sun.star.awt.FontSlant.ITALIC
						.CharPostureAsian = com.sun.star.awt.FontSlant.OBLIQUE
						.CharHeight=12
						.CharHeightAsian=16
					end with
				case 1
					with oAntShape
						.CharFontName = "MS Gothic"
						.CharFontNameAsian = "MS UI Gothic"
						.CharPosture = com.sun.star.awt.FontSlant.REVERSE_OBLIQUE
						.CharPostureAsian = com.sun.star.awt.FontSlant.REVERSE_ITALIC
						.CharHeight=16
						.CharHeightAsian=10
					end with
				case 2
					with oAntShape
						.CharFontName = "Century"
						.CharFontNameAsian = "MS Gothic"
						.CharPosture = com.sun.star.awt.FontSlant.NONE
						.CharPostureAsian = com.sun.star.awt.FontSlant.ITALIC
						.CharHeight=14
						.CharHeightAsian=14
					end with
			end select
		next i
		'
		oDisp = "Success"
		msgbox oDisp,0,"Annotation"
End Sub

CCCmt-)[Calc]Comment ObjectからCell Object取得


Sub CalcAnnotation()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oCmt as Object, oPntCmt as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		oCell.String = "A1 Cellの値"
		oCmt = oCell.getAnnotation()
		oPntCmt = oCmt.getParent()
		msgbox(oPntCmt.String, 0, "Comment Cellの文字")
End Sub

CCCmt-)[Calc]Commnetの最終更新者と更新日取得


Sub CalcAnnotation()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oCmt as Object
	Dim oDate as String, oAuth as String
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		' Annotation Object 作成
		oCmt = oCell.getAnnotation()
		' 新規Commentの挿入
		oSheet.getAnnotations().insertNew(oCell.getCellAddress(), "Commentの更新")
		' Commnet最終更新者と日付取得
		oAuth = oCmt.getAuthor()
		oDate = oCmt.getDate()
		oDisp = "Commnet更新者 ⇒ " & oAuth & Chr$(10) & "Commnet更新日 ⇒ " & oDate
		msgbox oDisp, 0, "Commnet"
End Sub

CCCmt-)[Calc]Commnet ObjectのAddress取得


Sub CalcAnnotation()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oCmt as Object, oCmtAddr as Object
	Dim oCol as Long, oRow as Long
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(2,5)
		' Annotation Object 作成
		oCmt = oCell.getAnnotation()
		' com:.sun.star.table.CellAddress
		CmtAddr = oCmt.getPosition()
		oCol = CmtAddr.Column
		oRow = CmtAddr.Row
		'
		oDisp = "Address of Commnet Object" & Chr$(10) & " ⇒ (" & oCol & ", " & oRow & ")"
		msgbox oDisp, 0, "Commnet"
End Sub

CCCmt-)[Calc]





[ 内容の削除 ]

CCC-)[Calc]選択範囲のClaer(1)

Sub CalcContentsClear()
	Dim Flags as Long
	Dim oDoc as Object
	Dim oSheet as Object
		oDoc=ThisComponent
		oSheet=oDoc.sheets(0)
		oCellRange=oSheet.getCellRangeByPosition(0,0,3,3) '←A1~D4の範囲
		Flags=com.sun.star.sheet.CellFlags.STRING + com.sun.star.sheet.CellFlags.VALUE + com.sun.star.sheet.CellFlags.FORMULA
		oCellRange.clearContents(Flags)
End Sub
'
' [ Note ]
' VALUE			: selects constant numeric values that are not formatted as dates or times.
' DATETIME		: selects constant numeric values that have a date or time number format.
' STRING		: selects constant strings.
' ANNOTATION	: selects cell annotations.
' FORMULA		: selects formulas.
' HARDATTR		: selects all explicit formatting, but not the formatting which is applied implicitly through style sheets.
' STYLES		: selects cell styles.
' OBJECTS		: selects drawing objects.
' EDITATTR		: selects formatting within parts of the cell contents.
' FORMATTED		: selects cells with formatting within the cells or cells with more than one paragraph within the cells.

CCC-)[Calc]選択範囲のClaer(2)

Sub CalcContentsClear()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc=ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "A1:B6"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
			oProp(0).Name = "Flags"
			oProp(0).Value = "SNDFT"
		oDispatcher.executeDispatch(oFrame, ".uno:Delete", "", 0, oProp())
		msgbox "Success"
End Sub
'
' [ Flag Value ]
' S    : String ( テキスト )
' V    : Value ( 値 )
' D    : Date ( 日付 )
' F    : Formula ( 式 )
' N    : Note ( コメント )		' ← Comentを表示のままでは、表示が消えない( ver4.0.1.2 )
' T    : Format ( 書式 )
' 空白 : Object ( オブジェクト )
' A    : 全て

CCC-)[Calc]指定範囲の内容を全てClear

Sub subClearWrksheet(i as integer,sRange as string)
    Dim oRange as object
    	oRange = ThisComponent.getSheets().getByIndex(i).getCellRangeByName(sRange)
    	oRange.clearContents(511)
End Sub

CCC-)[Calc]










[ Selection ]

CCSel-)[Calc]CellのSelection(1)


Sub CellSelection()
	Dim oDoc as Object, oCtrl as Object
	Dim oSelRange as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oSelRange = oCtrl.getActiveSheet().getCellRangeByName( "A1" )
		oCtrl.select( oSelRange )
		'
	msgbox "Success"
End Sub
'
' [ Note ]
' .select後、Curosrを別Cellに移動させても、A1がselectされたままになるので、selectが不要になれば選択解除を行うこと。

CCSel-)[Calc]CellのSelection(2)


Sub CellSelection()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCSel-)[Calc]ColumnのSelection(1)


Sub ColSelection()
	Dim oDoc as Object, oCtrl as Object
	Dim oSheet as Object
	Dim oSelRange as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oSheet = oDoc.getSheets().getByName("sheet1")
		oSelRange = oSheet.getColumns().getByIndex(1)		' B Column
		oCtrl.select( oSelRange )
		'
	msgbox "Success"
End Sub
'
' [ Note ]
' .select後、Curosrを別Cellに移動させても、B列がselectされたままになるので、selectが不要になれば選択解除を行うこと。

CCSel-)[Calc]ColumnのSelection(2)


Sub ColSelection()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B:B"			' B Column
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCSel-)[Calc]ColumnのSelection(3)


Sub ColSelection()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B2"			' B1 Cell
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		oDispatcher.executeDispatch(oFrame, ".uno:SelectColumn", "", 0, Array())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCSel-)[Calc]RowのSelection(1)


Sub RowSelection()
	Dim oDoc as Object, oCtrl as Object
	Dim oSheet as Object
	Dim oSelRange as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oSheet = oDoc.getSheets().getByName("sheet1")
		oSelRange = oSheet.getRows().getByIndex(1)		' No.2 Row
		oCtrl.select( oSelRange )
		'
	msgbox "Success"
End Sub
'
' [ Note ]
' .select後、Curosrを別Cellに移動させても、2行目がselectされたままになるので、selectが不要になれば選択解除を行うこと。

CCSel-)[Calc]RowのSelection(2)


Sub RowSelection()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "3:3"			' No.3 Row
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCSel-)[Calc]RowのSelection(3)


Sub RowSelection()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1"			' A1 Cell
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		oDispatcher.executeDispatch(oFrame, ".uno:SelectRow", "", 0, Array())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub

CCSel-)[Calc]Selection解除(1)


Sub DeSelection()
	Dim oDoc as Object, oCtrl as Object
	Dim oUtilUrl as Object
	Dim oUrlTrans as Object
	Dim oDeSel as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oUtilUrl = CreateUnoStruct("com.sun.star.util.URL")
  		oUtilUrl.Complete = ".uno:Deselect"
  		oUrlTrans = CreateUnoService("com.sun.star.util.URLTransformer")
    	oUrlTrans.parseStrict(oUtilUrl)
  		oDeSel = oCtrl.queryDispatch(oUtilUrl, "_self", 0)
  		oDeSel.dispatch(oUtilUrl, Array()
	msgbox "Success"
End Sub

CCSel-)[Calc]Selection解除(2)


Sub DeSelection()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oDispatcher.executeDispatch(oFrame, ".uno:Deselect", "", 0, oProp())
		'
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub
'
' [ Note ]
' 本Codeを slot 値を用いて記すと Selection解除(1) になる

CCSel-)[Calc]選択Cellの選択状態を調べる


Sub oCalcIsAnythingSelected()
	Dim oDoc as Object
	Dim oSelection as object
	Dim oImpName as String, oString as String
	Dim oCount as Integer
	Dim oDisp as String
		oDoc = ThisComponent
		oSelection = oDoc.getCurrentSelection()
		'
		oDisp = "[ Current Select in Calc ]" & Chr$(10)
		If oSelection.supportsService("com.sun.star.sheet.SheetCell") then
			oImpName = oSelection.getImplementationName()
			oString = oSelection.getString()
			oDisp = oDisp & "One Cell Selected : " & oImpName & Chr$(10) & _
							"Strimg : " & oString & Chr$(10)
		Else
			If oSelection.supportsService("com.sun.star.sheet.SheetCellRange") then
				oImpName = oSelection.getImplementationName()
				oDisp = oDisp & "One Cell Range Selected : " & oImpName & Chr$(10)
			Else
				If oSelection.supportsService("com.sun.star.sheet.SheetCellRanges") then			' SheetCellRanges : 複数
					oImpName = oSelection.getImplementationName()
					oCount = oSelection.getCount()
					oDisp = oDisp & "Multiple Cell Range Selected : " & oImpName & Chr$(10) & _
								"Count : " & oCount & Chr$(10)
				Else
					oImpName = oSelection.getImplementationName()
					oDisp = oDisp & "Something else Selected : " & oImpName & Chr$(10)
				End If
			End If
		End If
		msgbox(oDisp,0,"Is Calc anything select? ")
End Sub

CCSel-)[Calc]選択Cell全てに文字列を入力


Sub oSetSlectedCell()
	Dim oStr
	Dim oSelections
	DIm oCell
	Dim oRanges
		oStr = "Current Controll"
		oSelections = ThisComponent.getCurrentSelection()
		If IsNull(oSelections) Then Exit Sub
	'
		If oSelections.supportsService( "com.sun.star.sheet.SheetCell") then
			oCell = oSelections
			oCell.setString(oStr)
		ElseIf oSelections.supportsService( "com.sun.star.sheet.SheetCellRange") then
			SetRangeText(oSelections, oStr)
		ElseIf oSelections.supportsService( "com.sun.star.sheet.SheetCellRanges") then
			oRanges = oSelections
			for i = 0 to oRange.getCount()-1
				setRangeText(oRanges.getByIndex(i), oStr)
			next i
		Else
			oImpName = oSelections.getImplementationName()
			print oImpName
		End If
End Sub

'[ Function1 ]
Function setRangeText(oRange, s as String)
	Dim nCol as Long
	Dim nROw as Long
	Dim oCols
	Dim oRows
		oCols = oRange.Columns
		oRows = oRange.Rows
		for nCol = 0 to oCols.getCount()-1
			for nRow = 0 to oRows.getCount()-1
				oRange.getCellByPosition(nCol,nRow).setString(s)
			next nRow
		next nCol
End Function

CCSel-)[Calc]











[ Address ]

CCA-)[Calc]Current CellのAddress取得(1)


Sub AddressOfCell()
	Dim oDoc as Object
	Dim oSel as Object
	Dim oActCol as Long, oActRow as Long
	Dim oShtNo as Integer
		oDoc = ThisComponent
		oSel = oDoc.CurrentController.getSelection()
		oActCol = oSel.getRangeAddress().StartColumn
		oActRow = oSel.getRangeAddress().StartRow
		oShtNo = oSel.getRangeAddress().Sheet
		'
		oDisp = "[ Current Cell ]" & Chr$(10) & "Sheet No. =" & oShtNo & Chr$(10) & "Address = ( " & oActCol & " , " & oActRow & " )"
		msgbox(oDisp,0,"Address of Cell")
End Sub

CCA-)[Calc]Current CellのAddress取得(2)


Sub AddressOfCell()
	Dim oDoc as Object
	Dim oSel as Object
	Dim oCellAddr as Object
	Dim oActCol as Long, oActRow as Long
	Dim oShtNo as Integer
		oDoc = ThisComponent
		oSel = oDoc.CurrentController.getSelection()
		oCellAddr = oSel.getCellAddress()
		oActCol = oCellAddr.Column
		oActRow = oCellAddr.Row
		oShtNo = oCellAddr.Sheet
		'
		oDisp = "[ Current Cell ]" & Chr$(10) & "Sheet No. = " & oShtNo & CHr$(10) & "Address = ( " & oActCol & " , " & oActRow & " )"
		msgbox(oDisp,0,"Address of Cell")
End Sub
'
' [ Note ]
' Current selection が Areaの場合、Error になる。

CCA-)[Calc]名前で指定したCellのAddress取得


Sub AddressOfCell()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellRange as Object
	Dim oCol as Long, oRow as Long
	Dim oShtNo as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCellRange = oSheet.getCellRangeByName("B3_Sheet1")		' OOo3.0 では getCellByName() method があったが 3.4 以降は使用不可
		'
		' oCellRange がAreaの場合は不可 / getCellRangeAddress 使用
		oCol = oCellRange.getCellAddress.Column
		oRow = oCellRange.getCellAddress.Row
		oShtNo = oCellRange.getCellAddress.Sheet
		'
		oDisp = "[ Address of Cell ]" & Chr$(10) & "Sheet No = " & oShtNo & Chr$(10) & _
					"Address = ( " & oCol &  " , " & oRow & " )"
		msgbox(oDisp,0,"Address of Cell")
End Sub

CCA-)[Calc]Current Cellの絶対Address取得(1)


Sub oRetrieveTheActiveCell
	Dim oDoc as Object
	Dim oldSelection as Object
	Dim oRange as Object
	Dim oActiveCell as Object
	Dim oConv as Object
		oDoc = ThisComponent
		oldSelection = oDoc.CurrentSelection
		oRange = oDoc.createInstance("com.sun.star.sheet.SheetCellRanges")
		oDoc.CurrentController.Select(oRange)
		' Get the active cell
			oActiveCell = oDoc.CurrentSelection
			oConv = oDoc.createInstance("com.sun.star.table.CellAddressConversion")
			oConv.Address = oActiveCell.getCellAddress
			oUI  = oConv.UserInterfaceRepresentation
			oPS = oConv.PersistentRepresentation
			oDisp = "[  UserInterfaceRepresentation  ]" & CHr$(10) & Chr$(9) & oUI & Chr$(10) & Chr$(10)
			oDisp = oDisp & "[  PersistentRepresentation  ]" & CHr$(10) & Chr$(9) & oPS & Chr$(10)
		msgbox(oDisp, 0, "Representation")
		oDoc.CurrentController.Select(oldSelection)
End Sub

CCA-)[Calc]Current Cellの絶対Address取得(2)


Sub ActiveCellName()
	Dim oDoc as Object
	Dim oActiveCell as Object
	Dim oAbsName as String
		oDoc = ThisComponent
		oActiveCell = oDoc.CurrentSelection
		oAbsName = oActiveCell.AbsoluteName
		oDisp = "[ AbsoluteName  ]" & Chr$(10) & oAbsName
		msgbox(oDisp, 0, "Current Cell")
End Sub

CCA-)[Calc]選択範囲の最初と最後の行と列番号を取得

Sub Main
	Dim oCell As Object
		oCell = ThisComponent.CurrentController.getSelection()
		With oCell.RangeAddress
			MsgBox "Sheet: " & .Sheet & Chr(10) & _
				"StartColumn: " & .StartColumn & Chr(10) & _
				"StartRow:" & .StartRow & Chr(10) & _
				"EndColumn: " & .EndColumn & Chr(10) & _
				"EndRow: " & .EndRow
		End With
End Sub

CCA-)[Calc]最終行の取得


Sub CellAddress()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCursor as Object
	Dim oCntrl as Object
	Dim oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(1) as new com.sun.star.beans.PropertyValue
	Dim oShtEndRow as Long
	Dim oEndRow as Long
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCursor = oSheet.createCursor()
		oShtEndRow  = oCursor.getRangeAddress().EndRow
		'
		oCntrl = oDoc.getCurrentController()
		oFrame = oCntrl.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "$A$" & oShtEndRow
		oProp(1).Name = "Sel"
		oProp(1).Value = false
		oDispatcher.executeDispatch( oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "By"
		oProp(0).Value = 1
		oProp(1).Name = "Sel"
		oProp(1).Value = false
		oDispatcher.executeDispatch( oFrame, ".uno:GoUpToStartOfData", "", 0, oProp())
		oEndRow = oCntrl.getSelection().getRangeAddress().EndRow
		'
		oDisp = "[ Address of End Row ]" & Chr$(10) & "End Row  = " & oEndRow
		' Display
		msgbox(oDisp,0,"最終行取得")
End Sub

CCA-)[Calc]列番号を数字から英字へ変換

Sub oColumnNumberToString
	Dim oColumnString(5)
	Dim nColumn(5) As Long
		nColumn(0) = 0
		nColumn(1) = 5
		nColumn(2) = 10
		nColumn(3) = 15
		nColumn(4) = 20
		nColumn(5) = 25
		for i= 0 to UBound(nColumn)
			oColumnString(i) = Chr$(65+ (nColumn(i) MOD 26))
			oDisp = oDisp & nColumn(i) & " => " & oColumnString(i) & Chr$(10)
		next i
		msgbox(oDisp ,0, "Column No => String")
End Sub

CCA-)[Calc]列番号を数字から英字へ変換(2)

Function ColumnName ( ByVal ColumnNo As Long ) As String
    If ColumnNo / 26 > 1 then
        ColumnName = Chr ( 65 + int( ColumnNo / 26 ) - 1 ) & Chr( 65 + ColumnNo MOD 26 )
    Else
        ColumnName = Chr ( 65 + ColumnNo MOD 26 )
    End If
End Function

CCA-)[Calc]Cell Addressの変換/(0,0)→A1


Sub CellAddrConv()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oConv as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oConv = oDoc.createInstance("com.sun.star.table.CellAddressConversion")
		oCell = oSheet.getCellByPosition(0,0)			' Sheet1 / Cell A1
		oConv.Address = oCell.getCellAddress()
		oDisp = "Sheet1.(0,0) → " & oConv.PersistentRepresentation
	msgbox(oDisp,0,"Conversion")
End Sub

CCA-)[Calc]Data Areaの最初と最後のCell Address取得


Sub StartEndRowNo()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oFirstCell as Object
	Dim oCursor as Object
	Dim oFristRow as Long, oFirstCol as Long
	Dim oStartRow as Long, oEndRow as Long
	Dim oStartCol as Long, oEndCol as Long
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		oFirstCol = 2
		oFristRow = 0
		oDisp = "[ Case1 ]" & Chr$(10) & "First Cell = ( " & oFirstCol & " , " & oFristRow & " )[ C1 ]" & Chr$(10)
		'
		oFirstCell = oSheet.getCellByPosition(oFirstCol, oFristRow)					' C1 Cell
		if oFirstCell.getType() = com.sun.star.table.CellContentType.EMPTY then
			oDisp = oDisp & "First Rowが空白です。"
		else
			oCursor = oSheet.createCursorByRange(oFirstCell)
			oCursor.gotoStart()		' Dataの始まりへ
			oStartCol = oCursor.getRangeAddress.StartColumn			' 1つしかCellを選択していないので、 .EndColumn でも同じ
			oStartRow = oCursor.getRangeAddress.EndRow				' 1つしかCellを選択していないので、 .StartRow でも同じ
  			oCursor.gotoEnd()		' Dataの最後へ
  			oEndCol = oCursor.getRangeAddress.StartColumn			' 1つしかCellを選択していないので、 .StartColumn でも同じ
  			oEndRow = oCursor.getRangeAddress.EndRow				' 1つしかCellを選択していないので、 .EndColumn でも同じ
  			oDisp = oDisp & "Column  : " & oStartCol & " ~ " & oEndCol & Chr$(10) & _
  									"Row       : " & oStartRow & " ~ " & oEndRow
		end if
		'
		oFirstCol = 2
		oFristRow = 4
		oDisp = oDisp & Chr$(10) & Chr$(10) & "[ Case2 ]" & Chr$(10) & "First Cell = ( " & oFirstCol & " , " & oFristRow & " )[ C5 ]" & Chr$(10)
		'
		oFirstCell = oSheet.getCellByPosition(oFirstCol, oFristRow)					' C5 Cell
		if oFirstCell.getType() = com.sun.star.table.CellContentType.EMPTY then
			oDisp = oDisp & "First Rowが空白です。"
		else
			oCursor = oSheet.createCursorByRange(oFirstCell)
			oCursor.gotoStart()		' Dataの始まりへ
			oStartCol = oCursor.getRangeAddress.StartColumn			' 1つしかCellを選択していないので、 .EndColumn でも同じ
			oStartRow = oCursor.getRangeAddress.EndRow				' 1つしかCellを選択していないので、 .StartRow でも同じ
  			oCursor.gotoEnd()		' Dataの最後へ
  			oEndCol = oCursor.getRangeAddress.StartColumn			' 1つしかCellを選択していないので、 .StartColumn でも同じ
  			oEndRow = oCursor.getRangeAddress.EndRow				' 1つしかCellを選択していないので、 .EndColumn でも同じ
  			oDisp = oDisp & "Column  : " & oStartCol & " ~ " & oEndCol & Chr$(10) & _
  									"Row       : " & oStartRow & " ~ " & oEndRow
		end if
		'
		oFirstCol = 2
		oFristRow = 8
		oDisp = oDisp & Chr$(10) & Chr$(10) & "[ Case3 ]" & Chr$(10) & "First Cell = ( " & oFirstCol & " , " & oFristRow & " )[ C9 ]" & Chr$(10)
		'
		oFirstCell = oSheet.getCellByPosition(oFirstCol, oFristRow)					' C5 Cell
		if oFirstCell.getType() = com.sun.star.table.CellContentType.EMPTY then
			oDisp = oDisp & "First Rowが空白です。"
		else
			oCursor = oSheet.createCursorByRange(oFirstCell)
			oCursor.gotoStart()		' Dataの始まりへ
			oStartCol = oCursor.getRangeAddress.StartColumn			' 1つしかCellを選択していないので、 .EndColumn でも同じ
			oStartRow = oCursor.getRangeAddress.EndRow				' 1つしかCellを選択していないので、 .StartRow でも同じ
  			oCursor.gotoEnd()		' Dataの最後へ
  			oEndCol = oCursor.getRangeAddress.StartColumn			' 1つしかCellを選択していないので、 .StartColumn でも同じ
  			oEndRow = oCursor.getRangeAddress.EndRow				' 1つしかCellを選択していないので、 .EndColumn でも同じ
  			oDisp = oDisp & "Column  : " & oStartCol & " ~ " & oEndCol & Chr$(10) & _
  									"Row       : " & oStartRow & " ~ " & oEndRow
		end if
		'
  		msgbox(oDisp,0,"最初と最後のAddress取得")
End Sub
'
' Refer to " Sheet操作/ Sheet Cursors / Simple Cursor Movement(1) "

CCA-)[Calc]Sheetの最初と最後のCell Address取得


Sub CellAddress()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCursor as Object
	Dim oShtFirstCol as Long, oShtFirstRow as Long
	Dim oShtEndCol as Long, oShtEndRow as Long
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCursor = oSheet.createCursor()
		'
		oDisp = "[ Cell Address of Sheet ]" & Chr$(10)
		'
		oShtFirstCol = oCursor.getRangeAddress().StartColumn
		oShtFirstRow  = oCursor.getRangeAddress().StartRow
		'
		oShtEndCol = oCursor.getRangeAddress().EndColumn
		oShtEndRow  = oCursor.getRangeAddress().EndRow
		oDisp = oDisp & "First Cell  = ( " & oShtFirstCol & " , " & oShtFirstRow & " )" & Chr$(10) & _
								" End Cell = (  " & oShtEndCol & " , " & oShtEndRow & " )"
		' Display
		msgbox(oDisp,0,"Sheetの最初と最後のCell Address")
End Sub
'
' Refer to " Sheet操作/ Sheet Cursors / Simple Cursor Movement(2) "

CCA-)[Calc]











[ 行・列 ]

CCR-)[Calc]行の挿入(1)

sub Main()
	Dim oDoc as Object
		oDoc=ThisComponent
		oSheet=oDoc.Sheets(0)
		oRows = oSheet.getRows()
		oRows.insertByIndex(16,3) '←17行目から3行挿入
End Sub

CCR-)[Calc]行の挿入(2)

Sub UnoInsertRow()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "3:5"
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		oDispatcher.executeDispatch(oFrame,  ".uno:InsertRows", "", 0, Array())
		'
		msgbox "Success"
End Sub

CCR-)[Calc]列の挿入(1)

sub Main()
	Dim oDoc as Object
		oDoc=ThisComponent
		oSheet=oDoc.Sheets(0)
		oColumns = oSheet.getColumns()
		oColumns.insertByIndex(2,3) '←C列目から3列挿入
End Sub

CCR-)[Calc]列の挿入(2)

Sub UnoInsertCol()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B:D"
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		oDispatcher.executeDispatch(oFrame,  ".uno:InsertColumns", "", 0, Array())
		'
		msgbox "Success"
End Sub

CCR-)[Calc]行の削除(1)

sub Main()
	Dim oDoc as Object, oSheet as Object
	Dim oRows as Object
		oDoc=ThisComponent
		oSheet=oDoc.Sheets(0)
		oRows = oSheet.getRows()
		oRows.removeByIndex(0,10) '←1行目から10列削除
End Sub

CCR-)[Calc]行の削除(2)

Sub UnoDeleteRow()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "2:4"
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		oDispatcher.executeDispatch(oFrame,  ".uno:DeleteRows", "", 0, Array())
		'
		msgbox "Success"
End Sub

CCR-)[Calc]列の削除(1)

Sub Main()
	Dim oDoc as Object, oSheet as Object
	Dim oCols as Object
		oDoc = ThisComponent
		oSheet = oDoc.Sheets(0)
		oCols = oSheet.getColumns()
		oCols.removeByIndex(1, 4) '← B列から4列削除
		msgbox "Success"
End Sub

CCR-)[Calc]列の削除(2)

Sub UnoDeleteCol()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B:D"
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		oDispatcher.executeDispatch(oFrame,  ".uno:DeleteColumns", "", 0, Array())
		'
		msgbox "Success"
End Sub

CCR-)[Calc]Cellの高さ値&幅値を取得

Sub Height_Width_1
	Dim oDoc As Object
	Dim oCell As Object
		oDoc=ThisComponent
		oSheet=oDoc.sheets(0)
		oCell=oSheet.getCellByPosition(0,0)
		Unit_Hieght=oCell.getRows().Height
		Unit_Width=oCell.getColumns().Width
End Sub

CCR-5)[Calc]全ての行高さ&列幅を設定する。

Sub Height_Width_2
  oDoc = ThisComponent
  oSheet = oDoc.getSheets().getByIndex(0)
  oRows = oSheet.Rows
  oColumns = oSheet.Columns
  oRows.Height=1000 '全ての行高さ=1cm
  oColumns.Width=5000 '全ての列幅=5cm
End Sub

CCR-)[Calc]行高さ&列幅を設定(1)

Sub Height_Width_3()
	Dim oDoc as Object, oSheet as Object
		oDoc = ThisComponent
  		oSheet = oDoc.getSheets().getByIndex(0)
  		oSheet.Rows(0).Height=5000 '1行目の高さ=5cm
  		oSheet.Columns(1).Width=1000 'B列目の幅=1cm
End Sub

CCR-)[Calc]列高さ&列幅を設定(2)


Sub UnoOptimalColRow()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "1:1"
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		oProp(0).Name = "RowHeight"
		oProp(0).Value = 2000		' 20mm
		oDispatcher.executeDispatch(oFrame,  ".uno:RowHeight", "", 0, oProp())
		msgbox "Set Row Height",0,"Set row and column"
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B:B"
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		oProp(0).Name = "ColumnWidth"
		oProp(0).Value = 1000
		oDispatcher.executeDispatch(oFrame,  ".uno:ColumnWidth", "", 0, oProp())
		msgbox "Set Colwmn Width",0,"Set row and column"
End Sub

CCR-)[Calc]行高さ&列幅の最適化(1)


Sub ColRowOptimaize()
	Dim oDoc as Object, oSheet as Object
  		oDoc = ThisComponent
  		oSheet = oDoc.getSheets().getByIndex(0)
  		oSheet.getColumns.OptimalWidth = true
  		oSheet.getRows.OptimalHeight = true
	msgbox "Success"
End Sub


CCR-)[Calc]行高さ&列幅の最適化(2)


Sub UnoOptimalColRow()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A:A"
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		' 引数を省略すると最適な列幅Dialogが表示される。
		oProp(0).Name = "aExtraWidth"
		oProp(0).Value = 0
		oDispatcher.executeDispatch(oFrame,  ".uno:SetOptimalColumnWidth", "", 0, oProp())
		msgbox "Optimal Colwmn Width",0,"Optimize"
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "1:2"
		oDispatcher.executeDispatch(oFrame,  ".uno:GoToCell", "", 0, oProp())
		oProp(0).Name = "aExtraHeight"
		oProp(0).Value = 0
		oDispatcher.executeDispatch(oFrame,  ".uno:SetOptimalRowHeight", "", 0, oProp())
		msgbox "Optimal Row Height",0,"Optimize"
End Sub

CCR-)[Calc]選択範囲を新しい場所に行と列を入れ替えて貼り付ける(String型)


Sub CopyRowReplaceColString()
    Dim oDoc as Object, oSheet as Object
    Dim document as object, dispatcher as object
    Dim oCellD as object
    Dim oCopyRange as string
    Dim oRangeDest as string
    Dim args1(0) as new com.sun.star.beans.PropertyValue
    Dim args2(5) as new com.sun.star.beans.PropertyValue
    	oDoc = ThisComponent
    	oSheet = oDoc.getSheets().getByIndex(0)
    	document   = oDoc.CurrentController.Frame
    	dispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
    	'
    	oCopyRange = "A1:C3"	' 列と行の数は一致させる
    	oRangeDest = "D4:F6"	' 列と行の数は一致させる
		'
    	oCellD = oSheet.getCellRangeByName(oCopyRange)
    	oDoc.getCurrentController().select(oCellD)
		'
    	args1(0).Name = "ToPoint"
    	args1(0).Value = oCopyRange
   		'
    	dispatcher.executeDispatch(document, ".uno:GoToCell", "", 0, args1())
    	dispatcher.executeDispatch(document, ".uno:Copy", "", 0, Array())
   		'
    	args2(0).Name = "Flags"
    	args2(0).Value = "SVD"
    	args2(1).Name = "FormulaCommand"
    	args2(1).Value = 0
    	args2(2).Name = "SkipEmptyCells"
    	args2(2).Value = false
    	args2(3).Name = "Transpose"
    	args2(3).Value = true
    	args2(4).Name = "AsLink"
    	args2(4).Value = false
    	args2(5).Name = "MoveMode"
    	args2(5).Value = 4
    	oCellD = oSheet.getCellRangeByName(oRangeDest)
    	oDoc.getCurrentController().select(oCellD)
    	dispatcher.executeDispatch(document, ".uno:InsertContents", "", 0, args2())
    	msgbox "Success"
End Sub

CCR-9)[Calc]選択範囲を新しい場所に行と列を入れ替えて貼り付ける(Object型)

Sub subCopyRowReplaceColObject(oCopyRange as Object,oRangeDest as Object)
    dim dispatcher as object
    dim document   as object
    dim args1(5) as new com.sun.star.beans.PropertyValue
    document   = ThisComponent.CurrentController.Frame
    dispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
    ThisComponent.getCurrentController().select(oCopyRange)
    dispatcher.executeDispatch(document, ".uno:Copy", "", 0, Array())
  args1(0).Name = "Flags"
    args1(0).Value = "SVD"
    args1(1).Name = "FormulaCommand"
    args1(1).Value = 0
    args1(2).Name = "SkipEmptyCells"
    args1(2).Value = false
    args1(3).Name = "Transpose"
    args1(3).Value = true
    args1(4).Name = "AsLink"
    args1(4).Value = false
    args1(5).Name = "MoveMode"
    args1(5).Value = 4
  ThisComponent.getCurrentController().select(oRangeDest)
    dispatcher.executeDispatch(document, ".uno:InsertContents", "", 0, args1())
End Sub

CCR-10)[Calc]2行目&C列を非表示後に再度表示設定にする。

Sub Hide_Visible
  oDoc = ThisComponent
  oSheet = oDoc.getSheets().getByIndex(0)
  oSheet.Rows(1).isVisible=false '2行目の非表示設定
  oSheet.Columns(2).isVisible=false 'C列の非表示設定
  oSheet.Rows(1).isVisible=true '2行目の表示設定
  oSheet.Columns(2).isVisible=true 'C列の表示設定
End Sub

CCR-)[Calc]行高さ調整機能を無効化

Sub oIsAjustHiehgt
	Dim oDoc As Object
		oDoc=ThisComponent
		oCell=oDoc.Sheets(0).getCellByPosition(0,0)
		oCell.String = "LibreOffice マクロマニュアル"
		oCell.IsTextWrapped = true
		' Rowを選択してDouble ClickしてもRow高さを変更されない様にする。
		oDoc.IsAdjustHeightEnabled = false
		msgbox "Success"
End Sub

CCR-)[Calc]列のGroup化(1)

Sub ColRow()
	Dim oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "$B:$C"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "RowOrCol"
		oProp(0).Value = "C"
		oDispatcher.executeDispatch(oFrame, ".uno:Group", "", 0, oProp())
		msgbox("Goup化 OK",0,"Display")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "$B:$C"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "RowOrCol"
		oProp(0).Value = "C"
		oDispatcher.executeDispatch(oFrame, ".uno:Ungroup", "", 0, oProp())
		msgbox("Goup化解除 OK",0,"Display")
End Sub

CCR-)[Calc]列のGroup化(2)

Sub ColRow()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellAdr as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		oCellAdr = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr
			.Sheet = 0
  			.StartColumn = 1		' Column B
  			.EndColumn = 2			' Column C
		end with
		oSheet.group( oCellAdr, com.sun.star.table.TableOrientation.COLUMNS )
		msgbox("Goup化 OK",0,"Display")
		'
		oCellAdr = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr
			.Sheet = 0
  			.StartColumn = 1		' Column B
  			.EndColumn = 2			' Column C
		end with
		oSheet.ungroup( oCellAdr, com.sun.star.table.TableOrientation.COLUMNS )
		msgbox("Goup化解除 OK",0,"Display")
End Sub

CCR-)[Calc]行のGroup化(1)

Sub ColRow()
	Dim oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "$3:$5"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "RowOrCol"
		oProp(0).Value = "R"
		oDispatcher.executeDispatch(oFrame, ".uno:Group", "", 0, oProp())
		msgbox("Goup化 OK",0,"Display")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "$3:$5"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		'
		oProp(0).Name = "RowOrCol"
		oProp(0).Value = "R"
		oDispatcher.executeDispatch(oFrame, ".uno:Ungroup", "", 0, oProp())
		msgbox("Goup化解除 OK",0,"Display")
End Sub

CCR-)[Calc]行のGroup化(2)

Sub ColRow()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellAdr as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		oCellAdr = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr
			.Sheet = 0
  			.StartRow = 2			' Row No.3
  			.EndRow = 4			' Row No.4
		end with
		oSheet.group( oCellAdr, com.sun.star.table.TableOrientation.ROWS )
		msgbox("Goup化 OK",0,"Display")
		'
		oCellAdr = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr
			.Sheet = 0
  			.StartRow = 2			' Row No.3
  			.EndRow = 4			' Row No.4
		end with
		oSheet.ungroup( oCellAdr, com.sun.star.table.TableOrientation.ROWS )
		msgbox("Goup化解除 OK",0,"Display")
End Sub

CCR-)[Calc]Sheet内の全てのGoup化の削除

Sub ColRow()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellAdr as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		oCellAdr = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr
			.Sheet = 0
			' 1つ目のGroup
			.StartColumn = 1
			.EndColumn = 2
			' 2つ目のGropu
  			.StartRow = 2			' Row No.3
  			.EndRow = 4			' Row No.4
		end with
		oSheet.group( oCellAdr, com.sun.star.table.TableOrientation.COLUMNS )
		oSheet.group( oCellAdr, com.sun.star.table.TableOrientation.ROWS )
		msgbox("Goup化 OK",0,"Display")
		'
		oSheet.clearOutline()
		msgbox("全てのGoup化解除 OK",0,"Display")
End Sub

CCR-)[Calc]Sheet内の全てのGoup化の削除(2)

Sub ColRow()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellAdr as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		oCellAdr = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr
			.Sheet = 0
			' 1つ目のGroup
			.StartColumn = 1
			.EndColumn = 2
			' 2つ目のGropu
  			.StartRow = 2			' Row No.3
  			.EndRow = 4			' Row No.4
		end with
		oSheet.group( oCellAdr, com.sun.star.table.TableOrientation.COLUMNS )
		oSheet.group( oCellAdr, com.sun.star.table.TableOrientation.ROWS )
		msgbox("Goup化 OK",0,"Display")
		'
	' Group化の削除
	Dim oFrame as Object
	Dim oDispatcher as Object
	Dim oProp()
		oFrame = oDoc.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		' Outlineの削除
		oDispatcher.executeDispatch(oFrame,  ".uno:ClearOutline", "", 0, oProp())
		msgbox("全てのGoup化解除 OK",0,"Display")
End Sub

CCR-)[Calc]Goupの表示/非表示

Sub ColRow()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellAdr as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		oCellAdr = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr
			.Sheet = 0
			' 1つ目のGroup
			.StartColumn = 1
			.EndColumn = 2
			' 2つ目のGropu
  			.StartRow = 2			' Row No.3
  			.EndRow = 4			' Row No.4
		end with
		oSheet.group( oCellAdr, com.sun.star.table.TableOrientation.COLUMNS )
		oSheet.group( oCellAdr, com.sun.star.table.TableOrientation.ROWS )
		msgbox("Goup化 OK",0,"Display")
		'
		oCellAdr = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr
			.Sheet = 0
			' 1つ目のGroup
			.StartColumn = 1
			.EndColumn = 2
		end with
		oSheet.hideDetail( oCellAdr )
		msgbox("Goup部の非表示化 OK",0,"Display")
		'
		oSheet.ShowDetail( oCellAdr )
		msgbox("Goup部の表示化 OK",0,"Display")
End Sub

CCR-)[Calc]Outlineの自動作成

Sub ColRow()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellAdr as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		oCellAdr = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr
			.Sheet = 0
  			.StartRow = 1			' ← 正確な範囲指定は不要
  			.EndRow = 10			' ←  但し、範囲内に無いDataは 自動Outline(Group化)は作成されない
		end with
		' Outlineの自動作成
		oSheet.autoOutline(oCellAdr)
		msgbox("Outlineの自動作成 → OK",0,"Outline")
		'
		' Outlineの削除
		oSheet.clearOutline()
		msgbox("全てのGoup化解除 OK",0,"Display")
End Sub
'
' Outlineの自動作成については http://help.libreoffice.org/Calc/AutoOutline/ja を参照
'
' [ 注意 ]
' = Sum(A1:A3) → OK
' = A1 + A2 + A3 → NG
'
















CCR-)[Calc]Outlineの自動作成(2)

Sub ColRow()
	Dim oFrame as Object
	Dim oDispatcher as Object
	Dim oProp()
		oFrame = ThisComponent.CurrentController.Frame
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		' Outlineの自動作成
		oDispatcher.executeDispatch(oFrame,  ".uno:AutoOutline", "", 0, oProp())
		msgbox("Outlineの自動作成 → OK",0,"Outline")
		'
		' Outlineの削除
		oDispatcher.executeDispatch(oFrame,  ".uno:ClearOutline", "", 0, oProp())
		msgbox("Outlineの削除 → OK",0,"Outline")
End Sub

CCR-)[Calc]任意Levelまで一度に表示


Sub ColRow()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCellAdr1 as Object
	Dim oCellAdr2 as Object
	Dim oCellAdr3 as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		oCellAdr1 = createUnoStruct("com.sun.star.table.CellRangeAddress")
		' 1 Level目のGroup作成
		with oCellAdr1
			.Sheet = 0
  			.StartRow = 0
  			.EndRow = 10
		end with
		oSheet.group( oCellAdr1, com.sun.star.table.TableOrientation.ROWS )
		'
		' 2 Level目のGroup作成
		oCellAdr2 = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr2
			.Sheet = 0
  			.StartRow = 2
  			.EndRow = 8
		end with
		oSheet.group( oCellAdr2, com.sun.star.table.TableOrientation.ROWS )
		'
		' 3 Level目のGroup作成
		oCellAdr3 = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oCellAdr3
			.Sheet = 0
  			.StartRow = 4
  			.EndRow = 5
		end with
		oSheet.group( oCellAdr3, com.sun.star.table.TableOrientation.ROWS )
		'
		' 3Level を非表示
		oSheet.hideDetail( oCellAdr3 )		' 範囲が小さいものから非表示化 / 手作業と同じ
		' 2Level を非表示
		oSheet.hideDetail( oCellAdr2 )
		' 1Level を非表示
		oSheet.hideDetail( oCellAdr1 )
		msgbox("Goupの非表示化完了",0,"Display")
		'
		' 2 Levelまで一度に表示
		oSheet.showLevel(2,com.sun.star.table.TableOrientation.ROWS)
		msgbox("2 Levelまで展開",0,"Display")
		'
		' Outlineの削除
		oSheet.clearOutline()
		msgbox("全てのGoup化解除 OK",0,"Display")
End Sub

[ HyperLink ]

CCH-)[Calc]HyperLink設定(1)

Sub HyperLinkCell
	dim name_HyperLink(0) as new com.sun.star.beans.PropertyValue
	dim setHyperLinkArgs(2) as new com.sun.star.beans.PropertyValue

	document = ThisComponent.CurrentController.Frame
	dispatcher = createUnoService("com.sun.star.frame.DispatchHelper")

		'ハイパーリンクセット
			name_HyperLink(0).name="ToPoint"
			name_HyperLink(0).value="B1" ←HyperLink設定セル
			dispatcher.executeDispatch(document, ".uno:GoToCell", "", 0, name_HyperLink())
			setHyperLinkArgs(0).Name = "Hyperlink.Text"
			setHyperLinkArgs(0).value = "Yahoo Japan"
			setHyperLinkArgs(1).Name = "Hyperlink.URL"
			setHyperLinkArgs(1).Value ="http://www.yahoo.co.jp"
			setHyperLinkArgs(2).name="Hyperlink.Type"
			setHyperLinkArgs(2).value=1
			dispatcher.executeDispatch(document, ".uno:SetHyperlink", "", 0, setHyperLinkArgs())
End Sub

CCH-)[Calc]HyperLink設定(2)

Sub HyperLinkCell
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
	Dim oTextCursor as Object
	Dim oLink as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,0)
		'
		oLink = oDoc.createInstance("com.sun.star.text.TextField.URL")
		with oLink
			.URL = "http://ja.libreofficeforum.org/forum"
			.Representation = "LibreOffice Forum"
			.TargetFrame = "_blank"
		end with
		'
		oTextCursor = oCell.createTextCursor()
		oCell.insertTextContent( oTextCursor, oLink, false )
		'
	msgbox "Success"
End Sub
'
' [ TargetFrame ]
'   _blank
'   _parent
'   _self
'   _top


[ Array ]

CCD-)[Calc]配列の文字列を纏める

Sub Main5()
	Dim oItems(0 to 2) as String
	Dim str as String
		oItems(0)="123"
 		oItems(1)="abc"
 		oItems(2)="456"
 		str=Join(Items,"+")
 	Print str
End Sub

CCD-)[Calc]文字列を分割して、配列として返す。(CSV fileを扱うときに便利)

Sub Main4
	Dim Items()
 		Items=Split("Apple,Orange,Lemon",",")
 		Print Items(0),Items(1),Items(2)
End Sub

CCD-)[Calc]指定範囲のDataを全て取得

Sub oGetAndSetData
	Dim oRange
	Dim oSheet
	Dim oAllData
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:G10")
	'Get Data
		oAllData = oRange.getDataArray()
		for i = 0 to Ubound(oAllData)
			oDisp = oDisp & " " & Join(oAllData(i), " : ") & " " & Chr$(10)
		next i
	msgbox(oDisp,0,"Data In Range")
End Sub

CCD-)[Calc]指定範囲にDataを入力

Sub oGetAndSetData
	Dim oRange
	Dim oSheet
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B2")
	'Set Data
		oRange.setDataArray(Array(Array("A1", "B1"), Array("A2", "B2")))
End Sub

CCD-)[Calc]Array Fourmula


Sub CalcArrayFormula()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oRange as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
	'Set the two top cells
		oCell = oSheet.getCellByPosition(1,2)
			oCell.setValue(1)
		oCell = oSheet.getCellByPosition(2,2)
			oCell.setValue(3)
	'Fill the Values Down
		oRange = oSheet.getCellRangeByName("B3:C8")
		oRange.fillAuto(com.sun.star.sheet.FillDirection.TO_BOTTOM, 1)
	'Setting each cell individually
		for i=3 to 8
			oCell = oSheet.getCellByPosition(3, i-1)
			oCell.setFormula("=B" & i & "+C" & i)
		next i
	'Setting a single array formula
		oRange = oSheet.getCellRangeByName("E3:E8")
		oRange.setArrayFormula("=B3:B8+C3:C8")
	'Title for Column
		oRange = oSheet.getCellRangeByName("B2:E2")
		oRange.setDataArray(Array(Array("B", "C", "Formula", "Array Formula")))
		'
		msgbox "Success",0,"Array Formula"
End Sub


[ Sort ]

CCS-1)[Calc]指定範囲を任意の列の昇順でソートする

Sub DataSort(oRange as object,iCol as integer)
Dim descriptors_obj(1) As New com.sun.star.beans.PropertyValue
Dim sortFields(0) As New com.sun.star.util.SortField
     sortFields(0).Field = iCol
     sortFields(0).SortAscending = True
     descriptors_obj(0).Name = "SortFields"
     descriptors_obj(0).Value = sortFields()
     descriptors_obj(1).Name = "ContainsHeader"
     descriptors_obj(1).Value = False
     oRange.sort(descriptors_obj())
End Sub

CCS-1)[Calc]数字としてSort

Sub oShortColOne
	Dim oSheet
	Dim oRange
	Dim oSortFields(0) as new com.sun.star.util.SortField
	Dim oSortDesc(0) as new com.sun.star.beans.PropertyValue
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:A10")
			oSortFields(0).Field = 0
			oSortFields(0).SortAscending = true
			oSortFields(0).FieldType = com.sun.star.util.SortFieldType.NUMERIC
		oSortDesc(0).Name = "SortFields"
		oSortDesc(0).Value = oSortFields()
	oRange.Sort(oSortDesc())
End Sub

CCS-1)[Calc]Text DataとしてSort

Sub oShortColOne
	Dim oSheet
	Dim oRange
	Dim oSortFields(0) as new com.sun.star.util.SortField
	Dim oSortDesc(0) as new com.sun.star.beans.PropertyValue
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:A10")
			oSortFields(0).Field = 0
			oSortFields(0).SortAscending = true
			oSortFields(0).FieldType = com.sun.star.util.SortFieldType.ALPHANUMERIC
		oSortDesc(0).Name = "SortFields"
		oSortDesc(0).Value = oSortFields()
	oRange.Sort(oSortDesc())
End Sub

CCS-1)[Calc]Sort Descriptor


Sub oDisplaySortDescriptor
	On Error Resume Next
	Dim oSheet
	Dim oRange
	Dim oSortDescript()
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("B28:D33")
	oSortDescript = oRange.createSortDescriptor()
		for i = LBound(oSortDescript) to UBound(oSortDescript)
			oDisp = oDisp & oSortDescript(i).Name & " = "
			oDisp = oDisp & oSortDEscript(i).Value
			oDisp = oDisp & Chr$(10)
		next
	msgbox(oDisp,0,"Sort Descriptor")
End Sub


[ Filter ]

CCFlt-)[Calc]AutoFilterの設定/解除(1)


Sub SetAutoFlter()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oDbRanges as Object
	Dim oRange as Object
	Dim oRangeName as String
	Dim oFilterRange as Object
  		oDoc = ThisComponent
  		oSheet = oDoc.getSheets().getByIndex(0)
  		'
  		oDBRanges = oDoc.DatabaseRanges
  		oRange = oSheet.getCellRangeByPosition(0,0,1,1000)		' A1 ~ B1001
  		' AutoFilterを設定するRangeにNameを付ける( 必須 )
  		oRangeName = "RangeName"
 		'
 		' 同じRange Nameを付けようとするとCrashするので、同名Range Nameは一旦、削除する
 		If oDBRanges.hasByName(oRangeName) Then
   			oDBRanges.removeByName(oRangeName)
 		End If
 		' A1 ~ B1001の範囲にRange Nameを設定する
 		oDBRanges.addNewByName(oRangeName, oRange.RangeAddress)
 		' Range Objectを取得
 		oFilterRange = oDBRanges.getByName(oRangeName)
 		' AutoFilter 設定 ON
 		oFilterRange.AutoFilter = true
 		' Display
 		msgbox "AutoFilter設定完了"
 		'
 		' AutoFilter 解除
 		oFilterRange.AutoFilter = false
 		' Display
 		msgbox "AutoFilter解除完了"
End Sub

CCFlt-)[Calc]AutoFilterの設定/解除(2)


Sub UnoSetAutoFlter()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
		oDoc = ThisComponent
  		oSheet = oDoc.getSheets().getByIndex(0)
  		oCtrl = oDoc.getCurrentController()
  		oFrame   = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
  		'
  		'まずオートフィルタの範囲を選択します。(アクティブなセルを指定)
		oCtrl.select (oSheet.getCellRangeByName ("A1:B1001"))
 		'オートフィルタ設定 ON
		oDispatcher.executeDispatch(oFrame, ".uno:DataFilterAutoFilter", "", 0, Array())
 		msgbox "AutoFilter設定完了",0,"AutoFilter"
 		'オートフィルタ設定 OFF
		oDispatcher.executeDispatch(oFrame, ".uno:DataFilterAutoFilter", "", 0, Array())
 		msgbox "AutoFilter設定解除",0,"AutoFilter"
End Sub

CCFlt-)[Calc]AutoFilterでFiltering


Sub SetAutoFlter()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oDbRanges as Object
	Dim oRange as Object
	Dim oRangeName as String
	Dim oFilterRange as Object
  		oDoc = ThisComponent
  		oSheet = oDoc.getSheets().getByIndex(0)
  		'
  		oDBRanges = oDoc.DatabaseRanges
  		oRange = oSheet.getCellRangeByPosition(0,0,1,1000)		' A1 ~ B1001
  		' AutoFilterを設定するRangeにNameを付ける( 必須 )
  		oRangeName = "RangeName"
 		'
 		' 同じRange Nameを付けようとするとCrashするので、同名Range Nameは一旦、削除する
 		If oDBRanges.hasByName(oRangeName) Then
   			oDBRanges.removeByName(oRangeName)
 		End If
 		' A1 ~ B1001の範囲にRange Nameを設定する
 		oDBRanges.addNewByName(oRangeName, oRange.RangeAddress)
 		' Range Objectを取得
 		oFilterRange = oDBRanges.getByName(oRangeName)
 		' AutoFilter 設定 ON
 		oFilterRange.AutoFilter = true
 		'
 	' AutoFilter Display
 	Dim oFilterDisp as Object
 		oFilterDisp = oFilterRange.FilterDescriptor
 		'
 	' FilterFieldの作成が必要		' FilterFieldsでは上手くいかない?
 	Dim oFilterItem(0) As New com.sun.star.sheet.TableFilterField		' AutoFilter では 条件Columnは1つしか無いので 0 だけらしい。
 		With oFilterItem(0)
 			.Connection = com.sun.star.sheet.FilterConnection.AND		' com.sun.star.sheet.FilterConnection.OR でも同じらしい
    		.Field = 0
    		.Operator = com.sun.star.sheet.FilterOperator.EQUAL
    		.IsNumeric = true
    		.NumericValue = 5
 		End With
 	' Set
 		oFilterDisp.setFilterFields( oFilterItem )
 		'
  	' Filter 範囲の表示の更新
  		oFilterRange.refresh()
  		'
  	msgbox("設定1",0,"AutoFilterの設定")
  		'
  	' 2回目の設定
  		With oFilterItem(0)
 			.Connection = com.sun.star.sheet.FilterConnection.OR
    		.Field = 1
    		.Operator = com.sun.star.sheet.FilterOperator.EQUAL
    		.IsNumeric = false
    		.StringValue = "Taro"
 		End With
 		' Set
 		oFilterDisp.setFilterFields( oFilterItem )
 		'
  	' Filter 範囲の表示の更新
  		oFilterRange.refresh()
  		'
  	msgbox("設定2",0,"AutoFilterの設定")
End Sub

CCFlt-)[Calc]標準Filter設定Dialog表示


Sub UnoSetStdFlter()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
		oDoc = ThisComponent
  		oCtrl = oDoc.getCurrentController()
  		oFrame   = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
  		' DIsplay Dialog
		oDispatcher.executeDispatch(oFrame, ".uno:DataFilterStandardFilter", "", 0, Array())
 		msgbox "Succcess",0,"Filter"
End Sub

CCFlt-)[Calc]特殊Filter設定Dialog表示


Sub UnoSetSpecialFlter()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
		oDoc = ThisComponent
  		oCtrl = oDoc.getCurrentController()
  		oFrame   = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
  		' DIsplay Dialog
		oDispatcher.executeDispatch(oFrame, ".uno:DataFilterSpecialFilter", "", 0, Array())
 		msgbox "Succcess",0,"Filter"
End Sub

CCFlt-)[Calc]標準/特殊Filter解除(1)


Sub RemoveSheetFilter()
	Dim oDoc as Object, oSheet as Object
	Dim oFilterDesc as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
  		oFilterDesc = oSheet.createFilterDescriptor(True)
  		oSheet.filter(oFilterDesc)
  		msgbox "Success",0,"Remove Filter"
End Sub

CCFlt-)[Calc]標準/特殊Filter解除(2)


Sub UnoRemoveSheetFilter()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oSheet as Object
		oDoc = ThisComponent
  		oCtrl = oDoc.getCurrentController()
  		oFrame   = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		' Filter Area
		oSheet = oDoc.getSheets().getByIndex(0)
		oCtrl.select (oSheet.getCellRangeByName ("A1:C100"))
  		' Remove Filter
		oDispatcher.executeDispatch(oFrame, ".uno:DataFilterRemoveFilter", "", 0, Array())
 		msgbox "Succcess( Uno )",0,"Remove Filter"
End Sub

CCFlt-)[Calc]





[ Search ]

CCSh-1)[Calc]Simple Search

Sub oSearchSheet
	Dim oSheet
		oSheet = ThisComponent.Sheets(1)
		oSearch = oSheet.createSearchDescriptor()
		With oSearch
			.SearchString = "newOoo3"		'	<=		検索文字
			.SearchWords = false 				'	<=		検索文字が一部含まれる(false),絶対一致(true)。 大文字と小文字の区別無し
			.SearchCaseSensitive = false	'	<=		大文字小文字区別( true )
		End With
		' Search
			oFind = oSheet.findFirst(oSearch)
			oDisp = oFind.getString()
		msgbox( oDisp )
End Sub

CCSh-2)[Calc]Simple Replace

Sub oSearchSheet
	Dim oSheet
		oSheet = ThisComponent.Sheets(1)
		oSearch = oSheet.createReplaceDescriptor()
		With oSearch
			.SearchString = "newOoo3"				'	←		検索文字
			.ReplaceString = "OpenOffice.org"		'	←		置換文字
			.SearchWords = true 					'	←		検索文字が一部含まれる(false),絶対一致(true)。 大文字と小文字の区別無し
			.SearchCaseSensitive = false			'	←		大文字小文字区別( true )
		End With
		' Relace
			oDisp = oSheet.replaceAll(oSearch)
		msgbox( oDisp, 0, "置換した数" )
End Sub

CCSh-)[Calc]Cell内改行を検索


Sub oSearchSheet
	Dim oSheet
		oSheet = ThisComponent.Sheets(0)
		oSearch = oSheet.createSearchDescriptor()
		With oSearch
			REM  ' 検索は出来るが、任意の文字をCell内改行はほぼ出来ない。
			REM  ' 正確には置換しているが、Cell内改行されている様に表示されない。
			REM  ' 対象Cellを手動で選択するとセル内改行されている事が分る。
			.SearchString = Chr$(10)
			.SearchWords = false 				'	←		検索文字が一部含まれる(false),絶対一致(true)。 大文字と小文字の区別無し
			.SearchCaseSensitive = false	'	←		大文字小文字区別( true )
		End With
		' Search
			oFind = oSheet.findFirst(oSearch)
			oDisp = oFind.getString()
		msgbox( oDisp )
End Sub

[ Merge ]

CCM-)[Calc]Cellの結合/結合解除(1)


Sub CellMerge()
	Dim oDoc as Object, oSheet as Object
	Dim oRange as Object
		oDoc = ThisComponent
		oSheet = oDoc.Sheets().getByIndex(0)
		oRange = oSheet.getCellRangeByName("A1:B2")
		'
		oRange.merge(true)
		msgbox "Merge cell",0,"Merge of Cell"
		'
		oRange.merge(false)
		msgbox "Split cell",0,"Merge of Cell"
End Sub

CCM-)[Calc]Cellの結合/結合解除(2)


Sub UnoMergeCell()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A1:B3"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		' Merge cells
		oDispatcher.executeDispatch(oFrame, ".uno:MergeCells", "", 0, Array())
		msgbox "Merge Cells" & Chr$(10) & "(DispatchHelper)",0,"Merge of Cell"
		' Split cell
		oDispatcher.executeDispatch(oFrame, ".uno:SplitCell", "", 0, Array())
		msgbox "Split Cell" & Chr$(10) & "(DispatchHelper)",0,"Merge of Cell"
End Sub

CCM-)[Calc]結合されたセル(事前に選択)のサイズを調べる(その1)

Sub UnoCellMerge()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as object
	Dim oCell as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getSheets().getByName("sheet1")
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		oDispatcher.executeDispatch(oFrame, ".uno:ToggleMergeCells", "", 0, Array())
		oCell = ThisComponent.CurrentController.getSelection()
		cs=oCell.RangeAddress.StartColumn
		rs=oCell.RangeAddress.StartRow
		ce=oCell.RangeAddress.EndColumn
		re=oCell.RangeAddress.EndRow
		oWidth=0
		oHeight=0
		for i=cs to ce
			oW=ThisComponent.Sheets(0).getCellByPosition(i,0)
			oWidth_tmp=oW.getColumns().Width
			oWidth = oWidth + oWidth_tmp
		next
		for i=rs to re
			oH=ThisComponent.Sheets(0).getCellByPosition(0,i)
			oHeight_tmp=oH.getRows().Height
			oHeight= oHieght + oHeight_tmp
		next
		oDispatcher.executeDispatch(oFrame, ".uno:ToggleMergeCells", "", 0, Array())
		MsgBox("結合セルの幅 : " & oWidth &Chr(10) & _
				"結合セルの高さ : " & oHeight)
End Sub

CCM-)[Calc]結合されたセル(事前に選択)のサイズを調べる(その2)

Option VBASupport 1
Sub MergeCell2()
	Dim oSheet As Object
	Dim oCursor As Object
	Dim oSelection As Object
	Dim oWidth As Long
	Dim oHeight As Long
		oSheet =ThisComponent.CurrentController.ActiveSheet
		oSelection = ThisComponent.CurrentSelection
		oCursor = oSheet.createCursorByRange( oSelection )
		oCursor.collapseToMergedArea()
		oWidth = oCursor.Size.Width
		oHeight = oCursor.Size.Height
		MsgBox("結合セルの幅 : " & oWidth &Chr(10) & _
				"結合セルの高さ : " & oHeight)
End Sub

[ Note ] :(その1)と(その2)の違い
(その1) : セルの結合解除 ⇒ 選択範囲の各セルサイズ(幅、高さ)を取得 ⇒ 各セルサイズを足し合わせる ⇒ 再度セルの結合を実施
(その2) : 結合セルのAreaサイズを直接取得。(その1)に比べると少し調査精度が低いが、概略サイズの取得ならばこちらのコードの方がSmartである。

CCM-)[Calc]各Sheet内に結合しているセルがあるかどうか調べる。

Sub sheet_by_enumeration()
	Dim oSheetsEnumeration As Object, oSheets As Object
		oSheets = ThisComponent.getSheets()
		oSheetsEnumeration = oSheets.createEnumeration()
	While ( oSheetsEnumeration.hasMoreElements() )
		MsgBox oSheetsEnumeration.nextElement.IsMerged()
	WEnd
End Sub

[ Calc Function ]

CCFc-)[Calc]Find

Sub oFunction
	Dim oFunction(2)
		ShtFnc = CreateUnoService("com.sun.star.sheet.FunctionAccess")
		oSource = "ABCDEFGHIJKLMNOPQRSTUVWXYZ"
 			oFunction(0) = "T"
 			oFunction(1) = oSource
 			oFunction(2) = 1
 		oPosFind = ShtFnc.callFunction("Find", oFunction())+1
 	msgbox(oFunction(0) & " => " & oPosFind & " 文字目",0,"Calc Function")
End Sub

CCFc-)[Calc]値をValue形式にする

Sub oFunction
	Dim oFunction(0)
		ShtFnc = CreateUnoService("com.sun.star.sheet.FunctionAccess")
			oFunction(0) = "1,234"
 		oPosFind = ShtFnc.callFunction("Value", oFunction())
 	msgbox(oFunction(0) & " → " & oPosFind ,0,"Calc Function")
End Sub

CCFc-)[Calc]値をText形式にする

Sub oFunction
	Dim oFunction(0)
		ShtFnc = CreateUnoService("com.sun.star.sheet.FunctionAccess")
			oFunction(0) = "1,234"
 		oPosFind = ShtFnc.callFunction("T", oFunction())
 	msgbox(oFunction(0) & " => " & oPosFind ,0,"Calc Function")
End Sub

CCFc-)[Calc]指定範囲の合計(1)[連続範囲]


Sub UseComputeSum()
	Dim oRange as Object
	Dim oSheet as Object
	Dim oResult as double
		oSheet = ThisComponent.Sheets(0)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.SUM )
		oDisp = "A1:B5 => Sum = " & oResult & Chr$(10) & "文字列・空白は自動的に除外"
	msgbox(oDisp,0,"ComputerFunction")
End Sub
'
' [ Note ]
' 1) 範囲内に文字列、空白があってもOK。式値は含まれる。

CCFc-)[Calc]指定範囲の合計(2)[不連続範囲]


Sub UseComputeSum()
	Dim oRange(1) as Object
	Dim oSheet as Object
	Dim oResult as Double
		oSheet = ThisComponent.Sheets(0)
		oRange(0) = oSheet.getCellRangeByName("A1:A5")
		oRange(1) = oSheet.getCellRangeByName("D1:D5")
		oResult = 0
		for i = 0 to UBound(oRange)
		  oResult = oResult + oRange(i).computeFunction(com.sun.star.sheet.GeneralFunction.SUM )
		next i
		oDisp = "A1:A5/D1:D5 → Sum = " & oResult & Chr$(10) & "文字列・空白は自動的に除外"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]空白以外のCell数

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.COUNT )
		oDisp = "A1:B5 => COUNT = " & oResult & Chr$(10) & "空白以外のCell数"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]指定範囲の平均

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.AVERAGE )
		oDisp = "A1:B5 => Average = " & oResult & Chr$(10) & "平均"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]最大値

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.MAX )
		oDisp = "A1:B5 => MAX = " & oResult & Chr$(10) & "MAX値"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]最小値

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.MIN )
		oDisp = "A1:B5 => MIN = " & oResult & Chr$(10) & "MIN値"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]Product

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.PRODUCT )
		oDisp = "A1:B5 => PRODUCT = " & oResult & Chr$(10) & "PRODUCT値"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]数値Cellの数

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.COUNTNUMS )
		oDisp = "A1:B5 => COUNTNUMS = " & oResult & Chr$(10) & "COUNTNUMS値"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]推定標準偏差

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.STDEV )
		oDisp = "A1:B5 => STDEV = " & oResult & Chr$(10) & "STDEV値"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]標準偏差

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.STDEVP )
		oDisp = "A1:B5 => STDEVP = " & oResult & Chr$(10) & "STDEVP値"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]標本に基づいて分散を予測

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.VAR )
		oDisp = "A1:B5 => VAR = " & oResult & Chr$(10) & "VAR値"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]母集団に基づき、分散

Sub oUseCompute
	Dim oRange
	Dim oSheet
	Dim oResult as double
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:B5")
		oResult = oRange.computeFunction(com.sun.star.sheet.GeneralFunction.VARP )
		oDisp = "A1:B5 => VARP = " & oResult & Chr$(10) & "VARP値"
	msgbox(oDisp,0,"ComputerFunction")
End Sub

CCFc-)[Calc]Auditing Function


Sub oQUaryRange
	Dim oSheet
	Dim oCell
		oSheet = ThisComponent.Sheets(1)
		oCell = oSheet.getCellByposition(0,7)		'	A8 = Sum(A1:A7)
		oCellAd = oCell.CellAddress
		oDisp1= oSheet.showPrecedents(oCellAd)
		oDisp2= oSheet.hidePrecedents(oCellAd)
		oDisp3= oSheet.showDependents(oCellAd)
		oDisp4= oSheet.hideDependents(oCellAd)
		oDisp5= oSheet.showErrors(oCellAd)
		oDisp6= oSheet.showInvalid()
		oDisp7= oSheet.clearArrows()
		oDisp = "[ A8 = SUM(A1:A7) ]" & Chr$(10) & Chr$(10)
		oDisp= oDisp & "oSheet.showPrecedents(oCell.Address) = " & oDisp1 & Chr$(10)
		oDisp= oDisp & "oSheet.hidePrecedents(oCell.Address) = " & oDisp2 & Chr$(10)
		oDisp= oDisp & "oSheet.showDependents(oCell.Address) = " & oDisp3 & Chr$(10)
		oDisp= oDisp & "oSheet.hideDependents(oCell.Address) = " & oDisp4 & Chr$(10)
		oDisp= oDisp & "oSheet.showErrors(oCell.Address) = " & oDisp5 & Chr$(10)
		oDisp= oDisp & "oSheet.showInvalid() = " & oDisp6 & Chr$(10)
		oDisp= oDisp & "oSheet.clearArrows() = " & oDisp7 & Chr$(10)
	MsgBox(oDisp,0,"com.sun.star.sheet.XSheetAuditing Intrface")
End Sub

CCFc-)[Calc]指定Cellの参照の表示


Sub CalcFunctionAuding()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oRowNo as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		'
		' 事前準備
		oRowNo = 6
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 0, i )
			oCell.Value = i
		next i
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 1, i )
			if i = 3 then
				oCell.Formula = "= A2"
			else
				oCell.Value = i
			end if
		next i
		oSheet.getCellByPosition( 0, oRowNo + 1 ).Formula = "=Sum(A1:A" & oRowNo + 1 & ")"
		'
		' 指定Cellの参照元を表示
		oCell = oSheet.getCellByPosition( 0, oRowNo + 1 )		' A7 の参照元から矢印。
		oSheet.showPrecedents(oCell.CellAddress)
		'
		msgbox "Success" & Chr$(10) & "( showPrecedents )"
End Sub

CCFc-)[Calc]指定Cellの参照の表示


Sub CalcFunctionAuding()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oRowNo as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		'
		' 事前準備
		oRowNo = 6
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 0, i )
			oCell.Value = i
		next i
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 1, i )
			if i = 3 then
				oCell.Formula = "= A2"
			else
				oCell.Value = i
			end if
		next i
		oSheet.getCellByPosition( 0, oRowNo + 1 ).Formula = "=Sum(A1:A" & oRowNo + 1 & ")"
		'
		' 指定Cellの参照先を表示
		oCell = oSheet.getCellByPosition( 0, 1 )		' A2 の参照先を矢印。共に参照されているCell も囲まれる。表示結果は showPrecedents と同じ
		oSheet.showDependents(oCell.CellAddress)
		'
		msgbox "Success" & Chr$(10) & "( showDependents )"
End Sub

CCFc-)[Calc]Formula Cellの参照元の表示削除(1a)


Sub CalcFunctionAuding()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oRowNo as Integer
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		'
		' 事前準備
		oRowNo = 6
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 0, i )
			oCell.Value = i
		next i
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 1, i )
			if i = 3 then
				oCell.Formula = "= A2"
			else
				oCell.Value = i
			end if
		next i
		oSheet.getCellByPosition( 0, oRowNo + 1 ).Formula = "=Sum(A1:A" & oRowNo + 1 & ")"
		'
		' 指定Cellの参照元を表示
		oCell = oSheet.getCellByPosition( 0, oRowNo + 1  )
		oSheet.showPrecedents(oCell.CellAddress)
		oDisp = "指定Cellの参照元を表示"
		msgbox(oDisp, 0, "showPrecedents")
		'
		' 参照先表示の削除
		if oSheet.hideDependents(oCell.CellAddress) then
			oDisp = "参照先表示を削除しました"
		else
			oDisp = "参照先表示は" & Chr$(10) & "設定されていません。"
		end if
		msgbox(oDisp, 0,"hideDependents")
		'
		if oSheet.hidePrecedents(oCell.CellAddress) then
			oDisp = "参照元を削除しました"
		else
			oDisp = "参照元表示は" & Chr$(10) & "設定されていません。"
		end if
		msgbox(oDisp, 0,"hideDependents")
End Sub

CCFc-)[Calc]指定CellのError元を参照(1)


Sub CalcFunctionAuding()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oRowNo as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		'
		' 事前準備
		oRowNo = 6
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 0, i )
			if i = 1 then
				oCell.Formula = "= B4"
			else
				oCell.Value = i
			end if
		next i
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 1, i )
			if i = 3 then
				oCell.Formula = "= A2"
			else
				oCell.Value = i
			end if
		next i
		oSheet.getCellByPosition( 0, oRowNo + 1 ).Formula = "=Sum(A1:A" & oRowNo + 1 & ")"
		'
		' 指定CellのError元Cellを表示
		oCell = oSheet.getCellByPosition( 0, oRowNo + 1 )		' A7 のError元から矢印。
		oSheet.showErrors(oCell.CellAddress)
		'
		msgbox "Success" & Chr$(10) & "( showErrors )"
End Sub

CCFc-)[Calc]指定CellのError元を参照(2)


Sub CalcFunctionAuding()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oRowNo as Integer
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		'
		' 事前準備
		oRowNo = 6
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 0, i )
			if i = 1 then
				oCell.Formula = "= B4"
			else
				oCell.Value = i
			end if
		next i
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 1, i )
			if i = 3 then
				oCell.Formula = "= A2"
			else
				oCell.Value = i
			end if
		next i
		oSheet.getCellByPosition( 0, oRowNo + 1 ).Formula = "=Sum(A1:A" & oRowNo + 1 & ")"
		'
		' ErrorのCellに移動 & Trace
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "A8"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		oDispatcher.executeDispatch(oFrame,  ".uno:ShowErrors", "", 0, Array())
		'
		msgbox "Success" & Chr$(10) & "( uno:ShowErrors )"
End Sub

CCFc-)[Calc]Sheet中の全ての参照表示を削除


Sub CalcFunctionAuding()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oRowNo as Integer
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		'
		' 事前準備
		oRowNo = 6
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 0, i )
			if i = 1 then
				oCell.Formula = "= B4"
			else
				oCell.Value = i
			end if
		next i
		for i = 0 to oRowNo
			oCell = oSheet.getCellByPosition( 1, i )
			if i = 3 then
				oCell.Formula = "= A2"
			else
				oCell.Value = i
			end if
		next i
		oSheet.getCellByPosition( 0, oRowNo + 1 ).Formula = "=Sum(A1:A" & oRowNo + 1 & ")"
		'
		' Sheetの参照Cellを表示
		oCell = oSheet.getCellByPosition( 0, oRowNo + 1 )		' A7 のError元から矢印。
		oSheet.showErrors(oCell.CellAddress)
		oDisp = "指定CellのErrorCellの" & Chr$(10) & "参照を表示しました。"
		msgbox(oDisp, 0, "showErrors")
		'
		' Sheet中の参照を全て削除
		oSheet.clearArrows()
		oDisp = "Sheet中の全ての参照表示を" & Chr$(10) & "削除しました。"
		msgbox(oDisp, 0, "clearArrows")
End Sub

CCFc-)[Calc]Trace → 自動更新ON/OFF

Sub UnoAuding()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
    Dim oProp(0) as new com.sun.star.beans.PropertyValue
    	oDoc = ThisComponent
    	oCtrl = oDoc.getCurrentController()
    	oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oProp(0).Name = "AutoRefreshArrows"
		oProp(0).Value = false					' ON : true / OFF : false
		oDispatcher.executeDispatch(oFrame,  ".uno:AutoRefreshArrows", "", 0, Array())
		msgbox "自動更新をOFFにしました。"
End Sub
'
' IDEからの実行では反映しない。
'






















CCFc-)[Calc]











[ Subtotal of Column ]

CCSbTL-)[Calc]列の小計


Sub CalcSubTotal
	Dim oDoc as Object, oSheet as Object, oRange as Object
	Dim oUnoObj01 as Object, oUnoObj02 as Object
	Dim oDesc as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		oRange = oSheet.getCellRangeByName("B1:E5")
		' Subtotal Condion of Column 1
		oUnoObj01 =  CreateUnoStruct("com.sun.star.sheet.SubTotalColumn")
		oUnoObj01.Column = 0 ' Column Index / relative Index = B Column
  		oUnoObj01.Function = com.sun.star.sheet.GeneralFunction.SUM
  		' Subtotal Condion of Column 2
		oUnoObj02 =  CreateUnoStruct("com.sun.star.sheet.SubTotalColumn")
		oUnoObj02.Column = 3 ' Column Index / relative Index = B Column
  		oUnoObj02.Function = com.sun.star.sheet.GeneralFunction.SUM
  		'
  		oDesc = oRange.createSubTotalDescriptor(True)
  		oDesc.addNew(Array(oUnoObj01, oUnoObj02), 1)  '
  		oDesc.BindFormatsToContent = False
		'
  		oRange.applySubTotals(oDesc, True)
  		msgbox "Success"
End Sub
'
' [ Note ]
' 1) ' B列の横に結果を記す
'   oDesc.addNew(Array(oUnoObj01, oUnoObj02),1) 第二引数(=1)は結果を示すColumn No.( B列の結果を示す )

CCSbTL-)[Calc]列の小計(2)


Sub CalcSubTotal
	Dim oDoc as Object, oSheet as Object, oRange as Object
	Dim oUnoObj01 as Object, oUnoObj02 as Object
	Dim oDesc as Object
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByName("sheet1")
		oRange = oSheet.getCellRangeByName("B1:E5")
		' Subtotal Condion of Column 1
		oUnoObj01 =  CreateUnoStruct("com.sun.star.sheet.SubTotalColumn")
		oUnoObj01.Column = 0 ' Column Index / relative Index = B Column
  		oUnoObj01.Function = com.sun.star.sheet.GeneralFunction.SUM
  		' Subtotal Condion of Column 2
		oUnoObj02 =  CreateUnoStruct("com.sun.star.sheet.SubTotalColumn")
		oUnoObj02.Column = 3 ' Column Index / relative Index = B Column
  		oUnoObj02.Function = com.sun.star.sheet.GeneralFunction.SUM
  		'
  		oDesc = oRange.createSubTotalDescriptor(True)
  		oDesc.addNew(Array(oUnoObj01, oUnoObj02), 4)  '
  		oDesc.BindFormatsToContent = False
		'
  		oRange.applySubTotals(oDesc, True)
  		msgbox "Success"
End Sub
' [Note ]
' oDesc.addNew(Array(oUnoObj01, oUnoObj02),4)
' 選択範囲の最終列(E列)に第二引数にすると表示が違う?

CCSbTL-)[Calc]Subtotal Dialog表示


Sub UnoSubTotal()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		' 範囲を指定した列のみ、Dialogに候補に表示される。
		oProp(0).Name = "ToPoint"
		oProp(0).Value = "B1:D5"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp())
		oDispatcher.executeDispatch(oFrame, ".uno:DataSubTotals", "", 0, Array())
	msgbox "Success" & Chr$(10) & "( DispatchHelper )"
End Sub


CCSbTL-)[Calc]





[ 入力値規則 ]

CCVS-)[Calc]入力値を1~10に限定する

Sub SetValidationRange()
	Dim oRange as Object
	Dim oValidation as Object
	Dim oSheets as Object
		oSheets = ThisComponent.getSheets().getByName("sheet1")
		oRange = oSheets.getCellRangeByName("A1:D10")
		oValidation = oRange.Validation
			oValidation.Type = com.sun.star.sheet.ValidationType.DECIMAL
			oValidation.ErrorMessage = "Please enter a number between 1 to 10"
			ovalidation.ShowErrorMessage = true
			oValidation.ErrorAlertStyle = com.sun.star.sheet.ValidationAlertStyle.STOP
			oValidation.setOperator(com.sun.star.sheet.ConditionOperator.BETWEEN)
			'
			oValidation.setFormula1(1.0)
			oValidation.setFormula1(10,0)
			'
		oRange.Validation = oValidation
		msgbox "Success"
End Sub
'
'com.sun.star.sheet.TableValidation Service
'	Type				:	Validation Type
'	ShowInputMessage	:	True => Input Message表示
'	InputTitle			:	Input MessageのTitel指定
'	InputMessage		:	Input Messageの表示文
'	ShowErrorMessage	:	true => Error Message表示
'	ErrorTitle			:	Error MessageのTitel指定
'	ErrorMessage		:	Eroor Messageの表示文
'	IgnoreBlankCells	:	true => Blank OKとする。
'	ErrorAlertStyle		:	Error Message後の処理方法



’Type
'com.sun.star.sheet.ValidationType enum( LibreOffice / ApacheOpenOffice )
'	com.sun.star.sheet.ValidationTYPE.ANY		:	全て拒否
'	com.sun.star.sheet.ValidationTYPE.WHOLE		:	整数のみOK
'	com.sun.star.sheet.ValidationTYPE.DECIMAL	:	特定の値のみOK
'	com.sun.star.sheet.ValidationTYPE.DATE		:	日付のみOK
'	com.sun.star.sheet.ValidationTYPE.TIME		:	時間のみOK
'	com.sun.star.sheet.ValidationTYPE.TEXT_LEN	:	既定長さ内の文字列OK
'	com.sun.star.sheet.ValidationTYPE.LIST		:	文字列LIST
'	com.sun.star.sheet.ValidationTYPE.CUSTOM	:	Custom
'
'com.sun.star.sheet.ValidationAlertStyle enum
'	com.sun.star.sheet.ValidationTYPE.STOP		:	Error Messege後入力値消去。
'	com.sun.star.sheet.ValidationTYPE.WARNING	:	Warning Message。 このまま使用可能。
'	com.sun.star.sheet.ValidationTYPE.INFO		:	Information Message。このまま使用可能。
'	com.sun.star.sheet.ValidationTYPE.MACRO		:	指定MACRO実行

CCVS-)[Calc]文字列及び0以上の値以外は90°回転表示

Sub oSetConditionalStyle
	Dim oSheets
	Dim oRange
	Dim oConFormat
	Dim oCondition(2) as new com.sun.star.beans.PropertyValue
		oSheets = ThisComponent.Sheets(3)
		oRange = oSheets.getCellRangeByName("A1:D10")
	'Obtain the Validation object
		oConFormat = oRange.ConditionalFormat
			oCondition(0).Name = "Operator"
			oCondition(0).Value = com.sun.star.sheet.ConditionOperator.LESS
			oCondition(1).Name = "Formula1"
			oCondition(1).Value = 0
			oCondition(2).Name = "StyleName"
			oCondition(2).Value = "Heading1"
		oConFormat.addNew(oCondition())
		oRange.ConditionalFormat = oConFormat
End Sub
'
'com.sun.star.sheet.ConditionOperator enum
'	com.sun.star.sheet.ConditionOperator.NOME				:	全てOK
'	com.sun.star.sheet.ConditionOperator.EQUAL				:	指定値と同じ
'	com.sun.star.sheet.ConditionOperator.NOT_EQUAL			:	指定値以外
'	com.sun.star.sheet.ConditionOperator.GENERATER			:	指定値より大きい
'	com.sun.star.sheet.ConditionOperator.GENERATER_EQUAL	:	指定値以上
'	com.sun.star.sheet.ConditionOperator.LESS				:	指定値より小さい
'	com.sun.star.sheet.ConditionOperator.LESS_EQUAL			:	指定値以下
'	com.sun.star.sheet.ConditionOperator.BETWEEN			:	指定値間
'	com.sun.star.sheet.ConditionOperator.NOT_BETWEEN		:	指定値間以外
'	com.sun.star.sheet.ConditionOperator.FORMULA			:	結果が0にならない式

CCVS-)[Calc]条件付き書式Dialog表示(1)[ 条件 ]

Sub CalcConditionFormat()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		oDispatcher.executeDispatch(oFrame, ".uno:ConditionalFormatDialog", "", 0, Array())
End Sub

CCVS-)[Calc]条件付き書式Dialog表示(2)[ ColorScale ]

Sub CalcConditionFormat()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		oDispatcher.executeDispatch(oFrame, ".uno:ColorScaleFormatDialog", "", 0, Array())
End Sub
'
' [ Note ]
' Style名で設定する以外の設定方法については、APIが未対応の模様( LibreOffice4.0.1 )
' ColorScale / Databar / ManagerについてはDialog表示まで。
' 既に ColorScaleのFormatが設定済みの時は 条件 と同じDialogが表示

CCVS-)[Calc]条件付き書式Dialog表示(3)[ DataBar ]

Sub CalcConditionFormat()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		oDispatcher.executeDispatch(oFrame, ".uno:DataBarFormatDialog", "", 0, Array())
End Sub

CCVS-)[Calc]条件付き書式Dialog表示(4)[ 管理 ]

Sub CalcConditionFormat()
	Dim oDoc as Object, oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
		oDoc = ThisComponent
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		oDispatcher.executeDispatch(oFrame, ".uno:ConditionalFormatManagerDialog", "", 0, Array())
End Sub

CCVS-)[Calc]List入力設定


Sub CalcSetValidationRange()
	Dim oDoc as Object, oSheet as Object
	Dim oValidation as Object
		oDoc = ThisComponent
		oSheet = oDoc.Sheets().getByName("sheet1")
		oCell = oSheet.getCellRangeByName("A1")
		oValidation = oCell.Validation
		'
		oValidation.Type = com.sun.star.sheet.ValidationType.LIST
		'
		oValidation.Formula1 = """New York"" ""London"" ""Paris"" ""Tokyo"""
		oCell.Validation = oValidation
		'
		msgbox "Success"
End Sub
'
' [ Note ]
'  oValidation.Formula1 = Array("NewYork","London","Paris","Tokyo") はError → Only String
'  区切りは Spaceのみ
' """New York"" London Paris Tokyo"  →  "" で囲っていない場合、全て小文字になる。

CCVS-)[Calc]入力規則Dialog表示


Sub CalcValidation()
    Dim oDoc as Object, oCtrl as Object, oFrame as Object
    Dim oDispatcher as Object
    	oDoc = ThisComponent
    	oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
		'
		oDispatcher.executeDispatch(oFrame,  ".uno:Validation", "", 0, Array())
		'
		msgbox "Success"
End Sub

CCVS-)[Calc]











[ 連続Data / Fill ]

CCCd-)[Calc]右方向に連続Data作成

Sub oFill
	Dim oRange
	Dim oSheet
	Dim oAllData
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:G1")
		oSheet.getCellByPosition(0,0).Value=1
		oRange.fillAuto(com.sun.star.sheet.FillDirection.TO_RIGHT, 1)	' 	2 => 1cell飛ばしで入力 1=>連続
	'Get Data
		oAllData = oRange.getDataArray()
		for i = 0 to UBound(oAllData)
			oDisp = join(oAllData(i), " : ")
		next i
	msgbox(oDisp,0,"連続Data")
	oRange.clearContents(com.sun.star.sheet.CellFlags.VALUE)
End Sub

CCCd-)[Calc]左方向に連続Data作成

Sub oFill
	Dim oRange
	Dim oSheet
	Dim oAllData
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:G1")
		oSheet.getCellByPosition(6,0).Value=1
		oRange.fillAuto(com.sun.star.sheet.FillDirection.TO_LEFT, 2)	' 	2 => 1cell飛ばしで入力 1=>連続
	'Get Data
		oAllData = oRange.getDataArray()
		for i = 0 to UBound(oAllData)
			oDisp = join(oAllData(i), " : ")
		next i
	msgbox(oDisp,0,"連続Data")
	oRange.clearContents(com.sun.star.sheet.CellFlags.VALUE)
End Sub

CCCd-)[Calc]上方向に連続Data作成

Sub oFill
	Dim oRange
	Dim oSheet
	Dim oAllData
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:A10")
		oSheet.getCellByPosition(0,9).Value=1
		oRange.fillAuto(com.sun.star.sheet.FillDirection.TO_TOP, 1 )	' 	2 => 1cell飛ばしで入力 1=>連続
	'Get Data
		oAllData = oRange.getDataArray()
		for i = 0 to UBound(oAllData)
			oDisp = oDisp & join(oAllData(i) ) & Chr$(10)
		next i
	msgbox(oDisp,0,"連続Data")
	oRange.clearContents(com.sun.star.sheet.CellFlags.VALUE)
End Sub

CCCd-)[Calc]下方向に連続Data作成1


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oRange as Object
	Dim oAllData() as Variant
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oRange = oSheet.getCellRangeByName("A1:C10")
		oSheet.getCellByPosition(0,0).Value = 1	' 値
		' 日付、時刻 / Serial値で無いと月や分が変わらない / Cell Formatは事前に設定
		oSheet.getCellByPosition(1,0).Value = DateSerial(2012,12,29)
		oSheet.getCellByPosition(2,0).Value = TimeSerial(12,24,56)
		oRange.fillAuto(com.sun.star.sheet.FillDirection.TO_BOTTOM, 2 )
	'Get Data
		oAllData = oRange.getDataArray()
		for i = 0 to UBound(oAllData)
			oDisp = oDisp & join(oAllData(i)," → ") & Chr$(10)
		next i
	msgbox(oDisp,0,"連続Data")
	'
	' DataのClear
	Dim oFlag as Long
		' VALUE, DATETIMEの削除
		oFlag = com.sun.star.sheet.CellFlags.VALUE + com.sun.star.sheet.CellFlags.DATETIME
	oRange.clearContents(oFlag)
End Sub
'
' [ Note ]
' .fillAuto(com.sun.star.sheet.FillDirection.TO_BOTTOM, 2 )	' 	2 → Cell Addressの増分値

CCCd-)[Calc]下方向に連続Data作成2-1(足し算)


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(5) as new com.sun.star.beans.PropertyValue
	Dim oStep as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		' Cell Formatは事前に設定
		oSheet.getCellByPosition(0,0).Value = 1
		oSheet.getCellByPosition(1,0).Value = DateSerial(2012,12,29)
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "$A$1:$B$10"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
			'
			oProp(0).Name = "FillDir"
			oProp(0).Value = "B"
			oProp(1).Name = "FillCmd"
			oProp(1).Value = "L"
			oProp(2).Name = "FillStep"
			oProp(2).Value = "2"
			oProp(3).Name = "FillDateCmd"
			oProp(3).Value = "D"
			oProp(4).Name = "FillStart"
			oProp(4).Value = ""
			oProp(5).Name = "FillMax"
			oProp(5).Value = "1.70000000E+307"
		oDispatcher.executeDispatch(oFrame, ".uno:FillSeries", "", 0, oProp())
		'
	msgbox "Success"
End Sub
'
' [  Note ]
'  0) FillDir : 方向
'   B : 上から下へ / T : 下から上へ / R : 左から右へ / L : 右から左へ
'  1) FillCmd : 連続Dataの種類
'   L : 足し算 / G : 掛け算 / D : 日付 / A : AutoFill
'   日付Dataが含まれている時は G : 掛け算 不可
'  2) FillStep : 増分
'  3) FillDateCmd : 日付の単位
'   Y : Year / M : Month / D : Day / W : WeekDay( FillCmd が D or L の時のみ利用可能 )
'  4) FillStart : 開始値
'   複数の列の連続Dataを作成する際、macro の 記録では "1.70000000E+307"となるが、空白に修正しないと左端の列は "1.70000000E+307"に置き換わってしまう
'  5) FillMax : 停止値
'   "1.70000000E+307"は設定無しと同じ

CCCd-)[Calc]下方向に連続Data作成2-2(掛け算)


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(5) as new com.sun.star.beans.PropertyValue
	Dim oStep as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		' Cell Formatは事前に設定
		oSheet.getCellByPosition(0,0).Value = 1
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "$A$1:$A$10"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
			'
			oProp(0).Name = "FillDir"
			oProp(0).Value = "B"
			oProp(1).Name = "FillCmd"
			oProp(1).Value = "G"
			oProp(2).Name = "FillStep"
			oProp(2).Value = "5"
			oProp(3).Name = "FillDateCmd"
			oProp(3).Value = ""
			oProp(4).Name = "FillStart"
			oProp(4).Value = ""
			oProp(5).Name = "FillMax"
			oProp(5).Value = "1.70000000E+307"
		oDispatcher.executeDispatch(oFrame, ".uno:FillSeries", "", 0, oProp())
		'
	msgbox "Success"
End Sub

CCCd-)[Calc]下方向に連続Data作成2-3(Weekday)


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(5) as new com.sun.star.beans.PropertyValue
	Dim oStep as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		' Cell Formatは事前に設定
		oSheet.getCellByPosition(1,0).Value = DateSerial(2012,12,28)
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "$B$1:$B$10"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
			'
			oProp(0).Name = "FillDir"
			oProp(0).Value = "B"
			oProp(1).Name = "FillCmd"
			oProp(1).Value = "D"			' ← D or L のみ
			oProp(2).Name = "FillStep"
			oProp(2).Value = "4"
			oProp(3).Name = "FillDateCmd"
			oProp(3).Value = "W"
			oProp(4).Name = "FillStart"
			oProp(4).Value = ""
			oProp(5).Name = "FillMax"
			oProp(5).Value = "1.70000000E+307"
		oDispatcher.executeDispatch(oFrame, ".uno:FillSeries", "", 0, oProp())
		'
	msgbox "Success"
End Sub

CCCd-)[Calc]下方向に連続Data作成2-4(AutoFill)


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(5) as new com.sun.star.beans.PropertyValue
	Dim oStep as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		' Cell Formatは事前に設定
		oSheet.getCellByPosition(0,0).String = "1月"
		oSheet.getCellByPosition(0,1).String = "3月"
		oSheet.getCellByPosition(1,0).String = "10年"
		oSheet.getCellByPosition(1,1).String = "20年"
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "$A$1:$B$6"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
			'
			oProp(0).Name = "FillDir"
			oProp(0).Value = "B"
			oProp(1).Name = "FillCmd"
			oProp(1).Value = "A"
			oProp(2).Name = "FillStep"
			oProp(2).Value = ""			' ← AutoFill 時は 設定不可
			oProp(3).Name = "FillDateCmd"
			oProp(3).Value = ""
			oProp(4).Name = "FillStart"
			oProp(4).Value = ""
			oProp(5).Name = "FillMax"
			oProp(5).Value = "1.70000000E+307"
		oDispatcher.executeDispatch(oFrame, ".uno:FillSeries", "", 0, oProp())
		'
	msgbox "Success"
End Sub

CCCd-)[Calc]下方向に連続Data作成2-5(上限を付けて)


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(5) as new com.sun.star.beans.PropertyValue
	Dim oStep as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		' Cell Formatは事前に設定
		oSheet.getCellByPosition(0,0).Value = 3
		oSheet.getCellByPosition(1,0).String = 5
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "$A$1:$B$7"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
			'
			oProp(0).Name = "FillDir"
			oProp(0).Value = "B"
			oProp(1).Name = "FillCmd"
			oProp(1).Value = "G"
			oProp(2).Name = "FillStep"
			oProp(2).Value = "2"
			oProp(3).Name = "FillDateCmd"
			oProp(3).Value = ""
			oProp(4).Name = "FillStart"
			oProp(4).Value = ""
			oProp(5).Name = "FillMax"
			oProp(5).Value = "100"
		oDispatcher.executeDispatch(oFrame, ".uno:FillSeries", "", 0, oProp())
		'
	msgbox "Success"
End Sub

CCCd-)[Calc]Table Operation1

Sub oMultipleOpsColumns
	Dim oRange
	Dim oSheet
	Dim oCell
	Dim oBlockAddress
	Dim oCellAddress
		oSheet = ThisComponent.Sheets(1)
	'Set the topmost Value
		oCell = oSheet.getCellByPosition(0,9)
			oCell.setValue(0)
		'Fill the Values Down! for 0 to about 6.4
		oRange = oSheet.getCellRangeByName("A10:A73")
		oRange.fillAuto(com.sun.star.sheet.FillDirection.TO_BOTTOM, _
								com.sun.star.sheet.FillMode.LINEAR, _
								com.sun.star.sheet.FillDateMode.FILL_DATE_DAY, 0.1, 6.4)
	'Setting the Sin() and Cos() Header Values
		oCell = oSheet.getCellByPosition(1,8)
			oCell.setString("Sin()")
		oCell = oSheet.getCellByPosition(2,8)
			oCell.setString("Cos()")
	'Setting the Sin() and Cos() Formulas
		oCell = oSheet.getCellByPosition(1,9)
			oCell.setFormula("Sin(A10)")
		oCell = oSheet.getCellByPosition(2,9)
			oCell.setFormula("Cos(A10)")
	'Set Range
		oRange = oSheet.getCellRangeByName("A11:C73")
	'Get Address to copy
		oBlockAddress = oSheet.getCellRangeByName("B10:C10").getRangeAddress()
	'Column Address
		oCellAddress = oSheet.getCellByPosition(0,9).getCellAddress()
	'
		oRange.setTableOperation(oBlockAddress, _
		com.sun.star.sheet.TableOperationMode.COLUMN , oCellAddress, oCellAddress)
		'
End Sub
'
' [ com.sun.star.sheet.FillDateMode enum( LibreOffice / Apache OpenOffice ]
' com.sun.star.sheet.FillDateMode.FILL_DATE_DAY
' com.sun.star.sheet.FillDateMode.FILL_DATE_WEEKDAY
' com.sun.star.sheet.FillDateMode.FILL_DATE_MONTH
' com.sun.star.sheet.FillDateMode.FILL_DATE_YEAR
'
'

CCCd-)[Calc]Table Operation2

Sub oMultipleOpsColumns
	Dim oRange
	Dim oSheet
	Dim oCell
	Dim oBlockAddress
	Dim oCellAddress
		oSheet = ThisComponent.Sheets(1)
	'Set the Row Values of constant values
		oRowCell = oSheet.getCellByPosition(1,9)
			oRowCell.setValue(1)
		oRange = oSheet.getCellRangeByName("B10:K10")
			oRange.fillAuto(com.sun.star.sheet.FillDirection.TO_RIGHT,  1)
	'Set the Column Values of constant values
		oColCell = oSheet.getCellByPosition(0,10)
			oColCell.setValue(1)
		oRange = oSheet.getCellRangeByName("A11:A20")
			oRange.fillAuto(com.sun.star.sheet.FillDirection.TO_BOTTOM,  1)
	'Set the first formula and Value
		oCell = oSheet.getCellByPosition(0, 9)
			oCell.setFormula("=A11*B10")
	'Get Range of the Cells
		oRange = oSheet.getCellRangeByName("A10:K20")
	'Fill the multiplication tables for the value 1*1 through 10*10
		oRange.setTableOperation(oRange.getRangeAddress(), _
									com.sun.star.sheet.TableOperationMode.BOTH, _
								oColCell.getCellAddress(), _
								oRowCell.getCellAddress())
End Sub

CCCd-)[Calc]右方向に同じ値を入力


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
	Dim oStep as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		' Cell Formatは事前に設定
		oSheet.getCellByPosition(0,0).Value = 1
		oSheet.getCellByPosition(0,1).Value = DateSerial(2012,1,1)
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "$A$1:$D$2"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
		oDispatcher.executeDispatch(oFrame, ".uno:FillRight", "", 0, oProp())
		'
	msgbox "Success"
End Sub

CCCd-)[Calc]左方向に同じ値を入力


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
	Dim oStep as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		' Cell Formatは事前に設定
		oSheet.getCellByPosition(3,0).String = "Left"
		oSheet.getCellByPosition(3,1).Value = DateSerial(2012,2,3)
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "$A$1:$D$2"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
		oDispatcher.executeDispatch(oFrame, ".uno:FillLeft", "", 0, oProp())
		'
	msgbox "Success"
End Sub

CCCd-)[Calc]上方向に同じ値を入力


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
	Dim oStep as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		' Cell Formatは事前に設定
		oSheet.getCellByPosition(0,4).String = "Up"
		oSheet.getCellByPosition(1,4).Value = DateSerial(2012,3,1)
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "$A$1:$B$5"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
		oDispatcher.executeDispatch(oFrame, ".uno:FillUp", "", 0, oProp())
		'
	msgbox "Success"
End Sub

CCCd-)[Calc]下方向に同じ値を入力


Sub SetFillData()
	Dim oDoc as Object, oSheet as Object
	Dim oCtrl as Object, oFrame as Object
	Dim oDispatcher as Object
	Dim oProp1(0) as new com.sun.star.beans.PropertyValue
	Dim oProp(0) as new com.sun.star.beans.PropertyValue
	Dim oStep as Integer
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		' Cell Formatは事前に設定
		oSheet.getCellByPosition(0,0).String = "Down"
		oSheet.getCellByPosition(1,0).Value = DateSerial(2012,4,3)
		'
		oCtrl = oDoc.getCurrentController()
		oFrame = oCtrl.getFrame()
		oDispatcher = createUnoService("com.sun.star.frame.DispatchHelper")
			'
			oProp1(0).Name = "ToPoint"
			oProp1(0).Value = "$A$1:$B$5"
		oDispatcher.executeDispatch(oFrame, ".uno:GoToCell", "", 0, oProp1())
		oDispatcher.executeDispatch(oFrame, ".uno:FillDown", "", 0, oProp())
		'
	msgbox "Success"
End Sub








[ Recalcuation( 再計算 ) ]

CCRC-)[Calc]再計算[ Key F9 ](1)


Sub oCalcReCalculation()
	Dim oDoc as Object
		oDoc = ThisComponent
	' ReCalculation
		oDoc.calculateAll()
		'
	msgbox "Success"
End Sub
'
' [ 注意事項 ]
1) Default では図の 「ツール」→「セルの内容」→「自動計算」にCheckが入っているので、
Macroの効果を確認する為には事前にCheckを外しておく。

CCRC-)[Calc]再計算[ Key F9 ](2)

Sub oCalcReCalculation()
	Dim oDoc as Object
		oDoc = ThisComponent
	' ReCalculation
	Dim oFrame as Object
	Dim oDispacher as Object
		oFrame   = oDoc.CurrentController.Frame
		oDispacher = createUnoService("com.sun.star.frame.DispatchHelper")
		oDispacher.executeDispatch(oFrame, ".uno:Calculate", "", 0, Array())
		oDoc.calculateAll()
		'
	msgbox "Success"
End Sub

CCRC-)[Calc]無条件の再計算[ Key Ctrl+Shift+F9 ](1)

Sub CalcReCalculation()
	Dim oDoc as Object
		oDoc = ThisComponent
	' ReCalculation
		oDoc.calculate()
		'
	msgbox "Success"
End Sub

CCRC-)[Calc]無条件の再計算[ Key Ctrl+Shift+F9 ](2)

Sub oCalcReCalculation()
	Dim oDoc as Object
		oDoc = ThisComponent
	' ReCalculation
	Dim oFrame as Object
	Dim oDispacher as Object
		oFrame   = oDoc.CurrentController.Frame
		oDispacher = createUnoService("com.sun.star.frame.DispatchHelper")
		oDispacher.executeDispatch(oFrame, ".uno:CalculateHard", "", 0, Array())
		'
	msgbox "Success"
End Sub

CCRC-)[Calc]自動計算のToggleのON / OFF設定


Sub oCalcReCalculation()
	Dim oDoc as Object
		oDoc = ThisComponent
	' ReCalculation
	Dim oFrame as Object
	Dim oDispacher as Object
		oFrame   = oDoc.CurrentController.Frame
		oDispacher = createUnoService("com.sun.star.frame.DispatchHelper")
		oDispacher.executeDispatch(oFrame, ".uno:AutomaticCalculation", "", 0, Array())
		'
	oDisp = "自動計算の設定を変更しました。" & Chr$(10) & _
				" ON → OFF  又は  OFF → ON"
	msgbox oDisp,0,"自動計算の設定"
End Sub

CCRC-)[Calc]自動計算のToggleのON / OFF設定と確認



Sub CalcCalculation()
	Dim oDoc as Object
	Dim oChkCalc as Boolean
	Dim oDisp as String
		oDoc = ThisComponent
		' Check Automatic Calculation( Before )
		oChkCalc = oDoc.IsAutomaticCalculationEnabled()
		'
		oDisp = "[ 自動計算ON/OFF ]" & Chr$(10) & "Before : " & oChkCalc
		'
		' Change Setting of Automatic Calculation
		oDoc.enableautomaticCalculation( false )	' true : ON / false : OFF
		msgbox "自動計算をOFFにしました。"
		'
		oChkCalc = oDoc.IsAutomaticCalculationEnabled()
		oDisp = oDisp & Chr$(10) & "After : " & oChkCalc
		'
		msgbox oDisp,0,"自動計算"
End Sub








[ Tokens ]

CCTkn-)[Calc]FormulaToken


Sub CalcTokens()
	Dim oDoc as Object
	Dim oSheet as Object
	Dim oCell as Object
	Dim oToken as Object
	Dim oDisp as String
	Dim oTokenStr as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oCell = oSheet.getCellByPosition(0,2)
		'
		oToken = oCell.getTokens()
		'
		oDisp = CStr(oCell.Formula) & Chr$(10) & Chr$(10)
		for i = 0 to UBound(oToken)
			select case oToken(i).OpCode
				case 0
					oTokenStr = "Cell Addess or 数値"
				case 8
					oTokenStr = "("
				case 9
					oTokenStr = ")"
				case 14
					oTokenStr = " "		' 半角Space
				case 40
					oTokenStr = "+"
				case 41
					oTokenStr = "-"
				case 42
					oTokenStr = "*"
				case 43
					oTokenStr = "/"
				case 65
					oTokenStr = "PI"
				case 82
					oTokenStr = "Sin"
				case 83
					oTokenStr = "Cos"
				case 84
					oTokenStr = "Tan"
				case 224
					oTokenStr = "Sum"
				case else
					oTokenStr = "未登録"
			end select
			oDisp = oDisp & " " & i + 1 & ") " & oTokenStr & Chr$(10)
		next i
		msgbox(oDisp,0,"Cell の Tokens")
End Sub

CCTkn-)[Calc]





[ Name Range ]

CCNmRg-)[Calc]Name Range有無確認/削除/設定


Sub CalcNameRange()
	Dim oDoc as Object, oSheet as Object
	Dim oRange as Object
	Dim oRngAbsName as String
	Dim oRngName as String
	Dim oDocNmRng as Object
	Dim oTbCellAdrr as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oRange = oSheet.getCellRangeByName("A2:D6")
		oRngAbsName = oRange.AbsoluteName
		'
		oRngName = "TestName"
		'
		' 同じRange Nameを付けようとするとCrashするので、同名Range Nameは一旦、削除する
		oDocNmRng = oDoc.NamedRanges
 		If oDocNmRng.hasByName(oRngName) Then
   			oDocNmRng.removeByName(oRngName)
 		End If
 		'
 		' Rangeの相対Origin設定
 		oTbCellAdrr = createUnoStruct("com.sun.star.table.CellAddress")
 		with oTbCellAdrr
 			.sheet = 0
 			.column = 0
 			.row = 0
 		end with
 		' Name Range設定
 		oDocNmRng.addNewByName(oRngName, oRngAbsName, oTbCellAdrr, 0 )
 		'
 		oDisp = "Name Range : " & oRngName & Chr$(10) & " Exist ? →  " & oDocNmRng.hasByName(oRngName)
 		msgbox oDisp,0,"Name Range"
End Sub
'
' [ Note ]
' com.sun.star.sheet.XNamedRanges( LibreOffice / Apache OpenOffice )
' Name Ranges( Apache OpenOffice )
' NamedRanges Service Reference( LibreOffice )
'
' constans com.sun.star.sheet.NamedRangeFlag( LibreOffice / Apache OpenOffice )
' 0 : Common name range
' 1 : com.sun.star.sheet.NamedRangeFlag.FILTER_CRITERIA
' 2 : com.sun.star.sheet.NamedRangeFlag.PRINT_AREA
' 4 : com.sun.star.sheet.NamedRangeFlag.COLUMN_HEADER
' 8 : com.sun.star.sheet.NamedRangeFlag.ROW_HEADER

CCNmRg-)[Calc]Title RowからName Range設定


Sub CalcNameRange()
	Dim oDoc as Object
	Dim oDocNmRng as Object
	Dim oEnum as Object
	Dim oElmt as Object
	Dim oTbRngCellAdrr as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oDocNmRng = oDoc.NamedRanges
		'
		' 同じRange Nameを付けようとするとCrashするので、一旦、全てのRange Nameを削除する
		oEnum = oDocNmRng.createEnumeration()
		nn = 0
		Do while oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oDocNmRng.removeByName(oElmt.Name)
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			End if
		Loop
		'
 		' Range設定
 		oTbRngCellAdrr = createUnoStruct("com.sun.star.table.CellRangeAddress")
 		with oTbRngCellAdrr
 			.sheet = 0
 			.StartColumn = 0
 			.EndColumn = 2
 			.StartRow = 0
 			.EndRow = 4
 		end with
 		' Name Range設定 / Title行取得
 		oDocNmRng.addNewFromTitles(oTbRngCellAdrr, com.sun.star.sheet.Border.TOP )
 		'
 		oDisp = "[ Name Range ]"
 		oEnum = oDocNmRng.createEnumeration()
		nn = 0
		Do while oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oDisp = oDisp & Chr$(10) & oElmt.Name
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			End if
		Loop
 		msgbox oDisp,0,"Name Range"
End Sub

CCNmRg-)[Calc]Name Range出力


Sub CalcNameRange()
	Dim oDoc as Object
	Dim oDocNmRng as Object
	Dim oEnum as Object
	Dim oElmt as Object
	Dim oTbRngCellAdrr as Object
	Dim oTbCellAddr as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oDocNmRng = oDoc.NamedRanges
		'
		oEnum = oDocNmRng.createEnumeration()
		nn = 0
		Do while oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oDocNmRng.removeByName(oElmt.Name)
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			End if
		Loop
		'
 		' Range設定
 		oTbRngCellAdrr = createUnoStruct("com.sun.star.table.CellRangeAddress")
 		with oTbRngCellAdrr
 			.sheet = 0
 			.StartColumn = 0
 			.EndColumn = 2
 			.StartRow = 0
 			.EndRow = 4
 		end with
 		' Name Range設定 / Title行取得
 		oDocNmRng.addNewFromTitles(oTbRngCellAdrr, com.sun.star.sheet.Border.TOP )
 		'
 		oTbCellAddr  = createUnoStruct("com.sun.star.table.CellAddress")
 		with oTbCellAddr
 			.sheet = 0
 			.Column = 0
 			.Row = 6
 		end with
 		'
 	' output先Cell のFormatを Text設定
 	Dim NumberFormats As Object
	Dim NumberFormatString As String
	Dim NumberFormatId As Long
	Dim LocalSettings As New com.sun.star.lang.Locale
 		oSheet = oDoc.getSheets().getByIndex(0)
 		oOutRng = oSheet.getCellRangeByname("A7:B9")
 		NumberFormats = oDoc.NumberFormats
		NumberFormatString = "@"
		NumberFormatId = NumberFormats.queryKey(NumberFormatString, LocalSettings, True)
 		'
		NumberFormatId = NumberFormats.queryKey(NumberFormatString, LocalSettings, True)
		If NumberFormatId = -1 Then
   			NumberFormatId = NumberFormats.addNew(NumberFormatString, LocalSettings)	'書式コードを追加
		End If
		oOutRng.NumberFormat = NumberFormatId
 		'
 		' Output Name Range
 		oDocNmRng.outputList(oTbCellAddr)
 		'
 		msgbox "Success",0,"Name Range"
End Sub

CCNmRg-)[Calc]











Query

CCQ-)[Calc]空白以外のCell Address抽出1

Sub oNonEmptyCellsinRange
	Dim oSheet
	Dim oRange
	Dim oCell
	Dim orangeQuery
	Dim oAddress()
	Dim oAd
	Dim i as Long
	Dim nRow as Long
	Dim nCol as Long
		oSheets = ThisComponent.Sheets(1)
		oRange = oSheets.getCellRangeByName("A1:G20")
		oRangeQuery =oRange.queryContentCells(com.sun.star.sheet.CellFlags.VALUE OR _
												com.sun.star.sheet.CellFlags.DATETIME OR _
												com.sun.star.sheet.CellFlags.STRING OR _
												com.sun.star.sheet.CellFlags.FORMULA)
		oAddress() = oRangeQuery.getRangeAddresses()
		for i = 0 to UBound(oAddress())
			oAd = oAddress(i)
			for nRow = oAddress(i).StartRow to oAddress(i).EndRow
				for nCol = oAddress(i).StartColumn to oAddress(i).EndColumn
					oCell = oRange.Spreadsheet.getCellByPosition(nCol,nRow)
					oDisp = oDisp & PrintableAddressOfCell(oCell) & Chr$(10)
				next nCol
			next nRow
		next i
	msgbox(oDisp,0,"")
End Sub

'[ Function1 ]
Function PrintableAddressOfCell(oCell) as String
	If IsNull(oCell) OR IsEmpty(oCell) then
		PrintableAddressOfCell = "Unknown"
	else
		PrintableAddressOfCell =oCell.getSpreadSheet().getName & " : " & _
			ColumnNumberToString(oCell.CellAddress.Column) & _
			CStr(oCell.CellAddress.Row+1)
	End If
End Function
'
'[ Function2 ]
Function ColumnNumberToString(ByVal nColumn As Long) as String
	Dim oReturn2 as String
	Do While nColumn>=0
		oReturn2= Chr$(65+ (nColumn MOD 26)) & oReturn2
		nColumn= nColumn / 26 -1
	Loop
	ColumnNumberToString = oReturn2
End Function

CCQ-)[Calc]空白以外のCell Address抽出2

Sub oTraverseRows
	Dim oSheet
	Dim oRange
	Dim oRangeRow
	Dim oRow
	Dim oRowEnum
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:G20")
			oRangeRow = oRange.getRows()
			oRowEnum = oRangeRow.createEnumeration()
			Do While oRowEnum.hasMoreElements()
				oRow = oRowEnum.nextElement()
				oDisp = oDisp & oNonEmptyCellsInRange(oRow,"  ") & Chr$(10)
			Loop
		Msgbox(oDisp,0,"Non-Empty Cell In Row")
End Sub

'[ Function1 ]
Function oNonEmptyCellsinRange(oRange, sep$)
	Dim oCell
	Dim orangeQuery
	Dim oAddress()
	Dim oAd
	Dim i as Long
	Dim nRow as Long
	Dim nCol as Long
		oRangeQuery =oRange.queryContentCells(com.sun.star.sheet.CellFlags.VALUE OR _
												com.sun.star.sheet.CellFlags.DATETIME OR _
												com.sun.star.sheet.CellFlags.STRING OR _
												com.sun.star.sheet.CellFlags.FORMULA)
		oAddress() = oRangeQuery.getRangeAddresses()
		for i = 0 to UBound(oAddress())
			oAd = oAddress(i)
			for nRow = oAddress(i).StartRow to oAddress(i).EndRow
				for nCol = oAddress(i).StartColumn to oAddress(i).EndColumn
					oCell = oRange.Spreadsheet.getCellByPosition(nCol,nRow)
					oDisp = oDisp & PrintableAddressOfCell(oCell) & sep$
				next nCol
			next nRow
		next i
	oNonEmptyCellsinRange = oDisp
End Function

'[ Function2 ]
Function PrintableAddressOfCell(oCell) as String
	If IsNull(oCell) OR IsEmpty(oCell) then
		PrintableAddressOfCell = "Unknown"
	else
		PrintableAddressOfCell =oCell.getSpreadSheet().getName & " : " & _
			ColumnNumberToString(oCell.CellAddress.Column) & _
			CStr(oCell.CellAddress.Row+1)
	End If
End Function
'
'[ Function3 ]
Function ColumnNumberToString(ByVal nColumn As Long) as String
	Dim oReturn2 as String
	Do While nColumn>=0
		oReturn2= Chr$(65+ (nColumn MOD 26)) & oReturn2
		nColumn= nColumn / 26 -1
	Loop
	ColumnNumberToString = oReturn2
End Function

CCQ-)[Calc]空白のCell Address取得


Sub QueryEmpCellRange()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oRange as Object
	Dim oEmptyCellObj as Object
	Dim oCellAddr as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		for i = 0 to 3
			for k = 0 to 5
				oCell = oSheet.getCellByPosition( i, k )
				if k = 2 or k = 3 or k = 4 then
					if i = 1 then
						' Empty
					else
						oCell.String = CStr("A" & i + k)
					end if
				else
					oCell.String = CStr( i * k )
				end if
			next k
		next i
		'
		' EmptyCell Object取得
		oRange = oSheet.getCellRangeByName("A1:D6")
		oEmptyCellObj = oRange.queryEmptyCells()
		'
		oDisp = "[ Address of Empty Cell ]" & Chr$(10) & " Addresses of Empty Cell " & Chr$(10) & "  ↓"
		oCellAddr = oEmptyCellObj.getRangeAddresses()
		'
		for i = 0 to UBound(oCellAddr)
			for j = oCellAddr(i).StartColumn to oCellAddr(i).EndColumn
				for k = oCellAddr(i).StartRow to oCellAddr(i).EndRow
					oDisp = oDisp & Chr$(10) & "( " & j & ", " & k & " )"
				next k
			next j
		next i
		msgbox oDisp,0,"Empty Cell"
End Sub

CCQ-)[Calc]指定範囲内でC2:C6に関連するCell Addrss取得1

Sub oQueryRange
	Dim oCell
	Dim oCellAddress
	Dim oRange
	Dim oSheet
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:G20")
	'CLear
		oClearFlag = com.sun.star.sheet.CellFlags.VALUE OR _
						com.sun.star.sheet.CellFlags.DATETIME OR _
						com.sun.star.sheet.CellFlags.STRING OR _
						com.sun.star.sheet.CellFlags.ANNOTATION OR _
						com.sun.star.sheet.CellFlags.FORMULA OR _
						com.sun.star.sheet.CellFlags.HARDATTR OR _
						com.sun.star.sheet.CellFlags.STYLES OR _
						com.sun.star.sheet.CellFlags.OBJECTS OR _
						com.sun.star.sheet.CellFlags.EDITATTR
		oRange.clearContents(oClearFlag)
	'Value Input
		for i= 1 to 5
			oCell = oSheet.getCellByPosition(1,i)
				oCell.setValue( i )
			oCell = oSheet.getCellByPosition(2,i)
				oCell.setFormula ( "=B" & CStr(i+1) & " + 1")
			oCell = oSheet.getCellByPosition(3,i)
				oCell.setFormula ( "=C" & CStr(i+1) & " - 1")
		next i
		oCell = oSheet.getCellByPosition(1,6)
			oCell.setFormula ( "=SUM(B2:B5)")
		oCell = oSheet.getCellByPosition(2,6)
			oCell.setFormula ( "=SUM(C2:C6)")
		oCell = oSheet.getCellByPosition(2,0)
			oCell.setFormula ( "=B1 - 1")
		oCell = oSheet.getCellByPosition(1,0)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(1,7)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,2)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,7)
			oCell.setValue(2)
	'queryPrecedents
		oCell = oSheet.getCellRangeByName("C2:C6")
		oDisp = oDisp & "oCell.queryPredents(false).getRangeAddressesAsString()  => " & _
					oCell.queryPrecedents(false).getRangeAddressesAsString() & Chr$(10)
		oDisp = oDisp & Chr$(10)
	Msgbox(oDisp,0,"Manipulating A Range")
End Sub

CCQ-)[Calc]指定範囲内でC2:C6に関連するCell Addrss取得2

Sub oQueryRange
	Dim oCell
	Dim oCellAddress
	Dim oRange
	Dim oSheet
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:G20")
	'CLear
		oClearFlag = com.sun.star.sheet.CellFlags.VALUE OR _
						com.sun.star.sheet.CellFlags.DATETIME OR _
						com.sun.star.sheet.CellFlags.STRING OR _
						com.sun.star.sheet.CellFlags.ANNOTATION OR _
						com.sun.star.sheet.CellFlags.FORMULA OR _
						com.sun.star.sheet.CellFlags.HARDATTR OR _
						com.sun.star.sheet.CellFlags.STYLES OR _
						com.sun.star.sheet.CellFlags.OBJECTS OR _
						com.sun.star.sheet.CellFlags.EDITATTR
		oRange.clearContents(oClearFlag)
	'Value Input
		for i= 1 to 5
			oCell = oSheet.getCellByPosition(1,i)
				oCell.setValue( i )
			oCell = oSheet.getCellByPosition(2,i)
				oCell.setFormula ( "=B" & CStr(i+1) & " + 1")
			oCell = oSheet.getCellByPosition(3,i)
				oCell.setFormula ( "=C" & CStr(i+1) & " - 1")
		next i
		oCell = oSheet.getCellByPosition(1,6)
			oCell.setFormula ( "=SUM(B2:B5)")
		oCell = oSheet.getCellByPosition(2,6)
			oCell.setFormula ( "=SUM(C2:C6)")
		oCell = oSheet.getCellByPosition(2,0)
			oCell.setFormula ( "=B1 - 1")
		oCell = oSheet.getCellByPosition(1,0)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(1,7)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,2)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,7)
			oCell.setValue(2)
	'queryPrecedents
		oCell = oSheet.getCellRangeByName("C2:C6")
		oDisp = oDisp & "oCell.queryPredents(true).getRangeAddressesAsString()  => " & _
					oCell.queryPrecedents(true).getRangeAddressesAsString() & Chr$(10)
		oDisp = oDisp & Chr$(10) & Chr$(10)
	Msgbox(oDisp,0,"Manipulating A Range")
End Sub

CCQ-)[Calc]指定範囲内でB3に依存するCell Addrss取得

Sub oQueryRange
	Dim oCell
	Dim oCellAddress
	Dim oRange
	Dim oSheet
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:G20")
	'CLear
		oClearFlag = com.sun.star.sheet.CellFlags.VALUE OR _
						com.sun.star.sheet.CellFlags.DATETIME OR _
						com.sun.star.sheet.CellFlags.STRING OR _
						com.sun.star.sheet.CellFlags.ANNOTATION OR _
						com.sun.star.sheet.CellFlags.FORMULA OR _
						com.sun.star.sheet.CellFlags.HARDATTR OR _
						com.sun.star.sheet.CellFlags.STYLES OR _
						com.sun.star.sheet.CellFlags.OBJECTS OR _
						com.sun.star.sheet.CellFlags.EDITATTR
		oRange.clearContents(oClearFlag)
	'Value Input
		for i= 1 to 5
			oCell = oSheet.getCellByPosition(1,i)
				oCell.setValue( i )
			oCell = oSheet.getCellByPosition(2,i)
				oCell.setFormula ( "=B" & CStr(i+1) & " + 1")
			oCell = oSheet.getCellByPosition(3,i)
				oCell.setFormula ( "=C" & CStr(i+1) & " - 1")
		next i
		oCell = oSheet.getCellByPosition(1,6)
			oCell.setFormula ( "=SUM(B2:B5)")
		oCell = oSheet.getCellByPosition(2,6)
			oCell.setFormula ( "=SUM(C2:C6)")
		oCell = oSheet.getCellByPosition(2,0)
			oCell.setFormula ( "=B1 - 1")
		oCell = oSheet.getCellByPosition(1,0)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(1,7)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,2)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,7)
			oCell.setValue(2)
	'
		oCell = oSheet.getCellByPosition(1,2)
		oDisp = oDisp & "oCell.queryDependents(true).getRangeAddressesAsString()  => " & _
								oCell.queryDependents(true).getRangeAddressesAsString()  & Chr$(10)
	'
		oDisp = oDisp & Chr$(10) & Chr$(10)
	Msgbox(oDisp,0,"Manipulating A Range")
End Sub

CCQ-)[Calc]指定範囲内でB3と値が異なるCellAddress取得1

Sub oQueryRange
	Dim oCell
	Dim oCellAddress
	Dim oRange
	Dim oSheet
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:G20")
	'CLear
		oClearFlag = com.sun.star.sheet.CellFlags.VALUE OR _
						com.sun.star.sheet.CellFlags.DATETIME OR _
						com.sun.star.sheet.CellFlags.STRING OR _
						com.sun.star.sheet.CellFlags.ANNOTATION OR _
						com.sun.star.sheet.CellFlags.FORMULA OR _
						com.sun.star.sheet.CellFlags.HARDATTR OR _
						com.sun.star.sheet.CellFlags.STYLES OR _
						com.sun.star.sheet.CellFlags.OBJECTS OR _
						com.sun.star.sheet.CellFlags.EDITATTR
		oRange.clearContents(oClearFlag)
	'Value Input
		for i= 1 to 5
			oCell = oSheet.getCellByPosition(1,i)
				oCell.setValue( i )
			oCell = oSheet.getCellByPosition(2,i)
				oCell.setFormula ( "=B" & CStr(i+1) & " + 1")
			oCell = oSheet.getCellByPosition(3,i)
				oCell.setFormula ( "=C" & CStr(i+1) & " - 1")
		next i
		oCell = oSheet.getCellByPosition(1,6)
			oCell.setFormula ( "=SUM(B2:B5)")
		oCell = oSheet.getCellByPosition(2,6)
			oCell.setFormula ( "=SUM(C2:C6)")
		oCell = oSheet.getCellByPosition(2,0)
			oCell.setFormula ( "=B1 - 1")
		oCell = oSheet.getCellByPosition(1,0)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(1,7)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,2)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,7)
			oCell.setValue(2)
	'queryPrecedents
		oCell = oSheet.getCellRangeByName("C2:C6")
		oDisp = oDisp & "oCell.queryPredents(false).getRangeAddressesAsString()  => " & _
					oCell.queryPrecedents(false).getRangeAddressesAsString() & Chr$(10)
		oDisp = oDisp & Chr$(10)
		oDisp = oDisp & "oCell.queryPredents(true).getRangeAddressesAsString()  => " & _
					oCell.queryPrecedents(true).getRangeAddressesAsString() & Chr$(10)
		oDisp = oDisp & Chr$(10) & Chr$(10)
	'
		oCell = oSheet.getCellByPosition(1,2)
		oDisp = oDisp & "oCell.queryDependents(true).getRangeAddressesAsString()  => " & _
								oCell.queryDependents(true).getRangeAddressesAsString()  & Chr$(10)
	'
		oDisp = oDisp & Chr$(10) & Chr$(10)
	'
	oCellAddress = oCell.CellAddress
	'queryColumnDifferences / queryRowDifferences
		oDisp = oDisp & "[ " & oCell.value & " ]" & Chr$(10)
		oDisp = oDisp & "oRange.queryColumnDifferences(oCellAddress).getRangeAddressesAsString() => " & _
					oRange.queryColumnDifferences(oCellAddress).getRangeAddressesAsString() & Chr$(10)
		oDisp = oDisp & Chr$(10)
	Msgbox(oDisp,0,"Manipulating A Range")
End Sub

CCQ-)[Calc]指定範囲内でB3と値が異なるCellAddress取得2

Sub oQueryRange
	Dim oCell
	Dim oCellAddress
	Dim oRange
	Dim oSheet
		oSheet = ThisComponent.Sheets(1)
		oRange = oSheet.getCellRangeByName("A1:G20")
	'CLear
		oClearFlag = com.sun.star.sheet.CellFlags.VALUE OR _
						com.sun.star.sheet.CellFlags.DATETIME OR _
						com.sun.star.sheet.CellFlags.STRING OR _
						com.sun.star.sheet.CellFlags.ANNOTATION OR _
						com.sun.star.sheet.CellFlags.FORMULA OR _
						com.sun.star.sheet.CellFlags.HARDATTR OR _
						com.sun.star.sheet.CellFlags.STYLES OR _
						com.sun.star.sheet.CellFlags.OBJECTS OR _
						com.sun.star.sheet.CellFlags.EDITATTR
		oRange.clearContents(oClearFlag)
	'Value Input
		for i= 1 to 5
			oCell = oSheet.getCellByPosition(1,i)
				oCell.setValue( i )
			oCell = oSheet.getCellByPosition(2,i)
				oCell.setFormula ( "=B" & CStr(i+1) & " + 1")
			oCell = oSheet.getCellByPosition(3,i)
				oCell.setFormula ( "=C" & CStr(i+1) & " - 1")
		next i
		oCell = oSheet.getCellByPosition(1,6)
			oCell.setFormula ( "=SUM(B2:B5)")
		oCell = oSheet.getCellByPosition(2,6)
			oCell.setFormula ( "=SUM(C2:C6)")
		oCell = oSheet.getCellByPosition(2,0)
			oCell.setFormula ( "=B1 - 1")
		oCell = oSheet.getCellByPosition(1,0)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(1,7)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,2)
			oCell.setValue( 2 )
		oCell = oSheet.getCellByPosition(4,7)
			oCell.setValue(2)
	'queryPrecedents
		oCell = oSheet.getCellRangeByName("C2:C6")
		oDisp = oDisp & "oCell.queryPredents(false).getRangeAddressesAsString()  => " & _
					oCell.queryPrecedents(false).getRangeAddressesAsString() & Chr$(10)
		oDisp = oDisp & Chr$(10)
		oDisp = oDisp & "oCell.queryPredents(true).getRangeAddressesAsString()  => " & _
					oCell.queryPrecedents(true).getRangeAddressesAsString() & Chr$(10)
		oDisp = oDisp & Chr$(10) & Chr$(10)
	'
		oCell = oSheet.getCellByPosition(1,2)
		oDisp = oDisp & "oCell.queryDependents(true).getRangeAddressesAsString()  => " & _
								oCell.queryDependents(true).getRangeAddressesAsString()  & Chr$(10)
	'
		oDisp = oDisp & Chr$(10) & Chr$(10)
	'
	oCellAddress = oCell.CellAddress
	'queryColumnDifferences / queryRowDifferences
		oDisp = oDisp & "[ " & oCell.value & " ]" & Chr$(10)
		oDisp = oDisp & "oRange.queryRowDifferences(oCellAddress).getRangeAddressesAsString() => " & _
					oRange.queryRowDifferences(oCellAddress).getRangeAddressesAsString()
	Msgbox(oDisp,0,"Manipulating A Range")
End Sub

CCQ-)[Calc]2つの範囲で重なる範囲Address取得


Sub QryIntSec()
	Dim oDoc as Object, oSheet as Object
	Dim oRange as Object
	Dim oTbRng as Object
	Dim oIntSecObj as Object
	Dim oCellAddr as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		'
		' 重なる対象範囲 ( com.sun.star.table.CellRangeAddress )
		oTbRng = createUnoStruct("com.sun.star.table.CellRangeAddress")
		with oTbRng
			.Sheet = 0
			.StartColumn = 2	' Col C
  			.StartRow = 3			' Row No.4
  			.EndColumn = 5		' Col F
  			.EndRow = 8			' Row No.8
		end with
		'
		' Intersection Object取得
		oRange = oSheet.getCellRangeByName("A1:D6")
		oIntSecObj = oRange.queryIntersection(oTbRng)
		'
		oDisp = "[ Intersection of Range ]" & Chr$(10) & "(A1:D6)と(C4:F9)の重複範囲" & Chr$(10) & "  ↓"
		oCellAddr = oIntSecObj.getRangeAddresses()
		'
		for i = 0 to UBound(oCellAddr)
			for j = oCellAddr(i).StartColumn to oCellAddr(i).EndColumn
				for k = oCellAddr(i).StartRow to oCellAddr(i).EndRow
					oDisp = oDisp & Chr$(10) & "( " & j & ", " & k & " )"
				next k
			next j
		next i
		msgbox oDisp,0,"Intersection "
End Sub
'
' [ Note ]
' Target Rangeは com.sun.star.table.CellRangeAddress である事に注意。LibreOffice / Apache OpenOffice

CCQ-)[Calc]表示CellのAddress取得


Sub QryVisibleCell()
	Dim oDoc as Object, oSheet as Object, oCell as Object
	Dim oRange as Object
	Dim oVisibleCellObj as Object
	Dim oCellAddr as Object
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		for i = 0 to 3
			for k = 0 to 5
				oCell = oSheet.getCellByPosition( i, k )
				oCell.String = CStr( i * k )
			next k
		next i
		'
		' Set InVisible
		oSheet.Columns(1).isVisible = false
		oSheet.Columns(2).isVisible = false
		oSheet.Rows(1).isVisible = false
		oSheet.Rows(3).isVisible = false
		oSheet.Rows(4).isVisible = false
		'
		' VisibleCell Object取得
		oRange = oSheet.getCellRangeByName("A1:D6")
		oVisibleCellObj = oRange.queryVisibleCells()
		'
		oDisp = "[ Address of Visible Cell ]" & Chr$(10) & "Range =  A1:D6 の表示Cell" & Chr$(10) & "  ↓"
		oCellAddr = oVisibleCellObj.getRangeAddresses()
		'
		for i = 0 to UBound(oCellAddr)
			for j = oCellAddr(i).StartColumn to oCellAddr(i).EndColumn
				for k = oCellAddr(i).StartRow to oCellAddr(i).EndRow
					oDisp = oDisp & Chr$(10) & "( " & j & ", " & k & " )"
				next k
			next j
		next i
		msgbox oDisp,0,"Visible Cell"
End Sub

CCQ-)[Calc]Formula Cell取得


Sub CalcQuery()
	Dim oDoc as Object, oSheet as Object
	Dim oRange as Object
	Dim oFormulaCell as Object
	Dim oCells as Object, oEnum as Object, oElmt as Object
	Dim oAddrStr as String
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oRange = oSheet.getCellRangeByName("A1:D6")
		' Formula Cell取得
		oFormulaCell = oRange.queryFormulaCells(1)
		' Cell Objectを取得
		oCells = oFormulaCell.getCells()
		oEnum = oCells.createEnumeration()
		nn = 0
		oDisp = "[ A1:D6 / Formula Cell ]" & Chr$(10) & "1) VALUE"
		Do While oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oAddrStr = oElmt.AbsoluteName
			oDisp = oDisp & Chr$(10) & oAddrStr
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			end if
		Loop
		'
		oFormulaCell = oRange.queryFormulaCells(2)
		' Cell Objectを取得
		oCells = oFormulaCell.getCells()
		oEnum = oCells.createEnumeration()
		nn = 0
		oDisp = oDisp & Chr$(10) & Chr$(10) & "2) STRING"
		Do While oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oAddrStr = oElmt.AbsoluteName
			oDisp = oDisp & Chr$(10) & oAddrStr
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			end if
		Loop
		'
		oFormulaCell = oRange.queryFormulaCells(4)
		' Cell Objectを取得
		oCells = oFormulaCell.getCells()
		oEnum = oCells.createEnumeration()
		nn = 0
		oDisp = oDisp & Chr$(10) & Chr$(10) & "3) ERROR"
		Do While oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oAddrStr = oElmt.AbsoluteName
			oDisp = oDisp & Chr$(10) & oAddrStr
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			end if
		Loop
		'
		oFormulaCell = oRange.queryFormulaCells(2+4)
		' Cell Objectを取得
		oCells = oFormulaCell.getCells()
		oEnum = oCells.createEnumeration()
		nn = 0
		oDisp = oDisp & Chr$(10) & Chr$(10) & "4) STRING + ERROR"
		Do While oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oAddrStr = oElmt.AbsoluteName
			oDisp = oDisp & Chr$(10) & oAddrStr
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			end if
		Loop
		'
		msgbox oDisp,0,"Formula Cell / getCells"
End Sub
'
' [ Note ]
' com.sun.star.sheet.FormulaResultLibreOffice / Apache OpenOffice )
' VALUE  = 1
' String = 2
' ERROR  = 3
' 値はLONG値

CCQ-)[Calc]指定Contents Cell取得


Sub CalcQuery()
	Dim oDoc as Object, oSheet as Object
	Dim oRange as Object
	Dim oFormulaCell as Object
	Dim oCells as Object, oEnum as Object, oElmt as Object
	Dim oAddrStr as String
	Dim oDisp as String
		oDoc = ThisComponent
		oSheet = oDoc.getSheets().getByIndex(0)
		oRange = oSheet.getCellRangeByName("A1:D6")
		' Formula Cell取得
		oFormulaCell = oRange.queryContentCells(2)
		' Cell Objectを取得
		oCells = oFormulaCell.getCells()
		oEnum = oCells.createEnumeration()
		nn = 0
		oDisp = "[ A1:D6 / Content Cell ]" & Chr$(10) & "1) DATETIME"
		Do While oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oAddrStr = oElmt.AbsoluteName
			oDisp = oDisp & Chr$(10) & oAddrStr
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			end if
		Loop
		'
		oFormulaCell = oRange.queryContentCells(8)
		' Cell Objectを取得
		oCells = oFormulaCell.getCells()
		oEnum = oCells.createEnumeration()
		nn = 0
		oDisp = oDisp & Chr$(10) & Chr$(10) & "2) ANNOTATION"
		Do While oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oAddrStr = oElmt.AbsoluteName
			oDisp = oDisp & Chr$(10) & oAddrStr
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			end if
		Loop
		'
		oFormulaCell = oRange.queryContentCells(4+16)
		' Cell Objectを取得
		oCells = oFormulaCell.getCells()
		oEnum = oCells.createEnumeration()
		nn = 0
		oDisp = oDisp & Chr$(10) & Chr$(10) & "3) STRING + FORMULA"
		Do While oEnum.hasMoreElements()
			oElmt = oEnum.nextElement()
			oAddrStr = oElmt.AbsoluteName
			oDisp = oDisp & Chr$(10) & oAddrStr
			nn = nn + 1
			if nn > 1000 then
				Exit Do
			end if
		Loop
		'
		msgbox oDisp,0,"Content Cell / getCells"
End Sub
'
' [ Note ]
' com.sun.star.sheet.CellFlags( LibreOffice / Apache OpenOffice )
' ANNOTATION は ANNOTATION削除の時に利用。

CCQ-)[Calc]











Top of Page

inserted by FC2 system
